INSTRUCTION MANUAL
S2630, REV B
Tyre Inflator
Gauge
Reliable and sturdy,
this 3 in 1 tyre gauge is
designed to:
a. Measure tyre
pressure
b. Inflate tyres
c. Deflate tyres
Tyre deflation is via
the deflation valve on
the gun body. A simple
press of the valve will
activate it and reduce
pressure
Available with choice of
a. Analog Gauge
b. Digital Gauge
Also available with tyre
inflator gauge with
homologated pressure
gauge, conforming to
EU directive 86/217/CEE
Available with choice of
a. Flexible hose with
straight chuck
b. Flexible hose with
rigid extension &
dual chuck
Especially useful for
HCV's
Air
Inlet
2-1/2"
(63 mm)
Dual
chuck
Deflation
valve
Air hose
Analog
gauge
Swivel for
convenience
in use
CAT NR. DESCRIPTION
BSP THREADS NPT THREADS
TIG/M/12/BSP TIG/M/12/N 12" (300 mm) Flexible hose with straight chuck; Analog Gauge
TIG/D/12/BSP TIG/D/12/N 12" (300 mm) Flexible hose with straight chuck; Digital Gauge
-TIG/M/24/N 24" (600 mm) Flexible hose with straight chuck; Analog Gauge
TIG/M/24D/BSP TIG/M/24D/N 24" (600 mm) Flexible hose with dual chuck; Analog Gauge
TIG/D/24D/BSP TIG/D/24D/N 24" (600 mm) Flexible hose with dual chuck; Digital Gauge
-TIG/D/72D/N 72" (1830 mm) Flexible hose with dual chuck; Digital Gauge
TIG/M-CEE/12/BSP -12" (300 mm) Flexible hose with straight chuck; Analog Gauge;
Conforming to EU directive 86/217/CEE
TIG/M-CEE/24D/BSP -24" (600 mm) Flexible hose with dual chuck; Analog Gauge;
Conforming to EU directive 86/217/CEE
TIG
TIG-CEE
Straight
chuck
Set unit
Back lit
Digital
gauge

2
TIG/D/24D TIG/D/72D TIG/M-CEE/12 TIG/M-CEE/24D
GAUGE TYPE Digital Digital Analogue Analogue
GAUGE DIA 2-1/2" (63 mm) 2-1/2" (63 mm) 2-1/2" (63 mm) 2-1/2" (63 mm)
BACKLIGHT Yes Yes No No
AVAILABLE UNIT PSI, Bar, Mpa, Kg/cm2 PSI, Bar, Mpa, Kg/cm2 PSI, Bar PSI, Bar
MAX. PRESSURE Upto 300 PSI (21 BAR) Upto 300 PSI (21 BAR) Upto 140 PSI (10 BAR) Upto 140 PSI (10 BAR)
ACCURACY ± 1% of Full scale ± 1% of Full scale ±0.08% < 4 BAR (58 PSI)
±1.6% > 4 BAR (58 PSI)
±0.08% < 4 BAR (58 PSI)
±1.6% > 4 BAR (58 PSI)
RESOLUTION 0.1 PSI 0.1 PSI 2 PSI 2 PSI
POWER SUPPLY Lithium Battery Lithium Battery No No
THREAD TYPE BSP, NPT NPT BSP BSP
CHUCK TYPE Dual Chuck Dual Chuck Straight Chuck Dual Chuck
EXTENSION TYPE Flexible with Rigid
Extension
Flexible with Rigid
Extension
Flexible Flexible with Rigid
Extension
EXTENSION LENGTH 24" (600 mm) 72" (1830 mm) 12" (300 mm) 24" (600 mm)
APPLICATION Truck & Buses Truck & Buses Cars Truck & Buses
SPECIFICATIONS
TIG/M/12 TIG/D/12 TIG/M/24 TIG/M/24D
GAUGE TYPE Analogue Digital Analogue Analogue
GAUGE DIA 2-1/2" (63 mm) 2-1/2" (63 mm) 2-1/2" (63 mm) 2-1/2" (63 mm)
BACKLIGHT No Yes No No
AVAILABLE UNIT PSI, Bar PSI, BAR, Mpa, Kg/cm2 PSI, BAR PSI, BAR
MAX. PRESSURE Upto 50 PSI (3.5 BAR) Upto 300 PSI (21 BAR) Upto 50 PSI (3.5 BAR) Upto 210 PSI (15 BAR)
ACCURACY ± 2 PSI ± 1% of Full scale ± 2 PSI ± 1.6%
RESOLUTION 1 PSI 0.1 PSI 1 PSI 2 PSI
POWER SUPPLY No Lithium Battery No No
THREAD TYPE BSP, NPT BSP, NPT NPT BSP, NPT
CHUCK TYPE Straight Chuck Straight Chuck Straight Chuck Dual Chuck
EXTENSION TYPE Flexible Flexible Flexible Flexible with Rigid
Extension
EXTENSION LENGTH 12" (300 mm) 12" (300 mm) 24" (600 mm) 24" (600 mm)
APPLICATION Cars Cars Truck & Buses Truck & Buses

3
SAFETY INFORMATION
• Follow workshop health & safety rules,
regulations and conditions when using the tyre
inflator gauge
• During their period of use, accessories must be
checked for wear, cracks and other damage,
replace any damaged or worn parts
• Use genuine parts only. Unauthorized parts
may be dangerous and will void the warranty
• Wear approved safety gloves and eye and ear
protection
• Keep the tyre inflator gauge clean and in good
working order for best and safest performance.
• DO NOT use the tyre inflator gauge for a task
it is not designed to perform
• DO NOT drop, throw or abuse the tyre inflator
gauge
• DO NOT carry the tyre inflator gauge by the
hose
WARNING!
• DO NOT use tyre inflator gauge if damaged or
thought to be faulty. Contact your local service
agent
PACKAGE CONTENT
DESCRIPTION QTY.
Tyre Inflator Gauge 1
O.I.P.M. 1
BEFORE INSTALLATION
• Use only original accessories compliant with
this tyre inflator gauge
• Make sure that all connections are secure.
• Clean Supply of Air: Make sure air quality is
good with no contaminants or moisture
• Regulator: Since compressed air may be used
at many points in the shop, air pressure in the
line will keep fluctuating. It is important to
use an air regulator in the air line which will
maintain constant pressure
• Use thread sealant for all threaded connections
WARNING!
• Defective accessories can lead to personal
injury and material damage
INSTALLATION
1. Connect the Tyre Inflator Gauge with the air
compressor line
2. Press & hold the chuck lever & push the chuck
onto the Inflator Valve on the tyre. In case of
dual chuck, it is only required to be pushed
onto the valve
3. Straight chuck is used for passenger cars,
motor bikes etc. with air valve facing outward
whereas the Dual chuck is used for commercial
vehicles where the air valves face outward and
inward both
CAUTION
• An FRL unit must be used in the air supply,
before it is connected to the tyre inflator
gauge
• While inserting the Chuck onto the Tyre
Inflator Valve, make sure that it properly sits
onto the valve
OPERATING INSTRUCTIONS
To check the pressure
1. Connect the chuck to the Inflator Valve on the
tyre and observe the pressure on the pressure
gauge
To switch On/O the back-light in digital gauge
1. Press the ON button once to switch ON the
light
2. Press the ON button again to switch OFF the
light
To set the measuring unit in digital gauge
1. The Digital Gauge can measure in 4 dierent
units PSI, BAR, Kpa & Kg/cm2
2. Press the PSI-KPA button on the right once to
switch on the display
3. Now with every press of this button the
measuring unit will change.
4. Keep pressing it till it displays the desired
measuring unit
Inflating the tyre
1. Firstly check the tyre pressure.
2. Now, press the trigger on the tyre inflator
gauge to start inflating the tyre
3. Release the trigger and check the tyre
pressure again by looking at the tyre inflator
gauge
4. Repeat the above steps until the desired
pressure has been reached, release the trigger
of tyre inflator gauge and pull out the chuck
Deflating the tyre
1. Firstly check the tyre pressure
2. Press the deflator valve on the tyre inflator
gauge to start deflating the tyre
3. Release the deflator valve and check the tyre
pressure again by looking at the tyre inflator
gauge
4. Repeat the above steps until the pressure
inside the tyre reduces to the desired pressure,
release the deflator valve and pull out the
chuck
WARNING!
• Dual chuck needs to be held & pushed by
the operator during all the above mentioned
operations as it is not a clip on type chuck or
straight chuck
• Make sure tyre is not inflated beyond its rated
pressure rating which is generally mentioned
on the tyre itself

GROZ Engineering Tools (P) Ltd.
GROZ Net Industries
Village Kherki Daula, National Highway-8,
Gurugram-122001, Haryana, INDIA
Tel [phone]
Fax [phone]
E-Mail [e-mail]
Url www.groz-tools.com
The GROZ name, GROZ logo and the mark are
trademarks of GROZ Engineering Tools (P) Ltd.,
India
GROZ WARRANTY POLICY
GROZ makes all eorts to ensure that its products meet the highest standards of quality and durability and warrants to the original purchaser its
range of products for a period of 12 months from GROZ Invoice date, against defects in materials and workmanship. If the GROZ product is part of
a set, only the portion that is defective is subject to this warranty.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, wear and tear, negligence or accident, repairs or alterations
outside Groz plants, or to lack of maintenance. GROZ shall in no event be liable for death, injuries to persons or property or for incidental,
contingent, special or consequential damages arising from the use of its products. It is upto the user to determine suitability and safety of the
product for their intended use, and the user assumes all risks and liability herewith.
In no event, shall GROZ’s liability exceed the invoiced cost of the product In case of identification of defect covered under this warranty, the same
must be notified in writing to GROZ /GROZ designated authorized service location. Proof of purchase date must accompany the complaint. GROZ
reserves the right to call back the faulty unit, all charges including transportation prepaid. On verification of the defect, the unit will be repaired or
replaced with a new or reconditioned product or part of equal utility or a full refund given at GROZ’s discretion. The repaired /replaced units will be
returned to the user freight prepaid, using most economical freight carrier. However if determined that the defect resulted from causes not within
the scope of the warranty, then the cost of returning the product would be to buyer’s account.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Leakage in dual Chuck
during inflation
Not enough force applied
on the chuck
In dual chuck force has to be applied externally so that the chuck stays
intact on the tyre air valve. Whereas as straight chuck comes with a clip
which keeps the chuck in place during operation
Leakage from inflator
gauge and air supply
interface
Loose connection Push the air supply pipe firmly into the quick connect coupler
Pressure gauge not
showing the correct
reading
Faulty Gauge Replace the gauge
DISPOSAL
The components or the used products must be given to companies that specialize in the disposal and
recycling of industrial waste.
