Grizzly H5527 User manual

COPYRIGHT © JULY, 2003 BY GRIZZLY INDUSTRIAL, INC., REVISED OCTOBER, 2017 (MN)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#TR5451 PRINTED IN CHINA
MODEL H5527
18-GAUGE BRAD NAILER
OWNER'S MANUAL
(For models manufactured since 01/14)
V2.01.14

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre-
hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to filter
out microscopic particles.

H5527 18-Gauge Brad Nailer -1-
SECTION 1: SAFETY
For Your Own Safety Read Instruction Manual
Before Operating This Equipment
The purpose of safety symbols is to attract your attention to possible hazard-
ous conditions. This manual uses a series of symbols and signal words which
are intended to convey the level of importance of the safety messages. The
progression of symbols is described below. Remember that safety messages by
themselves do not eliminate danger and are not a substitute for proper accident
prevention measures.
Indicates an imminent hazardous situation which, if
not avoided, WILL result in death or serious injury.
Indicates a potentially hazardous situation which, if
not avoided, COULD result in death or serious injury.
Indicates a potentially hazardous situation which, if
not avoided, MAY result in minor or moderate injury.
It may also be used to alert against unsafe practices.
This symbol is used to alert the user to useful infor-
mation about proper operation of the equipment.
NOTICE
Safety Instructions for Pneumatic Tools
KEEP ALL SAFETY DEVICES IN PLACE
and in working order.
REMOVE ADJUSTING KEYS AND
WRENCHES. Form habit of checking to
see that keys and adjusting wrenches are
removed from tool before operation.
KEEP WORK AREA CLEAN. Cluttered
areas and benches invite accidents.
DO NOT USE IN DANGEROUS
ENVIRONMENT. Do not use pneumatic
tools in damp or wet locations, or where
any flammable or noxious fumes may
exist. Keep work area well lighted.
KEEP CHILDREN AND VISITORS
AWAY. All children and visitors should be
kept at a safe distance from work area.
MAKE WORKSHOP CHILD PROOF by
locking the shop and shutting off air
valves.
DO NOT FORCE TOOL. It will do the job
better and safer at the rate for which it was
designed.
USE THE RIGHT TOOL. Do not force tool
or attachment to do a job for which it was
not designed.
DO NOT USE UNDER INFLUENCE OF
DRUGS OR ALCOHOL.

H5527 18-Gauge Brad Nailer
-2-
USE PROPER AIR HOSE for the tool.
Make sure your air hose is in good condi-
tion and is long enough to reach your work
area without stretching.
WEAR PROPER APPAREL. Do not wear
loose clothing, gloves, neckties, rings,
bracelets, or other jewelry which may get
caught in moving parts. Non-slip footwear
is recommended. Wear a protective hair
covering to contain long hair.
ALWAYS USE SAFETY GLASSES. Also
use a face or dust mask if operation is
dusty. Everyday eyeglasses only have
impact resistant lenses, they are NOT
safety glasses.
WEAR APPROVED HEARING
PROTECTION. Air escaping from pneu-
matic tools can exceed safe exposure
limits and may cause hearing damage
with prolonged exposure.
AWKWARD POSITIONS. Keep proper
footing and balance at all times when
operating tool. Do not overreach! Avoid
awkward hand positions that make work-
piece control difficult or increase the risk
of accidental injury.
REDUCE THE RISK OF
UNINTENTIONAL FIRING. Do not carry
tool with hand on trigger and always dis-
connect from air when not in use.
CHECK FOR DAMAGED PARTS.
Regularly inspect tool for any con-
dition that may affect safe operation.
Immediately repair or replace damaged or
mis-adjusted parts before operating tool.
DISCONNECT TOOLS before servic-
ing, changing accessories, or moving to
another location.
USE RECOMMENDED ACCESSORIES.
Consult this owner’s manual or the manu-
facturer for recommended accessories.
Using improper accessories will increase
the risk of serious injury.
NEVER LEAVE UNATTENDED TOOL
CONNECTED TO AIR. Disconnect the
air hose and do not leave tool until it is
relieved of any built up pressure.
NEVER ALLOW UNTRAINED
USERS TO USE THIS TOOL WHILE
UNSUPERVISED.
IF YOU ARE UNSURE OF THE
INTENDED OPERATION, STOP USING
TOOL. Seek formal training or research
books or magazines that specialize in
pneumatic tools.
BE AWARE OF HOSE LOCATION WHEN
USING PNEUMATIC TOOLS. Hoses can
easily become a tripping hazard when laid
across the floor or spread out in a disorga-
nized fashion.
SECURE WORK. When required, use
clamps or vises to secure workpiece. A
secured workpiece protects hands and
frees both of them to operate the tool.
MAINTAIN TOOLS WITH CARE. Keep
tools lubricated and clean for best and
safest performance. Follow instructions
for lubricating and changing accessories.
Safety Instructions for Pneumatic Tools

H5527 18-Gauge Brad Nailer -3-
Additional Safety Instructions for Nailers/
Staplers
HAND INJURIES: Do not place your
hands near the nail/staple point of entry.
A nail/staple can deflect and tear through
the surface of the workpiece, puncturing
your hand or fingers.
COMBUSTIBLE GASES: Never connect
the nailer/stapler to pressurized oxygen
or other combustible gases as an air
source. Only use filtered, lubricated, and
regulated compressed air.
SAFE HANDLING: Never point the nailer/
stapler at others! Do not keep the trigger
pulled when loading fasteners, carrying,
or holding tool. Carry the tool only by the
handle, never by any other part. Do not
carry the tool by the air hose. Disconnect
the nailer/stapler from the air hose when
going up and down ladders.
MODIFICATIONS: DO NOT modify this
tool or bypass the safety nose mecha-
nism.
COMPRESSED AIR RATING: Do not
connect the nailer/stapler to compressed
air that exceeds 120 PSI.
HOSE USAGE: Make sure your air hose
is designed for the tool in use, is in good
condition, and is long enough to reach
your work without stretching. However,
an overly long air hose in the work area
may be a tripping hazard.
OPERATING QUESTIONS: If you are
not sure about the intended operation,
stop using the nailer/stapler. Seek formal
training.
CLEANING: Never use gasoline or
other flammable liquids to clean the
nailer; vapors in the nailer/stapler will
ignite by a spark and cause it to explode.
MAINTENANCE: Always disconnect air
from the nailer/stapler when servicing or
installing nails. During maintenance, a
nailer/stapler connected to air may fire
accidentally, causing serious personal
injury.
CHECK VALVE: Do not use a check
valve or any other fitting that allows air to
remain in the tool after it is disconnected
from the air source.

H5527 18-Gauge Brad Nailer
-4-
Operating this nailer can propel
objects into the air, causing imme-
diate eye damage. To protect your-
self, always wear American National
Standards Institute (ANSI) approved
safety glasses or goggles when oper-
ating this equipment. In addition, this
nailer discharges at up to 85-90 deci-
bels. To protect your hearing, always
wear ANSI approved ear protection
when operating this nailer.
Never point this nailer at yourself or
another person! Always pay attention
to the direction this nailer is pointed.
Use this tool with respect and caution
to lessen the possibility of operator or
bystander injury. Ignoring this warning
may result in serious personal injury.
Nailer/stapler accidents routinely hap-
pen while moving the gun to another
location, such as up ladders, to anoth-
er room, or even another job site.
Always disconnect the gun immedi-
ately after use and never transport the
gun while connected to the air—even
if the air compressor is disconnected
from its power source!
No list of safety guidelines can be
complete. Every shop environment is
different. Always consider safety first,
as it applies to your individual working
conditions. Use this and other tools
with caution and respect. Failure to
do so could result in serious personal
injury, damage to equipment or poor
work results.
Read the manual before operation.
Become familiar with this nailer, its
safety instructions, and its operation
before beginning any work. Serious
personal injury may result if safety or
operational information is not under-
stood or followed.

H5527 18-Gauge Brad Nailer -5-
Machine Data
Nail Gauge .............................................. 18
Nail Length ........................................5⁄8"–2"
Magazine Capacity ...................... 100 Nails
Air Inlet ...........................................¼" NPT
Weight .............................................3.1 lbs.
Operating Pressure .................. 70-110 PSI
We stand behind our machines! If you
have questions or need help, contact us
with the information below.
Grizzly Technical Support
1815 W. Battlefield
Springfield, MO 65807
Phone: [phone]
Email: [e-mail]
We want your feedback on this manual.
What did you like about it? Where could it
be improved? Please take a few minutes to
give us feedback.
Grizzly Documentation Manager
P.O. Box 2069
Bellingham, WA 98227-2069
Email: [e-mail]
Contact Info
SECTION 2: INTRODUCTION

H5527 18-Gauge Brad Nailer
-6-
Inventory
After you open the nailer box, you should
find the following.
Model H5527 Inventory (Figure 1)
A. Carrying Case .................................... 1
B. Brad Nailer ......................................... 1
C. Hex Wrenches 3mm, 4mm ....... 1 Each
D. Safety Glasses ................................... 1
Figure 1. Model H5527 inventory.
A
B
C
D
Your new item was carefully packaged for
safe shipping. If you discover any damage
after you have signed for delivery, immedi-
ately call Customer Service at (570) 546-
9663 for advice.
Save the containers and all packing mate-
rials for possible inspection by the car-
rier or its agent. Otherwise, filing a freight
claim can be difficult.
When you are completely satisfied with
the condition of the shipment, you should
inventory the contents.
Unpacking
SECTION 3: SETUP

H5527 18-Gauge Brad Nailer -7-
The Model H5527 is designed to be oper-
ated at 70-110 PSI using clean, dry, regu-
lated, compressed air. DO NOT exceed
the 120 PSI maximum operating pres-
sure for your model.
Before using your new nailer, regulate the
air pressure on your air compressor to the
minimum PSI for your model.
An in-line filter/lubricator/regulator unit,
depicted in Figure 2, can be installed and
should be located as close to the nailer as
possible.
This filter/lubricator/regulator unit will
protect your tool from damaging water
build-up, allow you to adjust and maintain
constant air pressure to your tool, and
save you the inconvenience of having to
manually lubricate your tool every time
you use it.
Quick
Connector
Quick
Coupler
Air Hose Quick
Coupler
Quick
Connector
Lubricator
Filter
Regulator
Air
Compressor
Your
Tool
Figure 2. Typical filter/lubricator/regulator installation order.
Compressed Air
System
Check the current Grizzly catalog for avail-
ability of this unit. If you plan on install-
ing a filter/lubricator/regulator unit in your
compressed air system, always follow the
connection instructions that come with
the unit.
Exceeding the maximum permissible
operating pressure may cause the
nailer to explode, blowing metal frag-
ments in all directions. To protect
yourself from serious personal injury,
DO NOT allow your air compressor to
exceed the recommended pressure
when connected to this nailer!

H5527 18-Gauge Brad Nailer
-8-
A safety mechanism on the nose of the
nailer protects against accidental firing.
When the trigger is pressed, the nailer will
not fire until the safety nose mechanism is
depressed.
Before you use your nailer for the first
time, check the safety nose mechanism to
ensure proper function.
To check the safety nose mechanism:
1. DISCONNECT NAILER FROM THE
AIR SUPPLY!
2. Make sure the magazine is empty and
contains no nails.
3. Make sure the trigger and the safety
nose mechanism move up and down
without sticking.
4. Connect the nailer to the air supply.
Safety Nose
Mechanism
5. Without pressing the trigger, depress
the safety nose mechanism against a
scrap piece of wood that is clean and
free of any knots, nails, or other foreign
objects.
— If the nailer does not fire, then the
safety nose mechanism is working
correctly.
— If the nailer does fire when you
do this, immediately disconnect the
nailer from the air supply and call
Grizzly Technical Support at (570)
546-9663 for help.
— If the nailer fires when the trigger
is pulled, without the safety nose
mechanism being depressed, then
the nailer is not working properly.
— If you find that the safety nose
mechanism is not working properly,
check the lubrication of its sliding
components.
The safety mechanism is a mechanical
device that can fail. Never rely on this
mechanism as an excuse to point the
nailer at yourself or any bystanders.
Serious injury may occur.
safety nose mechanism

H5527 18-Gauge Brad Nailer -9-
Loading
When replacing nails in your Model
H5527, follow these guidelines:
Gauge: 18
Length: 5⁄8" – 2"
Capacity: 100
To load your nailer:
1. DISCONNECT NAILER FROM THE
AIR SUPPLY!
2. Grip the nailer firmly, and depress the
magazine latch, as shown in Figure 3.
Figure 4. Loading nails into magazine.
Figure 3. Releasing magazine latch.
3. Pull the magazine cover back until it
stops.
4. Point the nailer down and insert a stick
of brad nails into the magazine, as
shown in Figure 4. Make sure that the
pointed ends of the nails rest in the slot
at the bottom of the magazine.
5. Push the magazine cover forward until
the magazine latch locks in place.
SECTION 4: OPERATIONS

H5527 18-Gauge Brad Nailer
-10-
5. Pull the trigger.
— If the nail drove into the wood far
enough, continue with your intended
operations.
— If the nail either went too far or not
far enough, then adjust the air pres-
sure. More air pressure will make
the nail go deeper and less air pres-
sure will decrease the nail penetra-
tion.
Figure 5. Example of nail deflection.
Deflection is caused when grain
irregularities, knots or foreign
objects inside the wood cause the
nail to change its path, resulting in
the nail puncturing the surface of the
workpiece, as shown in Figure 5.
Besides damaging your workpiece,
deflection can cause injury if your free
hand is securing the workpiece in the
location that the nail deflects.
If you have not read the safety instruc-
tions in this manual, do not operate the
nailer.
Before you operate your nailer, place five
to six drops of the included oil into the
quick connect fitting where the nailer con-
nects to the air supply.
To operate your nailer:
1. Connect the air supply to the quick con-
nect fitting.
2. To test for proper nail penetration, hold
the nailer perpendicular to the surface
of a piece of clean scrap wood that is
thick enough for the length of nails you
have loaded.
3. Depress the safety nose mechanism
against your workpiece.
4. Before pulling the trigger, make sure
your free hand and other body parts
are positioned out of the way of a
potential path of a nail in case of deflec-
tion.
Operating

H5527 18-Gauge Brad Nailer -11-
Clearing Jammed
Nails
Always disconnect air from nailer
whenever clearing a jammed nail! A
nailer connected to air may fire acci-
dentally, causing serious personal
injury!
A jammed nail must be cleared before
using the nailer again.
To clear a jammed nail from the
magazine:
1. DISCONNECT NAILER FROM THE
AIR SUPPLY!
2. Unlatch and pull the magazine all the
way back.
3. Remove the nail stick from the
magazine.
4. Open the nailer nose with the nose
release lever (see Figure 6).
5. Remove the jammed nail with a tool
that will fit in the slot on the underside
of the nose, such as needle nose pli-
ers.
6. Throw the damaged nail away and
insert a new nail stick that only contains
clean, undamaged nails. DO NOT use
dirty or damaged nails!
7. Close the nose cover, and push the
magazine all the way forward until the
catch lever locks it in place.
Figure 6. Example of nose being opened
to clear a jam.
Nose
Cover
Nose Release Lever

H5527 18-Gauge Brad Nailer
-12-
Replacing Pistons
& O-Rings
If you use your nailer day in and day out,
repair pistons are cheap insurance against
wasted down time and lost profits, in the
event that a piston or piston shaft becomes
worn out.
6. Open the nose cover as if to clear a
jammed nail.
7. Watch the discharge area and push the
top of the piston with your finger. You
will see the piston shaft slide down the
discharge area.
8. With a long flathead screwdriver or sim-
ilarly shaped tool, push the piston shaft
back inside the nailer until you can grip
the piston head and remove it from the
cylinder. (Be careful not to scratch the
discharge area when pushing the pis-
ton shaft with the screwdriver.)
9. Place a new O-ring on the new piston
and apply a thin film of the nailer lubri-
cating oil on the O-ring.
10. Insert the new piston in the cylinder.
Make sure that the grooves on the pis-
ton shaft line up with those on the guide
at the bottom of the cylinder. The new
piston should easily slide into the cyl-
inder. DO NOT force the piston into
the cylinder! If the piston is not easily
inserted, double-check the alignment of
the piston shaft with the grooves on the
guide.
11. After the piston is inserted correctly,
close the magazine. Replace the rear
cap assembly and tighten the 4 cap
screws.
12. For more assistance, or to install a
complete O-ring set, refer to the appro-
priate breakdown diagram in the back
of this manual for component loca-
tions.
To replace a piston:
1. DISCONNECT NAILER FROM THE
AIR SUPPLY!
2. Remove all nails from the magazine
cartridge.
3. Remove the four cap screws on the
back of the nailer, near the exhaust
port.
4. Remove the cap.
5. The top of the piston should now be
visible inside the cylinder, which is
housed in the head of the nailer.
Always disconnect air from nailer
whenever servicing! During mainte-
nance, a nailer connected to air may
fire accidentally, causing serious
personal injury!

H5527 18-Gauge Brad Nailer -13-
Figure 9. Red rubber air hose.
G8114 —3⁄8" x 25 Ft. Air Hose
G8115 — 3⁄8" x 50 Ft. Air Hose
Multi-purpose red rubber air hose is flex-
ible and abrasion resistant. Rated for 200
PSI, this air hose has a bursting strength
of 800 PSI 1⁄4" NPT ends.
Figure 10. T28041 Primrose Air
Compressor Oil.
T28041—Primrose Plus Air Compressor
Oil, 1 Quart
Primrose Plus Air Compressor Oil is a
blend of the highest quality solvent refined,
paraffinic, and naphthenic petroleum min-
eral oils and additives, which prevent rust
and oxidation. This oil is formulated for
clean, trouble-free air compressor lubrica-
tion and effective control of carbon depos-
its for longer life.
Replacement Brad Nails
G1853—18 Gauge, 5⁄8", 5000
G1854—18 Gauge, 3⁄4", 5000
G1855—18 Gauge, 1", 5000
G1858—18 Gauge, 13⁄8", 5000
G1859—18 Gauge, 11⁄2", 5000
Figure 7. Selection of Brad nails.
T24889—Air Filter/Regulator 3⁄8"NPT
T24890—Air Filter/Regulator 1⁄2"NPT
These units are indipensable for prolong-
ing the lifespan of your air tools. The filter
keeps water/rust out. The regulator allows
you to control the optimum PSI delivery for
each air tool. Maximum pressure for each
unit is 150 PSI.
Figure 8. Models T24889 & T24890
Air Filter/Regulators.
T24889 T24890
SECTION 5: ACCESSORIES

H5527 18-Gauge Brad Nailer
-14-
Cleaning
Use a good solvent to clean the nose
assembly of the nailer. Always be sure that
the nailer is dry before using it again.
Do not allow dust, chips, sand, etc. into
the air connectors or into the body of the
nailer; this may result in leaks and damage
to the nailer and the air couplings.
Lubricating
Use Grizzly Model G2820 Pneumatic Tool
Oil or any other type of pneumatic tool oil.
Place two to six drops of oil in the nailer
air inlet (as shown in Figure 11) before
every use, or after 2 hours of continuous
use. Wipe off any excess oil near the nailer
exhaust to avoid dust build-up.
Another option to manual oiling would be
to install a lubricator in your air compres-
sor line. If your air compressor line already
has a lubricator, then regular lubrication
of your nailer will not be necessary. Just
make sure there is always oil in the lubri-
cator.
Figure 11. Lubricating nailer via air inlet.
Never use gasoline or other flamma-
ble liquids to clean this tool. Vapors
in the tool may ignite, causing the
tool to explode. Ignoring this warning
may lead to serious personal injury or
even death!
SECTION 6: MAINTENANCE

H5527 18-Gauge Brad Nailer -15-
Symptom Possible Cause Solution
Air leaking at trig-
ger valve area.
1. O-rings in trigger valve hous-
ing are damaged.
1. O-rings must be replaced
& operation of safety nose
must be checked.
Air leaking between
housing and hose.
1. Loose screws in housing.
2. Damaged O-ring.
3. Loose air fitting.
1. Tighten screws.
2. Replace O-ring.
3. Tighten air fitting & use tef-
lon tape.
Air leaking between
housing and cap
assembly.
1. Damaged seal. 1. Replace damaged seals.
Tool skips nails
while discharging.
1. Air leaks.
2. Dirt in nose.
3. Dirt or damage prevents nails
from moving freely in maga-
zine.
4. Inadequate air flow to tool.
5. Worn O-ring on piston or lack
of lubrication.
6. Damaged O-rings on trigger
valve.
7. Worn bumper.
8. Cap seal leaking.
1. Tighten screws and fittings.
2. Clean nose.
3. Clean magazine and
inspect/repair damage.
4. Check air fitting, hose,
compressor & air pressure.
5. Replace piston O-ring.
Lubricate.
6. Replace trigger valve O-
rings.
7. Replace bumper.
8. Replace cap seal.
Tool runs slowly
or has a loss of
power.
1. Nailer is not sufficiently lubri-
cated.
2. Broken spring in cap assem-
bly.
3. Exhaust port in cap is blocked.
1. Lubricate nailer.
2. Replace spring.
3. Clean or replace damaged
internal parts.
Fasteners frequent-
ly jam the nailer.
1. Nails are the wrong size.
2. Nails are bent or dirty.
3. Magazine or nose screws are
loose.
4. Driver or driver guide are worn
or damaged.
5. Nails are wrong angle.
1. Use correct nails.
2. Use undamaged, clean
nails.
3. Tighten magazine.
4. Replace worn or damaged
parts.
5. Use correct angle nails.
Nailer does not fire. 1. Nail is jammed in magazine or
discharge area.
2. Piston shaft is damaged.
3. Air pressure too low.
1. Clear nailer magazine or
discharge area.
2. Replace piston shaft.
3. Check/increase air pres-
sure.
SECTION 7: SERVICE
Troubleshooting

H5527 18-Gauge Brad Nailer
-16-
SECTION 8: Parts
Main
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38V2
39
80
49
43V2 44 45 46
47
48
49
50
51
52
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
73
32
5
4
81
30
72
74
75
76
77
78
75
79

H5527 18-Gauge Brad Nailer -17-
Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH5527001 STEPPED BOLT M4-.7 X 4, 6 X 7 43V2 PH5572043V2 DRIVER GUIDE COVER V2.01.14
2 PH5527002 EXHAUST CAP 44 PH5527044 NAIL GUIDE LINER
3 PH5527003 COMPRESSION SPRING 7.2 X 7 45 PH5527045 MAGAZINE SEAT
4 PH5527004 CAP SCREW M5-.8 X 20 46 PH5527046 SET SCREW M4-.7 X 16
5 PH5527005 LOCK WASHER 5MM 47 PH5527047 MAGAZINE CAP
6 PH5527006 CYLINDER CAP 48 PH5527048 BRACKET
7 PH5527007 O-RING 13.8 X 2.4 P14 49 PH5572049 CAP SCREW M4-.7 X 14
8 PH5527008 SEALING WASHER 2.5 X 31.2 50 PH5527050 PUSHER
9 PH5527009 COMPRESSION SPRING 8 X 7 51 PH5527051 PUSHER PIPE
10 PH5527010 HEAD VALVE PISTON 52 PH5527052 COMPRESSION SPRING 6.7 X 204
11 PH5527011 O-RING 31.2 X 3.5 P13.5 54 PH5527054 PIN 3 X 20
12 PH5527012 O-RING 24.7 X 3.5 P25 55 PH5527055 LATCH SPRING 6.2 X 9.4
13 PH5527013 SEALING WASHER 43 X 53.5 56 PH5527056 LATCH
14 PH5527014 CYLINDER RING 57 PH5527057 CAP SCREW M4-.7 X 8
15 PH5527015 O-RING 29.7 X 3.5 P30 58 PH5527058 LATCH BRACKET
16 PH5527016 O-RING 41.7 X 3.5 P42 59 PH5527059 CAP SCREW M4-.7 X 16
17 PH5527017 CYLINDER 60 PH5527060 RUBBER SLEEVE
18 PH5527018 O-RING 20.8 X 2.4 P21 61 PH5527061 O-RING 35.7 X 3.5 P36
19 PH5527019 PISTON (W/DRIVER) 62 PH5527062 CAP
20 PH5527020 BUMPER 63 PH5527063 AIR PLUG 1/4" NPT MALE
21 PH5527021 BODY 64 PH5527064 CARRYING CASE
22 PH5527022 RUBBER WASHER 4.5 X 8 65 PH5527065 HEX WRENCH 5MM
23 PH5527023 SEAL 66 PH5527066 HEX WRENCH 4MM
24 PH5527024 INNER VALVE SEAT 67 PH5527067 COMPLETE O-RING KIT
25 PH5527025 TRIGGER VALVE GUIDE (INNER) 68 PH5527068 PISTON REPAIR KIT
26 PH5527026 O-RING 10.6 X 1.8 69 PH5527069 SAFETY GLASSES
27 PH5527027 TRIGGER VALVE GUIDE (OUTER) 70 PH5527070 RUBBER WASHER
28 PH5527028 O-RING 11 X 2.4 P11.2 71 PH5527071 O-RING 36.3 X 3.55
29 PH5527029 COMPRESSION SPRING 9.1 X 17.5 72 PH5572072 POSITION PIN
30 PH5527030 STEP PIN 73 PH5527073 COVER PLATE PIN
31 PH5527031 TRIGGER 74 PH5527074 CAP SCREW M4-.7 X 8
32 PH5527032 E-CLIP 3MM 75 PH5527075 LOCK WASHER 4MM
33 PH5572033 SAFETY PLATE 76 PH5527076 SQUARE WASHER 4MM
34 PH5572034 PIN 77 PH5527077 HEX NUT M4-.7
35 PH5572035 STAND 78 PH5527078 AIR INLET PLUG CASE
36 PH5572036 COMPRESSION SPRING 5.3 X 21 79 PH5527079 BUMPER
37 PH5572037 SAFETY STAND 80 PH5527080 QUICK RELASE HANDLE
38V2 PH5572038V2 DRIVER GUIDE V2.01.14 81 PH5527081 E-CLIP 2.5MM
39 PH5572039 SPACER
