G0481 42" Swivel Bending Brake -21-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0481001 CLAMPING LEAF FRAME 12 P0481012 CLAMPING LEAF HANDLE
2 P0481002 CROSSBEAM 13 P0481013 CLAMPING LEAF ADJ BLOCK
3 P0481003 STAND 14 P0481014 RT BENDING LEAF ADJ PLATE
4 P0481004 BENDING LEAF 15 P0481015 LT BENDING LEAF ADJ PLATE
5 P0481005 T-SLOT PLATE 16 P0481016 QUICK STOP
6 P0481006 CLAMPING LEAF FINGER SET 17 P0481017 STOP ROD
6-1 P0481006-1 25MM FINGER 18 P0481018 STOP COLLAR BRACKET
6-2 P0481006-2 30MM FINGER 19 P0481019 STOP COLLAR
6-3 P0481006-3 35MM FINGER 20 P0481020 FENDER WASHER 8MM
6-4 P0481006-4 40MM FINGER 21 P0481021 ECCENTRIC SLEEVE
6-5 P0481006-5 45MM FINGER 22 PSB31M CAP SCREW M8-1.25 X 25
6-6 P0481006-6 50MM FINGER 23 PB87M HEX BOLT M8-1.25 X 15
6-7 P0481006-7 75MM FINGER 24 PB38M HEX BOLT M12-1.75 X 60
6-8 P0481006-8 100MM FINGER 25 P0481025 T-NUT M8-1.25
6-9 P0481006-9 150MM FINGER 26 PSB11M CAP SCREW M8-1.25 X 16
6-10 P0481006-10 250MM FINGER 27 PSB60M CAP SCREW M8-1.25 X 55
7 P0481007 CLAMPING BLOCK SET 28 P0481028 ECCENTRIC SHAFT
7-1 P0481007-1 25MM CLAMPING BLOCK 29 PB27M HEX BOLT M12-1.75 X 30
7-2 P0481007-2 30MM CLAMPING BLOCK 30 P0481030 ROUND PIN 8 X 50
7-3 P0481007-3 35MM CLAMPING BLOCK 31 P0481031 BUSHING
7-4 P0481007-4 40MM CLAMPING BLOCK 32 PB27M HEX BOLT M12-1.75 X 30
7-5 P0481007-5 45MM CLAMPING BLOCK 33 PB49M HEX BOLT M12-1.75 X 20
7-6 P0481007-6 50MM CLAMPING BLOCK 34 PB27M HEX BOLT M12-1.75 X 30
7-7 P0481007-7 75MM CLAMPING BLOCK 35 PB02M HEX BOLT M6-1 X 12
7-8 P0481007-8 100MM CLAMPING BLOCK 36 P0481036 BUSHING
7-9 P0481007-9 150MM CLAMPING BLOCK 37 PW06M FLAT WASHER 12MM
7-10 P0481007-10 250MM CLAMPING BLOCK 38 P0481038 BUSHING
8 P0481008 TRANSMISSION BAR 39 PB87M HEX BOLT M8-1.25 X 15
9 P0481009 BENDING LEAF FINGER SET 40 P0481040 BUSHING
9-1 P0481009-1 25MM BENDING LEAF FINGER 41 PEC03M E-CLIP 10MM
9-2 P0481009-2 30MM BENDING LEAF FINGER 42 P0481042 STOP NUT M10-1.5
9-3 P0481009-3 35MM BENDING LEAF FINGER 43 PN02M HEX NUT M10-1.5
9-4 P0481009-4 40MM BENDING LEAF FINGER 44 PB34M HEX BOLT M10-1.5 X 60
9-5 P0481009-5 45MM BENDING LEAF FINGER 45 PB33M HEX BOLT M12-1.75 X 50
9-6 P0481009-6 50MM BENDING LEAF FINGER 46 PB27M HEX BOLT M12-1.75 X 30
9-7 P0481009-7 75MM BENDING LEAF FINGER 47 PSB31M CAP SCREW M8-1.25 X 25
9-8 P0481009-8 100MM BENDING LEAF FINGER 48 PN09M HEX NUT M12-1.75
9-9 P0481009-9 150MM BENDING LEAF FINGER 49 P0481049 G0481 ID LABEL
9-10 P0481009-10 250MM BENDING LEAF FINGER 50 PLABEL11 SAFETY GLASSES 2" X 3 5/16"
10 P0481010 CLAMP PLATE 51 P0481051 DEBURR LABEL
Parts List
Safety labels warn about machine hazards and ways to prevent injury. The owner of this machine
MUST maintain the original location and readability of the labels on the machine. If any label is
removed or becomes unreadable, REPLACE that label before using the machine again. Contact
Grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
