GT SONIC S Series User manual

Thank you for purchasing GT SONIC ultrasonic cleaner. Please take
the time to read these operating instructions before use and retain
them for future reference. Failure to follow these instructions may
lead to serious personal injury and damage to property.
GT SONIC-S SERIES ULTRASONIC CLEANER
USER MANUAL

Content
01.Overview /Scope of Delivery
02.Safety Instructions
03.Applications
04.Introduction
05.Operation
06.Care and maintenance
07.Specifications
01. OVERVIEW/SCOPE OF DELIVERY
Note:Check that all accessories are include and undamaged.
A
B
C
D
EI
H
J
F
G
A : Lid B:Handles C:Warning marking D: Housing
E: Drain tap H: Louver
J: Powerswitch
I: Socket
F: Controlpanel G:Rubber feet
2
2-3
4 7 -
7 9 -
9 11 -
11 13 -
13-14
14

Contents:
a: Main machine b: Soundproof lid c: Power cord
d: Outlet filter e: Mesh basket f: User manual
available for 6L-9L
3

02. SAFETY INSTRUCTIONS
Intended use
The cleaner can be used for commercial purpose indoors only.
Possible misuse
The cleaner must only be used according to the purposes described
DANGER for children
//This cleaner is not intended to use by individuals with restricted
physical sensory or metal capacities or those with lack of experience
or knowledge, include children, unless they are supervised by an
//Cleaning and maintenance shall not be carried out by children
//Store the cleaner and accessories where it is not reachable by children.
//Children must not play with packaging material.
//Do not allow children to play with bags.Danger of suffocation.
in these instructions.
individual who is responsible for their safety or have received training
in operating the cleaner .
without supervision.
4

DANGER of electric shock
//Do not operate the cleaner if it or the cable shows visible signs of
//Only connect the mains plug to a properly installed socket,which
is easily accessible and supplies voltage matching the rating plate.
//Ensure that the cable not damaged by sharp edges or hot surfaces.
//Make sure the cable is not trapped or crushed.
//Do not remove the grounding prong on the line cord plug.
//Remove the mains plug from the socket,when after each use,if a
//To avoid any risk,do not make any changes to the cleaner or accessories.
//Do not replace the cable yourself either.Repairs must only be
//Do not disassemble your cleaner--high voltage inside the cleaner
//Do not immerse the cleaner or power cord in water or other liquid.
damage or if the cleaner has been dropped.
The socket must still be easily accessible after connection.
Do not wrap the cable around the cleaner (cable break danger!)
fault occurs,when you are not using the cleaner,before cleaning the
cleaner and during thunderstorms.
carried out by a specialized company.
is dangerous.Except by specialist.
5

//Do not ever use alcohol ,gasoline or flammable solutions.Doing so
could cause a fire or explosion and will avoid your warranty.Only use
non-flammable solutions and water-based solutions.
DANGER of electric shock as a result of moisture
//Do not use this cleaner in the vicinity of bathtubs, showers,
//Never put the cleaner down in such a way that it could fall into water
//Protect the cleaner from moisture,dripping water or splash water.
//Never touch the cleaner with the wet hands.
//The cleaner ,the cable and the mains plug must not fall into water.
//If the cleaner has fallen into water,pull out the mains plug immediately,
and only then remove the cleaner from the water.Do not use the cleaner
WARNING !To prevent personal damage
//Do not touch the stainless steel tank or cleaning solution--they may be hot.
//Do not allow fluid temperature to exceed 70 (160 ).When temperature
℃℉
//Do not place your fingers or hands into the tank while the cleaner is
washbasins or other vessels containing water.
again,but have it checked by a specialist.
exceed 70 ,cleaning effect will be affect.The best temperature suggest ℃
is 40 -60 . ℃ ℃
operating.Doing so may cause discomfort and possible skin irritation.
6

WARNING !To prevent damage to the cleaner
//Do not operate the cleaner when the tank is empty.
Dry running will damage the cleaner.
//When filling the tank, always ensure that the water immersed the
//Do not place parts or containers directly on the bottom of the
//Use the original accessories only.
//Never place the cleaner on hot surfaces or near heat sources or
//Do not place the cleaner on a soft surface that might cover the openings.
//Do not run the cleaner for continuous working more than 1.5 hours .
//Do not hit the cleaner.Be careful when moving the cleaner.
//Do not expose the cleaner to temperature below -10℃ or above +40℃.
//Do not ever use strong acid and alkali .These could damage the tank.
1/2 of tank and do not exceeded the max line.
cleaning tank; Use basket to suspend items.Failure to comply may
cause transducer damage .The stainless steel basket absorbs less
ultrasonic energy .
open fire.Place the cleaner on a dry and smooth surface.
03.Application
7

Objects to be cleaned(application examples):
Jewelry especially gold, silver & platinum
Hospital &Dental
Automotive and motor parts
Laser Component
Metal parts cleaning
Electronic Boards
Beauty& Nail tools
Industrial parts and tools
Laboratory
The list is almost endless. Provided the product is non porous and can
normally be immersed in water almost anything can be thoroughly cleaned.
8

Ultrasonic cleaning is based on
the cavitation effect caused by
the vibration of high frequency
These implode causing the cavitation
being cleaned. The bubbles are small
enough to penetrate microscopic
ultrasonic waves in the liquid .
Microscopic bubbles are formed.
which create an intense scrubbing
action on the surface of the item
crevices, cleaning them thoroughly and consistently.
Ultrasonic cleaning is extremely effective in removing dirt and grime
which would normally require tedious manual cleaning . It is used to
clean a wide variety of instruments and mechanical parts ,returning
them to almost “brand new” condition without damage to delicate parts.
Items Not suitable for ultrasonic cleaning:
04. INTRODUCTION
SUS304 TANK
Transducer
Generator
Detergent
Tiny vibration Cavitation Debris come off
Solution
9
Soft Jewelry: Pearls, emerald, ivory, coral. Agate, sea turtle shells, etc.
Welded, Plated and Glued Items: Welded or plated metal items, glued items.
Watches: Except diver’s watches with depth rating over 50m(150ft).
Others: Ceramic, camera filters with preexisting cracks.

A
C F G
D
B
H
I
E
A: LED display temperature.
B: LED display cleaning time.
C: Heating button: Touch this button to start/stop heating.
(Note 1: The new machine will display the ambient temperature
D: Increase Temperature:
Touch this button to set the temperature.
Touch one time to increase 1 holding the button to increase by 10 .℃ ℃,
E: Temperature reduce:
Touch this button to set the temperature.
Touch one time to reduce 1 , holding the button to reduce by 10 .℃ ℃
F: Degas: Fresh solutions with many airs which reduce effective
Using Degas mode speeds up the degassing process and improves
G: Ultrasonic button: touch this button for start/stop ultrasonic.
when first time use.)
ultrasonic action.
cleaning efficiency.
H: Timer increase: touch this button to set the cleaning time.
Touch one time to increase 1minute, holding the button to increase
by 10minutes.
I: Timer reduce:
Touch one time to reduce 1minute, holding the button to reduce by
10minutes.
10
