GSS Professional PADE 7006 User manual

English
GSS
Grundig SAT Systems GmbH
Beuthener Strasse 43
D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877
Fax: +49 (0) 911 / 703 9210
E-mail: [email protected]
Internet: http://www.gss.de
PADE 7006
Professional Analogue Digital Encoder
CLASS
KLASSE

- 2 - PADE 7006
Contents
1 Safety regulations ...............................................................................................4
2 General information ............................................................................................5
2.1 Packing contents.................................................................................. 5
2.2 Meaning of the symbols used................................................................ 5
2.2 Technical data..................................................................................... 5
2.3 Description ......................................................................................... 7
2.3.1 Software versions ................................................................................ 7
3 Assembly ............................................................................................................8
3.1 Installing the cassette............................................................................ 8
3.2 Cassette overview................................................................................ 8
3.3 Connecting the cassette........................................................................ 9
4 The control panel at a glance ............................................................................. 10
4.1 Menu items ........................................................................................10
4.2 Control panel .....................................................................................10
5 Programming .................................................................................................... 11
5.1 Programming procedure ......................................................................11
5.2 Programming the cassette ....................................................................13
Selecting the cassette ..........................................................................14
Setting the Ethernet parameters ............................................................14
Setting the IP address of the cassette.....................................................15
Setting the address range (subnet mask) ................................................15
Setting the address of the gateway .......................................................16
Setting the UDP port............................................................................16
Selecting the output signal path............................................................16
Output signal path "ASI" .....................................................................17
Setting the ASI transfer rate..................................................................17
Setting the ASI options ........................................................................17
Output signal path "IP MPTS"/" IP SPTS"................................................18
Selecting the transmission protocol........................................................18
Setting the port number .......................................................................18
Defining the quantity of data packets ....................................................19
Setting the forward error correction ......................................................19
Setting the transmission channel ..........................................................19

- 3 - PADE 7006
Setting the output IP address ............................................................... 20
Setting the input parameter ................................................................. 20
Setting the bit rate of the video signal ...................................................21
Setting the video signal type ................................................................21
Setting the TV standard .......................................................................21
Setting the aspect ratio....................................................................... 22
Setting the sharpness ......................................................................... 22
Setting the teletext option.................................................................... 22
Setting the audio signal type and bit rate ............................................. 22
Setting the level of the audio signal...................................................... 23
Setting the programme ID ................................................................... 23
Setting the channel name.................................................................... 24
Setting the ASI station filter ................................................................. 24
Setting the transport stream ID and ORGNET ID.................................... 25
Saving settings ................................................................................. 26
6 Final procedures................................................................................................ 26
6.1 Combination with other cassettes......................................................... 26

- 4 - PADE 7006
1 Safety regulations
Important information
Ê UÊ ÃÃiLÞ]ÊÃÌ>>ÌÊ>`ÊÃiÀÛV}ÊÃÕ`ÊLiÊV>ÀÀi`ÊÕÌÊ LÞÊ>ÕÌÀÃi`Ê
electricians.
Ê UÊ -ÜÌVÊvvÊÌiÊ«iÀ>Ì}ÊÛÌ>}iÊvÊÌiÊÃÞÃÌiÊLivÀiÊLi}}ÊÜÌÊ>ÃÃi-
bly or service work or pull out the mains plug.
Ê UÊ ÃÌ>ÊÌiÊÃÞÃÌiÊÃÊÌÊÜÊÌÊLiÊ>LiÊÌÊÛLÀ>Ìio
Ê Ê Ê>Ê`ÕÃÌvÀii]Ê`ÀÞÊiÛÀiÌ
Ê Ê ÊÊÃÕVÊ>Ê>iÀÊÌ>ÌÊÌÊÃÊ«ÀÌiVÌi`ÊvÀÊÃÌÕÀi]ÊvÕiÃ]Êë>Ã}ÊÜ>-
ter and dampness
- somewhere protected from direct sunlight
- not within the immediate vicinity of heat sources
- in an ambient temperature of 0 °C to +50 °C.
Ê UÊ Ensure that the head-end station is adequately ventilated. Do not cover the ven-
tilation slots.
Ê UÊ iÜ>ÀiÊvÊÃÀÌÊVÀVÕÌÃÊ
Ê UÊ Ê>LÌÞÊÃÊ>VVi«Ìi`ÊvÀÊ>ÞÊ`>>}iÊV>ÕÃi`ÊLÞÊv>ÕÌÞÊViVÌÃÊÀÊ
inappropriate handling.
Ê UÊ "LÃiÀÛiÊÌiÊÀiiÛ>ÌÊÃÌ>`>À`Ã]ÊÀi}Õ>ÌÃÊ>`Ê}Õ`iiÃÊÊÌiÊÃÌ>>ÌÊ>`Ê
operation of antenna systems.
Ê UÊ >ÀÌÊÌiÊ-/ÊÀiViÛiÀÊÊ>VVÀ`>ViÊÜÌÊ Ê ÊxäänÎ£ÊÉÊÈäÇÓn££Ê
>`Ê6ÊänxxÊi>ÀÌ}]ÊiµÕ«ÌiÌ>ÊL`} ).
Ê UÊ ÊÌÊ«iÀvÀÊÃÌ>>ÌÊ>`ÊÃiÀÛViÊÜÀÊ`ÕÀ}ÊÌÕ`iÀÃÌÀð
UÊ Test the software versions of the head-end station and the cassette and
update them if necessary. The current software versions can be found at
”www.gss.de”.
Ê UÊ For further information please read the assembly instructions for the head-
end station used.
Take action to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.

- 5 - PADE 7006
2 General information
2.1 Packing contents
1 Cassette PADE 7006
1 CD (assembly instructions)
1 Brief assembly instructions
1 BNC cable
1 LAN cable (RJ45)
2.2 Meaning of the symbols used
Important note
—> General note
Ê UÊÊ Ê *iÀvÀ}ÊÜÀÃÊ
2.2 Technical data
The devices meet the following EU directives:
ÇÎÉÓÎÉ7]ÊnÉÎÎÈÉ7
The product fulfils the guidelines and standards for CE labelling.
Unless otherwise noted all values are specified as "typical".
CVBS Video Input:
Standard: ..................................................................... DIN EN 50049-1
Input level: ..................................................................................... 1 Vpp
Input impedance:............................................................... 75 1]Ê>
Frequency range:........................................................... ÓäÊâÊoÊxÊâ
S-Video (Y/C) Input:
Standard: ..................................................................... DIN EN 50049-1
Input level:
Y (Luminance)................................................................................. 1 Vpp
C (Chrominance) ............................................................................ 1 Vpp
Input impedance:............................................................... 75 1]Ê>
Frequency range:........................................................... ÓäÊâÊoÊxÊâ

- 6 - PADE 7006
Audio Input:
Standard: ..................................................................... DIN EN 50049-1
Input level: ..............................................................................500 mVrms
Input impedance:...........................................................................10 k1
Frequency range:........................................................... ÓäÊâÊoÊ£xÊkHz
ASI Interfaces
Standard: .....................................................................DIN EN 50083-9
Format:................................................................MPEG ISO IEC 13818-1
max. data rate .......................................................................108 Mbit/s
User data rate: ................................................................. ÓÊoÊäÊLÌÉÃ
Impedance:.................................................................................... 75 
Level (input / output): ..................................................... 800 mVpp ± 10%
Rise/Fall Time:..............................................................< 1.2 ns (20-80%)
Reflexion loss (input):........................................... Ê£ÇÊ`ÊxÊoÊÓÇäÊâ®
LAN Interface
Standard: .................................................................10/100/1000 MB/s
Transport streams:.................... SPTS$(Single$Programme$Transport$Stream),
MPTS (Multi Programme Transport Stream)
Protocols:.......................................................... 1*Ê1ÃiÀÊ>Ì>Ê*ÀÌV®]Ê
RTP (Real-Time Transport Protocol)
Connections:
Audio inputs: ...................................................................4 Cinch sockets
Video inputs: ..................................................................ÓÊVÊÃViÌÃ]Ê
2 S-Video sockets (Mini-DIN)
LAN:................................................................................1 RJ 45 socket
ASI input: .................................................................£Ê ÊÃViÌ]ÊÇxÊ
ASI output:................................................................£Ê ÊÃViÌ]ÊÇxÊ
Connection strip (10-pin):......................................... for supply voltages and
control circuit
RS-232 socket: ....................................................... serial update interface

- 7 - PADE 7006
2.3 Description
In the cassette PADE 7006 two analogue audio and video signals are con-
verted into MPEG2 data streams (transport streams).
The transport streams are emitted via the LAN interface or the ASI output.
Ê/iÊV>ÃÃiÌÌiÊÃÊiµÕ««i`ÊÜÌÊÌÜÊÃÌiÀiÉ>Õ`Ê«ÕÌÃ]ÊÌÜÊ-®Û`iÊ«ÕÌÃÊ
and one ASI data stream input. The fed in analogues signals are digitized and
supplied to an encoder that encodes them in real time.
The stereo audio signals are transferred via an adjustable amplifier to the en-
coder. Encoding is done according to the MPEG 2 standard. The bit rates are
adjustable. A transport stream fed via the ASI input socket will be inserted into
the transport streams of the encoded analogous signals.
At the ASI output sockets (BNC) a transport stream is provided according to
ISO/IEC 13818. Alternatively one IP MPTS data stream or two IP SPTS data
streams (equipped with IP addresses) can be provided at the network socket.
Ê/iÊV>ÃÃiÌÌiÊÃÕ««ÀÌÃÊ`>Ì>ÊÀ>ÌiÃÊvÊÓÊoÊ£xÊLÌÉÃiV°Ê
It is intended for use in the head end stations PSU 12]ÊPSU 8]ÊPGT 8 and
PST 19-1.
2.3.1 Software versions
Cassette
After activating the cassette the software version of the cassette is displayed
(see page 14).
Control unit
To operate these cassettes the software version of the control unit must be
“V41” or higher. Approx. 5 minutes after the last keypress the software version
of the control unit is displayed.
ÊvÊiViÃÃ>ÀÞ]ÊÞÕÊV>Ê>VÌÛ>ÌiÊÌiÊ`V>ÌÊvÊÌiÊÃvÌÜ>ÀiÊÛiÀÃÊvÊÌiÊ
control unit manually:
Ê UÊ *ÀiÃÃÊ>ÞÊÌÜÊiÞÃÊÊÌiÊVÌÀÊÕÌÊvÊÌiÊi>`i`ÊÃÌ>ÌÊÃÕÌ>iÕÃÞÊ
ÕÌÊÌiÊ`ë>ÞÊ}iÃÊ`>ÀÊ>`ÊÌiÊÃvÌÜ>ÀiÊÛiÀÃ]Êi°}° " V 41 " appears .

- 8 - PADE 7006
3 Assembly
3.1 Installing the cassette
Before installing or changing a cassette unplug the power cable from the
mains power socket.
Ê UÊ ,iÛiÊÌiÊv>ÃÌi}ÊÃVÀiÜÃÊ1of an unoccupied slot from the bracket of
the head-end station.
Ê UÊ ÃiÀÌÊÌiÊV>ÃÃiÌÌiÊÊÌÃÊÃÌÊ>`Ê«ÕÃÊÌÊÌÊÌiÊÕÃ}°
Ê UÊ }ÊÌiÊV>ÃÃiÌÌiÊ>`Ê>««ÞÊÃ}ÌÊ«ÀiÃÃÕÀiÊÌÊViVÌÊÌÊÌÊÌiÊViVÌÃÊ
of the board and the HF bus bar.
Ê UÊ >ÃÌiÊÌiÊV>ÃÃiÌÌiÊÜÌÊÌiÊÃVÀiÜÃÊ1.
0°
KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE KASSETTE
AUSGANG
max. 90 dBµV
ACHTUNG!
Vordem Kassettenwechsel
unbedingt denNetzstecker ziehen.
CAUTION!
Before changing cassettes remove
mains plug.
Grundig SAT Systems
1
1
3.2 Cassette overview
Kanalzug "B" / Channel strip "B" Kanalzug "A" / Channel strip "A"
2 3 4 5 6 7 8 2 3 4 5 9
2 S-Video input (Mini-DIN)
3 Video input (Cinch)
4 Audio input L (Cinch)
5 Audio input R (Cinch)
6 Ethernet socket (RJ45)
7 ASI input (BNC)
8 ASI output (BNC)
9 RS232 socket (9-Pin-Sub-D)

- 9 - PADE 7006
3.3 Connecting the cassette
To comply with the current EMC regulations, it is necessary to connect the lines
leading in and out of the head-end station using cable terminals.
When mounting the cassette in a head-end station which is installed in a 19”
cabinet (e.g. PGT 8 or PST 19-1 ), make sure the connections leading in and out
for the 19” cabinet are made using cable terminals.
Ê UÊ ÃiÀÌÊÌiÊÀiµÕÀi`ÊÕLiÀÊvÊV>LiÊÌiÀ>ÃÊÊÌiÊ«i}ÃÊ«ÀÛ`i`ÊÊ
the head-end station or in the 19" cabinet.
—> Cable terminals are commercially availiable and not included in the
scope of delivery.
Tighten the nuts on the cable terminals until the teeth on the lock washer have pen-
etrated the exterior coating and a good connection is made between the housing
and cable terminals.
Ê UÊ iVÌÊÌiÊ peripheral devices via cable terminals to the input sockets "Vid-
eo" 3or "S-Video" 2]ʸAudio R" 5and "Audio L" 4of the channel
strips "A" and "B".
—> connect a mono audio signal to input "Audio L" 4.
Ê UÊ iVÌÊÌiÊ ASI input 7 and the ASI output 8 to the peripheral devices -
or
Ê UÊ ViVÌÊÌiÊ ÊÃViÌÊ6.
Ê UÊ iVÌÊÌiÊi>`i`ÊÃÌ>ÌÊÌÊÌiÊ>ð
Note:
The "RS-232" socket (9-pin Sub-D) is for updating the operating software of
the cassette using a PC or notebook. Use the "BE-Flash" software as the up-
date software. You can find the current operating software of the cassette on
the website "www.gss.de".

- 10 - PADE 7006
4 The control panel at a glance
4.1 Menu items
Program the cassette using the buttons on the control unit of the head-end sta-
tion. The two-line display of the control unit then shows the menus.
Use the key to select the following main menu items:
– Cassette
– Ethernet
– Output
– Input
– ASI
– TS/ONID
4.2 Control panel
The key pad on the head-end station is used to scroll through the menus:
scrolls forward through the menus.
scrolls backward through the menus.
select parameters in the menus
selects sub-menus
ÊÃiÌÊÛ>ÕiÃ]°
saves all entries.
BE-Remote V41
PROFESSIONAL
