GTO GP-SW100 User manual

www.gtoaccess.com
Available from:
Technology • Innovation • Quality
Since 1987
GP-SW100
CONTINUOUS DUTY
SWING GATE OPERATOR
ACCESS
SYSTEMS
COMMERCIAL SERIES
Inherent UPS
(Battery Back-up)
System
ACCESS
SYSTEMS
COMMERCIAL SERIES
For gates up to 20 ft. (6.1 m) long & 1200 lbs. (544.3 kg) per leaf

GTO®,GTO/PRO®, Bulldog®, GTO Access Systems™, are trademarks of GTO, Inc. and are the exclusive property of GTO,Inc. (“GTO”).
All rights are reserved by GTO, and these marks may not be used, in any for without the prior, written permission of GTO. Copyright © 2008 rev-3-2008
www.gtoaccess.com
ACCESS
SYSTEMS
Technology • Innovation • Quality
Since 1987
COMMERCIAL SERIES
GP-SW100
CONTINUOUS DUTY SWING GATE OPERATOR
Inherent UPS
(Battery Back-up)
System
GP-SW100
SUGGESTED ACCESSORIES:
• Pluggable loop detectors (LOOPDT1)
• Driveway Vehicle Sensor:
(50’-250’ lengths) (FM139-FM141)
• Safety Photo Beams (R4222)
• Estate Wireless Intercom with
integrated keypad (F4100MBC)
• Universal receiver (RB709U-NB)
• Loops (L-SC-408-L-PO-0612)
• Automatic Gate Lock (FM144)
• Keychain Transmitter (RB741)
• Digital Keypad (F310)
CAPACITY:
The GP-SW100 is designed for operation of swing gates.
Max Gate; Weight 1200 lbs. (544.3 kg), Length 20 ft. (6.1 m)
(For bi-parting dual gates, a second operator is required).
Assumes gate to be free swinging, in good working condition,
and on a level plane.
MECHANICAL SPECIFICATIONS:
• AC Powered with inherent UPS (Uninterrupted Power System /
Battery Backup) gate operation and all DC powered counters /
safety devices.
• On board 12 V DC power delivers 300 Amp UPS
• 120 Vac 60 Hz built in power receptacles (1 amp rated)
• 1200:1 direct drive worm gear with totally enclosed gear reduction
• 2500 RPM, 24V brushless DC motor 1/2 HP. equivalent
• 100% solid-state motor controls circuitry
• Operating temp 5 F (-28C) to +160 F (71 C)
• Opening speed to 90 degrees from 15 seconds
• Weatherproof high density ABS, UV resistant cover
• Heavy Duty Steel Chassis
ELECTRICAL SPECIFICATIONS:
• GTO’s advanced technology residential control board
— Digital / optical limits with ne adjustment JOG push buttons
for easy and accurate setting of limits
— 100% solid-state motor controls circuitry
— APS (Absolute Position System) tracking system
— On board 3-Push button control station
• Operation, diagnostic and safety alarms, reverse sensor system
• Visual LED and audible diagnostic indicators
• Plug-in loop detector inputs for exit, shadow and safety loops
• Smooth start / smooth stop—for long mechanical
life expectancy
• Built in power management system utilizing a high efency
switchmode power supply. (AC power supply, audible and visual
low battery indicators, no loss of functionality in battery back up mode)
• Auto close adjustable 3-120 seconds delay
• Fail Safe or Fail Secure DIP switch selectable for low battery operation
• 12 Vdc, 300mA (.3 Amp), poly fuse protected auxiliary power output.
DIMENSIONS:
Height: 33”
Depth: 18”
Width: 15”
SHIPPING WEIGHT: 130 lbs.
WARRANTY:
7 Year RESIDENTIAL
5 Year COMMERCIAL
CLASS OF OPERATION:
Class I, II, III, IV
SAFETY LISTINGS:
System Certied with UL325 5th Edition
safety standards, ETL listed
DUAL GATE APPLICATIONS:
The GP-SW100 is dual gate capable via
communication link wires (14 – 20
gauge multi stranded 2-wire shielded)
