Grunbeck GENODOS DME 6 User manual

We understand water.
Dosing system | GENODOS DME 6 –100 /
GENODOS DME Delta-p
Operation manual

General Contact
Germany
International Sales
Phone [phone]
Service
Phone [phone]
[email protected]
Availability
Monday to Thursday
7:00 am - 6:00 pm
Friday
7:00 am - 4:00 pm
We reserve the right to technical modifications.
© by Grünbeck Wasseraufbereitung GmbH
Original operation manual
Edition: February 2023
Order no.: 100174850000_en_034

Table of contents
3 | 64
Table of contents
1Introduction ............................................................... 4
1.1 Validity of the manual ................................................ 4
1.2 Other applicable documents ...................................... 4
1.3 Product identification ................................................. 5
1.4 Symbols used ............................................................ 7
1.5 Depiction of warnings ................................................ 7
1.6 Demands on personnel.............................................. 8
2Safety ....................................................................... 10
2.1 Safety measures...................................................... 10
2.2 Product-specific safety instructions ......................... 12
2.3 Conduct in emergencies .......................................... 13
3Product description ................................................ 14
3.1 Intended use ............................................................ 14
3.2 Product components................................................ 15
3.3 Functional description.............................................. 17
3.4 Accessories ............................................................. 18
3.5 Mineral solutions...................................................... 19
4Transport and storage............................................ 21
4.1 Transport ................................................................. 21
4.2 Storage .................................................................... 21
4.3 Transport/storage of the canisters ........................... 21
5Installation ............................................................... 22
5.2 Requirements for the installation site....................... 26
5.3 Checking the scope of supply.................................. 27
5.4 Water installation ..................................................... 27
6Start-up/commissioning......................................... 31
6.1 Connecting the canister ........................................... 31
6.2 Checking the system ............................................... 32
6.3 Handing over the product to the owner/operator/
operating company .................................................. 35
7Operation..................................................................36
7.1 Checking and documenting operation as intended ..36
7.2 Replacing the canister ..............................................36
8Maintenance and repair...........................................39
8.1 Cleaning ...................................................................39
8.2 Intervals ....................................................................40
8.3 Inspection .................................................................41
8.4 Maintenance .............................................................41
8.5 Consumables............................................................43
8.6 Changing the mineral solution ..................................43
8.7 Spare parts ...............................................................44
8.8 Wearing parts ...........................................................44
9Troubleshooting.......................................................46
9.1 Messages .................................................................46
9.2 Observations ............................................................46
10 Decommissioning....................................................47
10.1 Temporary standstill .................................................47
10.2 Restart/recommissioning ..........................................47
10.3 Final shutdown .........................................................47
11 Dismantling and disposal .......................................48
11.1 Dismantling...............................................................48
11.2 Disposal....................................................................49
12 Technical specifications .........................................50
12.1 Dosing system GENODOS DME 6 –100.................50
12.2 Dosing system GENODOS DME Delta-p .................52
13 Operation log............................................................54
13.1 Start-up/commissioning log ......................................54

Introduction
4 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
1 Introduction
This manual is intended for owners/operators/operating companies, users as well as
qualified specialists and ensures the safe and efficient handling of the product. The manual
is an integral part of the product.
►Carefully read this manual and the included manuals on the components before
you operate your product.
►Obey all safety and handling instructions.
►Keep this manual and all other applicable documents, so that they are available
when needed.
Illustrations in this manual are for basic understanding and can differ from the actual design.
1.1 Validity of the manual
This manual applies to the products below:
●Dosing system GENODOS DME 6
●Dosing system GENODOS DME 10
●Dosing system GENODOS DME 20
●Dosing system GENODOS DME 30
●Dosing system GENODOS DME 80
●Dosing system GENODOS DME 100
●Dosing system GENODOS DME Delta-p
●Special designs that essentially correspond to the standard products given above.
For information on changes, please refer to the respective information sheet that is
enclosed, if applicable.
1.2 Other applicable documents
●Operation manual of GENODOS pump GP
●Technical Information on accessories for GENODOS pump GP
●Safety data sheets for exaliQ mineral solutions
In addition for GENODOS DME Delta-p
●Mounting instructions for insert, order no. 100104560000
●Mounting instructions for pulse cable, order no. 100103810000
●Operation manual and technical service manual of Delta-p/Delta-p-I
●Electric circuit diagram for GENO-IONO-matic3for Delta-p

Introduction
5 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
1.3 Product identification
You can identify your product based on the product designation and the order no. indicated
on the type plate.
►Check whether the products indicated in chapter 1.1 correspond to your product.
The type plate is located on the side of the GENODOS dosing pump GP.
1.3.1 Dosing systems GENODOS DME 6 –100
Designation
1
Obey the operation manual
2
Disposal information
3
DVGW test mark
4
CE mark
5
Product designation
6
Nominal connection diameter
7
Operating range
8
Operating pressure
9
Drinking water temperature
Designation
10
Water/ambient temperature
11
Pulse sequence
12
Dosing volume
13
Power supply
14
Power input
15
DIN EN 14812 compliance as suitable dosing
agent
16
Order no.
17
Serial no.
18
Date of manufacture

Introduction
6 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
1.3.2 Dosing system GENODOS DME Delta-p
Designation
1
Product designation
2
Data matrix code
3
CE mark
4
Nominal connection diameter
5
Operating range
6
Operating pressure
7
Drinking water temperature
8
Water/ambient temperature:
9
Pulse sequence
Designation
10
Dosing volume
11
Power supply
12
Power input
13
DIN EN 14812 compliance as suitable dosing
agent
14
Disposal information
15
Obey the operation manual
16
Serial no.
17
Order no.
18
QR code

Introduction
7 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
1.4 Symbols used
Symbol
Meaning
Danger and risk
Important information or requirement
Useful information or tip
Written documentation required
Reference to further documents
Work that must be carried out by qualified specialists only
Work that must be carried out by qualified electricians only
Work that must be carried out by technical service personnel only
1.5 Depiction of warnings
This manual contains information and instructions that you must obey for your personal
safety. The information and instructions are highlighted by a warning symbol and are
structured as shown below:
1.5.1.1
1.5.1.2 SIGNAL WORD
1.5.1.3 Type and source of hazard
1.5.1.4
●Possible consequences
►Preventive measures
The signal words below are defined subject to the degree of danger and might be used in the
present document:
Warning symbol and
signal word
Consequences if the information/instructions are ignored
DANGER
Personal
injury
Death or serious injuries
WARNING
Possible death or serious injuries
CAUTION
Possible moderate or minor injuries
NOTE
Damage to
property
Possible damage to components, the product and/or its
functions, or an object in its vicinity

Introduction
8 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
1.6 Demands on personnel
During the individual phases in the service life of the system, different persons carry out work
on the system. This work requires different qualifications.
1.6.1 Qualification of personnel
Personnel
Requirements
User
•No special expertise required
•Knowledge of the tasks assigned
•Knowledge of possible dangers in case of incorrect behaviour
•Knowledge of the required protective equipment and protective measures
•Knowledge of residual risks
Owner/operator/
operating company
•Product-specific expertise
•Knowledge of statutory regulations on work safety and accident prevention
Qualified specialist
•Electrical engineering
•Sanitary engineering
(HVAC and plumbing)
•Transport
•Professional training
•Knowledge of relevant standards and regulations
•Knowledge of detection and prevention of potential hazards
•Knowledge of statutory regulations on accident prevention
Technical service
(Grünbeck's technical
service/authorised service
company)
•Extended product-specific expertise
•Trained by Grünbeck
1.6.2 Authorisations of personnel
The table below describes which tasks may be carried out by whom.
User
Owner/
operator/
operating
company
Qualified
specialist
Technical
service
Transport and storage
X
X
X
Installation and mounting
X
X
Start-up/commissioning
X
X
Operation and handling
X
X
X
X
Cleaning
X
X
X
X
Inspection
X
X
X
X
Maintenance
semi-annually
X
X
annually
X
X
Troubleshooting
X
X
X
X
Repair
X
X
Decommissioning and
restart/recommissioning
X
X
X
Dismantling and disposal
X
X
X

Introduction
9 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
1.6.3 Personal protective equipment
►As an owner/operator/operating company, make sure that the required personal
protective equipment is available.
The components below fall under the heading of personal protective equipment (PPE):
Protective gloves
Protective footwear
Protective overall
Safety goggles
Protective apron
Mask

Safety
10 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
2 Safety
2.1 Safety measures
●Only operate your product if all components are installed properly.
●Obey the local regulations on drinking water protection, accident prevention and
occupational safety.
●Do not make any changes, alterations, extensions or program changes on your
product.
●Only use genuine spare parts for maintenance or repair.
●Keep the premises locked against unauthorised access to protect imperilled or
untrained persons from residual risks.
●Comply with the maintenance intervals (refer to chapter 8.2). Failure to comply can
result in the microbiological contamination of your drinking water system.
●Be aware of a possible slip hazard due to leaking water on the floor.
2.1.1 Mechanical hazards
●You must never remove, bridge, or otherwise tamper with safety equipment.
●For all work on the system that cannot be carried out from the ground, use stable,
safe and self-standing access aids (e.g. stepladders).
●Make sure that the system is set up in a way that it cannot tip over and that the
stability of the system is guaranteed at all times.
2.1.2 Pressure-related hazards
●Components can be under pressure. There is a risk of injuries and damage to
property due to escaping water and unexpected movement of components. Check
the system’s pressure lines for leaks at regular intervals.
●Before starting any repair and maintenance work, make sure that all affected
components are depressurised.
2.1.3 Electrical hazards
There is an immediate danger of fatal injury from electric shock when touching live parts.
Damage to the insulation or individual components can be life-threatening.
●Only have qualified electricians carry out electrical work on the system.
●In case of damage to live components, switch off the voltage supply immediately
and arrange for repair.
●Switch off the supply voltage before working on electrical system parts. Discharge
residual voltage.

Safety
11 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
●Never bridge electrical fuses. Do not disable fuses. Use the correct current ratings
when replacing fuses.
●Keep moisture away from live parts. Moisture can cause short-circuits.
2.1.4 Danger due to chemicals
●Chemicals can be hazardous to health and environment.
They can cause chemical burns to skin and eyes as well as irritation of the
respiratory tract or allergic reactions.
●Avoid any skin/eye contact with chemicals.
●Use personal protective equipment.
●Read the safety data sheet before handling chemicals. Obey the instructions for
different activities/situations.
●Current safety data sheets for chemicals are available for download at
www.gruenbeck.de/en/info-centre/safety-data-sheets.
●Obey in-house instructions when handling chemicals. Make sure that protective
and emergency equipment such as emergency showers and eyewash are
available where required, and functional.
Mixing and residual amounts of chemicals
●Do not mix different chemicals. Unforeseeable chemical reactions posing a lethal
danger can occur.
●Dispose of residual amounts of chemicals in accordance with local regulations
and/or in-house instructions.
●Residual amounts from used canisters should not be transferred into canisters with
fresh chemicals in order not to impair the effectiveness of the chemicals.
Labelling/Minimum shelf life/Storage of chemicals
●Check the labelling of the chemicals. Chemical labels must not be removed or
made illegible.
●Do not use any unknown chemicals.
●Comply with the use-by date (minimum shelf life) stated on the label.
●If stored incorrectly, chemicals could change their state of matter, crystallize,
outgas, or lose their effectiveness. Store and use the chemicals at the indicated
temperatures only.
Cleaning/Disposal
●Immediately absorb leaked chemicals with suitable binding agents.
●Collect and dispose of chemicals in such a way that they cannot pose any risks to
people, animals, or the environment.

Safety
12 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
2.1.5 Groups of persons requiring protection
●This product must not be used by persons (including children) with limited abilities,
lack of experience or knowledge.
●Children should be supervised to make sure that they do not play with the product.
●Cleaning and maintenance must not be carried out by children.
2.2 Product-specific safety instructions
►Always route lines such as dosing hose, mains cable, pulse connecting cable and
suction line away from traffic routes in order to prevent tripping and tearing them off.
►Secure the lines of the dosing system at the installation site where public traffic can
be expected.
On-site encoder voltage on the fault signal contact of the dosing pump.
►Have work on the electrical system carried out by qualified electricians only.
►Switch-off the on-site encoder voltage before working on the dosing pump.
►Comply with the 5 safety rules of electrical engineering.
2.2.1 About mineral solutions
WARNING
Skin and eye contact with mineral solution
●Chemical eye burns, irritation of the skin and the respiratory tract
►Use personal protective equipment (safety goggles, protective gloves, protective
clothing) when handling an open canister and when working on the dosing
system.
►Use approved exaliQ mineral solutions only.
►Do not mix exaliQ mineral solutions.
►Do not transfer exaliQ mineral solutions into other canisters.
►Do not use exaliQ mineral solutions whose shelf life has expired.

Safety
13 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
2.2.2 Safety-related components
Safety components must be replaced by genuine spare parts only.
●Dosing pump, pump head
●Dosing hose, dosing valve
●All pressurised parts and parts that come into contact with the media
2.2.3 Signals and warning devices
The affixed information and pictograms must be clearly legible.
They must not be removed, soiled or painted over.
►Obey all warnings and safety instructions.
►Immediately replace illegible or damaged symbols and pictograms.
2.3 Conduct in emergencies
WARNING
Pressurised media lines
●After the mains plug is unplugged, media lines on the pressure side are still
under pressure.
●Dosing media splashing out.
►Use personal protective equipment.
►Relieve the pressure on the pressure side of the dosing pump before working on
the pump head, its equipment parts or the dosing hose.
2.3.1 If the dosing agent escapes
1. Disconnect the product from the voltage supply.
2. Locate the leak.
3. Eliminate the cause of the dosing media escaping.
4. Contact the technical service.
2.3.2 In case of incorrect dosing/overdosing
1. Disconnect the product from the voltage supply
2. Contact the technical service.

Product description
14 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
3 Product description
3.1 Intended use
The mineral substances protect the water pipes and the connected water carrying system
components (fittings, devices, operating equipment, household appliances, boilers,
production plants, etc.) from malfunctions and damage due to scale deposits and/or
corrosion.
GENODOS DME 6 –100
●The dosing system GENODOS DME is designed for volume-based dosing of
exaliQ mineral solutions into the drinking and industrial water pipes of commercial
and industrial buildings.
●The dosing system GENODOS DME is suitable for long-lasting as well as
continuous flows.
GENODOS DME Delta-p
●The dosing system GENODOS DME Delta-p is designed for volume-based dosing
of exaliQ mineral solutions into the drinking and industrial water pipes of
commercial and industrial buildings.
●The dosing system GENODOS DME Delta-p is adapted to the water softener
Delta-p.
●The dosing system GENODOS DME Delta-p is suitable for long-lasting as well as
continuous flows.
3.1.2 Foreseeable misuse
●Dosing chemicals other than exaliQ mineral solutions is not approved by Grünbeck
Wasseraufbereitung GmbH and results in the loss of warranty claims.
●Using the mineral solution exaliQ neutra in combination with the dosing system
GENODOS DME Delta-p is not permitted.

Product description
15 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
3.2 Product components
3.2.1 GENODOS DME 6 –100
Designation
Function
1
Dosing pump
GENODOS GP ../40 with dosing volume pre-set to 100 ml/m3, under seal
2
Hose connection kit
in sizes: Ø 2/4 for DME 6/10/20/30 or Ø 4/6 for DME 80/100
3
Contact water meter
with pulse sensor, dosing point with non-return valve and water meter screw
connection
4
Pulse divider
With Hall pulse cable and coupling socket, 4-pole, for external connector plug
(red) on the dosing pump
5
Dosing valve
for injection point on the contact water meter
6
Suction lance
with integrated empty signal, pre-alarm, suction and return line for 15 L
canisters of exaliQ mineral solution
7
Dosing hose
in sizes: Ø 2/4 for DME 6/10/20/30 or Ø 4/6 for DME 80/100

Product description
16 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
3.2.2 GENODOS DME Delta-p
Designation
Function
1
Dosing valve
for injection point on the insert
2
Insert
(available separately as an
accessory, refer to chapter 3.4)
with injection point G¼" for dosing valve,
for the soft water outlet of Delta-p (in suitable size)
3
Dosing pump
GENODOS GP-2/40 with dosing volume pre-set to 100 ml/m3, under
seal
4
Hose connection kit
for dosing hose of size Ø 2/4
5
Pulse cable
Hall pulse cable and coupling socket, 4-pole, for external connector
plug (red)
6
Suction lance
with integrated empty signal, pre-alarm, suction and return line for 15 L
canisters of exaliQ mineral solution
7
Dosing hose
in size Ø 2/4

Product description
17 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
3.3 Functional description
GENODOS DME 6 –100
By means of a contact water meter with pulse generator, the dosing system
GENODOS DME registers the water volume flowing through and sends the control pulses to
the electronics of the dosing pump GENODOS GP according to the pulse interval of the
contact water meter.
GENODOS DME Delta-p
The dosing system DME Delta-p is tuned to the IONO-matic3control unit (starting from
software version V3.05 and higher) of the Delta-p.
The electronics of the dosing pump GENODOS GP-2/40 receives the dosing signal from the
control unit of the Delta-p water softener via the pulse connection cable.
The exaliQ mineral solution is injected into the drinking water pipe via the (optional) insert
with injection point for the dosing valve which is mounted on the soft water outlet of the
Delta-p water softener.
General
The electronics controls the dosing pump and thereby determines the dosing volume of the
mineral solution into the water pipe.
The mineral solution is withdrawn from the respective canister containing the mineral
solution by means of a suction lance and added to the water.
An electronic level control switches the pump off when the canister containing the mineral
solution is empty.
A yellow LED on the electronics of dosing pump GENODOS GP visually signals the need for
a replacement of the canister.

Product description
18 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
3.4 Accessories
You can retrofit your product with accessories. Please contact your local Grünbeck
representative or Grünbeck’s headquarters in Hoechstaedt/Germany for details.
Illustration
Product
Order no.
Conversion kit GENODOS DME
60 litre suction lance
163 765
For conversion to 60 L canisters
Optional insert with injection point G¼"
for the soft water outlet of Delta-p
For Delta-p 1"
185000010000
For Delta-p 1¼"
185000020000
For Delta-p 1½"
185000030000
For Delta-p 2"
185000040000
zu Anschluss-Set Delta-p 1½" –2"
Delta-p 185 823
Delta-p-I 185 824
185000050000
Pressure maintaining valve
Refer to Technical
Information (TI) on
accessories
Spring-loaded diaphragm valve

Product description
19 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
3.5 Mineral solutions
Grünbeck Wasseraufbereitung GmbH confirms that the mineral substances contained in the
colourless liquid concentrates correspond to the publication of the list of treatment
substances and disinfection procedures in accordance with §11 of the German Drinking
Water Ordinance –19th amendment (status: December 2017).
Mineral solution
Effect
Material
exaliQ control
Rehabilitation
Galvanised pipes
For the rehabilitation of corroded zinc pipes (often recognisable by brown-coloured water).
After the rehabilitation (approx. 6 months): Change to a different exaliQ dosing agent.
exaliQ safe
Corrosion protection
Galvanised pipes and
copper materials/brass
For corrosion protection of water in the hardness range soft to medium (up to 14 °dH) as well as downstream of
water softeners. For water temperatures up to 60 °C. To reduce the introduction of heavy metals (e.g. lead).
exaliQ safe+
Corrosion protection and
hardness stabilisation
Galvanised pipes and
copper materials/brass
For hardness stabilisation and corrosion protection of water in the hardness range up to 21 °dH and to reduce
the introduction of heavy metals (e.g. lead). For water temperatures up to 60 °C. For water temperatures up to
60 °C. In case of a water hardness > 21 °dH, we recommend a water softener (e.g. softliQ:SD21) to treat the
hardness and then to change to exaliQ safe.
exaliQ pure
Hardness stabilisation
Galvanised pipes and
copper materials/brass
For circulation water in solar systems or installation of the dosing technology in the cold water inlet to the
decentralised water heater. For high temperatures up to 80 °C and/or hard water with a total hardness > 21 °dH
(total alkalinity > 15 °dH ).
Note: Copper and brass materials are only suitable for warm water. Consultation with Grünbeck
Wasseraufbereitung GmbH recommended prior to first application.
exaliQ neutra
Increase of pH value
Galvanised pipes and
copper materials/brass
Corrosion protection for soft water with high carbon dioxide concentrations as well as downstream of water
softeners.
Corrosion protection due to the binding of free carbon dioxide and an increase of the pH value.
Note: The mineral solution exaliQ neutra must not be used with dosing system GENODOS DME Delta-p. The
stand-alone dosing system GENODOS DME 6 –100 must be used.

Product description
20 | 64
BA-100174850000_en_034_GENODOS_DME 6-100_GENODOS DME Delta-p.docx
The shelf life of the mineral solutions is 2 years following the filling date (protected against
cold and light).
●Once the canister has been opened, it is recommended to use up the contents
within 6 months, but within 12 months at the latest.
When changing from the mineral solution to another dosing agent, the dosing system must
be flushed (refer to chapter 8.6).
The mineral solutions are hygienically packaged at the factory and sterilely sealed with a
secured screw cap.
The ready-to-use concentrates are designed for a pump capacity of 100 ml/m³ drinking water
flow.
3.5.1 Canister designs
Illustration
Product
Design
Order no.
15 L plastic canister, stackable
1 Canister is sufficient for drinking water
treatment of approx. 150 m3
exaliQ control
114 071
exaliQ safe
114 072
exaliQ safe+
114 073
exaliQ pure
114 074
exaliQ neutra
114 075
60 L plastic canister, stackable
1 Canister is sufficient for drinking water
treatment of approx. 600 m3
Conversion kit GENODOS DME,
60 L suction lance required
(refer to chapter 3.4).
exaliQ control
114 081
exaliQ safe
114 082
exaliQ safe+
114 083
exaliQ pure
114 084
exaliQ neutra
114 085
