Growatt SPF 5000T DVM-MPV User manual

Off Grid Solar Inverter
Split Phase 4KW-12KW
Version: 1.1
User Manual

Table Of Contents
Information on this Manual ..........................................................................................................................................................1
Validity ...........................................................................................................................................................................................1
Scope..............................................................................................................................................................................................1
Target Group.................................................................................................................................................................................1
Safety Instructions .......................................................................................................................................................................1
Introduction........................................................................................................................................................................................2
Features .........................................................................................................................................................................................2
Product Overview .........................................................................................................................................................................3
Installation..........................................................................................................................................................................................4
Unpacking and Inspection...........................................................................................................................................................4
Preparation ....................................................................................................................................................................................4
Mounting the Unit.........................................................................................................................................................................4
Battery Connection.......................................................................................................................................................................5
AC Input/Output Connection ......................................................................................................................................................8
PV Connection.............................................................................................................................................................................10
Communication Connection ......................................................................................................................................................11
Dry Contact Signal......................................................................................................................................................................11
Electrical Performance ...............................................................................................................................................................12
Operation ...........................................................................................................................................................................................15
Power ON/OFF ............................................................................................................................................................................15
Operation and Display Panel.....................................................................................................................................................15
LCD Display Icons.......................................................................................................................................................................16
LCD Setting..................................................................................................................................................................................18
Display Information....................................................................................................................................................................23
Operating Mode Description .....................................................................................................................................................26
Fault Reference Code.................................................................................................................................................................27
Warning Indicator.......................................................................................................................................................................27
Trouble Shooting.............................................................................................................................................................................28
Specifications ...................................................................................................................................................................................29

1
Information on this Manual
Validity
This manual is valid for the following devices:
SPF 4000T DVM
SPF 5000T DVM
SPF 6000T DVM
SPF 8000T DVM
SPF 10000T DVM
SPF 12000T DVM
SPF 4000T DVM-MPV
SPF 5000T DVM-MPV
SPF 6000T DVM-MPV
SPF 8000T DVM-MPV
SPF 10000T DVM-MPV
SPF 12000T DVM-MPV
Scope
This manual describes the assembly, installation, operation and troubleshooting of this unit. Please read
this manual carefully before installations and operations.
Target Group
This document is intended for qualified persons and end users. Tasks that do not require any particular
qualification canalso be performed by end users. Qualified persons must have the following skills:
Knowledge of how an inverter works and is operated
Training in how to deal with the dangers and risks associated with installing and using electrical
devices and installations
Training in the installation and commissioning of electrical devices and installations
Knowledge of the applicable standards and directives
Knowledge of and compliance with this document and all safety information
Safety Instructions
WARNING: This chapter contains important safety and operating instructions.
Read and keep this manual for future reference.
1. CAUTION –Only qualified personnel can install this device with battery.
2. Before using the unit, read all instructions and caution marks on the unit, understand the batteries and all
appropriate sections of this manual.
3. CAUTION --To reduce risk of injury, charge only deep-cycle lead acid type rechargeable batteries. Other types
of batteries may burst, causing personal injury and damage.
4. NEVER cause AC output and DC input short circuit. Don‟t connect to the mains when DC input short circuits.
5. NEVER charge a frozen battery.
6. Do not disassemble the unit. Take it to a qualified service center when service or repair is required. Incorrect
re-assembly may result in a risk of electric shock or fire.
7. To reduce risk of electric shock, disconnect all wiring before attempting any maintenance or cleaning. Turning off
the unit will not reduce this risk.
8. Be very cautious when working with metal tools on or around batteries. A potential risk, such as dropping a tool
to spark or short circuit batteries or other electrical parts, could cause an explosion.
9. For optimum operation of this off grid solar inverter, please follow required spec to select appropriate cable size.
It‟s very important to correctly operate this off grid solar inverter.
10. Please strictly follow installation procedure when you want to disconnect AC or DC terminals. Please refer to
INSTALLATION section of this manual for the details.
11. GROUNDING INSTRUCTIONS –This off grid solar inverter should be connected to a permanent grounded wiring
system. Be sure to comply with local requirements and regulation to install this inverter.
12. Warning!! Only qualified service persons are able to service this device. If errors still persist after following
troubleshooting table, please contact local dealer or service center for maintenance.

2
Introduction
Hybrid Power System
This is a multifunctional split-phase output off grid solar inverter, integrated with a MPPT solar charge
controller, a low frequency pure sine wave inverter and a UPS function module in one machine, which is
perfect for off grid backup power and self-consumption applications.
The whole system also need other devices to achieve complete running such as PV modules, generator, or
utility grid. Please consult with your system integrator for other possible system architectures depending on
your requirements.The WiFi / GPRS module is a plug-and-play monitoring device to be installed on the
inverter. With this device, users can monitor the status of the PV system from the mobile phone or from the
website anytime anywhere.
Features
Rated power 4KW to 12KW
MPPT solar charge controller
Low frequency inverter with large transformer
Pure sine wave AC output
Overload, short circuit and deep discharge protection
Configurable AC/ solar input priority via LCD setting
Compatible to mains voltage or generator power
WiFi/ GPRS remote monitoring

3
Product Overview
(4KW/5KW/6KW) (8KW/10KW/12KW)
1. ON/OFF Power Switch
2. LCD Display
3. Status Indicator
4. Charging Indicator
5. Fault Indicator
6. Function Buttons
7. Negative Battery Terminal
8. Positive Battery Terminal
9. DC Fan
10. Dry Contact For AGS
11. USB Port
12. Wi-Fi/GPRS Device Port
13. BMS Port
14. RS485/Remote LCD Port（Optional）
15. AC Input Breaker
16. AC Output Breaker
17. AC Input Terminal
18. AC Output Terminal
19. PV Input Terminal
20. Grounding Terminal

4
Installation
Unpacking and Inspection
Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You should
have received the following items in the package:
The unit x1
User manual x 1
Communication cable x 1
Preparation
Before connecting all wiring, please take off bottom cover by removing eight screws as shown below.
Mounting the Unit
Consider the following points before selecting where to install:
Do not mount the inverter on flammable construction materials.
Mount on a solid surface
Install this inverter at eye level in order to allow the LCD display to
be read at all times.
The ambient temperature should be between 0°C and 50°C to ensure
optimal operation.
The recommended installation position is to be adhered to the wall
vertically.
Be sure to keep other objects and surfaces as shown in the right
diagram to guarantee sufficient heat dissipation and to have enough
space for removing wires.
SUITABLE FOR MOUNTING ONCONCRETE OR
OTHER NON-COMBUSTIBLE SURFACE ONL
4~6KW 8~12KW
Install the unit by screwing the six setscrews.

5
Battery Connection
CAUTION: For safety operation and regulation compliance, it‟s requested to install a separate DC over-current
protector or disconnect device between battery and inverter. It may not be requested to have a disconnect
device in some applications, however, it‟s still requested to have over-current protection installed. Please refer
to typical amperage in below table as required fuse or breaker size.
WARNING! All wiring must be performed by a qualified person.
WARNING! It's very important for system safety and efficient operation to use appropriate cable for battery
connection. To reduce risk of injury, please use the proper recommended cable and terminal size as below.
Recommended battery cable and terminal size:
Model
Battery Voltage
Wire Gage/min
0~1.0m
Wire Gage/min
1.0~5.0m
4kw
48V
30 mm²
40 mm²
5kw
48V
40 mm²
50 mm²
6kw
48V
50 mm²
60 mm²
8kw
48V
60 mm²
75 mm²
10kw
48V
75 mm²
90 mm²
12kw
48V
90 mm²
120 mm²
Please follow below steps to implement battery connection:
1. Assemble battery ring terminal based on recommended battery cable and terminalsize.
2. Connect all battery packs as units requires. It‟s suggested to connect at least 200Ah capacity battery for
4KW~6KW model and at least 400Ah capacity battery for 8KW~12KW model.
3. Insert the ring terminal of battery cable flatly into battery connector of inverter and make sure the bolts are
tightened with torque of 2-3 Nm. Make sure polarity at both the battery and the inverter/charge is correctly
connected and ring terminals are tightly screwed to the battery terminals.
WARNING: Shock Hazard
Installation must be performed with care due to high battery voltage in series.
CAUTION!! Do not place anything between the flat part of the inverter terminal and the ring
terminal. Otherwise, overheating may occur.
CAUTION!! Do not apply anti-oxidant substance on the terminals before terminals are connected
tightly.
CAUTION!! Before making the final DC connection or closing DC breaker/disconnector, be sure
positive (+) must be connected to positive (+) and negative (-) must be connected tonegative(-).

6
Lithium battery connection
If need to communicate with lithium battery BMS, the inverter protocol should have matched the BMS first. There‟re
two connectors on the lithium battery, RJ45 port of BMS and power cable. Please follow below steps to implement
lithium battery connection:
1. Assemble battery ring terminal based on recommended battery cable and terminal size (recommended standards
are in the previous page) .
2. Insert the ring terminal of battery cable flatly into battery connector of inverter and make sure the bolts are
tightened with torque of 2-3Nm. Make sure polarity at both the battery and the inverter/charge is correctly connected
and ring terminals are tightly screwed to the battery terminals
3. Connect the end of RJ45 of battery to BMS communication port of inverter.
4. The other end of RJ45 insert to battery comm port.
Note: if choosing lithium battery, make sure to connect the BMS communication cable between the battery and the
inverter. You need to choose battery type as“lithium battery”.
Lithium battery communication and setting
In order to communicate with battery BMS, you should set the battery type to “LI” in Program 5. Then the LCD will
switch to Program 51, which is to set the protocol type. There are several protocols in the inverter. Please get
instruction from the supplier to choose which protocol to match the BMS.
1. Connect the end of RJ45 of battery to BMS communication port of inverter
Make sure the lithium battery BMS port connects to the inverter is Pin to Pin. The BMS port supports communication
with BMS by RS485 protocol or CAN protocol.
The inverter BMS port pin and RS485 port pin assignment shown as below.
Pin number
BMS port
RS485 port
(for expansion)
1
RS485B
RS485B
2
RS485A
RS485A
3
--
--
4
CANH
--
5
CANL
--
6
--
--
7
--
--
8
--
--

7
2. LCD setting
To connect battery BMS, need to set the battery type as “LI” in Program 05.
After set “LI” in Program 05, it will switch to Program 51 to choose communication protocol. You can choose RS485 c
ommunication protocol which is from L01 to L50, and you can also choose CAN communication protocol which is from
L51 to L99.
Note: You can only use one communication type RS485 or CAN in a time.
05
Battery type
AGM (Default)
Flood
User-Defined
If “User-Defined” is selected, battery charge voltage and low DC cut-
off voltage can be set up in program 19, 20 and 21.
User-Defined 2
(Suitable for lithium battery when no communicating with BMS)
If „US2‟ is selected, battery charge voltage and low DC cut-off
voltage can be set up in program 19,20 and 21.
Lithium (Only suitable when communicate with BMS)
The lithium battery BMS communication protocol options
When the battery type set to Li, the setting option 12, 13, 21 will change to display percent.
Note: When the battery type set as“LI”, the Maximum charge current can't be modified by the user. When the
communication fail, the inverter will cut off output.
12
Setting SOC point back to
utility source when selecting
“SBU priority” or “Solar first”
in program 01
Default 40%, 5%~50% Settable
13
Setting SOC point back to
battery mode when selecting
“SBU priority” or “Solar first”
in program 01
Default 80%, 60%~100% Settable
21
Low DC cut-off voltage.
If self-defined is selected in
program 5, this program can be
set up
Default 20%, 5%~50% Settable

8
AC Input/Output Connection
CAUTION! !
Before connecting to AC input power source, please install a separate AC breaker between inverter and AC input
power source. This will ensure the inverter can be securely disconnected during maintenance and fully protected
from over current of AC input. The recommended spec of AC breaker is 40A for 4KW~6KW, 80A for 8KW~12KW.
There are two terminal blocks with “IN” and “OUT” markings. Please do NOT mis-connect input and output
connectors.
WARNING! !
All wiring must be performed by a qualified personnel.
It‟s very important for system safety and efficient operation to use appropriate cable for AC input connection. To
reduce risk of injury, please use the proper recommended cable size as below.
Suggested cable requirement for AC wires
Model
Gauge
Torque Value
4KW/5KW
10 AWG
1.4~ 1.6 Nm
6KW/8KW
8 AWG
1.4~ 1.6 Nm
10KW/12KW
6 AWG
1.6~ 1.8 Nm
AC Wiring
240Vac output
Input:
HOT1+ HOT2+Ground
Output:
HOT1+ HOT2
120Vac output
Input:
HOT1+ HOT2+Ground
Output:
HOT1+ N or HOT2+ N
Please follow below steps to implement AC input/output connection:
1. Before making AC input/output connection, be sure to open DC protector or disconnector first.
2. Remove insulation sleeve 10mm for six conductors. And shorten phase L and neutral conductor N 3 mm.
3. Insert AC input wires according to polarities indicated on terminal block and tighten the terminal screws. Be
sure to connect PE protective conductor first.

9
Hot1 --> Live wire (brown or black)
Hot2 --> Live wire (brown or black)
Ground --> Earth wire (yellow and green)
WARNING:
Be sure that AC power source is disconnected before attempting to hardwire it to the unit.
4. Then, insert AC output wires according to polarities indicated on terminal block and tighten terminal screws.
Hot1 --> Live wire (brown or black)
N --> Neutral wire (blue)
Hot2 --> Live wire (brown or black)
5. Make sure the wires are securely connected.
CAUTION: Appliances such as air conditioner are required at least 2~3 minutes to restart
because it‟s required to have enough time to balance refrigerant gas inside of circuits. If a power
shortage occurs and recovers in a short time, it will cause damage to your connected appliances.
To prevent this kind of damage, please check with manufacturer of air conditioner that if it‟s
equipped with time-delay function before installation. Otherwise, this off grid solar inverter will
trigger overload fault and cut off output to protect your appliance, but sometimes it still causes
internal damage to the air conditioner.
CAUTION: Important
Be sure to connect AC wires with correct polarity. If L and N wires are connected reversely, it may cause utilility
short-circuited when these inverters are worked in parallel operation.

10
PV Connection
CAUTION: Before connecting to PV modules, please install separately a DC circuit breaker between inverter and
PV modules.
WARNING! All wiring must be performed by a qualified personnel.
WARNING! It'‟ very important for system safety and efficient operation to use appropriate cable for PV module
connection. To reduce risk of injury, please use the proper recommended cable size as below.
Model
Typical Amperage
Cable Size
Torque
4KW/5KW/6KW
80A
8AWG
1.6~1.8 Nm
8KW/10KW/12KW
120A
8AWG
1.6~1.8 Nm
PV Module Selection:
When selecting proper PV modules, please be sure to consider below parameters:
1. Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage of inverter.
2. Open circuit Voltage (Voc) of PV modules should be higher than min. batteryvoltage.
Solar Charging Mode
INVERTER MODEL
SPF 4-12000T DVM
SPF 4-12000T DVM-MPV
Max. PV Array Open Circuit Voltage
150Vdc
250Vdc
PV Array MPPT Voltage Range
60~145Vdc
60~245Vdc
Please follow below steps to implement PV module connection:
1. Remove insulation sleeve 10 mm for positive and negativeconductors.
2. Check correct polarity of connection cable from PV modules and PV input
connectors. Then, connect positive pole (+) of connection cable topositive pole
(+) of PV input connector. Connect negative pole (-) of connection cable to
negative pole (-) of PV inputconnector.
3. Make sure the wires are securely connected.
PV Wiring
4KW/5KW/6KW，MPPT 80A
8KW/10KW/12KW, MPPT 120A

11
Communication Connection
Please use supplied communication cable to connect to inverter and PC. Follow on-screen instruction to install
the monitoring software. For the detailed software operation, please check user manual of software. The
monitoring software is downloadable from our website www.ginverter.com.
Dry Contact Signal
There is one dry contact (3A/250VAC) available on the rear panel. It could be used to deliver signal to
generator when battery voltage reaches warning level.
1. The wiring between generator and the inverter (not all generators are the same wiring diagram as below,
please ask supplier for instruction if there‟s any questions.)
Unit Status
Condition
Dry contact port:
NC & C
NO & C
Power Off
Unit is off and no output is powered.
Close
Open
Power On
Output is off and no output is powered
Close
Open
Battery not in “LI”
mode
Battery voltage <
Low DC Cut-off Voltage +2Vdc
Open
Close
Detected there‟s AC input
Close
Open
Battery in “LI”mode
Battery SOC <
Low DC Cut-off Soc +5%
Open
Close
Detected there‟s AC input
Close
Open
Electrical Performance
Inverting
Overload Capacity
1. For 100%<Load<120%, Fault (Power off) after 10 seconds.
2. For 120%<Load≤300%, Fault (Power off) after the 5 seconds.
Soft Start in Inverter Mode
When the inverter is turned on, the output voltage gradually ramps up from 0VAC to rated voltage in about 1.2 sec.
This effectively reduces otherwise very high starting inrush current drawn by AC loads such as Switched Mode Power
Supplies and inductive loads. This will result in lower motor inrush current, which means less impact on the loads and
inverter.
Caution:
After the inverter is switched on, it takes a finite amount of time to self-diagnose and get ready to deliver full power.
Always switch on the load(s) after a few seconds of switching on the inverter. Avoid switching on the inverter with
the load already switched on. This may prematurely trigger the overload protection. When a load is switched on, it
may require an initial higher power surge to start. If multiple loads are being powered, they should be switched on
individually so that the inverter is not overloaded by the higher starting surge.

12
AC Charger
The inverter is equipped with an active PFC (power factor correction) multistage battery charger. The PFC feature is
used to control the amount of power used to charge the batteries in order to obtain a power factor as close as
possible to 1.
When AC voltage is in the range of 154~260VAC, the charging current is 100%. Once it exceeds 260VAC, it must be
restored to 250VAC before it can be charged.
The inverter/charger has a very rapid charge current available, and the max charge current can be adjusted from 10A
to 100A in small increments on the inverter‟s LCD. This is helpful if this powerful charger applies charging to a small
capacity battery bank.
There are mainly 3 stages:
Bulk Charging: This is the initial stage of charging. While Bulk Charging, the charger supplies the battery with
controlled constant current. The charger will remain in Bulk charge until the absorption charge voltage is achieved.
Absorb Charging: This is the second charging stage and begins after the absorb voltage has been reached. Absorb
charging provides the batteries with a constant voltage and reduces the DC charging current in order to maintain the
absorb voltage setting.
In this period，the inverter will start a T1 time; the charger will keep the boost voltage in Boost CV mode until the T1
time has run out. When charging current is <0.01C or the time is over 12 hours, then drop the voltage
Down to the float voltage.
Float Charging: The third charging stage occurs at the end of the absorb charging time. During float charging, the
charge voltage is reduced to the float charge voltage. In this stage, the battery are kept fully charged and ready if
needed by the inverter.
AC Charging Current:
Model
Battery Voltage
Max. AC Charging Current
4KW
48V
40A
5KW
48V
50A
6KW
48V
60A
8KW
48V
70A
10KW
48V
80A
12KW
48V
100A
MPPT Charging Current:
Model
Battery Voltage
Max. Charging Current
4-6KW
48V
80A
8-12KW
48V
120A

13
Battery Equalization
Equalization function is added into charge controller. It reverses the buildup of negative chemical effects like
stratification, a condition where acid concentration is greater at the bottom of the battery than at the top.
Equalizationalso helps to remove sulfate crystals that might have built up on the plates. If left unchecked, this
condition, called sulfation, will reduce the overall capacity of the battery. Therefore, it‟s recommended to equalize
battery periodically.
How to Apply Equalization Function
You must enable battery equalization function in monitoring LCD setting program 23 first. Then, you may apply this
function in device by either one of following methods:
1. Setting equalization interval in program 27.
2. Active equalization immediately in program 28.
When to Equalize
In float stage, when the setting equalization interval (battery equalization cycle) is arrived, or equalization is active
immediately, the controller will start to enter Equalize stage.
Equalize charging time and timeout
In Equalize stage, the controller will supply power to charge battery as much as possible until battery voltage raises
to battery equalization voltage. Then, constant-voltage regulation is applied to maintain battery voltage at the
battery equalization voltage. The battery will remain in the Equalize stage until setting battery equalized time is
arrived.
However, in Equalize stage, when battery equalized time is expired and battery voltage doesn‟t rise to battery
equalization voltage point, the charge controller will extend the battery equalized time until battery voltage achieves
battery equalization voltage. If battery voltage is still lower than battery equalization voltage when battery
equalized timeout setting is over, the charge controller will stop equalization and return to float stage.

14
Power Saver
The “Power Saver” function is dedicated to conserve battery power when AC power demand is either minimal or not
required at all by the loads.
In this mode, the inverter pulses the AC output looking for an AC load (i.e., electrical appliance). Whenever an AC
load (greater than 500 watts at 120Vac) is turned on, the inverter recognizes the need for power and automatically
starts inverting and output goes to full voltage. When there is no load (or less than 500 watts) detected, the inverter
automatically goes back into search mode to minimize energy consumption from the battery bank.
In “Power saver on” mode, the inverter will draw power mainly in sensing moments, thus the idle consumption is
significantly reduced.
Power Saver On
Power Saver Off
Power Saver On (Load detected)
FAN Operation
For 4-6KW models, there are one DC fan and one AC fan.
For 8-12KW models, there are one DC fans and two AC fan.
The fans are designed to operate according to the following logic:
Condition
Enter Condition
Leave condition
Fan Speed
HEAT SINK TEMPERATURE
T ≤ 40℃(104℉)
T > 40℃(104℉)
OFF
T > 40℃(104℉)
T ≤ 40℃(104℉)
ON
UTLITY CHARGER
CURRENT
I ≤ 20A
I>20A
OFF
I>20A
I ≤ 20A
ON
LOAD PERCENTAGE
(INV MODE)
20% ≤ Load
Load>20%
OFF
Load>20%
20% ≤ Load
ON
Allow at least 80CM of clearance around the inverter for air flow. Make sure that the air can circulate freely around
the unit.
Output Power Derating
When DC input voltage drops to Low DC Warning Voltage OR Low DC Warning SOC, the output Voltage will be derated 10V.
When transformer temperature exceed to 150℃, the output Voltage will be derated 10V.
Remote LCD Connecting (Optional)
Plug in the remote LCD panel to the RS485 port.
There‟s a DIP switch on the inverter communication board. Change the DIP switch setting to all “ON”as picture
showed as below.
Warning:
Our cables are designed with special pinouts on the connectors, so don‟t use other cables, or the remote LCD panel
will not be powered on.

15
Operation
Power ON/OFF
Once the unit has been properly installed and the batteries are connected well, simply press On/Off switch
(located on the button of the case) to turn on the unit.
Operation and Display Panel
The operation and display panel, shown in below chart, is on the front panel of the inverter. It includes
three indicators, four function keys and a LCD display, indicating the operating status and input/output
power information.
1. LCD display
2. Status indicator
3. Charging indicator
4. Fault indicator
5. Function buttons
LED Indicator
LED Indicator
Messages
Green
Solid On
Output is powered by utility in Line mode.
Flashing
Output is powered by battery or PV in battery mode.
Green
Solid On
Battery is fully charged.
Flashing
Battery is charging.
Red
Solid On
Fault occurs in the inverter.
Flashing
Warning condition occurs in the inverter.
Function Buttons
Button
Description
ESC
To exit setting mode
UP
To go to previous selection
DOWN
To go to next selection
ENTER
To confirm the selection in setting mode or enter setting mode

16
LCD Display Icons
Icon
Function Description
Input Source Information
Indicates the AC input.
Indicates the PV input
Indicate input voltage, input frequency, PV voltage, battery voltage and
charger current.
Configuration Program and Fault Information
Indicates the setting programs.
Indicates the warning and fault codes.
Warning: flashing with warning code.
Fault:lighting with fault code
Output Information
Indicate output voltage, output frequency, load percent, load in VA, load in
Watt and discharging current.
Battery Information
Indicates battery level by 0-24%, 25-49%, 50-74% and 75-100% in battery
mode and charging status in line mode.
These two signs indicate the charge priority. SOLAR indicates solar first.
UTILITY indicate utility first. SOLAR blinking indicates solar only; SOLAR and
UTILITY both on indicates combined charging.
In AC mode, it will present battery charging status.
Status
Battery voltage
LCD Display
Constant
Current mode /
Constant
Voltage mode
<2V/cell
4 bars will flash in turns.
2 ~ 2.083V/cell
Bottom bar will be on and the other three
bars will flash in turns.
2.083 ~ 2.167V/cell
Bottom two bars will be on and the other
two bars will flash in turns.
> 2.167 V/cell
Bottom three bars will be on and the top
bar will flash.
Floating mode. Batteries are fully charged.
4 bars will be on.

17
In battery mode, it will present battery capacity.
Load Percentage
Battery Voltage
LCD Display
Load >50%
< 1.717V/cell
1.717V/cell ~ 1.8V/cell
1.8 ~ 1.883V/cell
> 1.883 V/cell
50%> Load > 20%
< 1.817V/cell
1.817V/cell ~ 1.9V/cell
1.9 ~ 1.983V/cell
> 1.983
Load < 20%
< 1.867V/cell
1.867V/cell ~ 1.95V/cell
1.95 ~ 2.033V/cell
> 2.033
Load Information
Indicates overload.
Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%.
0%~24%
25%~49%
50%~74%
75%~100%
Mode Operation Information
Indicates unit connects to the mains.
Indicates unit connects to the PV panel.
Indicates load is supplied by utility power.
Indicates the utility charger circuit is working.
Indicates the DC/AC inverter circuit is working.
These three sins indicate the output priority. SOL.FIRST indicates solar first.
BAT.FIRST indicates battery first. UTI.FIRST indicates utility first.
Mute Operation
Indicates unit alarm is disabled.

18
LCD Setting
After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press “UP” or “DOWN”
button to select setting programs. And then, press “ENTER” button to confirm the selection or ESC button to
exit.
Setting Programs:
Program
Description
Setting Option
01
Output source priority:
To configure load
power source priority
Solar first
Solar energy provides power to the loads as first priority.
If solar energy is not sufficient to power all connected loads,
battery energy will supply power the loads at the same time.
Utility provides power to the loads only when any one condition
happens:
- Solar energy is notavailable
- Battery voltage drops toeither low-level warning voltage orthe
setting point in program12.
Utility first (default)
Utility will provide power to the loads as first priority.
Solar and battery energy will provide power to the loads only
when utilitypower is not available.
SBU priority
Solar energy provides power to the loads as first priority.
If solar energy is not sufficient to power all connected loads,
battery energy will supply power to the loads at the same time.
Utility provides power to the loads only when battery voltage
drops to either low-level warning voltage or thesetting point in
program 12.
02
Maximum charging
current: To configure total
charging current for solar
and utility chargers.
(Max. charging current =
utility charging current +
solar charging current)
12KW model: default 80A, 10A~180A Settable
10KW model: default 80A, 10A~160A Settable
8KW model: default 80A, 10A~150A Settable
6KW model: default 80A, 10A~140A Settable
5KW model: default 80A, 10A~130A Settable
4KW model: default 80A, 10A~120A Settable
(If Li is selected in program 5, this program can‟t be set up)
