Grizzly G1049 User manual

6" COMBINATION ROTARY
TABLE
MODEL G1049
INSTRUCTION MANUAL
COPYRIGHT © DECEMBER 2003 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#5824 PRINTED IN TAIWAN

WARNING
Some dust created by power sanding, sawing, grind-
ing, drilling, and other construction activities contains
chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and
other masonry products.
• Arsenic and chromium from chemically treated
lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to fil-
ter out microscopic particles.

SECTION 1: SAFETY
Safety Instructions For Metalworking Machines
5. KEEP CHILDREN AND VISITORS
AWAY. All children and visitors should be
kept at a safe distance from work area.
6. MAKE WORK SHOP CHILD PROOF with
padlocks, master switches, or by removing
starter keys.
7. DO NOT FORCE TOOL. It will do the job
better and safer at the rate for which it was
designed.
8. USE RIGHT TOOL. DO NOT force tool or
attachment to do a job for which it was not
designed.
1. READ AND UNDERSTAND MACHINE
OWNERS MANUAL FOR THIS EQUIP-
MENT.
2. REMOVE ADJUSTING KEYS AND
WRENCHES. Form a habit of checking to
see that keys and adjusting wrenches are
removed from tool before turning on.
3. KEEP WORK AREA CLEAN. Cluttered
areas and benches invite accidents.
4. DO NOT USE IN DANGEROUS ENVI-
RONMENT. DO NOT use power tools in
damp or wet locations, or where any flam-
mable or noxious fumes may exist. Keep
work area well lighted.
For Your Own Safety Read Instruction
Manual Before Operating This Equipment
Indicates an imminently hazardous situation which, if not avoided,
WILL result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
COULD result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
MAY result in minor or moderate injury.
This symbol is used to alert the user to useful information about
proper operation of the equipment or property damage hazards.
The purpose of safety symbols is to attract your attention to possible hazardous conditions. This
manual uses a series of symbols and signal words which are intended to convey the level of
importance of the safety messages. The progression of symbols is described below. Remember
that safety messages by themselves do not eliminate danger and are not a substitute for proper
accident prevention measures.
NOTICE
G1049 6" Combination Rotary Table -1-

-2- G1049 6" Combination Rotary Table
9. USE PROPER EXTENSION CORD. Make
sure your extension cord is in good condi-
tion. Conductor size should be in accor-
dance with the chart below. The amperage
rating should be listed on the motor or tool
nameplate. An undersized cord will cause
a drop in line voltage resulting in loss of
power and overheating. Your extension
cord must also contain a ground wire and
plug pin. Always repair or replace exten-
sion cords if they become damaged.
Minimum Gauge for Extension Cords
10. WEAR PROPER APPAREL. DO NOT
wear loose clothing, gloves, neckties,
rings, bracelets, or other jewelry which
may get caught in moving parts. Non-slip
footwear is recommended. Wear protec-
tive hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES.
Everyday eyeglasses only have impact resis-
tant lenses, they are NOT safety glasses.
12. SECURE WORK. Use properly secured
clamps or vises to hold work while per-
forming the machining operation.
13. DO NOT OVER-REACH. Keep proper
footing and balance at all times.
14. MAINTAIN TOOLS AND MACHINERY
WITH CARE. Keep tools sharp and clean
for best and safest performance. Follow
instructions for lubricating and changing
accessories.
15. USE RECOMMENDED ACCESSORIES.
Consult the owner’s manual for recom-
mended accessories. The use of improper
accessories may cause risk of injury.
LENGTH
AMP RATING 25ft 50ft 100ft
0-6 16 16 16
7-10 16 16 14
11-12 16 16 14
13-16 14 12 12
17-20 12 12 10
21-30 10 10 No
Safety Instructions For Metalworking Tools
16. REDUCE THE RISK OF UNINTENTION-
AL STARTING. On machines with mag-
netic contact starting switches there is a
risk of starting if the machine is bumped or
jarred. Always disconnect from power
source before adjusting or servicing equip-
ment. Make sure switch is in OFF position
before reconnecting.
17. CHECK DAMAGED PARTS. Before fur-
ther use of the tool, a guard or other part
that is damaged should be carefully
checked to determine that it will operate
properly and perform its intended function.
Check for alignment of moving parts, bind-
ing of moving parts, breakage of parts,
mounting, and any other conditions that
may affect its operation. A guard or other
part that is damaged should be properly
repaired or replaced.
18. NEVER LEAVE MACHINE RUNNING
UNATTENDED. TURN POWER OFF. DO
NOT leave machine until it comes to a
complete stop.
19. SOME COOLANTS USED FOR MACHIN-
ING MAY CONTAIN HAZARDOUS CHEMI-
CALS. Read and understand all user infor-
mation on the coolant container and pro-
tect yourself accordingly.
20. NEVER OPERATE A MACHINE WHEN
TIRED, OR UNDER THE INFLUENCE OF
DRUGS OR ALCOHOL. Full mental alert-
ness is required at all times when running
a machine.
No list of safety guidelines can be com-
plete. Every shop environment is different.
Always consider safety first, as it applies to
your individual working conditions. Use
this and other machinery with caution and
respect. Failure to do so could result in
serious personal injury, damage to equip-
ment or poor work results.

G1049 6" Combination Rotary Table -3-
Grizzly Industrial, Inc. is proud to offer the Model
G1049 6" Combination Rotary Table. This rotary
table is part of Grizzly’s growing family of fine
metalworking equipment. When used according
to the guidelines stated in this manual, you can
expect years of trouble-free, enjoyable operation,
and proof of Grizzly’s commitment to customer
satisfaction.
We are also pleased to provide this manual for
the Model G1049 6" Combination Rotary Table. It
was written to guide you through assembly,
review safety considerations, and cover general
operating procedures. It represents our latest
effort to produce the best documentation possi-
ble.
If you have any comments or criticisms that you
feel we should address in our next printing,
please write to us at:
Grizzly Industrial, Inc.
C⁄OTechnical Documentation
P.O. Box 2069
Bellingham, WA 98227
Most important, we stand behind our machines.
We have excellent regional service departments
at your disposal should the need arise.
If you have any service questions or parts
requests, please call or write to us at the location
listed below.
Grizzly Industrial, Inc
1203 Lycoming Mall Circle
Muncy, PA 17756
Phone:[phone]
Fax:[phone]
E-Mail: [email protected]
Web Site: http://www.grizzly.com
The specifications, drawings, and photographs
illustrated in this manual represent the Model
G1049 as supplied when the manual was pre-
pared. However, owing to Grizzly’s policy of con-
tinuous improvement, changes may be made at
any time with no obligation on the part of Grizzly.
For your convenience, we always keep current
Grizzly manuals available on our website at
www.grizzly.com. Any updates to your machine
will be reflected in these manuals as soon as they
are complete.
If you DO NOT read this
entire manual before
operating the machine,
you will greatly increase
your chances of serious
personal injury. To pro-
tect yourself, read and
understand this entire
manual!
Commentary
SECTION 2: GENERAL INFORMATION

-4- G1049 6" Combination Rotary Table
After all the parts have been removed from
the box, you should have:
•6" Combination Rotary Table
•Handwheel Crank Handle
• Handwheel
In the event that any non-proprietary parts are
missing (e.g. nuts or washers), we would be glad
to replace them, or for the sake of expediency,
replacements can be obtained at your local hard-
ware store.
The Model G1049 6" Combination Rotary Table
was carefully packed when it left our warehouse.
If you discover the machine is damaged after you
have signed for delivery, please immediately call
Customer Service at [phone] for advice.
Save the containers and all packing materials for
possible inspection by the carrier or its agent.
Otherwise, filing a freight claim can be difficult.
When you are completely satisfied with the con-
dition of your shipment, you should inventory its
parts.
The purpose of this section is to guide you
through the required steps to get your machine
out of its packaging and into operating condition.
Wear safety glasses dur-
ing the entire setup
process!
This equipment pre-
sents serious injury haz-
ards to untrained users.
Read through this entire
manual to become famil-
iar with the controls and
operations before using
the equipment
Piece Inventory
Unpacking
About this Section
SECTION 3: SET UP
Figure 1. Piece inventory from packing box.

G1049 6" Combination Rotary Table -5-
To install your Model G1049 onto your mill
table:
1. Disconnect power to the milling machine
before installing the rotary table.
2.Position the 1/2" T-bolt slots on the rotary
table over the T-slots in the milling table.
3. Insert the T-slot nuts into the milling table
grooves.
4. Secure the rotary table in place. It is impor-
tant to secure the rotary table to the mill table
in a very strong and solid set up. This will
help with accuracy, efficiency and general
safety.
Note— The T-slots for the rotary table are 2"
between centers. You will need to have the
same distance between centers on your
milling table to be able to use T-nuts and
bolts. If your milling table has different T-slot
centers, you will need to incorporate step
blocks or clamps to secure the rotary table.
Installation
Make sure the rotary table is secured to
the milling table. Check the T-slot clamps
before each cutting operation. If rotary
table is not secured, serious personal
injury and damage to your mill and rotary
table could result.
Before installing the Model G1049 6"
Combination Rotary Table, make sure that your
mill table and spindle are aligned correctly as
described in your milling machine instruction
manual.
NOTICE
Make sure the rotary table handle is free of
any obstruction. Depending on your setup
in the vertical or horizontal positions, the
rotary table may have to be blocked up or
mounted so the handle is hanging over the
edge of the milling table. Once making a
setup, check for any possible obstructions
that may interfere with rotary table handle.

-6- G1049 6" Combination Rotary Table
Aligning the center of the rotary table to the spin-
dle is essential for achieving quality results.
There are many ways to align the Model G1049
to a vertical mill spindle. It is up to the machinist
and his capabilities to decide which approach is
best.
Here are a couple of ways to align the spindle
accurately to the center of the rotary table:
1. Using a test indicator, (see Models G9610,
G9611 & G9612 in the current Grizzly cata-
log) indicate the inside or the outside of the
rotary table. Position the spindle over center
of the rotary table and touch all four sides
(inside or outside) until all sides read “0” on
the indicator (remember to rotate the spindle
and not the rotary table). Using this proce-
dure of indicating, no measuring tools are
needed.
Alignment
Figure 2. Locations for edge finding.
2. Use an edge finder, like the Model H2939, to
locate the center of the rotary table by con-
tacting two outside edges (Figure 2) and
then moving the mill table half of the rotary
table diameter in both directions. Note—
Make sure to account for radius of the edge
finder and use a precision measuring instru-
ment when determining the diameter of the
rotary table.
Wear safety glasses dur-
ing the entire setup
process!

G1049 6" Combination Rotary Table -7-
NOTICE
The following section was designed to give
instructions on the basic operations of this
equipment. However, it is in no way com-
prehensive of all of the equipment applica-
tions. WE STRONGLY RECOMMEND that
you read books, trade magazines, or get for-
mal training to maximize the potential of
your equipment.
Loose hair and clothing
could get caught in
machinery and cause
serious personal injury.
Keep loose clothing
rolled up and long hair
tied up and away from
moving machinery.
Your safety is important! Please follow the
warnings below:
Table Movement
Operation Safety
SECTION 4: OPERATIONS
The rotary table moves by turning the handwheel
which engages a precision worm gear. The worm
gear ratio is 1:90. One complete turn of the hand-
wheel moves the table 4 degrees. The micro col-
lar is graduated in steps of 1 minute and the
vernier scale can be set to indicate to 20 sec-
onds.
Basic Example:
You are making a flange and you need to index
six holes for the bolt pattern:
Crank turns = 90⁄N
N = the desired division number (6).
90/6= 15 full crank turns
1. Turn the handwheel before making the first
hole to take up any play in the worm gears.
2. Make your first hole then turn the crank 15
times. Note—When you are cranking to a
desired number and crank too far, do not just
immediately back up to the number. You
must back up one revolution then dial back to
desired number, Then lock the table in place
to locate the second hole. This procedure
eliminates backlash in the worm gear.
3. Repeat step 2 for the remaining holes.
Damage to your eyes, lungs, and ears could
result from failure to wear safety glasses, a
respirator and hearing protection while
using this equipment. Make sure proper fil-
ter is worn while wearing respirator.
Rotary Table
Maintenance
Keep oiled to prevent rust. Do not use air to blow
off chips. A few drops of oil before each use will
prevent excessive wear. The worm gear is
greased at the factory.

-8- G1049 6" Combination Rotary Table
1. MT#2—Used for quick setups by placing a
dead center into the taper and aligning cen-
ters, picking up hole centers, ect and just
general machining operations.
2. Rotary Table Lock—Used during milling
operations to lock the table solid. This fea-
ture keeps the stresses of the milling opera-
tions off of the wormgear to extend the life of
the rotary table and ensure that accuracy is
not compromised. Simply tighten the handles
to lock the table.
3. Free Wheeling—This is a convience feature
which allows the operator to rotate the table
by hand and not having to turn the crank
handle. just loosen the lock handle (#3) and
rotate the adjustment ring (#6) C.W. By rotat-
ing the adjustment ring, this disengages the
wormgear and allows the table to rotate.
4. Vernier Scale—Allows precise rotary move-
ments. The vernier scale allows graduations
of 20" seconds.
5. Gross Scale—This scale will allow you
keep track of where the rotary table is going
and where its been. The scale reads from 0˚-
360˚ in one degree graduations.
Figure 3. Main view of rotary table features .
3
2
5
4
2
1
Main Features
FEATURES & CONTROLS
