Grundig GDKP5485BBSCH User manual

Hood / User Manual
Dunstabzugshaube / Bedienungsanleitung
Hotte murale / Manuel d’utilisation
Afzuigkap / Gebruiker Handleiding
GDKP5485BBSCH
185732357_1/ EN/ DE/ FR/ NL/ R.AB/ 10-2-2023 11:49
7703331112
EN
DE
FR
NL

EN / 2
Welcome!
Dear Customer,
Thank you for choosing the Grundig product. We want your product, manufactured with
high quality and technology, to offer you the best efficiency. Therefore, carefully read this
manual and any other documentation provided before using the product.
Keep in mind all the information and warnings stated in the user’s manual. This way, you
will protect yourself and your product against the dangers that may occur.
Keep the user’s manual. If you give the product to someone else, give the manual with it.
The warranty conditions, usage and troubleshooting methods for your product are
provided in this manual.
The symbols and their descriptions in the user’s manual:
Hazard that may result in death or injury.
Important information or useful usage tips.
Read the user’s manual.
Hot surface warning.
NOTICE Hazard that may result in material damage to the product or its environment.

EN / 3
Table of Contents
1 Safety Instructions........................ 4
1.1 General Safety ............................... 4
1.2 Electrical Safety............................. 5
1.3 Product Safety............................... 6
1.4 Intended Use.................................. 8
1.5 Child, Vulnerable Persons and
Pet Safety.......................................
8
1.6 Transportation Safety ................... 8
2 Environmental Instructions.......... 9
2.1 Waste Directive.............................. 9
2.1.1 Compliance with the WEEE Dir-
ective and Disposing of the
Waste Product ...........................
9
2.2 Package Information..................... 9
3 Your product ................................. 10
3.1 Product Introduction ..................... 10
3.2 Product Accessories..................... 10
3.3 Technical Specifications............... 12
4 Using the Hood ............................. 13
5 Maintenance and Cleaning .......... 18
5.1 General Cleaning Information....... 18
5.2 Aluminium Filter ............................ 19
5.3 Hood Lamp .................................... 19
5.4 Carbon Filter (Usage without a
flue) ................................................
19
6 Troubleshooting ........................... 20
EN
DE
FR
NL

EN / 4
1 Safety Instructions
• This section includes the
safety instructions necessary
to prevent the risk of personal
injury or material damage.
• If the product is handed over
to someone else for personal
use or second-hand use pur-
poses, the user’s manual,
product labels and other relev-
ant documents and parts
should also be given.
• Our company shall not be held
responsible for damages that
may occur if these instructions
are not observed.
• Failure to follow these instruc-
tions shall void any warranty.
• Always have the installation
and repair works made by the
manufacturer, the authorised
service or a person that the im-
porter company shall desig-
nate.
• Use original spare parts and
accessories only.
• Do not repair or replace any
component of the product un-
less it is clearly specified in the
user’s manual.
• Do not make technical modific-
ations on the product.
1.1 General Safety
• This product can be used by
children 8 years of age and
older, and people who are un-
derdeveloped in physical, sens-
ory or mental skills, or who
have lack of experience and
knowledge, as long as they are
supervised or trained about the
safe use and hazards of the
product. Children should not
play with the appliance. Clean-
ing and user maintenance
must not be made by children
without supervision.
•Poisoning Danger! While the
appliance is operating, air is
drawn from the whole house. If
adequate ventilation is not
provided, air flow occurs and
the waste and toxic gases re-
leased as a result of combus-
tion in the house are reab-
sorbed. Do not operate the
product together with products
that provide air circulation and
may emit toxic gas (wood, gas,
oil and coal stoves, boilers, wa-
ter heaters, etc.).
• Have the adequacy of your
building's ventilation and flue
system checked by authorized
persons.

EN / 5
• This product is not intended
for use by persons (including
children) with limited physical,
sensory or mental capacity or
without knowledge or experi-
ence, unless supervised or in-
structed by the individual re-
sponsible for their safety. Chil-
dren should be supervised to
ensure that they do not play
with the product. Cleaning and
user maintenance must not be
made by children without su-
pervision.
• Installation and repair proced-
ures must always be per-
formed by Authorised Service
Agents. The manufacturer can-
not be held responsible for any
damages that may arise due to
operations made by unauthor-
ized persons.
• Do not operate the product if it
is defective or has any visible
damage.
• Ensure that the product func-
tion knobs are switched off
after every use.
• If the product is handed over
to someone else for personal
use or second-hand use pur-
poses, the user’s manual,
product labels and other relev-
ant documents and parts
should also be given.
• Call the authorized service for
the installation of the product
to be used. The warranty term
starts after this process.
• Product must be installed by a
qualified person in accordance
with the regulations in force
for the warranty to be applic-
able.
1.2 Electrical Safety
• To have your product ready for
use, first provide the place of
installation and have the elec-
trical installation made. Then,
call the nearest Authorised
Service.
• If the product has a failure, it
should not be operated unless
it is repaired by an Authorised
Service Agent. There is the risk
of electric shock!
• Do not plug your hood in until it
is mounted.
• If your product has plug, never
touch the plug with wet hands!
Never unplug by pulling on the
cable, always pull out by hold-
ing the plug.
• The appliance power should be
cut off during installation,
maintenance, cleaning and re-
pair processes.
• In order to prevent any hazard
from occurring, in case of
damage, the electrical cable
must be replaced by the manu-
EN
DE
FR
NL

EN / 6
facturer, the manufacturer's
service centre or a similar
qualified person.
• If the cable is damaged, con-
tact our nearest service centre
and have a new one installed.
• If your product has plug, do not
make electrical connections by
disconnecting the plug during
installation. Connections made
by cutting off render the
product warranty void and
pose a danger to user safety.
• Do not install the mains cord
near the heaters. The cable
might melt, causing a fire.
• If your product does not have a
cable, only use the connecting
cable described in the "Tech-
nical specifications" section.
• Any work on electrical equip-
ment and systems should only
be carried out by authorised
and qualified persons.
• In case of any damage, switch
off the product and disconnect
it from the mains. To do this,
turn off the fuse at home.
• Make sure that fuse rating is
compatible with the product.
• Never wash the appliance by
spraying or pouring water on it!
There is the risk of electric
shock!
1.3 Product Safety
• Height between the bottom
surface of your hood and the
top surface of the oven should
be no less than 650 mm.
• Do not touch the lamps of your
hood after operating the hood
for a long time. Hot lamps may
burn your hand.
• Do not operate the appliance
without an oil entrapment fil-
ter. Do not remove the filters
while the appliance is operat-
ing.
• Do not create a high flame un-
der the product. Otherwise, the
oil in the oil trap filter may ig-
nite, causing a fire.
• Run the product after placing
the cooking pots, pans, etc. on
the ovens. Otherwise, rising
heat may deform some parts
of your product.
• Turn off the oven before taking
the cooking pots, pans, etc.
from the ovens.
• Do not keep easily flammable
materials under your hood.
• Do not expose the appliance to
open flame. It may cause the
oil accumulating in the filter to
catch fire. Do not operate the
appliance without a filter.

EN / 7
• Do not leave your cooker unat-
tended while cooking fried
foods, oils may catch fire while
cooking, and hot oil may cause
fire. Therefore pay attention to
the clothes and curtains.
• If cleaning is not performed in
a timely manner, the hood may
present a risk of fire.
• (For Models A and B) Run your
hood for another 15 minutes
after the cooking or frying pro-
cess to clean the kitchen air
thoroughly of the odours and
vapours generated during
cooking.
• Adequate ventilation must be
available in the room when gas
or other fuel-burning appli-
ances are used at the same
time while the oven hood with
a cooker is being used. (Not
applicable for only the appli-
ances that discharge air back
into the room).
• Gas or fuel oil burning appli-
ances, such as room heaters,
which share the same environ-
ment with the hood, must be
fully insulated from the ex-
haust of this product or they
must be hermetical.
• If there is another appliance
operating with fuel oil or
gaseous fuels in the environ-
ment, adequate ventilation of
the environment is required.
• If there is another appliance
operating with energy other
than electrical energy in the
same environment with the
hood, the negative pressure in
the room should be at most
0.04 mbar so that the exhaust
of the other appliance is not
drawn back into the room by
the hood.
• Do not connect to flues with
heating stove connection, flues
where waste gas is disposed
from or flues with rising
flames. Comply with local reg-
ulations on purging the out-
flow.
• Use pipes with a diameter of
120 mm when connecting a
flue to your product. The pipe
connection should be as short
as possible and with few
bends.
• Easily flammable and com-
bustible materials should not
be hung on the hood handles.
• Our company shall not be re-
sponsible for problems that
arise for not observing any of
the warnings above.
• There is a risk of fire if clean-
ing is not carried out in accord-
ance with the instructions.
• There should not be open fire
under the hood. (for example:
flambe)
EN
DE
FR
NL

EN / 8
•Caution: Accessible parts can
heat up when used with a
cooker.
• It is recommended to clean the
filter once a month under nor-
mal usage.
1.4 Intended Use
• This product is designed for
home use. Commercial use
will void the guarantee.
• The manufacturer assumes no
responsibility for any damage
due to misuse or mishandling.
• The service life of the product
you have purchased is 10
years. Manufacturer shall
provide the required spare
parts for the product to per-
form as defined during this
period.
1.5 Child, Vulnerable
Persons and Pet Safety
• Keep children away from the
product when it is running.
• Children should not play with
the product. Cleaning and user
maintenance should not be
performed by children unless
there is someone overseeing
them.
• This product should not be
used by people with limited
physical, sensory or mental ca-
pacity (including children), un-
less they are kept under super-
vision or receive the necessary
instructions.
• The packaging materials are
dangerous for children. Keep
the packaging materials out of
the reach of children or sort
them into waste according to
waste instructions.
• Electrical products are danger-
ous for children and pets. Keep
children away from the
product while it is operated
and do not let them play with
the product.
1.6 Transportation
Safety
• Disconnect the product from
the mains before transporting
the product.
• Do not put other items on the
product and carry the product
upright.
• When you need to transport
the product, wrap it with
bubble wrap packaging mater-
ial or thick cardboard and tape
it tightly. Secure the product
tightly with tape to prevent the
removable or moving parts of
the product and the product
from getting damaged.

EN / 9
• Check the overall appearance
of the product for any damage
that may have occurred during
transportation.
2 Environmental Instructions
2.1 Waste Directive
2.1.1 Compliance with the WEEE Dir-
ective and Disposing of the
Waste Product
This product complies with EU WEEE Dir-
ective (2012/19/EU). This product bears a
classification symbol for waste electrical
and electronic equipment (WEEE).
This product has been manu-
factured with high quality parts
and materials which can be re-
used and are suitable for recyc-
ling. Therefore, do not dispose
of the waste product with nor-
mal domestic and other wastes at the end
of its service life. Take it to a collection
point for the recycling of electrical and elec-
tronic equipment. You can ask your local
administration about these collection
points. Disposing of the appliance properly
helps prevent negative consequences for
the environment and human health.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
2.2 Package Information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the pack-
aging waste with the household or other
wastes, take it to the packaging material
collection points designated by the local
authorities.
EN
DE
FR
NL

EN / 10
3 Your product
3.1 Product Introduction
1
2
3
4
56
7
8
1 Hood body 2 Control panel
3 Lamp 4 Aluminium filter lock
5 Aluminium filter 6 Aluminium filter
7 Aluminium filter lock 8 Lamp
* Dependent on the model. It may not be avail-
able on your product.
3.2 Product Accessories
Depending on the product model, the sup-
plied accessory varies. All accessories de-
scribed in the user’s manual may not be
available in your product.
Wall mounting part
