Grimac TWENTY Series PUL 2 Manual

LEV - PUL - ELE
0
1
2
4
9
1216
0,5 1
1,5
2
3 2,5
ISTRUZIONI PER L’USO E LA MANUTENZIONE MODELLI:
OPERATING AND MAINTENANCE INSTRUCTIONS MODELS:
MOD. TWENTY MOD. TEN
MACHINES FOR ESPRESSO COFFEE’
MACHINES FOR ESPRESSO COFFEE
MACCHINE PER CAFFE’ ESPRESSO
MACCHINE PER CAFFÈ ESPRESSO

29
DICHIARAZIONE DI CONFORMITÀ CE
DECLARATION OF CONFORMITY CE
Noi:
We: Grimac s.r.l.
via Morazzo, 2
40069 - Zola Predosa (BO) ITALY
dichiariamo, sotto la nostra completa responsabilità, che i prodotti
declare, accepting full responsability, that the product
macchine per caffè
Coffee machines
modelli
models TEN PUL 2/3/4 LEV 2/3/4 ELE 2/3/4
TWENTY PUL 2/3/4 LEV 2/3/4 ELE 2/3/4
a cui la dichiarazione si riferisce, sono conformi alle seguenti norme:
to which this declaration relates conforms with the following standard:
CEI EN 60335 - 1 A55 : 1993
CEI EN 60335 - 2 - 15 : 1990
CEI EN 60335 - 1 A6 : 1989
ed ai requisiti delle seguenti direttive CEE
in accordance with the provisions of CEE
DIRETTIVA BASSA TENSIONE 73/23
con successivo emendamento 93/68
DIRETTIVA EMC 89/336
LOW VOLTAGE DIRECTIVE 73/23
with successive emendment 93/68
DIRECTIVE EMC 89/336
Zola Predosa, 15 January 2002 Il presidente ed amministratore delegato
The Manager and Managing Director
Sig. GIANCARLO GARDOSI

30
Dear Customer, Grimac Srl would like to thank you for the choice that you have made and guarantees that the
product that you have purchased is top quality.

31
CONTENTS
SECTION 0 - INTRODUCTION
0.1 - OPENING REMARKS 32
0.2 - SERVICING 33
0.3 - SYMBOLS 34
0.4 - GENERAL SAFETY NOTICES 35
0.5 - POSITION OF STICKERS 35
0.6 - SAFETY PRECAUTIONS TO BE TAKEN WHEN WORKING ON THE MACHINE 36
0.7 - PRACTICAL TIPS ON MAKING COFFEE 36
0.8 - TECHNICAL SPECIFICATIONS 37
SECTION 1 - TECHNICAL DATA
1.1 - BACKGROUND INFORMATION 38
1.2 - TAKING DELIVERY AND UNPACKING 38
1.3 - POSITIONING AND INSTALLATION 39
1.4 - PRELIMINARY CHECKS 40
SECTION 2 - GENERAL DESCRIPTION
2.1 - GENERAL DESCRIPTION 41
SECTION 3 - USING THE MACHINE
3.1 - USING THE MACHINE 42
3.2 - MACHINE OPERATIONS AND OPERATING INSTRUCTIONS 43
SECTION 4 - MAINTENANCE
4.1 - CLEANING 49
SECTION 5 - ACCESSORIES AVAILABLE ON REQUEST
5.1 - WATER SOFTENER 50
5.2 - CUP WARMER 51
5.3 - CAPPUCCINO MAKER 52
SECTION 6 - WIRING DIAGRAMS 53
SECTION 7 - WATER AND STEAM CIRCUIT DIAGRAM 54

32
SECTION 0 - INTRODUCTION
0.1 - OPENING REMARKS
These Operating Instructions are a guide to using and maintaining the TEN and TWENTY model machines manufactured by Grimac srl .
Before USING OR WORKING ON THE MACHINE in any way, carefully read the whole of this manual.
The manual contains all the information, advice and warnings about using the coffee machine that are required to ensure long term reliability and
maximum operating efficiency.
The Grimac coffee machines have been designed in such a way that it incorporates all the traditional features of a coffee machine in an Italian bar:
component parts designed for professional use, reliability and operating autonomy, a copper lined water heater but above all it provides coffee of
superlative quality. The TEN and TWENTY series machines have been designed for people who really know about coffee.
Follow all the advice contained in the manual carefully in order to ensure optimum machine efficiency and in order to ensure that it has a long working
life. Remember that the Operating Instructions are an integral part of the product and must be kept carefully throughout the whole working life of the
machine.
If the machine is passed onto another user or owner the Operating Instructions must go with it.
Should problems or faults arise, GRIMAC srl guarantees that you will be given every possible assistance from our after-sales service centres.

33
0.2 - SERVICING
DATE OF INSTALLATION................................................................... SERIAL NUMBER...........................................................
INSTALLED BY (NAME OF COMPANY)............................................ MODEL............................................................................
TOWN OR CITY................................................................................... TELEPHONE NUMBER...................................................
SERVICE ENGINEER TO BE CONTACTED........................................................................................................................................
SERVICED ON.................................................................................... BY ..................................................................................
SERVICED ON.................................................................................... BY ..................................................................................
SERVICED ON..................................................................................... BY ..................................................................................
SERVICED ON..................................................................................... BY ..................................................................................
SERVICED ON..................................................................................... BY ..................................................................................
SERVICED ON..................................................................................... BY ..................................................................................
HAVE THE COFFEE MACHINE SERVICED AT LEAST ONCE A YEAR BY QUALIFIED SERVICE ENGINEERS.

34
0.3 - SYMBOLS
The symbols below are used to draw the reader’s attention to important points regarding personal safety, machine safety and certain operating
conditions.
GENERAL OPERATING NOTICES
GENERAL WARNING
DAMAGE MAY BE CAUSED TO THINGS OR TO THE COFFEE MACHINE
WARNING!
SOURCE OF DANGER TO PERSONS OR THE MACHINE
WARNING!
DANGER OF ELECTRIC SHOCK TO PERSONS OR ELECTRICAL DAMAGE TO THE COFFEE
MACHINE.

35
0.4 - GENERAL SAFETY NOTICES
Any use of the TEN and TWENTY model machine that is not specified in this manual or any use of the product other than the use agreed upon at the
time of purchase exonerates GRIMAC srl from any liability for any harm or injury to persons or damage to things or the machine.
THE ELECTRICAL SYSTEM MUST BE EARTHED.
-Never place hands or metal or other objects inside the machine when it is connected to the electric power supply.
-Always contact our after-sales service centre for any repair or maintenance task that is not described in this manual.
-Before working on the machine in any way, ALWAYS take out the plug from the mains power supply socket.
-Check the power cable regularly. A worn cable is a potential source of electrocution.
-Before using the machine to make coffee, make sure that you are perfectly familiar with the location and function of all the controls and the
machine specifications contained in the OPERATING INSTRUCTIONS.
Certain safety regulations must be adhered to when using this machine.
0.5 - POSITION OF STICKERS
Stickers and plates displaying ‘Notices’ and ‘Warnings’ are located on the machine. Replace them if they become illegible.

36
0.6 - SAFETY PRECAUTIONS TO BE TAKEN WHEN WORKING ON THE MACHINE
-Switch off the machine and disconnect it from the electric power supply before carrying out routine maintenance, special maintenance and general
cleaning operations.
-In order to ensure that the machine has a long working life, have any component parts replaced only by manufacturer approved parts by properly
qualified service engineers.
-After carrying out any kind of maintenance, ensure that all parts of the machine are in proper working order.
-Repairs to the electrical system must be carried out only by properly qualified service engineers and only after the electric power supply has been
disconnected and the plug has been removed from the supply socket.
- Never use running water on the machine whilst it is switched on or being cleaned.
-Never wash the machine with solvents, paint thinners, alcohol, etc. We recommend the use of warm water and neutral detergent in order not to
damage the internal and external parts of the machine.
0.7 - PRACTICAL TIPS ON MAKING COFFEE
The TEN andTWENTY series coffee machines guarantee you a perfect cup of coffee because it uses the same professional standard component parts
as coffee machines in Italian bars. Nevertheless, the user must ensure that the steps prescribed in Section 3, Paragraph 3.1 are strictly adhered to and
in particular the user must ensure that the filter is filled with the correct amount of coffee.

37
0.8 - TECHNICAL SPECIFICATIONS
L 550 mm
512 mm
Ten ModelTwenty Model
3
Width .............................................
Depth ...............................................
Height ..................................................
Capacity ................................................
Supply voltage (volt) .................................
Absorbed power, resistance .....................
Absorbed power, electric pump ...........
Absorbed power, solenoid valve ...........
Operating pressure, water heater .............
Set pressure, safety valve ........................
Set pressure, heat exchanger safety
valve ......................................................
Pressure, mains water supply(*)...............
Pressure, coffee dispensing .................
Units
n°
24
mm
mm
mm
litres
V
kW
kW
kW
bar
bar
bar
bar
bar
658
550
512
10
115/230/400
3.3
0.165
0.018
0.9
1.9
12
0÷4
9÷10
828
550
512
15
115/230/400
4.5
0.165
0.027
0.9
1.9
12
0÷4
9÷10
1038
550
512
20
115/230/400
4.5
0.165
0.036
0.9
1.9
12
0÷4
9÷10
3
Units
n°
42
mm
mm
mm
litres
V
kW
kW
kW
bar
bar
bar
bar
bar
702
570
505
10
115/230/400
3.3
0.165
0.018
0.9
1.9
12
0÷4
9÷10
882
570
505
15
115/230/400
4.5
0.165
0.027
0.9
1.9
12
0÷4
9÷10
1092
570
505
20
115/230/400
4.5
0.165
0.036
0.9
1.9
12
0÷4
9÷10
(*)Use of a pressure reducer is recommended for values higher than those given.
TEN MODELTWENTY MODEL
L
505 mm
5
7
0
m
m
............................................. Width
............................................... Depth
.................................................. Height
................................................. Capacity
................................. Supply voltage (volt)
................... Absorbed power, resistance
........... Absorbed power, electric pump
........... Absorbed power, solenoid valve
.......... Operating pressure, water heater
...................... Set pressure, safety valve
Set pressure, heat exchanger safety
...................................................... valve
............... Pressure, mains water supply(*)
................... Pressure, coffee dispensing
(*)Use of a pressure reducer is recommended for values higher than those given.

38
SECTION 1 - TECHNICAL DATA
1.1 - BACKGROUND INFORMATION
This machine has been manufactured from component parts and materials that conform to the new standards now in force. Each part of the Grimac
machine has therefore been carefully designed with particular attention being paid to the electrical system components and the elements that come into
direct contact with the coffee being dispensed.
1.2 - TAKING DELIVERY AND UNPACKING
The The TEN and TWENTY coffee machines are housed in a box that protects it from
being jolted and broken.
Open the box and remove the moveable cardboard protection in order to be able to take
hold of the bottom of the machine with both hands. Lift out slowly and carefully.
Rest the machine on a flat surface or table for the preliminary operations.
First, check that the machine is complete and undamaged.
Also check that underneath the coffee dispenser unit there is the box containing the
accessories that come supplied with the machine. (See figure alongside).
Before connecting the coffee machine to the mains electric power supply, check that the
mains voltage is compatible with the technical specifications.
THE ELECTRICAL SYSTEM MUST BE EARTHED.
ACCESSORIES SUPPLIED WITH THE MACHINE

39
1.3 - POSITIONING AND INSTALLATION
After checking that the machine is complete, locate it in the position in which it will be used. Ensure that the position is stable and safe and allows
enough space for carrying out the different operations (fitting the filter holder, obtaining hot water and steam).
The following appliances must be installed, adjusted and connected to the mains water and electric power supplies by qualified people in strict
compliance with the instructions contained in this manual.
To ensure that the machine works correctly and remains in proper working order, read this manual carefully, adhere to the standards which it sets out
and refer to the diagrams it contains.
Place the machine on a flat surface that is out of the reach of children.
To prevent the machine’s being knocked, do not locate it in places where there is a lot of movement to and from or in narrow corridors.
Connecting to mains power supply
Connect the power cable to the mains by means of a 24 amp fused switch as shown on the label on the cable.
.
Connecting to the mains water supply
1 - cold water must be supplied to the machine;
2 - check that mains water supply pressure is compatible with the technical specifications for the machine;
3 - connect the drain pipe to the tank underneath the drip tray and do not make tight bends;
4 - connect the 3/8" hose to the mains supply;
5 - ensure that there is an adequate inclination to enable water to drain away;
6 - if the mains supply water is to be treated with a water softener, follow the instructions set out on page 50.

40
1.4 - PRELIMINARY CHECKS
Check that: the electric plug has been inserted;
the drain pipe is connected to the mains water supply;
the drain pipe has been positioned in the manner specified in the instructions above.

41
0
1
2
4
9
1216
0,51
1,5
2
3 2,5
SECTION 2 - GENERAL DESCRIPTION
2.1 - GENERAL DESCRIPTION
In order to avoid problems and complications, the motor and the pump have already been installed inside the machine in an accessible position.
When the product leaves the factory it has been fully tested and is ready to be rapidly installed. This allows space to be saved and ensures lower
working noise levels.
TWENTY MODEL TEN MODEL

42
0
1
2
4
9
1216
0,51
1,5
2
3 2,5
SECTION 3 - USING THE MACHINE
3.1 - USING THE MACHINE
Place the main switch at position 1.
Turn the external water supply knob and turn on the steam tap, let the water flow into the water heater and check the level on the reading scale. The
water level should come roughly half way up the MIN-MAX scale.
Place the resistance switch in the position 2.
Finally, shut off the steam tap.
The manometer will indicate that water heater pressure is between 0.9 - 1.2 bar.
Be very careful when dispensing water and steam.
DANGER OF BURNS.
To dispense hot water, turn the central knob
marked with the symbol .
To dispense steam, turn either one of the side handles
marked with the symbol .

43
3.2 - MACHINE OPERATIONS AND OPERATING INSTRUCTIONS
LEV Model
Manual operations with lever operated coffee dispenser unit; thermostatically controlled heat exchanger in water heater maintains water at a constant
temperature. Available in the 2, 3 and 4 unit versions.
A-Cup heater switch (optional)
B-Steam knob
C-Hot water knob
D-Water heater pressure gauge
E-Main switch
L-Boiler water level indicator
N-Coffee dispensing pressure gauge
P- Manually operated knob for supplying water
T-Start/Stop coffee dispensing lever
Put the required amount of coffee into the filter holder and fit it under the unit. Next, lower the lever (T) relative to the unit used to dispense the coffee.
Similarly, you can stop dispensing the coffee by turning the lever (T) back up.
A
C
T
E
ND
B
T
B
L
P
MAX
MIN

44
PUL Model
Semi-automatic continuous dispensing with solenoid valve.
The coffee dispenser unit is operated by a switch that meets approved standards and which dispenses the quantity in the upper part. Available in the 2,
3 and 4 unit versions.
A-Cup heater switch (optional)
B-Steam knob
C-Hot water knob
D-Water heater pressure gauge
E-Main switch
L-Boiler water level indicator
N-Coffee dispensing pressure gauge
P-Manually operated knob for supplying water
I-Start/Stop coffee dispensing switch
Put the required amount of coffee into the filter holder and fit it under the unit. Next, press the push-button (I) relative to the unit used to dispense the
coffee.
You can stop dispensing the coffee by pressing the push-button (I) again.
A
ICIB
LND
E
MAX
MIN
B
P

45
ELE Model (1st series) - Automatic monitoring of the level of the water in the water heater.
Electronic model with microprocessor managed control panel with pushbottons that operate independently from one another. It enables varying amounts
of coffee to be dispensed using different dosing patterns. The pushbottons are identified by warning leds. The electric circuit complies with safety and
operating emergency regulations and approved switch for each dispensing unit has been fitted to the front of the machine at the top.
The level of the water in the water heater is monitored automatically.
Available in the 2, 3 and 4 unit versions.
A- Emergency Start/Stop dispensing switch
B- Steam knob
C- Hot water knob
D- Water heater pressure gauge
E- Main switch
L- Boiler water level indicator
N- Coffee dispensing pressure gauge
P- Manually operated knob for supplying water
M1 - Coffee dispenser button for a small
cup of coffee
M2 - for a big cup of coffee
M3 - for two small cups of coffee
M4 - for two big cups of coffee
M5 - Programming
Put the required amount of coffee into the filter holder and fit it under the unit. Next, press the key corresponding to the desired delivery on the relative
keyboard. If the wrong selection is made, press the key again to stop supply.
A
C
LND
E
MAX
MIN
M1 M2 M3 M4 M5 B
M1 M2 M3 M4 M5
B
P

46
ELE Model (2nd series) - Automatic monitoring of the level of the water in the water heater.
Electronic model with microprocessor managed control panel with pushbottons that operate independently from one another. It enables varying amounts
of coffee to be dispensed using different dosing patterns. The pushbottons are identified by warning leds. The electric circuit complies with safety and
operating emergency regulations and approved switch for each dispensing unit has been fitted to the front of the machine at the top.
The level of the water in the water heater is monitored automatically.
Available in the 2, 3 and 4 unit versions.
A- Cup heater switch (optional)
B- Steam knob
C- Hot water knob
D- Water heater pressure gauge
E- Main switch
F- Emergency Start/Stop dispensing switch
L- Boiler water level indicator
N- Coffee dispensing pressure gauge
P- Manually operated knob for supplying water
M1 - Coffee dispenser button for a small
cup of coffee
M2 - for a big cup of coffee
M3 - for two small cups of coffee
M4 - for two big cups of coffee
M5 - Delivery Programming/Stop
Put the required amount of coffee into the filter holder and fit it under the unit. Next, press the key corresponding to the desired delivery on the relative
keyboard. The LED turning on indicates the delivery mode selected.
Now press the F key to start delivery. Delivery stops when the F key is pressed again.
If the wrong selection is made, press the key Fagain to stop supply.
A
C
LND
E
MAX
MIN
M1 M2 M3 M4 M5 B
M1 M2 M3 M4 M5
B
P
FF

47
ELE Model automatic electronic dosing
This reliable, high quality product ensures that Grimac’s new dosing system reduces assembly costs and the amount of space required.
The control panel controls both the coffee supply commands and the electronic controls. Each control panel is completely independent of the others.
If a control panel/control unit develops a fault, the others will continue to function as they are independent of one another.
The component parts used comply with European and American safety standards.
Programming doses:
Press M5 for 5 seconds. The leds will light up, allowing the operator to use the machine.
- Press the required selector button.
-When the selected dose has been reached, press the same pushbutton again (storage in memory OK).
-Repeat the procedure for the other pushbuttons in order to complete all 4 doses. To interrupt coffee dispensing, press the previously pressed
pushbutton again.
For reasons of safety, no more than 3 litres or 4 minutes of continuous dispensing can be programmed.
