Green Brook DHT01A-C User manual

Diagram 1
Do not mount chime on door
1. Remove front cover by unscrewing the
small screw at the base of cover.
2. Feed bell-push wire into top of chime
base and connect to terminals 0 and 2.
3. Remove transformer cover (Dia 3).
. Feed 230V mains Supply cable into the
bottom of the chime base (Dia 2)
5. Connect the Live (Brown) wire to
the”L” terminal and the Neutral (Blue)
wire to the “N” terminal (Dia 3)
SWI CH OFF HE MAINS AND
ISOLA E HE SUPPLY BY REMOVING HE
APPROPRIA E FUSE BEFORE S AR ING
HE INS ALLA ION
6. Replace the transformer cover and
front cover.
7. Test unit by pushing bell push.
INS RUC IONS FOR USE
DOORCHIME WI H BUIL -IN
RANSFORMER AND BELL PUSH
MODEL NUMBER: DHT01A-C
• Dual tone chime
• Powered by internal transformer
• Bellpush and woodscrews are supplied
Diagram 3
Recommended maximum overall
length of bell wire for doorchime
with built-in transformer:
SWG 21 (0.5mm2) - 30 metres
SWG 19 (0.75mm2) - 45 metres
PLEASE KEEP HESE
INS RUC IONS SAFE
FOR FU URE REFERENCE
Issue number: 701 03
Diagram 2
