Guardian® Homecare Bed Parts List
Manual Bed Models IC-5307 IC-5207 & IC-5107
Semi Electric Bed Models IC-5310 IC-5210 & IC-5110
Full Electric Bed Model IC-5410

Manual Bed (Head and Foot Spring)........................1.1
Semi/Full Electric (Head and Foot Spring) ...............1.2
Manual Bed End Set (Fixed Height).........................1.3
Semi Electric/Manual Bed End Set
(2 Crank, Hi/Lo) ........................................................1.4
Manual/Semi Electric Bed End Set
(1 Crank, Hi/Lo) ........................................................1.5
Full Electric Bed End Set..........................................1.6
Guardian Manual/Electric Bed
IN THIS SECTION

PARTS MANUAL
2002 SUNRISE MEDICAL
PAGE 1.1
HCB0X03
ITEM NUMBER DESCRIPTION QTY
11 IC-5300M054 QUICK RELEASE ATTACH HDWR 4
12 IC-5510M008 MANUAL CRANK ASSEMBLY,FOOT 1
14 IC-5510M015 MANUAL CRANK ASSEMBLY, HEAD 1
1,2,4,5, IC-5770 MANUAL FOOT SPRING SECTION
7-16
1-3,6 IC-5000 HEAD SPRING SECTION
ITEM NUMBER DESCRIPTION QTY
1 IC-51000M135 HELICAL SPRING SHORT 64
2 IC-51000M136 HELICAL SPRING, LONG 12
3 IC-51000M133 LINK FABRIC, HEAD (16x7) 1
4 IC-51000M134 LINK, FABRIC FOOT (19x7) 1
5 IC-5770M000 FOOT SPR W/FABRIC 1
10 IC-026159 MATTRESS STOP 1
MANUAL BED ( HEAD AND FOOT SPRING)

PARTS MANUAL PAGE 1.2
2002SUNRISE MEDICAL
HCB0X02
ITEM NUMBER DESCRIPTION QTY
18 IC-1104336 HI/LO MOTOR ASSEMBLY 1
19 IC-1104343 JUNCTION BOX ASSEMBLY(6 WAY) 1
19A IC-1104345 JUNCTION BOX ASSEMBLY(4 WAY) 1
21 IC-1104330 HEAD MOTOR ASSEMBLY 1
24 IC-5880M004 EMERGENCY CRANK 1
25 IC-7000M585 DRIVE SHAFT ASSEMBLY 1
1,2,4,5,7-18,
19,20-25 IC-5490 FULL ELECTRIC FOOT SPRING SECT.
1,2A,4,5,
7-17,19A, IC-5890 SEMI ELECTRIC FOOT SPRING SECT.
20-23
3,6-8 IC-5000 HEAD SPRING SECTION
ITEM NUMBER DESCRIPTION QTY
1 IC-54000M746 POWER CORD 1
2 IC-7001M297 6 FUNCTION PENDANT 1
2A IC-7001M298 4 FUNCTION PENDANT 1
3 IC-51000M133 LINK FABRIC, HEAD (16x7) 1
4 IC-51000M134 LINK FABRIC, FOOT (19x7) 1
7 IC-51000M136 HELICAL SPRING LONG 6
8 IC-51000M135 HELICAL SPRING SHORT 64
12 IC-1104333 FOOT MOTOR ASSEMBLY 1
14 IC-026159 MATTRESS STOP 1
16 IC-51000M225 MOTOR GUARD 1
17 IC-5300M054 QUICK RELEASE ATTACH HDWR 4
SEMI/FULL ELECTRIC (HEAD AND FOOT SPRING)

PARTS MANUAL
2002 SUNRISE MEDICAL
PAGE 1.3
HCB0X01A
ITEM NUMBER DESCRIPTION QTY
5 IC-51000M091 PANEL TRIM BED HEAD END 1
6 IC-51000M083 SOCKET CASTER 2
2,2A IC-54000M447 CASTERS (SET)
1,3-6 IC-52000M213 FOOT END KIT
1,3-6 IC-52000M214 HEAD END KIT / FIXED
1-6 IC-5100 SET HEIGHT END SET
ITEM NUMBER DESCRIPTION QTY
2 IC-54000M445 CASTER WITHOUT BRAKE 2
2A IC-54000M446 CASTER WITH BRAKE 2
3 IC-51000M076, PANEL BED FOOT END 2
IC-51000M087 PANEL BED HEAD END 2
4 IC-51000M908 # 6 x 5/16” SHEET METAL SCREW
5 IC-51000M080 PANEL TRIM BED FOOT END 1
MANUAL BED END SET (FIXED HEIGHT)

PARTS MANUAL PAGE 1.4
2002SUNRISE MEDICAL
HCB0X01B
SEMI/MANUAL BED END SET (2 CRANK, HI/LO)
ITEM NUMBER DESCRIPTION QTY
5 IC-51000M255 PANEL TRIM HEAD 1
6 IC-5200M026 ELECTRIC CRANK ASSM TOP CRANK 1
7 IC-51000M083 SOCKET CASTER 2
1,3-7 IC-52000M215 FOOT END KIT - TWO CRANK
1,3-7 IC-52000M216 HEAD END KIT - TWO CRANK
1-7 IC-5200 MANUAL END SET WITH TWO CRANKS
ITEM NUMBER DESCRIPTION QTY
2 IC-54000M445 CASTER WITHOUT BRAKE 2
2A IC-54000M446 CASTER WITH BRAKE 2
3 IC-51000M076 PANEL BED FOOT END 2
IC-51000M087 PANEL BED HEAD END 2
4 IC-51000M908 # 6 x 5/16” SHEET METAL SCREW 12,24
5 IC-51000M254 PANEL TRIM FOOT 1

PARTS MANUAL
2002 SUNRISE MEDICAL
PAGE 1.5
HCB0X01
ITEM NUMBER DESCRIPTION QTY
6 IC-51000M080 TOP TRIM FOOT 1
IC-51000M091 TOP TRIM HEAD (5100,5301,5410)
8 IC-53001053 BD GRBX CRANK ASSY HI/LO 2
10 IC-51000M083 SOCKET CASTER 4
2,2A IC-54000M447 CASTER (SET)
1-10 IC-5301 MANUAL END SET W/CONNECT ROD
ITEM NUMBER DESCRIPTION QTY
2 IC-54000M445 CASTER WITHOUT BRAKE 2
2A IC-54000M446 CASTER WITH BRAKE 2
3 IC-51000M076 PANEL FOOT TRIM 4
IC-51000M087 PANEL HEAD END
4 IC-51000M908 # 6 x 5/16” SHEET METAL SCREW 24
5 IC-7000M585 DRIVE SHAFT ASSM 1
MANUAL/SEMI BED END SET (1 CRANK, HI/LO)

PARTS MANUAL PAGE 1.6
2002SUNRISE MEDICAL
HCB0X01C
ITEM NUMBER DESCRIPTION QTY
5 IC-51000M080 TOP TRIM FOOT 1
IC-51000M091 TOP TRIM HEAD (5100,5301,5410)
8 IC-51000M083 SOCKET CASTER 4
IC-51000M581 LEG GUIDE
2,2A IC-54000M447 CASTER (SET)
1-8 IC-5401 FULL ELECTRIC BED END
ITEM NUMBER DESCRIPTION QTY
1 IC5401 FULL ELECTRIC END SET 2
2 IC-54000M445 CASTER WITHOUT BRAKE 2
2A IC-54000M446 CASTER WITH BRAKE 2
3 IC-51000M076 PANEL FOOT TRIM 4
IC-51000M087 PANEL HEAD END
4 IC-51000M908 # 6 x 5/16” SHEET METAL SCREW
FULL ELECTRIC BED END SET

PARTS MANUAL
2002 SUNRISE MEDICAL
PAGE 1.7
