Greencut BAT-56V-2AH User manual

BATTERY
BAT-56V-2AH
BAT-56V-4AH
Lithium-ion Battery 56V 2.0/4.0Ah
EN Operating
instructions
i

2

3
EN
INDEX
INTRODUCTION 4
SAFETY RULES AND PRECAUTIONS 4
BATTERY TOOL USE AND CARE 5
WARNING SYMBOLS 5
PRODUCT DESCRIPTION 6
DETAILED DESCRIPTION OF THE PRODUCT 6
TECHNICAL DATA 6
USING THE PRODUCT 7
FUEL GAUGE 7
BATTERY PROTECTION FEATURES 7
CHARGING THE BATTERY PACK 7
TO CHARGE 7
CHARGING A HOT BATTERY PACK 8
COLD WEATHER OPERATION 8
BATTERIES 8
BATTERY PACK REMOVAL AND PREPARATION FOR RE- CYCLING 9
TRANSPORTING LITHIUM BATTERIES 9
RECYCLING AND DISPOSING 10
GUARANTEE 10

4
INTRODUCTION
Thank you for choosing this GREENCUT product. We are sure you shall appreciate the quality and
performance of this machine, which will facilitate your task for a long period of time.
Remember that you can contact our Technical Support for any queries regarding assembly o
maintenance, as well as for the resolution to any problems that may arise, and for the purchase of
spare parts and/or accessories.
WARNING
Please read these Operating Instructions carefully as well as the safety precautions
before using your device. Failure to do so could result in an electric fault, re hazard
and/or in personal injury. The manufacturer will not take responsibility for accidents
or injuries caused to the user, third parties or objects as a result for not following
the instructions in the user manual.
This machine is not intended for professional use.
Keep this user manual safe for future reference. Should you sell this machine in the future, please
remember to hand it to the new owner.
SAFETY RULES AND PRECAUTIONS
The aim of the following warning signs and their meaning is to explain the levels of risk related to this
product.
WARNING
Please read all safety warnings and instructions. Not doing so may result in
electrical shocks, re, or in severe personal injuries.
• Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards when not using your battery tool or when
changing accessories. Following this rule will reduce the risk of electric shock, re, or serious
personal injury.
• Do not place battery tools or their batteries near re or heat. Following this rule will reduce the
risk of serious personal injury.
SYMBOL SIGN MEANING
WARNING
It indicates a dangerous situation where you need to pay full
attention to avoid any kind of personal injuries or damage to the
device.
NOTICE It indicates useful information which can facilitate your task.

5
EN
• Do not crush, drop or damage the battery pack. Do not use a battery pack or charger that has
been dropped or has received a sharp blow. Properly dispose of a dropped or damaged battery
immediately.
• Do not charge battery tool in a damp or wet location. Following this rule will reduce the risk of
electric shock.
• For best results, your battery tool should be charged in a location where the temperature is more
than 10°C but less than 35°C. To reduce the risk of serious personal injury, do not store outside
or in vehicles.
• Under extreme usage or temperature conditions, battery leakage may occur. If liquid comes in
contact with your skin, wash immediately with soap and water, then neutralize with lemon juice
or vinegar. If liquid gets into your eyes, ush them with clean water for at least 10 minutes, then
seek immediate medical attention. Following this rule will reduce the risk of serious personal
injury.
• Save these instructions. Refer to them frequently and use them to instruct others who may use
this tool. If you loan someone this tool, loan them these instructions also to prevent misuse of the
product and possible injury.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specied by the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of re when used with another battery pack.
• Use battery tools only with specically designated battery packs. Use of any other battery packs
may create a risk of injury and re.
• When battery pack is not in use, keep it away from other metal objects like paper clips, coins,
keys, nails, screws, or other small metal objects that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a re.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
WARNING SYMBOLS
The warning icons on labels in this machine and/or in the manual indicate the necessary information
for the safe use of the device.
Safety alert.
Please read the instructions carefully before starting the machine.
Recycle Li-Ion batteries.
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your local authority or retailer for recycling
advice.

6
PRODUCT DESCRIPTION
DETAILED DESCRIPTION OF THE PRODUCT
TECHNICAL DATA
BATTERY
Model BAT-56V-2AH BAT-56V-4AH
Battery capacity 2.0 Ah 4.0 Ah
Battery type 56 V DC Lithium-ion 56 V DC Lithium-ion
Compatible charger (not included) CHAR-50HZ CHAR-50HZ
Charger input 100V-240 V
50-60 Hz AC only
100V-240 V
50-60 Hz AC only
Maximum charging time 60minutes/40minute 120minutes/60minute
Weight 0,98 Kg 1,67 Kg
NOTE: GREENCUT reserves the right to modify the specications of the device without prior notice.

7
EN
USING THE PRODUCT
FUEL GAUGE
To display the amount of charge left in the battery, press the charge level indicator button.
• The battery pack charger level is between 0%-99%. 99% meas fully charger.
• Press the indicator button one time,the display shows the Percentage of battery charger status.
• Press two times quickly it shows the cell temperature degree centigrade
• when the battery capacity reduced to 0%,it can’t discharge on tool anymore need put back on
the specied charger to charge.
BATTERY PROTECTION FEATURES
56V LITHIUM-ION batteries are designed with features that protect the LITHIUM-ION cells and
maximise battery life. If the tool stops during use, the following may be the causes:
a. The maximum current draw of the battery has been exceeded, causing it to automatically stop
powering the tool. Release the trigger to reset the tool and pull the trigger to resume operation.
b. Excessive temperatures will cause the battery to stop powering the tool. Feel the battery pack; if
it is too warm, allow it to cool down.
If the tool still does not work, recharge the battery.
CHARGING THE BATTERY PACK
Battery packs are shipped in a low charge condition to prevent possible problems. Therefore, you
should charge them until the green LED on the front of the charger comes on.
If the charger does not charge the battery pack under normal circumstances, return both the battery
pack and charger to your nearest authorised service centre for electrical check.
TO CHARGE
• Use battery pack only with the recommended charger.
• Connect the charger to the power supply. Make sure the power supply is normal household
voltage, 100-240 volts, AC only, 50-60.Hz
• Make sure the latch of the charger snap into place and the battery pack is secured in the charger
before beginning operation.
• Slide the battery pack along the groove of the charger.
• Press down on the battery pack to be sure contacts on the battery pack engage properly with
contacts in the charger.
• Do not place the charger and battery pack in an area of extreme heat or cold. They will work best
at normal room temperature.

8
NOTE: The charger and battery pack should be placed in a location where the temperature is more
than 10°C but less than 35°C.
• The battery pack will become slightly warm to the touch while charging. This is normal and does
not indicate a problem.
• After charging is complete, the charger green LED will remain on until either the battery pack has
been removed from the charger or the charger has been removed from the power supply.
• When batteries become fully charged, unplug the charger from the power supply and remove the
battery pack.
• To remove the battery pack from the charger, depress the latch of the charger.
CHARGING A HOT BATTERY PACK
If the battery pack is above normal temperature range, the charger red LED and green LED will begin
ashing.
When the battery pack cools down to approximately 50°C, the charger will automatically begin fast
charge mode.
COLD WEATHER OPERATION
The LITHIUM-ION battery pack can be used in temperatures down to -10°C. Put the battery pack on a
tool and use the tool in a light duty application. After about a minute, the pack will have warmed up
and begin operating normally.
BATTERIES
These batteries have been designed to provide maximum trouble-free life. However, like all batteries,
they will eventually wear out. Do not disassemble battery pack and attempt to replace the batteries.
Handling of these batteries, especially when wearing rings and jewelry, could result in a serious burn.
To obtain the longest possible battery life, we suggest the following:
• Remove the battery pack from the charger once it is fully charged and ready for use. For battery
pack storage longer than 30 days:
- Store the battery pack where the temperature is below 27°C and away from moisture.
- Store battery packs in a 40%-60% charged condition.
- Every six months of storage, charge the battery pack as normal.

9
EN
BATTERY PACK REMOVAL AND PREPARATION FOR RE- CYCLING
To preserve natural resources, please recycle or dispose of batteries properly.
This product contains LITHIUM-ION batteries. Local, state or federal laws may prohibit disposal of
LITHIUM-ION batteries in ordinary trash.
Consult your local waste authority for information regarding available recycling and/or disposal
options.
WARNING
Upon removal, cover the battery pack’s terminals with heavy-duty adhesive tape.
Do not attempt to destroy or disassemble battery pack or remove any of its
components. LITHIUM-ION batteries must be recycled or disposed of properly. Also,
never touch both terminals with metal objects and/or body parts as short circuit
may result. Keep away from children. Failure to comply with these warnings could
result in re and/or serious injury.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national provisions and regulations.
Follow all special requirements on packaging and labelling when transporting batteries by a third
party. Ensure that no batteries can come in contact with other batteries or conductive materials while
in transport by protecting exposed connectors with insulating, non-conductive caps or tape. Do
not transport batteries that are cracked or leaking. Check with the forwarding company for further
advice.

10
RECYCLING AND DISPOSING
When you decide to get rid of the machine, make sure to follow the local regulation.
The batteries used in this mower’s battery pack contain the following toxic and corrosive material:
LITHIUM-ION.
WARNING
Toxic materials must be disposed of in a specified manner in order to prevent
contamination of the environment. Before disposing of damaged or worn out
Lithium-Ion battery packs, contact your local waste disposal agency for information
and specific instructions. Take the battery to a local recycling and/or disposal centre
that is certified for disposal. If the battery pack cracks or breaks, whether it leaks
or not, do not recharge it and do not use it. Dispose of it and replace it with a new
battery pack. DO NOT ATTEMPT TO REPAIR IT!
Follow these instructions in order to avoid injury and the risk of fire, explosion, or electric shock, and
to avoid damage to the environment:
• Cover the battery’s terminals with heavy- duty adhesive tape.
• Do not attempt to remove or destroy any of the components of the battery pack.
• Do not attempt to open the battery pack.
• If a leak develops, the electrolytes that are released are corrosive and toxic. Do not get the
solution in the eyes or on the skin, and do not swallow it.
• Do not place batteries in regular household trash.
• DO NOT incinerate batteries.
• DO NOT place batteries where they will become part of any waste landfill or municipal solid
waste stream.
• Dispose of batteries at a certified recycling or disposal center.
Package materials are recyclables. Please, throw them away on the appropriate trash can.
GUARANTEE
This product has a 2 years guarantee. This guarantee covers damages and bad function, only if the
product has not been misused and all the instructions has been correctly followed.
In order to prove guarantee a receipt must be presented. The product has to be complete and have all
its parts.
The guarantee do not cover wear, lack of maintenance, negligence, incorrect assembly and
inappropriate usage (blows, disrespect to power supply, storage, using conditions, etc).
It is also excluded when non original or non adequate to the assembly accessories or parts, has been
used on the product.

11
EN

www.greencut.es
Manual revisado en marzo 2017
