US2000 Lithium Battery Configuration with SPH Hybrid inverter
Guide
1,System wiring：
A, Battery terminal:
Figure1 .parallel connection of two batteries

Marketing Department
F：+ 86 755 2951 5888 [phone]
E ：[e-mail] W：www.growatt.com W：www.ginverter.com
B, SPH hybrid inverter terminal.
Figure2.SPH connect terminal position
2,How to install the battery in the IP55 Battery Box：
A, Use a Phillips screwdriver to loosen the six Phillips countersunk screws on the left and right
sides of the case (as shown in FIG. 3). Move the front panel up and away from the front panel (as
shown in figure 4) to avoid the l-shaped drop bracket on the upper part of the case from hanging
(as shown in figure 5).
B. Place the lithium iron phosphate battery as shown in the figure (note the placement direction of
the battery: the battery power terminal is on the right side of the chassis), tighten it with 4 M6*12
hexagonal combination bolts (as shown in figure6), and fix the other battery in this way (as shown
in figure7.

Marketing Department
F：+ 86 755 2951 5888 [phone]
E ：[e-mail] W：www.growatt.com W：www.ginverter.com
Figure3. remove screws on left and right sides Figure4.push up the front panel
Figure5.l‐shaped bracket Figure6.battery installation and placement

Marketing Department
F：+ 86 755 2951 5888 [phone]
E ：[e-mail] W：www.growatt.com W：www.ginverter.com
Figure 7.position of two groups of batteries after installation.
Before the front panel of the box is locked, the battery must be in the starting state. It is
recommended to turn on all the battery power buttons first, and then press SW button when
the parallel box of the last box is locked to avoid shutting down the box after sealing it.
1. Hang the front panel on the two l-shaped brackets at the upper end of the box (as shown in
Figure8). After hanging the front panel, push it down to avoid improper installation of the front
panel (as shown in Figure 9).
2.Press and hold the front panel of the box body by hand to compress the sealing bar to
ensure the matching of the hole position of the cross screws. Use the cross screwdriver to
tighten the 6 M4 countersunk screws (as shown in Figure 10).
3. Lock all M4 countersunk head screws once to complete installation
Figure 8 Figure 9

Marketing Department
F：+ 86 755 2951 5888 [phone]
E ：[e-mail] W：www.growatt.com W：www.ginverter.com
Figure 10
