GSS PHDQ 1000 ASI DF User manual

English
CLASS
KLASSE
PHDQ 1000 ASI LAN
PHDQ 1001
HDTV Digital QAM
GSS
Grundig SAT Systems GmbH
Beuthener Strasse 43
D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877
Fax: +49 (0) 911 / 703 9210
E-mail: [email protected]
Internet: http://www.gss.de

- 2 - PHDQ 1000 ASI LAN / PHDQ 1001
Contents
1 Safety regulations and notes........................................................................4
2 General information ....................................................................................5
2.1 Packing contents..............................................................................5
2.2 Meaning of the symbols used ............................................................5
2.3 Technical data.................................................................................5
2.4 Description......................................................................................6
Input signal path "INROUTE" ............................................................7
Menu setting "A+ASI = 1 B+ASI = 2" ...........................................7
Menu setting "A+B+ASI = 1 ASI = 2" ...........................................7
Menu setting "A+ASI = 1 A+ASI = 2"...........................................7
Output signal path "OUTROUTE".......................................................8
Menu setting "ASI => ASI".............................................................8
Menu setting "1 => ASI ASI => MA" ............................................8
Menu setting "2 => ASI ASI => MB".............................................8
General..........................................................................................9
2.5 Software query................................................................................9
2.6 How the TPS module works.............................................................10
Station filter ...............................................................................10
Stuffing......................................................................................10
Changing the Transport stream and ORGNET-ID.............................10
Changing the NIT.......................................................................10
Changing the operator ID (CAT) ...................................................10
2.7 Explanation of the term "symbol rate" ..............................................11
Reception from a transponder with a very low symbol rate (SCPC station).... 11
Defined symbol rates...................................................................11
3 Assembly..................................................................................................12
3.1 Installing the cassette......................................................................12
3.2 EMC regulations............................................................................13
3.3 Cassette overview..........................................................................14
3.4 Connecting the cassette ..................................................................14
3.4 Retrofitting a CA module.................................................................15
4 The control panel at a glance.....................................................................16
4.1 Menu items ...................................................................................16
4.2 Control panel ................................................................................16
5 Programming............................................................................................17
5.1 Preparation...................................................................................17
5.2 Notes on level setting .....................................................................17

- 3 - PHDQ 1000 ASI LAN / PHDQ 1001
5.3 Programming procedure .................................................................18
5.4 Programming the cassette ..............................................................21
Selecting the cassette ..................................................................21
Selecting the input signal path......................................................22
Selecting the output signal path ....................................................22
Setting the ASI transfer rate..........................................................23
Setting the ASI options ................................................................23
Selecting the channel strip ...........................................................24
Selecting channel / frequency setting............................................24
Setting the output channel............................................................25
Setting the output frequency .........................................................25
Switching the modulator off or on .................................................26
Adjusting the output levels of the channel strips...............................26
Setting the LNB oscillator frequency ..............................................27
Setting the input symbol rate ........................................................27
Setting the DVB mode..................................................................27
Setting the input frequency...........................................................28
Testing the signal to noise ratio.....................................................29
Setting the station filter ................................................................30
Setting the QAM modulation .........................................................33
Inverting the user signal...............................................................33
Setting stuffing............................................................................34
Setting a substitute signal in the case of an incorrect input signal .....35
Setting the transport stream ID and the ORGNET-ID.........................35
Network Information Table (NIT)...................................................36
Network/operator identification ...................................................37
Deleting a PID ............................................................................38
Renaming a PID..........................................................................38
Factory reset ..............................................................................39
Saving settings ...........................................................................39
Operation with a CA module ..........................................................40
Setting the scrambling .................................................................40
Setting the PID monitoring............................................................41
Configuring the CA module .........................................................41
Setting the station filter ................................................................43
6 Final procedures........................................................................................44
7 Channel and frequency tables....................................................................45

- 4 - PHDQ 1000 ASI LAN / PHDQ 1001
1 Safety regulations and notes
• Assembly,installationandservicingshould becarriedout byauthorised
electricians.
 • Switchofftheoperatingvoltageofthesystembeforebeginningwithassem-
bly or service work or pull out the mains plug.
 • Donotperforminstallationandserviceworkduringthunderstorms.
 • Installthesystemsoitwillnotbeabletovibrate…
 - inadust-free,dryenvironment
 - insuchamannerthatitisprotectedfrommoisture,fumes,splashingwa-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +50 °C. In case of the formation of
condensation wait until the system is completely dried.
 • Ensurethatthehead-endstationisadequatelyventilated.Donotcoverthe
ventilation slots.
 • Bewareofshortcircuits
 • Noliabilityisacceptedforanydamagecausedbyfaultyconnectionsor
inappropriate handling.
 • Observetherelevantstandards,regulationsandguidelinesontheinstalla-
tion and operation of antenna systems.
 • ThestandardsIEC/EN/DINEN50083resp.IEC/EN/DINEN60728must
be observed.
 • For further information please read the assembly instructions for the head-
end station used.
• Test the software versions of the head-end station and the cassette and
update them if necessary. The current software versions can be found at
"www.gss.de".
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.

- 5 - PHDQ 1000 ASI LAN / PHDQ 1001
2 General information
2.1 Packing contents
1 Cassette PHDQ 1000 ASI LAN or PHDQ 1001
2 HF cables
1 Brief assembly instructions
1 Measuring log
2.2 Meaning of the symbols used
Important note
—> General note
 •  Performingworks
2.3 Technical data
The devices meet the following EU directives:
 2006/95/EC,2004/108/EC
The product fulfils the guidelines and standards for CE labelling (page 46).
Unless otherwise noted all values are specified as "typical".
HF input
Frequency range:......................................................... 925…2150MHz
Level range: .............................................................60dBμV…80dBμV
DVB-S modes: ..............................................DVB-S 1/2 ,2/3 ,3/4 ,5/6 ,7/8
DVB-S2 modes: ......................QPSK 1/2 ,3/5 ,2/3 ,3/4 ,4/5 ,5/6 ,8/9 ,9/10
8PSK 3/5 ,2/3 ,3/4 ,5/6 ,8/9 ,9/10
Symbol rate DVB-S:...........................................QPSK: 2…45MSymb/s
Symbol rate DVB-S2:.........................................QPSK:10…30MSymb/s
 8PSK:10…31MSymb/s
HF output
Channels: .............................................................................S21…C69
Frequency range:............................................... 42.0MHz…860.0MHz
Output level: ............................................................................. 97 dBμV
Output impedance:......................................................................... 75 Ω

- 6 - PHDQ 1000 ASI LAN / PHDQ 1001
Connections
SAT inputs:.............................................................................2 F sockets
HF output:............................................................................1 IEC socket
ASI input: .................................................................1BNCsocket,75Ω
ASI output:................................................................1BNCsocket,75Ω
Connection strip (10-pin):...................for supply voltages and control circuits
RS-232 socket: ..................................... serial interface for software update
Conditional access:...........................several channels can be descrambled.
Remote maintenance
Remotely controllable (via PSW 1000*):...............................................yes
Remote update (via BEflash*):..............................................................yes
(* and a corresponding management unit)
2.4 Description
 ThedoubletransmodulatorcassetteisaQPSK-converter,whichconvertsall
stations modulated according to DVB-S / DVB-S2 standard into two QAM-
modulated cable signals. The cassette has two digital SAT IF inputs and one HF
output. Additionally it is equipped with an ASI input and an ASI output (ASI –
Asynchronous Serial Interface acc. DIN EN 50083-9).
The transport stream fed via the ASI socket can be inserted into the transport
streams of the receiving stages via the TPS module. T he signal path is set in the
menu items input signal path "INROUTE" and output signal path "OUTROUTE" .

- 7 - PHDQ 1000 ASI LAN / PHDQ 1001
Input signal path "INROUTE"
Menu setting "A+ASI = 1 B+ASI = 2"
The transport streams of the receiving stage "TS A" and of the ASI input
"TSASI" generate the transport stream 1. The transport streams of the receiv-
ing stage "TS B" and of the ASI input "TS ASI" generate the transport stream 2.
Transport stream 1
Transport stream 2
SAT input ”A“
ASI input
SAT input ”B“
Receiving stage
"A"
Receiving stage
"B"
TPSCA module
TPS
TS ASI
TS A
TS B
Menu setting "A+B+ASI = 1 ASI = 2"
The transport streams of the receiving stages "TS A" and "TS B" and of the ASI
input "TS ASI" generate the transport stream 1. The "TS ASI" transport stream
fed via the ASI input generates the transport stream 2.
Transport stream 1
ASI input
TPS
SAT input ”A“
SAT input ”B“
Receiving stage
"A"
Receiving stage
"B"
CA module
Transport stream 2
TS B
TS A
TS ASI
Menu setting "A+ASI = 1 A+ASI = 2"
The transport streams of the receiving stage "A" "TS A" and of the ASI input
"TS ASI" are split into transport stream 1 and 2. Receiving stage "B" is not
used .
TS A
Transport stream 1
Transport stream 2
SAT input ”A“
ASI input
Receiving stage
"A"TPS
CA module
TPS
TS ASI

- 8 - PHDQ 1000 ASI LAN / PHDQ 1001
Output signal path "OUTROUTE"
Menu setting "ASI => ASI"
Transport stream 1 is made available via modulator "A",transportstream2via
modulator "B" and the transport stream from the ASI input "TS ASI" via the ASI
output.
Transport stream 1
Transport stream 2
HF output
ASI input
Modulator
"B"
ASI output
Modulator
"A"
Combiner
TS ASI
Menu setting "1 => ASI ASI => MA"
 Transportstream1ismadeavailableviatheASIoutput,transportstream2
via modulator "B" and the transport stream from the ASI input "TS ASI" via
modulator "A" (MA).
Modulator
"B"
Modulator
"A"
Combiner
TS ASI
Transport stream 1
ASI input
Transport stream 2
HF output
ASI output
Menu setting "2 => ASI ASI => MB"
Transport stream 1 is made available via modulator "A",transportstream2
via the ASI output and the transport stream from the ASI input "TS ASI" via
modulator "B" (MB).
HF output
ASI output
Modulator
"B"
Modulator
"A"
Combiner
TS ASI
Transport stream 1
ASI input
Transport stream 2

- 9 - PHDQ 1000 ASI LAN / PHDQ 1001
General
The cassette is equipped with two channel strips (" A " and " B "). The channel
stripsconsistofthedigitaltuners,thedigitalsignalpreparationunitsandthe
output converter. The channel strips are indicated in the head-end station dis-
play with "Bx …A" and "Bx …B". Using an adequate CA module scrambled
channels can be descrambled via channel strip "A". In addition cassette PHDQ
1001 is able to scramble unscrambled channels via an adequate CA module.
The control of the cassette takes place via the control unit of the head-end sta-
tion.
Two LEDs indicate if the respective channel strip is switched on (LED illumi-
nates)oroff,andalsoprovideanindicationofthesignalqualitybasedon
their colour. Additionally the quality of the transport stream received is dis-
played ("CN…").
The integrated TPS module (Transport Stream Processing) processes the data
from the demodulated transport streams.
The HF output signals are sent through the HF output of the cassette to the out-
put collector. The common output level of the channel strips can be set at the
output collector. Additionally a transport stream is made available via the ASI
output dependent on the signal path set.
 Whenthehead-endstationisswitchedon,thetwo-lineLCdisplayshowsthe
software version of the control unit.
To operate this cassette the software version of the control unit must be "V 43"
or higher. You can find the current operating software for the control unit and
thecassette,thesoftware"BE-Flash" and the current assembly instructions on
the website "www.gss.de".
The cassette is designed for use in the following head-end stations:
PSU 12,PSU 8-16 and PST 19-1
2.5 Software query
Control unit
 If necessary, you can activate the indication of the software version of the
control unit manually:
 • Pressanytwokeysonthecontrolunitofthehead-endstationsimultaneously
untilthedisplaygoesdarkandthesoftwareversion,e.g."V 43" appears.

- 10 - PHDQ 1000 ASI LAN / PHDQ 1001
2.6 How the TPS module works
 After decoding QPSK- or 8PSK-modulated signals, the demodulated data
stream can be accessed via the integrated TPS module. This data stream,
alsocalledtransportstream,containsseveralstationsinalltheircomponents
(video,audio,dataandserviceinformation),whichcanbechangedusingthe
TPS module.
Station filter
 Individual stations can be deleted. This reduces the data rate and, conse-
quently,theoutputsymbolraterequired.Additionallystationsofthedifferent
transport streams can be assembled to a new transport stream.
Stuffing
 Thetransportstreamispaddedusingwhatisknownaszerodata.Thisensures
a steady and constant output symbol rate.
Changing the Transport stream and ORGNET-ID
The transport stream ID can be changed. If the stations of a transponder are
splitintothetransportstreamsofthechannelstrips"A"and"B",oneofthe
both transport streams a new identification must be allocated to realise the
channel search of the settop boxes connected without mistakes.
If the ORGNET-ID is changed a new NIT must be generated.
Changing the NIT
The transport stream contains data in the form of tables which the receiv-
ers evaluate and require for convenient use. The TPS module can adjust the
"Network Information Table" (NIT) to accommodate the new station data. The
"NIT" contains data which is required by the set-top box for the automatic
search feature.
Changing the operator ID (CAT)
Some network operators transmit an operator ID in the data stream (e.g.
visAvision). By changing the CAT the operator ID can be adjusted to the de-
mands.
