Grizzly G1026 User manual

3 H.P. HEAVY-DUTY SHAPER
MODEL G1026
PARTS LIST
COPYRIGHT © 1991 BY GRIZZLY INDUSTRIAL, INC. REG.# TX 3 175 914
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
REVISED AUGUST, 2001. PRINTED IN TAIWAN
PARTS LIST DISCLAIMER
THIS PARTS LIST AND DRAWINGS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CON-
FIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS
LIST MAY NOT DEPICT YOUR MACHINE EXACTLY. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFERENCES.
PREVIOUS PARTS LIST VERSIONS ARE NOT AVAILABLE ONLINE.

-B- G1026 3 H.P. Shaper

G1026 3 H.P. Shaper -C-
REF PART # DESCRIPTION
029 P1026029 MAIN FENCE HOUSING
030 PSB14 CAP SCREW
3⁄8"-16 x 1"
031A P1026031A FENCE MOUNT LEFT
032 P1026032 SWITCH MOUNT BRACKET
033 PSW01 3 H.P. MAGNETIC SWITCH
035 PSW03 FWD/REV SWITCH
036 P1035034 BRACKET
037 P1035031 SWITCH BOX
038 P1071075 STRAIN RELIEF
039 P1035033 SWITCH BOX COVER
040 PHTEK1 SELF-TAPPING SCREW
041 P1026041 SCALE
042 P1026042 GROMMET
043 P1026043 MOTOR CORD
044 P1026044 POWER CORD
045 PSW01-1 REPLACEMENT SCREW
046 P1026046 LOCK HANDLE
047 G8588 GRIZZLY NAMEPLATE
048 P1026048 ID/WARNING LABEL
049 PB16 HEX BOLT 3⁄8"-16 X 11⁄4"
050 P1026050 ELECTRICITY LABEL
051 P1026051 SAFETY GLASSES LABEL
052 P1026052 READ MANUAL LABEL
053 P1026053 HAND/CUTTER LABEL
054 P1026054 UNPLUG MACHINE LABEL
001 P1026001 STAND BODY
002 P1026002 EXTENSION WING
003 PB18 HEX BOLT 3⁄8"-16 x 11⁄4"
004 PLW04 LOCK WASHER 3⁄8"
005 PS07 PHLP HD SCR 1⁄4"-20 x 3⁄8"
006 P1026006 COVER
007 PB21 HEX BOLT 3⁄8"-16 x 3⁄4"
008 PW02 FLAT WASHER 3⁄8"
009 P1026009 TABLE INSERT
010 P1026010 TABLE INSERT
011 P1026011 TABLE INSERT
012 P1035012 STARTING PIN
013 PFH02 FLAT HD SCREW 10-24 x 1"
014 1035010 BARREL SCREW
015 P1026015 TABLE
016 PFH07 FLAT HD SCREW 5⁄16"-18 x 11⁄2"
018A P1026018A FENCE MOUNT RIGHT
021 PW07 FLAT WASHER 5⁄16"
022 PN02 HEX NUT 5⁄16"-18
023 PSS07 SETSCREW 1⁄4"-20 x 1⁄2"
024 PSB16 CAP SCREW 3⁄8"-16 x 3⁄4"
025 P1026025 HAND KNOB 3⁄8"
026 PSS17 SETSCREW 5⁄16"-18 x 5⁄16"
027A P1026027A FENCE ADJ SCREW
028 P1026028 ADJ SCREW BRACKET
REF PART # DESCRIPTION
We regret to inform you that the wood
facing for the G1026 Shaper fences are
no longer available as a replacement
part. For your convenience we have
included a measured drawing so you may
construct you own. We apologize for any
inconvenience this may cause you.

-D- G1026 3 H.P. Shaper

G1026 3 H.P. Shaper -E-
REF PART # DESCRIPTION
101 P1026101 HANDLE
102 P1026102 HANDWHEEL
103 PSS17 SETSCREW 5⁄16"-18 x 5⁄16"
105 P1026105 SLEEVE
107 PB07 HEX BOLT 5⁄16"-18 x 3⁄4"
108 P1026108 SHAFT MOUNT
111 P1026111 WORM SHAFT
112 P1026112 GIB
113 PN02 HEX NUT 5⁄16"-18
114 PSS14 SETSCREW 5⁄16"-18 x 13⁄8"
115 P1026115 ELEVATION HOUSING
116 PB56 HEX BOLT 1⁄2"-13 x 13⁄4"
117 PW01 FLAT WASHER 1⁄2"
120 P1026120 POINTER
123 P1026123 POINTER MOUNT
126 PB19 HEX BOLT 1⁄4"-20 x 1⁄2"
128 P1026128 LOCK KNOB
130 PLN07 LOCK NUT 5⁄8"-11
133 P1026133 GEAR
REF PART # DESCRIPTION
133A P1026133A THRUST BEARING 51103
135 PK14M KEY 5 x 5 x 18
136 P1026136 ELEVATION LEAD SCREW
139 PRP24M ROLL PIN 5 x 16
140 PB16 HEX BOLT 1⁄2"-13 x 13⁄8"
141 PLW04 LOCK WASHER 3⁄8"
142 PW07 FLAT WASHER 5⁄16"
143 PLW01 LOCK WASHER 5⁄16"
145 PSS23 SETSCREW 5⁄16"-24 x 5⁄8"
146 P1026146 V-BELT M7 x 690
147 P1026147 MOTOR PULLEY
148 PB03 HEX BOLT 5⁄16"-18 x 1"
149 PB56 HEX BOLT 1⁄2"-13 x 13⁄4"
151 P1026151 MOTOR MOUNT PLATE
152 P1026152 3H.P. MOTOR
153 PK15M KEY 5 x 5 x 35
154 PB09 HEX BOLT 5⁄16"-18 x 1⁄2"
155 PW14 FLAT WASHER 5⁄8"
156 PW06 FLAT WASHER 1⁄4"

-F- G1026 3 H.P. Shaper

G1026 3 H.P. Shaper -G-
Bore Diameter Height Replacement Part #
1⁄2'' 1'' 1⁄4'' G2454
1⁄2'' 1'' 3⁄8'' G2455
1⁄2'' 1'' 1⁄2'' G2456
1⁄2'' 1'' 3⁄4'' G2457
3⁄4'' 11⁄4'' 1⁄4'' G2460
3⁄4'' 11⁄4'' 3⁄8'' G2461
3⁄4'' 11⁄4'' 1⁄2'' G2462
3⁄4'' 11⁄4'' 3⁄4'' G2463
1'' 11⁄2'' 1⁄4'' G2466
1'' 11⁄2'' 3⁄8'' G2467
1'' 11⁄2'' 1⁄2'' G2468
1'' 11⁄2'' 3⁄4'' G2469
1'' 11⁄2'' 1'' G2470
11⁄4'' 13⁄4'' 1⁄4'' G2472
11⁄4'' 13⁄4'' 3⁄8'' G2473
11⁄4'' 13⁄4'' 1⁄2'' G2474
11⁄4'' 13⁄4'' 3⁄4'' G2475
11⁄4'' 13⁄4'' 1'' G2476
215 P1026215 3⁄4" SPINDLE
216 P1026216 1" SPINDLE
217 P1026217 DRAW BAR
218 P1026218 DRAW NUT
219 P1035201C 1⁄2" SPINDLE NUT
220 P1026220D 3⁄4" SPINDLE NUT
221 P1026221 1" SPINDLE NUT
222 P1026222 PIN
223 P1026223 1⁄2" SPINDLE WASHER
224A P1026224A 3⁄4" SPINDLE WASHER
225A P1026225A 1" SPINDLE WASHER
226 P1026219 SPINDLE WRENCH SET
201 PS01 PHILLIPS®HD SCR 10-24 x 1⁄2"
202 PR12M SNAP RING 35MM
203 P1026203 FLANGE
204 P1026204 SPINDLE CARTRIDGE
205 PK20M KEY 5 x 5 x 15
206 P6205 BEARING
207 PR11M SNAP RING 25MM
209 P1026209 HOUSING
210 PR14M SNAP RING 70MM
211 P1026211 PULLEY
212 P1035218 TOOTHED WASHER
213 P1025219 SPANNER NUT
214 P1026214 1⁄2" SPINDLE
REF PART # DESCRIPTIONREF PART # DESCRIPTION
SPACERS

-H- G1026 3 H.P. Shaper
309 P1026309 SHAFT
310 P1026310 LOCK HANDLE
313 PN02 HEX NUT 5⁄16"-18
314 P1026314 GUARD EXTENSION
315 P1026315 GUARD
316 PFH14 FLT HD SCREW 5⁄16"-18 x 3⁄4"
301 PSS02 SETSCREW 5⁄16"-18 x 3⁄8"
302 P1026302 SHAFT MOUNT
303 PW02 FLAT WASHER 3⁄8"
304 PB21 HEX BOLT 3⁄8"-16 x 3⁄4"
305 P1026305 EXTENSION BRACKET
306 P1026306 LOCK KNOB
REF PART # DESCRIPTION REF PART # DESCRIPTION

G1026 3 H.P. Shaper -I-
501 P1026501 HOLD-DOWN BAR
502 P1026502 HOLD-DOWN
503 P1026503 BRACKET HOLD-DOWN
504 PSS02 SETSCREW 5⁄16"-18 x 3⁄8"
REF PART # DESCRIPTION

-J- G1026 3 H.P. Shaper
601 P1023401 KNOB
602 P1023402 FLAT WASHER 5⁄16"
603 P1023403 MITER GAUGE BODY
604 P1023406 MITER BAR
607 P1023407 HEX NUT
608 P1023408 SETSCREW
609 P1023409 SETSCREW
610 P1023410 STOP
611 P1023411 POINTER
612 P1023212 SCALE
613 P1023413 STUD
REF# PART# DESCRIPTION
REF# PART# DESCRIPTION
