GT SONIC GT-F5 User manual

ULTRASONIC CLEANER
GT-F5
USER MANUAL
Thank you for purchasing GT SONIC ultrasonic cleaner. Please take
the time to read these operating instructions before use and retain
them for future reference. Failure to follow these instructions may
lead to serious personal injury and damage to property.

Content
01.Overview /Scope of Delivery 2
11
12
3-7
8-9
9-10
10-11
02.Safety Instructions
03.Introduction
04.Operation
05.Methods of Use
06.Care and Maintenance
07.Specifications
01. OVERVIEW/SCOPE OF DELIVERY
Note:Check that all accessories are include and undamaged.
View window
"ON" button
Watch holder
Basket
2
Digital display time
“SET" button “OFF" button
Lid

02. SAFETY INSTRUCTIONS
Intended use
The device is designed for private home use only and must not be
used for commercial purposes.
The device must only be used indoors.
Possible misuse
The device must only be used according to the purposes described
in these instructions.
DANGER for children
//This device is not intended to use by individuals with restricted
physical sensory or metal capacities or those with lack of experience
or knowledge, include children, unless they are supervised by an
individual who is responsible for their safety or have received training
in operating the device .
//Cleaning and user maintenance shall not be carried out by children
//Store the device and accessories where it is not reachable by children.
//Children must not play with packaging material.
//Do not allow children to play with bags.
//Danger of suffocation.
without supervision.
3

DANGER of electric shock as a result of moisture
//Do not use this device in the vicinity of bathtubs,showers,washbasins
or other vessels containing water.
//Never put the device down in such a way that it could fall into water
//Protect the device from moisture,dripping water or splash water.
//Never touch the device with the wet hands.
//The device ,the cable and the mains plug must not fall into water
//If the device has fallen into water,pull out the mains plug immediately,
and only then remove the device from the water.Do not use the
device again,but have it checked by a specialist.
DANGER of electric shock
//Do not operate the device if it or the cable shows visible signs
of damage or if the device has been dropped.
while still connected.
or other liquids.
4

//Only connect the mains plug to a properly installed socket,which
is easily accessible and supplies voltage matching the rating plate.
The socket must still be easily accessible after connection.
//Ensure that the cable not damaged by sharp edges or hot surfaces.
Do not wrap the cable around the device (cable break danger!)
//Make sure the cable is not trapped or crushed.
//Always pull on the plug and never on the cable when removing
//Remove the mains plug from the socket,when after each use,if
a fault occurs,when you are not using the device,before cleaning
the device and during thunderstorms.
//To avoid any risk,do not make any changes to the device or accessories.
//Do not replace the cable yourself either.Repairs must only be carried
out by a specialised company.
WARNING! Risk of material damage
//Use the original accessories only.
//Never place the device on hot surfaces or near heat sources or
open fire.Place the device on a dry and even surface.
//Do not place the device on a soft surface that might cover the openings.
the device.
5

//Do not operate the device when the tank is empty.
Dry running will damage the device.
//When filling the tank,always ensure that the “MAX” marking is
//Do not run the device for extended time or continuously .
//Do not use aggressive or abrasive cleaners.
//Do not hit the device.Be careful when moving the device.
//Do not expose the device to temperature below -10 or above +40 .℃ ℃
CAUTION!
//No liability is assumed for scratched or damaged abject.
Objects to be cleaned(application examples):
//Personal Items:Glasses,Dentures,Tooth brushes,razor blades,
not exceeded.
baby items,etc.
6
//Jewelry:Necklaces,rings,earrings,bracelets,watch chains,coins,etc.
//Metal parts:Coins,medals,badges,valves ,etc.

CAUTION!
Loosely framed stones,glued ornaments on decorative items as well
as loose items could be detached during the cleaning process.Ask
your dentist particularly in case of dentures including veneers.
The following object are not suitable for ultrasonic cleaning:
//Genuine pearls,semi-precious stones,costume jewelry or soft
stones such as pearls,turquoise,coral,emeralds,etc.
//Object that can easily be discoloured,waterlogged or damaged.
//Wooden items,leather items,fabric,materials with a sensitive/
already damaged surface,electric devices,polycarbonate lenses
(thermoplastics),glasses equipped with coated plastic lenses(even
the smallest damage to the surface layer may result in irreparable
//Mobile phones,watches,glass frames or artworks made from
damages to the material）.
tortoiseshell or abalone.
Cleaning detergent:
//Special cleaning detergent should be used in case of difficult
and/or stubborn dirt-such as grease,resinifications,rust,wax,pigments,
etc.-that cannot be removed with water and all-purpose cleaner.
7
//Do not use flammable or explosive detergent.

03. INTRODUCTION
The principle of ultrasonic cleaning
Ultrasonic cleaning is based on the cavitation effect caused by
8
the vibration of high frequency ultrasonic waves in the liquid .
Microscopic bubbles are formed.These implode causing the cavitation
SUS304 TANK
Transducer
Generator
Detergent
Tiny vibration Cavitation Debris come off
Solution
which create an intense scrubbing action on the surface of the item
being cleaned. The bubbles are small enough to penetrate microscopic
crevices, cleaning them thoroughly and consistently.

Ultrasonic cleaning is extremely effective in removing dirt and grime
which would normally require tedious manual cleaning . It is used to
clean a wide variety of instruments and mechanical parts such,
returning them to almost “like new” condition without damage to
delicate parts.
04. OPERATION
1)Open the lid and fill the stainless steel tank
WARINING: Running device without water may
2)Put the objects in the water. The object should be
3)Close the lid, connect the power cord to an outlet.
LED Display shows "180" as default time(Seconds).
Press "SET" button to choose working time. 5 cycle
time can be optional 180S, 280S, 280S, 480S, 90S.
completely immersed. Do not exceed “MAX” level.
3
1
with water.
damage device!
9
2
4
4)Press the "ON" button, to start default 180 seconds
working time.
Note: While cleaning, a buzzing sound will be heard.
This means the machine is working. Do not
continuous working over 30 minutes.
ON SET OFF

5
6
05. METHODS OF USE
General cleaning
Use normal water for general cleaning.The object
should be completely immersed.However, the
water should not exceed the maximum fill level.
1
2
Thorough cleaning
In order to obtain better results,you may add a
few drops of universal detergent.We recommend
using commercial dishwashing detergent-preferably
without an lipid-replenishing substances(“balm”) .
For professional cleaning purposes,special cleaning detergent can be
used.Find out which concentrate is suitable for your objects to be cleaned
and the type of contamination.
10
Note:Do not soak the operation button during pour out the water.
5)If you would like to stop cleaning during working,
please press"OFF" button.
6)When cleaning is completed, unplug the power
cord, open the lid, remove cleaned items. Then pour
out the dirty water from tank, clean and wipe the
tank dry and keep away from child.
ON SET OFF

Partial cleaning
3
For the partial cleaning of bigger objects,use
Do not touch the liquid during operation!
Ultra cleaning
Whenitemsrequireextensivecleaning,use
"Thorough Cleaning"procedurefirst,replace
waterandrepeat" Thorough Cleaning" process
4
the device with its lid open.
untilitemscompletelyclean.
06. CARE AND MAINTENANCE
DANGER!Before cleaning the device,pull out the power plug .Never
immerse the device,cable or power plug in water or another liquid
for cleaning and care purpose.
Do not cleaning the ultrasonic cleaner with corrosive detergent or
WARINING!
pointed object.
//Use a cloth to cleaning and dry the tank.
//Ensure that there is no residual water left in the tank in order to
//Store the device in a cool and dry place.
//Keep the device out of children’s reach.
//Check the joint of the power plug and cord.
//DO not impact,hit the device. Handle with care when moving the device.
prevent limescale.
11

07. Standard Specifications
Model GT-F5
Ultrasonic Frequency 43 kHz
Tank Material Stainless Steel SUS304
Tank Capacity 600ml
Timer 90S, 180S, 280S, 380S, 480S
Power Supply AC100~120V, 60Hz or
AC220~240V, 50Hz
Ultrasonic Power 35W
Tank Size 150x90x50(L*W*H)mm
Overall Size 206x145x133(L*W*H)mm
N.W. 895g
G.W. 1.20Kg
Guangdong GT Ultrasonic Co.,Ltd
T e l: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.gtsonic.net
Factory Add: GT SONIC Technology Park,
Meizhou City, Guangdong, China
12
