Grifco eDrive +2.0 User manual

D-M-RSO/037
160715
Vertical Lift Door Opener Kit
Supplementary Installation
Manual for eDrive +2.0 Vertical
Lift Door Opener Kit
NOTE:
This document contains information for the installation of the
Vertical Lift Door Opener Kit which has been specifically
designed for vertical lift cool room doors.
This document must be read in conjunction with the Grifco
eDrive +2.0 User Manual which contains setup, operation and
safety information.
Chamberlain Australia Pty Ltd
PO Box 1446, Lane Cove
NSW 1595, Australia
Phone toll free 1800 474 326
www.grifco.com.au
www.grifco.co.nz
Chamberlain New Zealand Ltd
PO Box 100-221
North Shore 0745, New Zealand
Phone toll free 0800 653 667

2
SAFETY INSTRUCTIONS
Mechanical
Electrical
When you see these Safety Symbols and Signal Words on the following pages,
they will alert you to the possibility of serious injury or death if you do not
comply with the warnings that accompany them. The hazard may come from
something mechanical or from electric shock.
When you see this Signal Word on the following pages, it will alert you to the
possibility of damage to your commercial door and/or the commercial door
opener if you do not comply with the cautionary statements that accompany it.
WARNING: The Grifco eDrive +2.0 User Manual contains important safety
information and must be read prior to attempting installation of this opener.
SYSTEM OVERVIEW
WARNING
WARNING
CAUTION
Opener, includes: motor,
gear box, APE and drive
sprocket.
Mounting
bracket
Hand chain mechanism
(Supplied chain not
shown)
APE Cable and
Motor Power cable
(Conduit not shown
–not supplied)
Wall Mount kit,
including Expansion
Board
C10A Controller
Existing Control
Box on site
NOTE:
This Grifco kit allows the retrofit conversion
of non-Grifco motors on vertical lift cool
room door configurations. The included
mounting plate requires a specific
counterweight idler arrangement to allow
chain drive as described. The existing
control box will require conversion to
house the new Grifco control system.
Although every attempt is made to ensure
this kit is flexible to differing installation
conditions, some site variations may exist
that require an alternate configuration
(Left Hand installation shown)

3
INSTALLATION - OPENER
Opener and mount plate assembly:
1. Mounting Plate (x1)
2. M8 screw (x4)
3. M8 Nyloc nut (x4)
4. M12 screw (x4)
5. M12 washer (x4)
6. Opener
Note: Left Hand installation shown
When replacing an existing non Grifco opener, it is recommended to follow these steps:
1. Clamp the mounting plate into position
and use the 4 x M8 holes as a jig to drill
through the installed idler bracket
2. Tin snip x 2 cuts (around 50mm vertically
down) and bend the counterweight box
guard where the hand chain is going to rub
when installed.
3. Bolt the mounting plate to the Grifco
Operator, lightly tightening in the “closest”
chain adjustment position.
4. Using the existing drive chain (8B), fit
around the “driven sprocket” as a closed
loop with con link fitted.
Drive Chain length: 711mm (28”)
5. Lift the Grifco opener into position, looping
the chain over the sprocket, and fixing with
the 4 x M8 fasteners to the door hanger
bracket.
6. Set the 13 tooth drive sprocket into
position and firmly tighten the 2 x M8 grub
screws, one into the key way. Note: there
is NO key steel required.
7. Adjust chain tension via the 4 x M12
mounting bolts on the Grifco operator.
8. Fit hand chain and connect electrically.
9. Check mechanical installation via hand
chain before operating electrically.
Reflective Beams are required to be fitted to operate the system. See instructions
supplied with Reflective Beam kit for installation and setup.
Beam Installation heights from ground level: 1st set 100mm, 2nd set 600mm
Pre-installer
Idler bracket
Bend counter weight box guard
to clear the hand chain
Supplied hand
chain not shown

4
INSTALLATION –ELECTRICAL CONNECTIONS
Cable Number
Relay
Expansion Board (EB1)
Main Control Board
(MCB)
C10A
1 (RJ6 cable supplied)
-
-
Ethernet connector
Ethernet connector
2 (Motor power cable, supplied)
-
-
N: BLUE
X: BROWN
Z: WHITE
Y: NOT CONNECTED
EARTH: YELLOW/GREEN
-
3 (APE cable, supplied)
-
-
APE3
-
© 2015 The Chamberlain Group, Inc
EXPANSION BOARD
INSTALLATION:
Refer to Expansion
Board manual for
mounting instructions.
DIP SWITCH SETTINGS:
Factory setting: Dip
Switch #2 to ON, set all
others to OFF
