-18- G0472/G0473/G0476 Sandblasters

 


 








 







 










 

















Parts Breakdown (G0476)

G0472/G0473/G0476 Sandblasters -19-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0476001 WINDOW FRAME AND SEAL 34 P0476034 SHORT LEFT LEG
2 P0476002 WINDOW PLEXIGLASSS 35 P0476035 SHORT RIGHT LEG
4 PN01M 6MM FLAT WASHER 36 P0476036 FLAT SPACER
5 P0476005 HINGE 37 P0476037 FLAT GASKET
8 PS14M PHLP HD SCR M6-1 X 12 38 P0476038 BULKHEAD FITTING
9 PN01M HEX NUT M6-1 39 P0476039 HOSE NIPPLE
15 P0476015 CABINET 40 PW05M FLAT WASHER 4MM
16 P0476016 RIGHT DOOR 41 PN04M HEX NUT M4-.7
17 P0476017 LEFT DOOR 42 PS38M PHLP HD SCR M4-.7 X 10
18 P0476018 HOPPER 43 P0476043 FOAM FILTER
19 P0476019 LAMP CLAMP 44 P0476044 RING
20 PS38M PHLP HD SCR M4-.7 X 10 45 P0476045 FILTER ELEMENT
21 P0476021 ZIP TIE 46 P0476046 NOZZLE SET
22 P0476022 COMPLETE LAMP ASSEMBLY 47 P0476047 JET SET
23 P0476023 AC/DC ADAPTER 48 P0476048 JET SEAL SET
24 PS38M PHLP HD SCR M4-.7 X 10 49 P0476049 SCREEN
25 PN04M HEX NUT M4-.7 50 P0476050 HOSE CLAMP
26 PW05M FLAT WASHER 4MM 52 P0476052 SWITCH
27 P0476027 RIGHT GLOVE 53 PHTEK18 TAP SCREW #10 X 5/8
27-1 P0476027-1 LEFT GLOVE 55 P0476055 LATCH
28 P0476028 HOSE CLAMP 55-1 P0476055-1 LATCH CATCH
29 P0476029 PRESSURE SUPPLY HOSE 56 PS38M PHLP HD SCR M4-.7 X 10
30 P0476030 SUCTION TUBE 57 P0476057 HOPPER PLUG
31 P0476031 SUCTION HOSE 58 P0476058 RECEPTACLE COVER
32 P0476032 BLAST GUN 59 P0476059 RECEPTACLE
33 P0476033 CLEAR ADHESIVE FILM SET (4)
Parts List (G0476)
