GSi Beta 40 Series User manual

®
54 Ft. (16.46 m) Diameter Metric
Roof Assembly - Beta
Models:
40-SERIES 4.00" CORRUGATION SILO
Assembly Manual
PNEG-M4054B
Version 1.0
Date: 09-04-19
PNEG-M4054B

All information, illustrations, photos, and specifications in this manual are based on the latest
information available at the time of publication. The right is reserved to make changes at any
time without notice.
2PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

Contents
Chapter 1 Safety Precautions ....................................................................................................................5
Safety Guidelines........................................................................................................................5
Safety Decals .............................................................................................................................9
Safety Sign-off Sheet.................................................................................................................10
Chapter 2 Roof Assembly........................................................................................................................11
Parts List .................................................................................................................................. 11
Bolt Torque Specifications..........................................................................................................18
Roof Assembly..........................................................................................................................19
Chapter 3 Roof Accessories....................................................................................................................41
Inspection Port Cover ................................................................................................................42
Roof Vent Assembly ..................................................................................................................43
Limited Warranty — EME Grain Products ................................................................................45
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 3

NOTES
4PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

1Safety Precautions
Topics Covered in this Chapter
▪ Safety Guidelines
▪ Safety Decals
▪ Safety Sign-off Sheet
Safety Guidelines
Follow Safety Instructions
Use Personal Protective Equipment
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 5

Chapter 1: Safety Precautions
Do Not Enter Bin
Prevent Roof Damage due to Vacuum Pressure
6PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

Chapter 1: Safety Precautions
Unload Bin Correctly
Do Not Overfill the Bin
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 7

Chapter 1: Safety Precautions
Stay Clear of Hoisted Equipment Sharp Edge Hazard
Store Bin Sheets Properly
Install and Operate Equipment Properly
Rotating Auger Hazard
8PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

Chapter 1: Safety Precautions
Safety Decals
To replace a damaged or missing decal, contact GSI to receive a free replacement.
Location Decal No. Decal
A DC-2306
B DC-2161
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 9

Chapter 1: Safety Precautions
C DC-2210
Safety Sign-off Sheet
Date Employee Name Supervisor Name
ST-0007
10 PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

2Roof Assembly
Topics Covered in this Chapter
▪ Parts List
▪ Bolt Torque Specifications
▪ Roof Assembly
Parts List
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 11

Chapter 2: Roof Assembly
12 PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

Chapter 2: Roof Assembly
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 13

Chapter 2: Roof Assembly
14 PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

Chapter 2: Roof Assembly
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 15

Chapter 2: Roof Assembly
16 PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

Chapter 2: Roof Assembly
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 17

Chapter 2: Roof Assembly
Table 2-1 Hardware list
S.No Part No Description
1 S-BFUBM08030BF M08 x 30N flange bolt with LPDE sealing washer
2 S-BFUBM10025BF M10 x 25N flange bolt with LPDE sealing washer
3 S-BFSBM10025BN M10 x 25N flange bolt
4 S-BFSBM10035BN M10 x 35N flange bolt
5S-BFUBM12035BF M12 x 35N flange bolt with LPDE sealing washer
6 S-BNIWM10 M10 standalone sealing washer
7 S-BFSBM08B M08 flange nut
8 S-BFSBM10B M10 flange nut
9 S-BFSBM12B M12 flange nut
Bolt Torque Specifications
IMPORTANT: Bolts should not be tightened in excess of the torque specifications chart listed below.
Bolt
Recommended Maximum Torque
Sealing Joints
(joints with sealing washers)
Structural Joints
(joints without any sealing washers)
N-m N-m
M8 JS500 Grade 10.9 with Seal 27.5 -
M10 JS500 Grade 10.9 with Seal 54 -
M12 JS500 Grade 10.9 with Seal 94.5 -
M10 JS500 Grade 10.9 Flanged - 54
M12 JS500 Grade 10.9 Flanged - 94.5
18 PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof

Chapter 2: Roof Assembly
Roof Assembly
Figure 2-1 Attaching the inside stiffener to the top outside stiffener
Figure 2-2 Attaching the eave bracket to the inside stiffener
PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof 19

Chapter 2: Roof Assembly
Figure 2-3 Eave angle alignment
Figure 2-4 Attaching the eave angle to the sidewall sheet
20 PNEG-M4054B 54 Ft. (16.46 m) Diameter Beta Roof
