GT SONIC GT-U1 User manual

ULTRASONIC CLEANER
GT -U1
USER MANUAL
Thank you for purchasing GT SONIC ultrasonic cleaner. Please take
the time to read these operating instructions before use and retain
them for future reference. Failure to follow these instructions may
lead to serious personal injury and damage to property.

Content
01.Overview /Scope of Delivery 2
13
14
3-8
8-9
10-12
12-13
02.Safety Instructions
03.Introduction
04.Operation
05.Methods of Use
06.Care and Maintenance
01. OVERVIEW/SCOPE OF DELIVERY
Note:Check that all accessories are included and undamaged.
2
1. Handle 2. Transparent lid 3. Housing
4. Unit base 5. ON 6. OFF
7. Red power indicator light 8. Basket
1
2
3
4
5
6
8
7

02. SAFETY INSTRUCTIONS
Intended use
The device is designed for private home use only and must not be
used for commercial purposes.
The device must only be used indoors.
Possible misuse
The device must only be used according to the purposes described
in these instructions.
DANGER for children
//This device is not intended to use by individuals with restricted
physical sensory or metal capacities or those with lack of experience
or knowledge, include children, unless they are supervised by an
individual who is responsible for their safety or have received training
in operating the device .
//Cleaning and user maintenance shall not be carried out by children
//Store the device and accessories where it is not reachable by children.
//Children must not play with packaging material.
//Do not allow children to play with bags.
//Danger of suffocation.
without supervision.
3

DANGER of electric shock as a result of moisture
//Do not use this device in the vicinity of bathtubs,showers,washbasins
or other vessels containing water.
//Never put the device down in such a way that it could fall into water
//Protect the device from moisture,dripping water or splash water.
//Never touch the device with the wet hands.
//The device ,the cable and the mains plug must not fall into water
//If the device has fallen into water,pull out the mains plug immediately,
and only then remove the device from the water.Do not use the
device again,but have it checked by a specialist.
DANGER of electric shock
//Do not operate the device if it or the cable shows visible signs
of damage or if the device has been dropped.
while still connected.
or other liquids.
4
//Should liquid get into the device, pull out the mains plug
immediately. Have the devicechecked before operating it again.

//Only connect the mains plug to a properly installed socket,which
is easily accessible and supplies voltage matching the rating plate.
The socket must still be easily accessible after connection.
//Ensure that the cable not damaged by sharp edges or hot surfaces.
Do not wrap the cable around the device (cable break danger!)
//Make sure the cable is not trapped or crushed.
//Always pull on the plug and never on the cable when removing
//Remove the mains plug from the socket,when after each use,if
a fault occurs,when you are not using the device,before cleaning
the device and during thunderstorms.
//To avoid any risk,do not make any changes to the device or accessories.
//Do not replace the cable yourself either.Repairs must only be carried
out by a specialised company.
WARNING! Risk of material damage
//Use the original accessories only.
//Never place the device on hot surfaces (e.g. hob plates) or near hea t
//Do not place the device on a soft surface that might cover the openings.
the device.
5

//Do not operate the device when the tank is empty.
Dry running will damage the device.
//Do not let the appliance run continuously or over a prolonged
//Do not use aggressive or abrasive cleaners.
//Do not hit the device.Be careful when moving the device.
//Do not expose the device to temperature below -10 or above +40 .℃ ℃
CAUTION!
not exceeded.
6
period of time.
//Do not use this appliance with an external time delay switch
or separate telecontrol system!
If you are unsure whether you can use the appliance to clean the
object and/or whether the object could be damaged when doing
so, please consult the retailer youpurchased the corresponding
object from. Or ask a specialist trader (jeweller, watch-maker etc.)
and/or the corresponding watch/jewellery manufacturer.
//Do not use the ultrasound cleaner without the basket. Otherwise, the
object to be cleaned and/or the stainless steel tank could be damaged.

//No liability is assumed for scratched or damaged object.
may come off during the cleaning process.
//Consult your dentist particularly in case of dentures with veneers.
//Consult your optician before cleaning of all ophthalmic lenses,
glasses may lead to damage. Irreparable damages cannot be excluded,
particularly in the case of glasses with coated plastic lenses. The
older the glasses, the shorter the cleaning time must be set. Do
not add any cleaning product containing alcohol or solvent.
Objects to be cleaned (application examples):
//Optical devices: glasses, sunglasses, magnifying glasses, etc.
//Personal hygiene: Toothbrushes, dentures, braces, dummies as
//Jewellery: Necklaces, rings, earrings, bracelets, watch chains,
//Metal parts: parts of water-tight watches, coins, medals, badges,
//Writing utensils: pens of fountain pens, ball-point pen covers,
well as shaving heads of razors, razor blades, etc.
coins, etc.
valves, parts of devices (shaving parts), etc.
printer nozzles, signature stamps, etc.
7

The following objects are not suitable for ultrasonic cleaning:
//Genuine pearls,semi-precious stones,costume jewelry or soft
stones such as pearls,turquoise,coral,emeralds,etc.
//Object that can easily be discoloured,waterlogged or damaged.
//Wooden items,leather items,fabric,materials with a sensitive/
already damaged surface,electric devices,polycarbonate lenses
(thermoplastics),glasses equipped with coated plastic lenses(even
the smallest damage to the surface layer may result in irreparable
//Mobile phones,watches,glass frames or artworks made from
damages to the material）.
tortoiseshell or abalone.
Cleaning detergent:
etc.-that cannot be removed with water and all-purpose cleaner.
8
03. INTRODUCTION
The principle of ultrasonic cleaning

Ultrasonic cleaning is based on the cavitation effect caused by
9
the vibration of high frequency ultrasonic waves in the liquid .
Microscopic bubbles are formed.These implode causing the cavitation
SUS304 TANK
Transducer
Generator
Detergent
Tiny vibration Cavitation Debris come off
Solution
which create an intense scrubbing action on the surface of the item
being cleaned. The bubbles are small enough to penetrate microscopic
crevices, cleaning them thoroughly and consistently.
Ultrasonic cleaning is extremely effective in removing dirt and grime
which would normally require tedious manual cleaning . It is used to
clean a wide variety of instruments and mechanical parts ,returning
them to almost “like new” condition without damage to delicate parts.

3
1
10
2
4
04. OPERATION
1 ) Open the lid, place the provided basket in the
WARNING: Running device without water may
NOTE: Place the dentures and/or jewellery to
damage device!
be cleaned as centred as possible in the basket.
2) Put the objects in the basket. Be sure to
exceed the “MIN” level. The object should be
completely immersed. Whereby the “MAX”
marking must not be exceeded.
3) Close the transparent lid, connect the
ultrasound cleaner to a grounded socket.
The red power indicator lights up.
4)Press the “ON” button, starts the cleaning
process which will take up to 5 minutes.The
blue indicators inside the tank lights on. When
blue indicator inside the tank turns off, and
the device stop working.

5
6
7
11
5) If you would like to continue cleaning the
object, simply press the “ON” button again.
6) If you would like to abort the cleaning process,
press the “OFF” b u tton. The “ Z IZI” noises
generated during the cleaning process mean
that the appliance is operating.
out the power plug, the red power indicator
lights off.
NOTES:
//The regular addition of commercial denture cleansers (tablets
orpowder)can inhibitbacte-riagrowthonthedenture.
//Increasing the cleaning effect is also possible by simply adding
commercialdishwashing detergent. It solves those grease traces
fromthesurfaceoftheobject to be cleaned that cannot be removed
bytheultrasonicimpulses.
//Ensure that the dishwashing detergent does not contain any
lipid-replenishing substances.
cleaning process, we recommend repeating the cleaning process.

05. METHODS OF USE
General cleaning
Use normal water for general cleaning.The object
should be completely immersed.However ,the
1
2
Thorough cleaning
In order to obtain better results,you may add a
few drops of universal detergent.We recommend
using commercial dishwashing detergent-preferably
without an lipid-replenishing substances(“balm”) .
For professional cleaning purposes,special cleaning detergent can be
used.Find out which concentrate is suitable for your objects to be cleaned
and the type of contamination.
new cleaning process.
Partial cleaning
3
For the partial cleaning of bigger objects,use
Do not touch the liquid during operation!
the device with its lid open.
12
level.

06. CARE AND MAINTENANCE
DANGER!Before cleaning the device,pull out the power plug .Never
immerse the device ,cable or power plug in water or another liquid
for cleaning and care purpose.
Do not cleaning the ultrasonic cleaner with corrosive detergent or
WARNING!
pointed object.
//Use a cloth to cleaning and dry the tank
//Ensure that there is no residual water left in the tank in order to
//Store the device in a cool and dry place.
//Keep the device out of children’s reach.
//Check the joint of the power plug and cord.
//DO not impact ,hit the device. Handle with care when move the device.
prevent limescale.
13
Ultra cleaning
water and repeat “Thorough Cleaning” process
4
Whenitemsrequireextensivecleaning,use
untilitemscompletelycleaned.

Model GT-U1
Ultrasonic Frequency 40 kHz
Tank Material Stainless Steel SUS304
Tank Capacity 450ml
Timer 5MIN
Power Supply AC100~120V,60Hz;
AC220~240V, 50Hz
Ultrasonic Power 35W
Tank Size 178×85×36(lxwxh)mm
Overall Size 226×130×118(lxwxh)mm
N.W. 860g
G.W. 1116g
