Grizzly G0821 User manual

MODEL G0821
6" BENCHTOP JOINTER
w/SPIRAL CUTTERHEAD
OWNER'S MANUAL
(For models manufactured since 03/18)
COPYRIGHT © FEBRUARY, 2017 BY GRIZZLY INDUSTRIAL, INC., REVISED FEBRUARY, 2018 (HE)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#JH18517 PRINTED IN CHINA V2.02.18
3092372

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre-
hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property damage
from negligence, improper training, machine modifications or misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to filter
out microscopic particles.

INTRODUCTION............................................... 2
Contact Info.................................................... 2
Manual Accuracy ........................................... 2
Identification ................................................... 3
Controls & Components ................................. 4
Machine Data Sheet ...................................... 6
SECTION 1: SAFETY....................................... 8
Safety Instructions for Machinery .................. 8
Additional Safety for Jointers ....................... 10
SECTION 2: POWER SUPPLY ...................... 11
SECTION 3: SETUP ....................................... 13
Needed for Setup ......................................... 13
Unpacking .................................................... 13
Inventory ...................................................... 14
Hardware Recognition Chart ....................... 15
Cleanup ........................................................ 16
Site Considerations ...................................... 16
Bench Mounting ........................................... 17
Assembly ..................................................... 17
Dust Collection ............................................. 19
Test Run ...................................................... 20
Tightening Drive Belt ................................... 20
SECTION 4: OPERATIONS ........................... 21
Operation Overview ..................................... 21
Stock Inspection & Requirements................ 22
Setting Depth of Cut .................................... 23
Setting Fence Stops .................................... 24
Rotating/Changing ....................................... 26
Cutterhead Inserts ....................................... 26
Squaring Stock............................................. 27
Surface Planing............................................ 28
Edge Jointing ............................................... 29
Bevel Cutting................................................ 30
SECTION 5: ACCESSORIES ......................... 31
SECTION 6: MAINTENANCE......................... 34
Schedule ...................................................... 34
Cleaning & Protecting .................................. 34
Lubrication ................................................... 35
SECTION 7: SERVICE ................................... 36
Troubleshooting ........................................... 36
Tensioning/Replacing Belts ......................... 38
Adjusting Infeed Table Parallelism .............. 39
Replacing Motor Brushes ............................ 41
SECTION 8: WIRING...................................... 42
Wiring Safety Instructions ............................ 42
Wiring Diagram ............................................ 43
SECTION 9: PARTS....................................... 44
Main ............................................................. 44
Labels & Cosmetics ..................................... 46
WARRANTY & RETURNS ............................. 49
Table of Contents

-2- Model G0821 (Mfd. Since 03/18)
We stand behind our machines! If you have ques-
tions or need help, contact us with the information
below. Before contacting, make sure you get the
serial number
and manufacture date from the
machine ID label. This will help us help you faster.
Grizzly Technical Support
1815 W. Battlefield
Springfield, MO 65807
Phone: [phone]
Email: [email protected]
We want your feedback on this manual. What did
you like about it? Where could it be improved?
Please take a few minutes to give us feedback.
Grizzly Documentation Manager
P.O. Box 2069
Bellingham, WA 98227-2069
Email: [email protected]
Contact Info
We are proud to provide a high-quality owner’s
manual with your new machine!
We
made every effort to be exact with the
instruc-
tions, specifications, drawings, and photographs
in this manual. Sometimes we make mistakes, but
our policy of continuous improvement also means
that
sometimes the machine
you receive is
slightly different than shown in the manual
.
If you find this to be the case, and the difference
between the manual and machine leaves you
confused or unsure about something
,
check our
website for an updated version. W
e post
current
manuals and
manual updates for free
on our web-
site at
www.grizzly.com.
Alternatively, you can call our Technical Support
for help. Before calling, make sure you write down
the
Manufacture Date and Serial Number
from
the machine ID label (see below). This information
is required for us to provide proper tech support,
and it helps us determine if updated documenta-
tion is available for your machine.
Manufacture Date
Serial Number
Manual Accuracy
INTRODUCTION

Model G0821 (Mfd. Since 03/18) -3-
Identification
For Your Own Safety Read Instruction Manual Before Operating Jointer
a) Wear eye and hearing protection.
b) Always keep cutterhead and drive guards in place and in proper operating condition.
c) Always use hold-down or push blocks when jointing material narrower than 3" or surface
planing material thinner than 3".
d) Never perform jointing or planing on pieces shorter than 8" in length.
Infeed
Table
Infeed Table
Adjustment
Knob
Fence
Outfeed
Table
Mounting
Hole (1 of 4)
Fence Tilt Lock Lever
Cutterhead
Guard
Handle
(1 of 2)
2.5" Dust Port ON/OFF Switch
w/Disabling Key
Fence Carriage
Lock Lever

-4- Model G0821 (Mfd. Since 03/18)
Controls &
Components
A. Fence: Supports workpiece laterally as it
moves across cutterhead; determines angle
of cut when edge or bevel joining.
B. Cutterhead Guard: Covers cutterhead until
pushed aside by workpiece during operation.
When workpiece leaves cutterhead, guard
springs back to its starting position. DO NOT
operate jointer if guard is not functioning
properly.
C. Infeed Table: Supports workpiece before it
reaches cutterhead. Height of infeed table
determines depth of cut.
D. Infeed Table Adjustment Knob: Adjusts
height of infeed table, which determines
depth of cut.
E. ON/OFF Switch w/Disabling Key: Turns
motor ON when flipped up; turns motor OFF
when pressed down. Removal of yellow key
disables switch so motor cannot start.
F. Outfeed Table: Supports workpiece after it
passes over cutterhead. For optimum cutting
results and safe operation, outfeed table must
be properly adjusted even with highest point
or TDC (Top Dead Center) of cutterhead
inserts.
Refer to Figures 1–3 and the following descrip-
tions to become familiar with the basic controls
and components of this machine. Understanding
these items and how they work will help you
understand the rest of the manual and stay safe
when operating this machine.
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
Component Descriptions
Figure 1. Main table controls.
AB
C
D
E
F

Model G0821 (Mfd. Since 03/18) -5-
H
I
Figure 2. Fence controls.
G. 45° Outward (135°) Fence Stop: Stops
fence at 45° outward (135°) position for bevel
cuts.
Note: Even when fence is resting against
stops, tilt locks must be tightened before
starting machine.
H. Fence Tilt Lock Lever: Secures fence tilt
angle. Fence can be quickly set to 90° (per-
pendicular to both tables), 45° inward, and
45° outward (135°) by setting and using fence
stops on bracket assembly.
I. Fence Carriage Lock Lever: Tightens to
secure fence position; loosens to allow lat-
eral adjustment. ALWAYS firmly tighten lock
before beginning operations.
J. Dust Port: Mounts to included collection
bag, or connects directly to a dust collector
or shop vacuum.
Figure 3. Fence carriage components.
K. 45° Inward Fence Stop: Stops fence at 45°
inward position for bevel cuts.
Note: Even when fence is resting against
stop, tilt locks must be tightened before start-
ing machine.
L. Limit Block: Features indents to quickly
adjusts angle of fence carriage to 90°.
M. Limit Plate: Locks into limit block indents at
preset fence angles to set a starting angle
prior to precision adjustments.
G
J
KL
M

-6- Model G0821 (Mfd. Since 03/18)
The information contained herein is deemed accurate as of 2/11/2018 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 1 OF 2
Model G0821
MACHINE DATA
SHEET
Customer Service #: [phone] · To Order Call: [phone] · Fax #: [phone]
MODEL G0821 6" BENCHTOP JOINTER WITH SPIRAL
CUTTERHEAD
Product Dimensions:
Weight................................................................................................................................................................ 50 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 36 x 19 x 12-1/2 in.
Footprint (Length x Width)..................................................................................................................... 19-1/2 x 11 in.
Shipping Dimensions:
Type..................................................................................................................................................... Cardboard Box
Content........................................................................................................................................................... Machine
Weight................................................................................................................................................................ 56 lbs.
Length x Width x Height....................................................................................................................... 38 x 16 x 13 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 120V, Single-Phase, 60 Hz
Full-Load Current Rating........................................................................................................................................ 12A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 6 ft.
Power Cord Gauge......................................................................................................................................... 16 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type................................................................................................................................................ 5-15
Switch Type.................................................................................................. Paddle Safety Switch w/Removable Key
Motors:
Main
Horsepower............................................................................................................................................. 1.5 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 12A
Speed............................................................................................................................................. 20,000 RPM
Type..................................................................................................................................................... Universal
Power Transfer .................................................................................................................................. Belt Drive
Bearings..................................................................................................... Shielded & Permanently Lubricated
Main Specifications:
Main Specifications
Jointer Size.................................................................................................................................................. 6 in.
Bevel Jointing............................................................................................................................. 0 – 45 deg. L/R
Maximum Width of Cut................................................................................................................................ 6 in.
Maximum Depth of Cut............................................................................................................................. 1/8 in.
Minimum Workpiece Length........................................................................................................................ 8 in.
Minimum Workpiece Thickness................................................................................................................ 1/2 in.
Number of Cuts Per Minute..................................................................................................................... 24,000
Machine Data Sheet

Model G0821 (Mfd. Since 03/18) -7-
The information contained herein is deemed accurate as of 2/11/2018 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. PAGE 2 OF 2
Model G0821
Fence Information
Fence Length....................................................................................................................................... 22-1/2 in.
Fence Width.......................................................................................................................................... 13/16 in.
Fence Height....................................................................................................................................... 4-5/16 in.
Fence Stops............................................................................................................................. 45, 90, 135 deg.
Cutterhead Information
Cutterhead Type........................................................................................................................................ Spiral
Cutterhead Diameter............................................................................................................................. 1-7/8 in.
Number of Cutter Spirals.................................................................................................................................. 3
Number of Indexable Cutters.......................................................................................................................... 18
Cutterhead Speed............................................................................................................................. 8000 RPM
Cutter Insert Information
Cutter Insert Type.................................................................................................................. Indexable Carbide
Cutter Insert Length................................................................................................................................. 15 mm
Cutter Insert Width................................................................................................................................... 15 mm
Cutter Insert Thickness........................................................................................................................... 2.5 mm
Table Information
Table Length........................................................................................................................................ 30-3/8 in.
Table Width........................................................................................................................................... 6-1/4 in.
Table Thickness........................................................................................................................................... 1 in.
Floor to Table Height............................................................................................................................. 8-1/4 in.
Table Adjustment Type.............................................................................................................................. Knob
Table Movement Type.............................................................................................................................. Swing
Construction
Body Assembly...................................................................................................................... Pre-Formed Steel
Fence Assembly.................................................................................................................. Extruded Aluminum
Guard.................................................................................................................................................. Aluminum
Table................................................................................................................................................... Aluminum
Paint Type/Finish....................................................................................................................... Powder Coated
Other Information
Number of Dust Ports....................................................................................................................................... 1
Dust Port Size........................................................................................................................................ 2-1/2 in.
Other Specifications:
Country of Origin ................................................................................................................................................ China
Warranty ........................................................................................................................................................... 1 Year
Approximate Assembly & Setup Time ........................................................................................................ 10 Minutes
Serial Number Location .................................................................................................................................. ID Label
ISO 9001 Factory .................................................................................................................................................. Yes
Certified by a Nationally Recognized Testing Laboratory (NRTL) .......................................................................... No
Features:
45, 90, 135-Degree Stops
2-1/2 in. Dust Port
Included Push Blocks
Spiral Cutterhead
Grab Handles for Portability
Aluminum Top with Non-Stick Coating
Built-in Dust Collection System Works Stand-Alone or with Dust Collector/Shop Vacuum

-8- Model G0821 (Mfd. Since 03/18)
ELECTRICAL EQUIPMENT INJURY RISKS. You
can be shocked, burned, or killed by touching live
electrical components or improperly grounded
machinery. To reduce this risk, only allow qualified
service personnel to do electrical installation or
repair work, and always disconnect power before
accessing or exposing electrical equipment.
DISCONNECT POWER FIRST.
Always discon-
nect machine from power supply BEFORE making
adjustments, changing tooling, or servicing machine.
This prevents an injury risk from unintended startup
or contact with live electrical components.
EYE PROTECTION. Always wear ANSI-approved
safety glasses or a face shield when operating or
observing machinery to reduce the risk of eye
injury or blindness from flying particles. Everyday
eyeglasses are NOT approved safety glasses.
OWNER’S MANUAL. Read and understand this
owner’s manual BEFORE using machine.
TRAINED OPERATORS ONLY. Untrained oper-
ators have a higher risk of being hurt or killed.
Only allow trained/supervised people to use this
machine. When machine is not being used, dis-
connect power, remove switch keys, or lock-out
machine to prevent unauthorized use—especially
around children. Make your workshop kid proof!
DANGEROUS ENVIRONMENTS. Do not use
machinery in areas that are wet, cluttered, or have
poor lighting. Operating machinery in these areas
greatly increases the risk of accidents and injury.
MENTAL ALERTNESS REQUIRED. Full mental
alertness is required for safe operation of machin-
ery. Never operate under the influence of drugs or
alcohol, when tired, or when distracted.
For Your Own Safety, Read Instruction
Manual Before Operating This Machine
The purpose of safety symbols is to attract your attention to possible hazardous conditions.
This manual uses a series of symbols and signal words intended to convey the level of impor-
tance of the safety messages. The progression of symbols is described below. Remember that
safety messages by themselves do not eliminate danger and are not a substitute for proper
accident prevention measures. Always use common sense and good judgment.
Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury. It may also be used to alert
against unsafe practices.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
This symbol is used to alert the user to useful information about
proper operation of the machine.
NOTICE
Safety Instructions for Machinery
SECTION 1: SAFETY

Model G0821 (Mfd. Since 03/18) -9-
WEARING PROPER APPAREL. Do not wear
clothing, apparel or jewelry that can become
entangled in moving parts. Always tie back or
cover long hair. Wear non-slip footwear to reduce
risk of slipping and losing control or accidentally
contacting cutting tool or moving parts.
HAZARDOUS DUST. Dust created by machinery
operations may cause cancer, birth defects, or
long-term respiratory damage. Be aware of dust
hazards associated with each workpiece mate-
rial. Always wear a NIOSH-approved respirator to
reduce your risk.
HEARING PROTECTION. Always wear hear-
ing protection when operating or observing loud
machinery. Extended exposure to this noise
without hearing protection can cause permanent
hearing loss.
REMOVE ADJUSTING TOOLS. Tools left on
machinery can become dangerous projectiles
upon startup. Never leave chuck keys, wrenches,
or any other tools on machine. Always verify
removal before starting!
USE CORRECT TOOL FOR THE JOB. Only use
this tool for its intended purpose—do not force
it or an attachment to do a job for which it was
not designed. Never make unapproved modifica-
tions—modifying tool or using it differently than
intended may result in malfunction or mechanical
failure that can lead to personal injury or death!
AWKWARD POSITIONS. Keep proper footing
and balance at all times when operating machine.
Do not overreach! Avoid awkward hand positions
that make workpiece control difficult or increase
the risk of accidental injury.
CHILDREN & BYSTANDERS. Keep children and
bystanders at a safe distance from the work area.
Stop using machine if they become a distraction.
GUARDS & COVERS. Guards and covers reduce
accidental contact with moving parts or flying
debris. Make sure they are properly installed,
undamaged, and working correctly BEFORE
operating machine.
FORCING MACHINERY. Do not force machine.
It will do the job safer and better at the rate for
which it was designed.
NEVER STAND ON MACHINE. Serious injury
may occur if machine is tipped or if the cutting
tool is unintentionally contacted.
STABLE MACHINE. Unexpected movement dur-
ing operation greatly increases risk of injury or
loss of control. Before starting, verify machine is
stable and mobile base (if used) is locked.
USE RECOMMENDED ACCESSORIES. Consult
this owner’s manual or the manufacturer for rec-
ommended accessories. Using improper acces-
sories will increase the risk of serious injury.
UNATTENDED OPERATION. To reduce the
risk of accidental injury, turn machine OFF and
ensure all moving parts completely stop before
walking away. Never leave machine running
while unattended.
MAINTAIN WITH CARE. Follow all maintenance
instructions and lubrication schedules to keep
machine in good working condition. A machine
that is improperly maintained could malfunction,
leading to serious personal injury or death.
DAMAGED PARTS. Regularly inspect machine
for damaged, loose, or mis-adjusted parts—or
any condition that could affect safe operation.
Immediately repair/replace BEFORE operating
machine. For your own safety, DO NOT operate
machine with damaged parts!
MAINTAIN POWER CORDS. When disconnect-
ing cord-connected machines from power, grab
and pull the plug—NOT the cord. Pulling the cord
may damage the wires inside. Do not handle
cord/plug with wet hands. Avoid cord damage by
keeping it away from heated surfaces, high traffic
areas, harsh chemicals, and wet/damp locations.
EXPERIENCING DIFFICULTIES. If at any time
you experience difficulties performing the intend-
ed operation, stop using the machine! Contact our
Technical Support at [phone].

-10- Model G0821 (Mfd. Since 03/18)
Additional Safety for Jointers
KICKBACK. Occurs when workpiece is ejected
from machine at a high rate of speed. Kickback
injuries occur from getting struck by workpiece or
hands being pulled into cutterhead. To reduce the
risk of kickback, only use proper workpieces, safe
feeding techniques, and proper machine setup or
maintenance.
GUARD REMOVAL. Operating jointer without
guards unnecessarily exposes operator to knives/
inserts and other hazardous moving parts. Except
when rabbeting, never operate jointer or allow it to
be connected to power if any guards are removed.
Turn jointer OFF and disconnect power before
clearing any shavings or sawdust from around cut-
terhead. After rabbeting or maintenance is com-
plete, immediately replace all guards and ensure
they are properly installed/adjusted before resum-
ing regular operations.
DULL OR DAMAGED KNIVES/INSERTS. Dull or
damaged knives/inserts increase risk of kickback
and cause poor workpiece finish. Only use sharp,
undamaged knives/inserts.
OUTFEED TABLE ALIGNMENT. Setting outfeed
table too high can cause workpiece to hit table or
get stuck while feeding. Setting outfeed table too
low may cause workpiece to rock or shift while
feeding. Both of these results will increase risk
of kickback. Always keep outfeed table even with
knives/inserts at highest point during rotation.
INSPECTING STOCK. Impact injuries or kick-
back may result from using improper workpieces.
Thoroughly inspect and prepare workpiece before
cutting. Verify workpiece is free of nails, staples,
loose knots or other foreign material. Warped
workpieces must be surface planed first with
cupped side facing down.
MAXIMUM CUTTING DEPTH. To reduce risk of
kickback, never cut deeper than 1⁄8" per pass.
GRAIN DIRECTION. Jointing against the grain
or end grain can increase risk of kickback. It also
requires more cutting force, which produces chat-
ter or excessive chip out. Always joint or surface
plane WITH the grain.
CUTTING LIMITATIONS. Cutting workpieces that
do not meet minimum dimension requirements can
result in kickback or accidental contact with cutter-
head. Never perform jointing, planing, or rabbeting
cuts on pieces smaller than 8" long, 3⁄4" wide, or
1⁄4" thick.
PUSH BLOCKS. Push blocks reduce risk of acci-
dental cutterhead contact with hands. Always use
push blocks when planing materials less than 3"
high or wide. Never pass your hands directly over
cutterhead without a push block.
WORKPIECE SUPPORT. Poor workpiece sup-
port or loss of workpiece control while feeding will
increase risk of kickback or accidental contact
with cutterhead. Support workpiece with fence
continuously during operation. Support long stock
with auxiliary tables if necessary.
FEED WORKPIECE PROPERLY. Kickback or
accidental cutterhead contact may result if work-
piece is fed into cutterhead the wrong way. Allow
cutterhead to reach full speed before feeding.
Never start jointer with workpiece touching cutter-
head. Always feed workpiece from infeed side to
outfeed side without stopping until cut is complete.
Never move workpiece backwards while feeding.
SECURE KNIVES/INSERTS. Loose knives or
improperly set inserts can be thrown from cutter-
head with dangerous force. Always verify knives/
inserts are secure and properly adjusted before
operation. Straight knives should never project
more than 1⁄8" (0.125") from cutterhead body.
Serious cuts, amputation, entanglement, or death can occur from contact with rotating cutterhead
or other moving components! Flying chips from cutting operations can cause blindness or eye
injuries. Workpieces or inserts/knives thrown by cutterhead (kickback) can strike nearby operator
or bystanders with deadly force. To reduce the risk of serious personal injury from these hazards,
operator and bystanders MUST completely heed the hazards and warnings below.

Model G0821 (Mfd. Since 03/18) -11-
SECTION 2: POWER SUPPLY
Availability
Before installing the machine, consider the avail-
ability and proximity of the required power supply
circuit. If an existing circuit does not meet the
requirements for this machine, a new circuit must
be installed. To minimize the risk of electrocution,
fire, or equipment damage, installation work and
electrical wiring must be done by an electrician or
qualified service personnel in accordance with all
applicable codes and standards.
Electrocution, fire, shock,
or equipment damage
may occur if machine is
not properly grounded
and connected to power
supply.
Full-Load Current Rating
The full-load current rating is the amperage a
machine draws at 100% of the rated output power.
On machines with multiple motors, this is the
amperage drawn by the largest motor or sum of all
motors and electrical devices that might operate
at one time during normal operations.
Full-Load Current Rating at 110V...... 12 Amps
The full-load current is not the maximum amount
of amps that the machine will draw. If the machine
is overloaded, it will draw additional amps beyond
the full-load rating.
If the machine is overloaded for a sufficient length
of time, damage, overheating, or fire may result—
especially if connected to an undersized circuit.
To reduce the risk of these hazards, avoid over-
loading the machine during operation and make
sure it is connected to a power supply circuit that
meets the specified circuit requirements.
For your own safety and protection of
property, consult an electrician if you are
unsure about wiring practices or electrical
codes in your area.
Note: Circuit requirements in this manual apply to
a dedicated circuit—where only one machine will
be running on the circuit at a time. If machine will
be connected to a shared circuit where multiple
machines may be running at the same time, con-
sult an electrician or qualified service personnel to
ensure circuit is properly sized for safe operation.
A power supply circuit includes all electrical
equipment between the breaker box or fuse panel
in the building and the machine. The power sup-
ply circuit used for this machine must be sized to
safely handle the full-load current drawn from the
machine for an extended period of time. (If this
machine is connected to a circuit protected by
fuses, use a time delay fuse marked D.)
110V Circuit Requirements
This machine is prewired to operate on a power
supply circuit that has a verified ground and meets
the following requirements:
Nominal Voltage .................... 110V, 115V, 120V
Cycle ..........................................................60 Hz
Phase ........................................... Single-Phase
Power Supply Circuit ......................... 15 Amps
Serious injury could occur if you connect
machine to power before completing setup
process. DO NOT connect to power until
instructed later in this manual.

-12- Model G0821 (Mfd. Since 03/18)
Improper connection of the equipment-grounding
wire can result in a risk of electric shock. The
wire with green insulation (with or without yellow
stripes) is the equipment-grounding wire. If repair
or replacement of the power cord or plug is nec-
essary, do not connect the equipment-grounding
wire to a live (current carrying) terminal.
Check with a qualified electrician or service per-
sonnel if you do not understand these grounding
requirements, or if you are in doubt about whether
the tool is properly grounded. If you ever notice
that a cord or plug is damaged or worn, discon-
nect it from power, and immediately replace it with
a new one.
Extension Cords
We do not recommend using an extension cord
with this machine.
If you must use an extension
cord, only use it if absolutely necessary and only
on a temporary basis.
Extension cords cause voltage drop, which can
damage electrical components and shorten motor
life. Voltage drop increases as the extension cord
size gets longer and the gauge size gets smaller
(higher gauge numbers indicate smaller sizes).
Any extension cord used with this machine must
be in good condition and contain a ground wire
and matching plug/receptacle. Additionally, it must
meet the following size requirements:
Serious injury could occur if you connect
machine to power before completing setup
process. DO NOT connect to power until
instructed later in this manual.
Minimum Gauge Size ...........................14 AWG
Maximum Length (Shorter is Better).......50 ft.
Figure 4. Typical 5-15 plug and receptacle.
Grounding Prong
Neutral Hot
5-15 PLUG
GROUNDED
5-15 RECEPTACLE
SHOCK HAZARD!
Two-prong outlets do not meet the grounding
requirements for this machine. Do not modify
or use an adapter on the plug provided—if
it will not fit the outlet, have a qualified
electrician install the proper outlet with a
verified ground.
Grounding Requirements
This machine MUST be grounded. In the event
of certain malfunctions or breakdowns, grounding
reduces the risk of electric shock by providing a
path of least resistance for electric current.
This machine is equipped with a power cord that
has an equipment-grounding wire and a grounding
plug. Only insert plug into a matching receptacle
(outlet) that is properly installed and grounded in
accordance with all local codes and ordinances.
DO NOT modify the provided plug!

Model G0821 (Mfd. Since 03/18) -13-
SECTION 3: SETUP
The following are needed to complete the setup
process, but are not included with your machine.
Description Qty
• Safety Glasses ........................................... 1
• Cleaner/Degreaser ..................... As Needed
• Disposable Shop Rags ............... As Needed
• Additional People ....................................... 1
• Straightedge 2' ........................................... 1
• Phillips Head Screwdriver #2 ..................... 1
• Hex Wrench 3mm ....................................... 1
• Hex Wrench 4mm ....................................... 1
• Hex Wrench 6mm ....................................... 1
Needed for Setup
This machine was carefully packaged for safe
transport. When unpacking, separate all enclosed
items from packaging materials and inspect them
for shipping damage.
If items are damaged
,
please
call us immediately at [phone].
IMPORTANT:
Save all packaging materials until
you are completely satisfied with the machine and
have resolved any issues between Grizzly or the
shipping agent. You MUST have the original pack-
aging to file a freight claim. It is also extremely
helpful if you need to return your machine later.
Unpacking
SUFFOCATION HAZARD!
Keep children and pets away
from plastic bags or packing
materials shipped with this
machine. Discard immediately.
This machine and its com-
ponents are very heavy.
Get lifting help if needed.
This machine presents
serious injury hazards
to untrained users. Read
through this entire manu-
al to become familiar with
the controls and opera-
tions before starting the
machine!
Wear safety glasses during
the entire setup process!

-14- Model G0821 (Mfd. Since 03/18)
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Jointer Inventory (Figures 5–6) Qty
A. Jointer Bed Assembly................................. 1
B. Fence.......................................................... 1
C. Dust Collection Bag Clamp ........................ 1
D. Dust Chute ................................................. 1
E. Dust Collection Bag .................................... 1
F. Push Blocks ................................................ 2
G. Handles ...................................................... 2
H. Fence Carriage Lock Lever ........................ 1
I. Fence Tilt Lock Lever ................................. 1
J. Replacement Inserts (5-Pack) .................... 1
K. Carriage Mounting Bracket ......................... 1
L. Carriage Assembly ..................................... 1
M. Fence Pivot Assembly ................................ 1
N. Limit Block .................................................. 1
O. Locking Pin Plate ........................................ 1
P. Hex Wrenches 5, 6mm .........................1 Ea.
Q. T-Handle Torx Wrench T25 ........................ 2
R. Beveled Washers 10 x 3.5mm ................... 2
Fasteners (See Hardware Recognition Chart)
• Cap Screws M6-1 x 20 ............................... 6
• Cap Screws M8-1.25 x 30 .......................... 4
• Flat Head Torx Screws M5-.8 x 10 ........... 10
• Flat Washers 6mm ..................................... 4
• Flat Washers 8mm ..................................... 2
• Lock Washers 6mm.................................... 6
• Lock Washers 8mm.................................... 2
Figure 5. Large components.
A
B
Inventory
Figure 6. Small components.
F
E
GHI
J
C
D
KL
MN
P
Q R
O

Model G0821 (Mfd. Since 03/18) -15-
Hardware Recognition Chart
USE THIS CHART TO MATCH UP
HARDWARE DURING THE INVENTORY
AND ASSEMBLY PROCESS.
5mm
5mm
Flat
Head
Cap
Screw

-16- Model G0821 (Mfd. Since 03/18)
Cleanup Site Considerations
Figure 7. Minimum working clearances.
36"
19"
The unpainted surfaces of your machine are
coated with a heavy-duty rust preventative that
prevents corrosion during shipment and storage.
This rust preventative works extremely well, but it
will take a little time to clean.
Be patient and do a thorough job cleaning your
machine. The time you spend doing this now will
give you a better appreciation for the proper care
of your machine's unpainted surfaces.
There are many ways to remove this rust preven-
tative, but the following steps work well in a wide
variety of situations. Always follow the manufac-
turer’s instructions with any cleaning product you
use and make sure you work in a well-ventilated
area to minimize exposure to toxic fumes.
Before cleaning, gather the following:
• Disposable rags
• Cleaner/degreaser (WD•40 works well)
• Safety glasses & disposable gloves
• Plastic paint scraper (optional)
Basic steps for removing rust preventative:
1.
Put on safety glasses.
2.
Coat the rust preventative with a liberal
amount of cleaner/degreaser, then let it soak
for 5–10 minutes.
3.
Wipe off the surfaces. If your cleaner/degreas-
er is effective, the rust preventative will wipe
off easily. If you have a plastic paint scraper,
scrape off as much as you can first, then wipe
off the rest with the rag.
4.
Repeat Steps 2–3 as necessary until clean,
then coat all unpainted surfaces with a quality
metal protectant to prevent rust.
NOTICE
Avoid chlorine-based solvents, such as
acetone or brake parts cleaner, that may
damage painted surfaces.
Children and visitors may be
seriously injured if unsuper-
vised around this machine.
Lock entrances to the shop
or disable start switch or
power connection to prevent
unsupervised use.
Workbench Load
Refer to the Machine Data Sheet for the weight
and footprint specifications of your machine.
Some workbenches may require additional rein-
forcement to support the weight of the machine
and workpiece materials.
Consider anticipated workpiece sizes and addi-
tional space needed for auxiliary stands, work
tables, or other machinery when establishing a
location for this machine in the shop. Below is
the minimum amount of space needed for the
machine.
Placement Location

Model G0821 (Mfd. Since 03/18) -17-
Bench Mounting
Figure 9. Typical "Direct Mount" setup.
Machine Base
Workbench
Lag Screw
Flat Washer
Another option is a "direct mount" (see example
below) where the machine is secured directly to
the workbench with lag screws and washers.
The base of this machine has mounting holes
that allow it to be fastened to a workbench or
other mounting surface to prevent it from moving
during operation and causing accidental injury or
damage.
The strongest mounting option is a "Through
Mount" (see example below) where holes are
drilled all the way through the workbench—and
hex bolts, washers, and hex nuts are used to
secure the machine in place.
Machine Base
Workbench
Hex
Bolt
Flat Washer
Flat Washer
Lock Washer
Hex Nut
Figure 8. Typical "Through Mount" setup.
Number of Mounting Holes ............................ 4
Dia. of Mounting Hardware Needed .......... 5⁄16"
Assembly
1. Use (2) M8-1.25 x 30 cap screws, (2) 8mm flat
washers, and (2) 8mm lock washers to attach
carriage support to jointer (see Figure 10).
2. Insert locking plate assembly into carriage
support, so locking plate pins are against
bottom edge of carriage support (see Figure
11). Then attach fence carriage lock lever
and 10 x 3.5mm beveled washer to locking
plate assembly, as shown in Figure 12 on
Page 18).
Figure 11. Inserting locking plate assembly.
Locking
Plate Pins
Locking Plate
Assembly
Figure 10. Attaching carriage support to bed
assembly.
Carriage Support
x 2
Cap Screws
The machine must be fully assembled before it
can be operated. Before beginning the assembly
process, refer to
Needed for Setup
and gather
all
listed items. To ensure the assembly process
goes smoothly, first clean any
parts that are cov-
ered or coated in heavy-duty rust preventative (if
applicable).

-18- Model G0821 (Mfd. Since 03/18)
6. Slide fence bracket assembly onto support
dovetails and locking plate assembly, as
shown in Figure 14.
7. Install fence tilt lock by threading handle shaft
into bracket assembly (see Figure 15).
8. Slide fence forward until it contacts cutterhead
guard. Cutterhead guard should completely
cover cutterhead, as shown in Figure 16.
Note: Do not fully tighten yet.
Figure 14. Fence assembly on support dovetails.
Support
Dovetails
Fence Bracket
Assembly
Locking
Plate
Assembly
9. Tighten fence carriage lock lever to lock
fence in place.
Figure 16. Fence positioned over jointer tables.
Cutterhead
Guard
Jointer
Tables
Fence
4. Press down on limit plate tab on carriage
assembly, and insert limit block with notched
side facing upward (see Figure 13).
5. Use (2) M6-1 x 20 cap screws and (2) 6mm
lock washers to attach fence to fence bracket
assembly (see Figure 13).
Figure 13. Attaching fence to fence bracket
assembly.
Bracket
Assembly
Limit Block
Cap Screws
x 2
Limit
Plate
Tab
Figure 15. Installing fence tilt lock.
Fence Tilting
Handle Shaft
Fence Tilt
Lock Lever
Bracket
Assembly
Figure 12. Securing locking plate assembly with
fence carriage lock lever and beveled washer.
Fence Carriage
Lock Lever
Locking Plate
Assembly Beveled
Washer
