Grundig GDK 2382 XB User manual

COOKER HOOD
GDK 2382 XB
EN

Please read this user manual first!
Dear Customer,
Thank you for purchasing this Grundig product. We hope that you get the best results form your
product which has been manufactured with high quality and starte-of-the-art technology.
Therefore, please read this entire user manual and all other accompanying documents carefully
before using the product and keep it as a reference for future use. If you handover the product to
someone else, give the user manual as well. Follow all warnings and information in the
user manual.
Remember that this user manual is also applicable for several othet models. Differences between
models will be identified in the manual.
Please visit the “Support” section on the Grundig website
www.grundig.co.uk.to register your 5 year warranty.
Grundig Helpline
0845 603 1234
0345 603 1234

4
1 Safety and set-up 6-7
2 At a glance 8
Control, parts and accessories . . . . . . 8
3 Operation 9-12
Wall drilling and bracket fixing . . . . . . 9
Mounting the hood body. . . . . . . . . . . 9
Connections ducted version
air exhaust system . . . . . . . . . . . . . . . . 9
Recirculation version air outlet . . . . . . 10
Electrical connection . . . . . . . . . . . . . 10
Chimnet assembly . . . . . . . . . . . . . . . 10
Upper exhaust chimney . . . . . . . . . . . 10
Lower exhaust chimney . . . . . . . . . . . 10
Grease filters . . . . . . . . . . . . . . . . . . . 12
Cleaning metal self-supporting
grease filters. . . . . . . . . . . . . . . . . . . . 12
Activated charcoal filter. . . . . . . . . . . 10
Activated charcoal filter
(Recirculation version) . . . . . . . . . . . . 12
Replacing the activated
charcoal filter . . . . . . . . . . . . . . . . . . . 12
Light replacement. . . . . . . . . . . . . . . . 12
4 Information 13
Technical data . . . . . . . . . . . . . . . . . . 13
Environmental note. . . . . . . . . . . . . . . 13
5 Guarantee 14
6 Service 15
TABLE OF CONTENTS _____________________

5
________________________________________________________
1
2
2.1
2.2
10
11
9
3
4
6
7
8
5

6
SAFETY AND SET-UP______________________
The Instructions for Use apply
to several versions of this ap-
pliance. Accordingly,you may
find descriptions of individual
features that do not apply to
your specific appliance.
Installation
7 The manufacturer will not be
held liable for any damages
resulting from incorrect or im-
proper installation.
7 The minimum safety distance
between the cooker top and
the extractor hood is 650 mm
(some models can be installed
at a lower height, please refer
to the paragraphs on working
dimensions and installation).
7 Check that the mains voltage
corresponds to that indicated
on the rating plate fixed to the
inside of the hood.
7 For Class I appliances, check
that the domestic power sup-
ply guarantees adequate
earthing. Connect the extrac-
tor to the exhaust flue through
a pipe of minimum diameter
120 mm. The route of the flue
must be as short as possible.
7 Do not connect the extractor
hood to exhaust ducts carry-
ing combustion fumes (boilers,
fireplaces, etc.).
7 If the extractor is used in con-
junction with non-electrical
appliances (e.g. gas burning
appliances), a sufficient de-
gree of aeration must be guar-
anteed in the room in order
to prevent the backflow of
exhaust gas. The kitchen must
have an opening communicat-
ing directly with the open air
in order to guarantee the entry
of clean air.
Use
7 The extractor hood has been
designed exclusively for do-
mestic use to eliminate kitchen
smells.
7 Never use the hood for pur-
poses other than for which it
has been designed.

7
SAFETY AND SET-UP______________________
7 Never leave high naked
flames under the hood when
it is in operation.
7 Adjust the flame intensity to
direct it onto the bottom of the
pan only, making sure that it
does not engulf the sides.
7 Deep fat fryers must be contin-
uously monitored during use:
overheated oil can burst into
flames.
7 Do not flambè under the
range hood; risk of fire.
7 This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given supervi-
sion or instruction concerning
use of the appliance in a safe
way and understand the haz-
ards involved. Children shall
not play with the appliance.
Cleaning and user mainte-
nance shall not be made by
children without supervision.
7 Children should be supervised
to ensure that they do not play
with the appliance.
Maintenance
7 Switch off or unplug the ap-
pliance from the mains supply
before carrying out any main-
tenance work.
7 Clean and/or replace the Fil-
ters after the specified time pe-
riod (Fire hazard).
7 Clean the hood using a damp
cloth and a neutral liquid de-
tergent.

8
AT A GLANCE____________________________
Control, parts and accessories
See the figure on page 3.
1 Hood Body, complete with: Controls, Light,
Blower, Filters
2 Telescopic Chimney comprising:
2.1 Upper Section
2.2 Lower Section
3 Air Outlet Connection
4 Air Outlet Connection Extension
5 Screws 4,2 x 44,4
6 Upper Chimney Section Fixing Brackets
7 Wall Plugs
8 Screws 2,9 x 9,5
9 Hood Body Air Outlet Extension Piece
consisting of two Half Shells
10 Reducer Flange ø 150-120 mm
11 Damper
GDK 2382 XB
Depth 345 mm
Width 598 mm
Min Height 730-1060 mm
Supply voltage 220-240 Volt 50 Hz
Control 4 positions
Suction power 355/550/640/740 m3
Motor power 275 W
Lamp power 2x20 W
To t a l p ow e r 315 W
Fuse 150 mm
Air outlet pipe
diameter 120-150 mm
Net weight 11,7 kg
Gross weight 16.3 kg
Color Inox

9
OPERATION________________________________
Wall drilling and bracket
fixing
Wall marking:
7 Draw a vertical line on the supporting wall up
to the ceiling, or as high as practical, at the
centre of the area in which the hood will be
installed.
7 Draw a horizontal line at 650 mm above the
hob. Place bracket 6 Screws 2,9 x 9,5 on
the wall as shown about 1-2 mm from the ceil-
ing or upper limit aligning the centre (notch)
with the vertical reference line.
7 Mark the wall at the centres of the holes in
the bracket.
7 Place bracket 6 on the wall as shown at X
mm below the first bracket (X = height of the
upper chimney section supplied), aligning the
centre (notch) with the vertical line.
7 Mark the wall at the centres of the holes in
the bracket.
7 Mark a reference point as indicated at 116
mm from the vertical reference line and 306
mm above the horizontal reference line.
7 Repeat this operation on the other side.
7 Drill ø 8 mm holes at all the centre points
marked.
7 Insert the wall plugs 7 in the holes.
7 Fix the brackets using the 8 (4,2 x 44,4)
screws supplied.
7 Insert the two screws 8 (4,2 x 44,4) supplied
in the hood body fixing holes, leaving a gap
of 5-6 mm between the wall and the head of
the screw.
Mounting the hood body
7 Before attaching the hood body, tighten the
two screws Vr located on the hood body
mounting points.
7 Hook the hood body onto the screws 8.
7 Fully tighten the support screws 8.
7 Adjust the screws Vr to level the hood body.
Connections
Ducted Version Air Exhaust
System
When installing the ducted version, connect the
hood to the chimney using either a flexible or
rigid pipe ø 150 or 120 mm, the choice of which
is left to the installer.
7 To install a ø 120 mm air exhaust connection,
insert the reducer flange 9 on the hood body
outlet.
7 Fix the pipe in position using sufficient pipe
clamps (not supplied).
7 Remove possible charcoal filters.

10
OPERATION________________________________
Recirculation Version Air
Outlet
7 Assemble the two halves of the hood body
extension piece 14.
7 Push fit the assembled hood body extension
piece 14 onto the air outlet.
7 Push fit connection 15 onto the hood body
extension piece 14.
7 Insert the connection extension pieces later-
ally 14.1 in connection 15.
7 Make sure that the outlet of the extension
pieces 14.1 is horizontally and vertically
aligned with the chimney outlets.
7 If this is not the case, adjust the position by ei-
ther reversing the connection extension pieces
14.1 or by cutting the hood body extension
14 along one of the thinner section channels
denoting the prefixed lengths, then reassem-
ble as described previously.
7 Ensure that the activated charcoal filters have
been inserted.
Electrical Connection
7 Connect the hood to the mains through a two-
pole switch having a contact gap of at least
3 mm.
7 Remove the grease filters (see paragraph
Maintenance) being sure that the connector
of the feeding cable is correctly inserted in the
socket placed on the side of the fan.
Chimney assembly
Upper exhaust Chimney
7 Slightly widen the two sides of the upper chim-
ney and hook them behind the brackets 6,
making sure that they are well seated.
7 Secure the sides to the brackets using the 4
screws 8 (2,9 x 9,5) supplied.
Lower exhaust Chimney
7 Slightly widen the two sides of the chimney and
hook them between the upper chimney and the
wall, making sure that they are well seated.
7 Fix the lower part laterally to the hood body
using the 2 screws 8 (2,9 x 9,5) supplied.

11
OPERATION________________________________
Control Panel
The hood can be switched on pushing directly onto the requested speed without firstly having to
select 0/1 button.
FunctionsLedKey
Turns the motor off.
_
T1
Turns the motor on at speed one.SpeedT2
Turns the motor on at speed two.SpeedT3
Press and hold for 2 seconds to switch on and off the function Delay.
Enable the automatic switch off (motor+lights) delayed of 30 sec-
onds. Useful to remove residual smells. It can be activated when the
Intensive speed is turned off; it turns off pressing the button or switch-
ing the motor off.
The relevant speed
LED flashes once
Turns the motor on at speed three.FixedT4
Turns the function Intensive on and off.
This speed is timed to run for 10 minutes At the end of this time, the
system returns automatically to the speed that was set before. It turns
off pressing the button or switching the motor off. It can’t be activated
when the Delay is turned on.
Flashing twice per
second
Turns the lights on/off at maximum strength
_
L

12
OPERATION________________________________
Grease Filters
Cleaning Metal Self- Sup-
porting Grease Filters
7 The filters must be cleaned every 2 months of
operation, or more frequently for particularly
heavy usage, and can be washed in a dish-
washer.
7 Remove the filters one at a time holding them
up with one hand and pulling the handle
downwards with the other hand at the same
time.
7 Wash the filters, taking care not to bend them.
Allow them to dry before refitting.
7 When refitting the filters, make sure that the
handle is visible on the outside.
Activated Charcoal Filter
(Recirculation Version)
Replacing The Activated
Charcoal Filter
7 The filter is not washable and cannot be
regenerated, and must be replaced approxi-
mately every 4 months of operation, or more
frequently for particularly heavy usage.
7 Remove the metal grease filters.
7 Remove the saturated activated carbon filter
by releasing the fixing hooks.
7 Fit the new filter by hooking it into its seating.
7 Refit the metal grease filters.
Lighting
Light Replacement
20 W Halogen Light.
7 Remove the snap-on lamp cover by levering
it from under the metal ring, supporting it with
one hand.
7 Remove the halogen lamp from the lamp
holder by pulling gently.
7 Replace the lamp with a new one of the same
type, making sure that you insert the two pins
properly into the housings on the lamp holder.
7 Replace the snap-on lamp cover.

13
Technical data
This product conforms to European
Directives 2004/108/EC,
2006/95/EC, 2009/125/EC and
2011/65/EU.
Power supply
Operating voltage:
220-240V~, 50Hz 220 V~, 60 Hz
Technical and design modifications reserved!
Environmental note
The symbol on the product or on its pack-
aging indicates that this product may not
be treated as household waste. Instead it
shall be handed over to the applicable
collection point for the recycling of elec-
trical and electronic equipment. By ensuring this
product is disposed of correctly, you will help pre-
vent potential negative consequences for the envi-
ronment and human health, which could otherwise
be caused by inappropriate waste handling of this
product. For more detailed information about recy-
cling of this product, please contact your local city
office, your household waste disposal service or
the shop where you purchased the product.
INFORMATION _____________________________

GUARANTEE________________________________
Guarantee for Refrigeration, Cooking Appliance, Washing Machines & Dishwashers
Your new Grundig product is guarenteed against the cost of breakdown repairs for 5 years from the
daie of the orginals purchase.
“Please visit the “support” section on the Grundig website at www.grundig.co.uk to
register your 5 year warranty.
What is covered?
• Repairs necessary as a result of faulty materisals, defective components or manufacturing defect.
• The cost of functional replacement paris, but excluding consumable items.
• The labour costs of a Grundig approved repairer to carry out the repair.
What is note covered?
• Transil, delivery or accidental damage or misuse and abuse.
• Cabiner or appearance parts, including knobs, flobs, handles or container lids.
• Accessories or consumable items including but not limited to, ice trays, scropers, cutlery baskets, filiers
and light bulbs.
• Repairs required as a result of unauthorised repair or inexport installation that fails to meet the
requirements contained in the user instruction book.
• Repairs to products used on commercial or non residential household premises.
• Loss of frozen food in freezers or fridge/freezers. (Food loss insurance is often inckuded within your
household contents insuarence policy, or may be available separately from your retailer.)
Important notes
• Your Grundig product is designed and built for domestic household use only.
• the guarantee will be vold if the product is installed or used in commercial or non-residential domestic
household premises.
• The product must be correctly insalled, located and operated in accordance with the instructions
contained in the User Instructions Booklet provided.
• Professional installation by a qualified Electrical Domestic Appliance Insttaller is recommended for all
Washing Machines, Dishwashers and Electric Cookers
• Gas Cookers must only be installed by a Gas Safe (or BORD GAIS) registered Gas Intaller.
• The guarantee is given only within the boundaries of the United Kingdom and the Republic of Ireland.
• The guarantee is applicable only to new products and is note transferable if the product is resold.
• Grındig disclains any liability for incidental or consequential damages.
• The guarantee does not in anyway diminsh your statutory or legal rights.
Should you experience any difficulty in obtaining service please contact the Grundig Customer
Helpline.
Tel : [phone]
0345 603 1234
e-mail : ser[email protected]

Service _____________________________________
Please keep your purchase receipt or other proof of purchase in a safe place; you will need to have it
should the product require attention under guarantee.
You should also complete the details below; it will help us assist you when requesting service. (The
model number is printed on the Instruction Booklet and the serial number is printed on the Rating Label
affixed to the appliance)
Model No:
Serial No:
Retailer:
Date of purchase:
For service under guarantee simply telephone the appropriate number below UK
Mainland & Northern Ireland
0845 603 1234
0345 603 1234
Republic of Ireland
All Refrigeration, All Cookers
Washing Machines and Dishwashers
01 862 34 11
Before requesting service please check the trouble- shooting guide in the Operating
Instructions as a charge may be levied where no fault is found even though your
product may still be under guarantee. Service once the manufacturers guarantee has
expired.
If you have purchased an exlended guarantee please refer to the instructions contained within the
extended guarantee agreement document. Otherwise please call the appropriate number above where
service can be oblained at a charge.
Grundig, 1 Greenhill Crescent, Watford Herts WD18 8QU

FOR A GOOD REASON
