The Best Got Better.
EclipseTM
Ergonomic
Braising Pan

ECLIPSETM ERGONOMIC
TILTING BRAISING PAN
Energy efficient, easy to use,
with the highest performance
Performance plus
Our performance is better than ever. Get the fastest
preheat and cook times in the business. Heats to 350ºF
in just 4 minutes – much faster than a conventional
oven. With fast, even cooking, you can cut preparation
times and increase batch consistency, while saving on
energy costs. No hot or cold spots either. Heat transfers
evenly over the entire cooking surface.
Ergonomic by design
The Eclipse ergonomic tilting braising pan has a
narrow-width footprint that saves on expensive
hood space. With only one control box, all controls
are centrally located and at an angle that ensures
easy viewing and access. Our streamlined, rounded
leg stands look great and are easy to clean, meeting
all NSF requirements. We’ve even made faucets
easier to reach by moving them closer to the front –
and you still have the option of a right-, left-handed,
or rear-mounted faucet. Plus, we’ve kept our famous
easy-to-clean, rounded interiors – no corners to clean.
We’ve eclipsed
even ourselves
Yes, we’ve taken a great braising pan and
made it even better. The new Eclipse™ ergonomic
tilting braising pan surpasses the competition
(and even our own pan) for performance,
water resistance, and ergonomics – all with a
streamlined new design.
The Eclipse is a multi-tasking, hard-working,
high-performance braising pan – so versatile it
can braise, grill, hold, steam, or cook just about
anything you can dish up.
Whether you choose the 30- or 40-gallon model
– in gas or electric, with manual tilt or power
tilt – you’ll get a fast, high-capacity braising pan
that will get the job done.
Easy-to-reach faucet for conveniently
adding water to the pan

Even more water resistance
The Eclipse is completely water-resistant, making it
less susceptible to water splashback or spray. The
control box is also water-resistant, protecting the
electric controls – and your investment. We’ve protect-
ed the ignition system and pilot light on gas mod-
els with a shield or baffle. Our thermostat is more
water-resistant. And we’ve even covered the worm
and gear mechanism to protect against water. It all
adds up to the quality you
need to run a clean,
busy kitchen.
Pouring made easier
The Eclipse center tilt design maximizes floor and aisle
space, and optimizes the pour path for customer use,
even with large-capacity batches of food product. It
uses less aisle and floor space, making it easy to navi-
gate the terrain of your kitchen. Pour out pan contents
easily with no mess or waste – every time. The pouring
lip is designed to deliver maximum effectiveness when
pouring food product, especially liquids.
3” radius seamless interiors
for durability and cleanability
Water-resistant controls
BPM-40G, 40 gallon, manual tilt,
standard with bullet feet

THE DIFFERENCE
IS IN THE DETAILS
Both 30- and 40-gallon models
Eclipse braising pans are offered in 30- and 40-gallon models that
are perfect for new installations or replacement business. The
30-gallon model has approximately the same width dimensions
as our previous 23-gallon model, and the 40-gallon model has
approximately the same width dimensions as our previous 30-
gallon model. Depth for both 30- and 40-gallon models has
increased slightly, but has proved ergonomically sound.
30-gallon model
40-gallon model
Precision controls
Precision thermostat regulates temperature for accurate
cooking every time. Dependable electronic ignition. Patented
burner system with high efficiency means lower energy costs. No
warping maintains an even pan surface, with no burning or
sticking for shallow cooking applications.
Smooth tilting action
Our smooth-action, quick-tilting body will never jerk or halt
when tilting the pan. Available in both manual tilt and electric
tilt — electric tilt has an easy-to-access manual override.
Manual tilt has a smooth-action, self-locking hand crank that
provides precise control when pouring. Ten-inch-high pan sides
and cover minimize grease and splatter — especially important
when pouring product during tilting.
Dial thermostat control for electric units
Previous 30-gallon
Eclipse 30-gallon
Width Height Depth
49" 38" 36.5"
39" 38" 40"
Previous 40-gallon
Eclipse 40-gallon
Width Height Depth
59" 38" 36.5"
48" 38" 40"
30-gallon model
40-gallon model
Previous 30-gallon
Eclipse 30-gallon
Width Height Depth
49" 38" 36.5"
39" 38" 40"
Previous 40-gallon
Eclipse 40-gallon
Width Height Depth
59" 38" 36.5"
48" 38" 40"
30-gallon model
40-gallon model
Dial thermostat control for gas units

Hand crank wheel for
manual tilt units
BPP-30E, 30 gallon, electric tilt,
standard with bullet feet

BPM-40G, 40 gallon, manual tilt,
shown with optional casters
Counterbalance cover design
The Eclipse tilting braising pan’s improved,
counterbalanced cover design ensures ease of assembly
and easier cleaning that meets all NSF standards. The
fully adjustable cover will stay put wherever you set it
for ease of operation. The new counterbalanced cover
allows you to control steam venting more easily during
cooking. The adjustable steam vent controls condensate
during cooking. The heavy-duty cover lets you oven cook
all meats, poultry, and seafood. And the counterbalanced
cover has fewer working parts, so you’re assured of
increased durability and higher performance.
Eclipse one-year warranty
A risk-free purchase is ensured by the Groen one-year
warranty on every Eclipse model.
Pan cooking volume to nominal
Eclipse has increased pan cooking volume to nominal
for increased holding capability, while preserving safety
standards. Cook more food product faster in fewer
batches with preserved food quality, texture, and flavor.
Increased flexibility
New bullet feet are field-retrofittable and interchangeable
with our new flanged feet or casters. Four bullet feet
are standard, while our casters and flanged feet are
offered as accessories.
Groen durability
No one beats our build quality. We’ve strengthened
our hinges on the cover for increased durability
and longer life. Easy-to-clean, three-inch rounded
interiors are just part of our streamlined pan design.
Our stainless steel interiors with easy-to-clean sanitary
finishes make cleanup easy and fast.

SPECIFICATIONS
Model Power Input Dimensions Approximate
(per cavity) Width x Depth x Height* Weight
30 Gallon Electric 11.5 KW 39” x 40” x 38” 425 LBS
BPM-30E Manual Tilt or BPP-30E Power Tilt 991mm x 1016mm x 965mm (193 Kg)
30 Gallon Gas 104,000 BTU 39” x 40” x 38” 440 LBS
BPM-30G Manual Tilt or BPP-30G Power Tilt 991mm x 1016mm x 965mm (200 Kg)
40 Gallon Electric 15 KW 48” x 40” x 38” 510 LBS
BPM-40E Manual Tilt or BPP-40E Power Tilt 1219mm x 1016mm x 965mm (232 Kg)
40 Gallon Gas 144,000 BTU 48” x 40” x 38” 540 LBS
BPM-40G Manual Tilt or BPP-40G Power Tilt 1219mm x 1016mm x 965mm (246 Kg)
*Add 3-1/2” in height for stands with casters
MENU APPLICATIONS
& COOK TIMES
*Cook times are only approximate and don’t include preparation or warm-up time.
Actual cook times will depend on the condition and size of ingredients, kitchen temperature and other variables.
MENU ITEMS TOTAL QUANTITY COOK TIME* (MINUTES)
SCRAMBLED EGGS 100 Servings 5
BACON 90 Servings 10 - 12
HAMBURGER 60 Servings (4 Ounce) 5
STEAK SANDWICH 26 Servings (7 Ounce) 5
MEAT LOAF 16 Loaves 90
CHICKEN 150 Pounds 40
FISH FILLETS 50 - 100 Fillets 10 - 14
CHILI 400 Servings 20
CUT & PEELED POTATOES 10 Pounds 25
GRAVY 23 Gallons 15
CHOCOLATE MOUSSE 200 - 300 Portions 15

07/04-2 (5m)
1055 Mendell Davis Drive • Jackson MS 39272 • 888-994-7636 • 601-372-3903 • Fax [phone] • difoodservice.com
Eclipse™ is a trademark of Groen
