GVision C55BI-AC-4000 User manual

C55BI-AC-4000
4K UHD
USER’S MANUAL
SECURITY CCTV MONITOR
GVISION USA, INC
30398 Esperanza, Rancho Santa Margarita CA 92688 / 949.586.3338 / [e-mail]
WWW.GVISION-USA.COM

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
2
Important Information
Care and Cleaning
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS
UNIT’S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS CAN BE
FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM WALL SOCKET. TO FULLY
DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER CORD FROM THE AC OUTLET. DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock.
Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included.
Therefore, it should be read carefully in order to avoid any problems.
CAUTION: Please use the power cord provided with this display in accordance with the table below. If a power cord is not supplied with
this equipment, please contact GVISION. For all other cases, please use the power cord with the plug style that matches the power
socket where the monitor is located. The compatible power cord corresponds to the AC voltage of the power outlet and has been
approved by, and complies with, the safety standards in the country of purchase.
*When operating this monitor with its AC 125-240V power supply, use a power supply cord that matches the power supply voltage of
the AC power outlet being used.
•Always unplug your monitor from the wall outlet before cleaning. Clean the LCD monitor surface with a lint-free, non-abrasive
cloth. Avoid using any liquid, aerosol or glass cleaners.
•Slots and openings on the back or top of the cabinet are for ventilation. They must not be blocked or covered. Your monitor
should never be placed near or over a radiator or heat source, or in a built-in installation unless proper ventilation is provided.
•Never push objects or spill liquid of any kind into this product.

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
3
Safety Precautions / Maintenance
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
Only use attachments/accessories specified by the
manufacturer.
Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the monitor combination to avoid injury from tip-
over.
Unplug monitor during lightning storms or when unused
for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the monitor has been exposed
to rain or moisture, does not operate normally, or has
been dropped.
Do not press strongly upon the panel with a hand or a
sharp object such as a nail, pencil, or pen, or make a
scratch on it.
Do not stick metal objects or any other conductive
material into the power cord. Do not touch the end of
the power cord while it is plugged in.
Keep the packing anti-moisture material or vinyl
packing out of the reach of children. Anti-moisture
material is harmful if swallowed. If swallowed, induce
vomiting and go to the nearest hospital. Additionally,
vinyl packing can cause suffocation. Keep it out of the
reach of children.
Concerning the Power Cord (Can differ by country):
Check the specification page of this owner’s manual to
be certain concerning current requirements. Do not
connect too many devices to the same AC power outlet
as this could result in fire or electric shock. Do not
overload wall outlets. Overloaded wall outlets, loose or
damaged wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation are
dangerous. Any of these conditions could result in
electric shock or fire. Periodically examine the cord of
your device, and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the device,
and have the cord replaced with an exact replacement
part by an authorized servicer. Protect the power cord
from physical or mechanical abuse, such as being
twisted, kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall outlets, and
the point where the cord exits the device. Do not move
the monitor with the power cord plugged in. Do not use
a damaged or loose power cord. Be sure do grasp the
plug when unplugging the power cord. Do not pull on
the power cord to unplug the monitor.
To reduce the risk of fire or electrical shock, do not
expose this product to rain, moisture or other liquids. Do
not touch the screen with wet hands. Do not install this
product near flammable objects such as gasoline or
candles, or expose the TV to direct air conditioning.
Do not use high voltage electrical equipment near the
TV (e.g., a bug zapper). This may result in product
malfunction.
Do not expose to dripping or splashing and do not place
objects filled with liquids, such as vases, cups, etc. on
or over the apparatus (e.g., on shelves above the unit).
Do not attempt to modify this product in any way without
written authorization from GVISION. Unauthorized
modification could void the user’s authority to operate
this product.
Moving: Make sure the product is turned off, unplugged,
and all cables have been removed. It may take 2 or
more people to carry monitor. Do not press or put stress
on the front panel of the monitor screen.
If you smell smoke or other odors coming from the
monitor screen, unplug the power cord and contact an
authorized service center.
If water or another substance enters the product (like an
AC adapter, power cord, or display unit), disconnect the
power cord and contact the service center immediately.
Otherwise, this may result in fire or electric shock.

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
4
Table of Contents
1. Controllers & Settings……………………………………………………………………………………………………5
1.1 Monitor Interface………………………………………………………………………………………………….5
1.2 Monitor Controller Button……………………………………………………………………………………….6
1.3 Remote Control……………………………………………………………………………………………………6
1.4 Select Input Source………………………………………………………………………………………………6
2. OSD Menu Control………………………………………………………………………………………………………7
2.1 Input Source………………………………………………………………………………………………….........7
2.2 Brightness / Contrast…………………………………………………………………………………………… 8
2.3 Color Settings……………………………………………………………………………………………………..9
2.4 Picture Quality Settings…………………………………………………………………………………………10
2.5 Display……………………………………………………………………………………………………………..11
2.6 Audio……………………………………………………………………………………………………………….12
2.7 Multi Window……………………………………………………………………………………………………...13
2.8 OSD………………………………………………………………………………………………………………....14
2.9 Other………………………………………………………………………………………………………………..15
3. Specifications…………………………………………………………………………………..…………...…............16
4. Dimensions…………………………………………………………………………………..…………...…................17

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
5
INTERFACES INSTRUCTION
1 HDMI IN The HDMI Input Source
2 DP IN The DP Input Source
3 AUDIO OUT The Audio Output for VGA Input channel
4 AC IN The main power input of monitor, AC IN
1 INPUT External signal input selection.
2 MENU Display main menu and confirm menu item selection.
3 VOL Adjusting Volume.
4 CH Selecting Channel
5 STANDBY Turn ON/OFF Powe
1Controllers & Settings
1.1 Monitor Interface
1.2 Monitor Controller Button

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
6
1 Power button
Press to enter or exit the standby mode.
2 Mute button
Press to turn on or off the audio output.
3 OK button
Press to confirm selection in the setup menu.
4 Menu button
Press to enter or exit the setup menu.
5 Source button
Press to enter or exit the interface menu.
6 Return button
Press this key to return the menu.
7 HDMI button
Press to enter HDMI mode.
8 DP button
Press to enter DP mode.
9 USB-C
Press to enter USB-C mode.
1.3 Remote Control
1.4 Select Input Source
1. Activate the Signal Input Selection menu. Use ◄and► to navigate and M
to select the source.
2. Activate the Line of Sight feature. Further press to cycle between the colors
or t urn off.
3. Activate the ECO Mode feature. Press to cycle through the presets.
Initial Set-Up
1. Press the POWER button on the monitor or to turn it on.
2. Connect the relevant cable to the corresponding input on the monitor. The source
will be automatically detected.
3. To change between inputs, press the “Source” button to enter the source menu.
Use the “◄”and“►” buttons to choose the input source between Auto Select,
Type-C, DP, HDMI1 and HDMI2.

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
7
2.1 Input Source
2OSD Menu Control
Switch the signal input to DP, HDMI1, HDMI2, HDMI2or have the Select the source

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
8
Brightness Change the display brightness value from 0 to 100.
Contrast Adjust the display contrast value from 0 to 100.
DCR Turn the Dynamic Contrast Ratio features On or Off.
2.2 Brightness / Contrast

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
9
Gamma Change the display Gamma Value to:2.0,2.2,2.4.
Picture Mode Change mode to Standard, photo, movie, Game, FPS, RTS.
Color Temperature Change the color temperature to Normal, Warm, Cool, User.
Hue Change the display Hue value from 0 to 100.
Saturation Change the display Saturation value from 0 to 100.
Low Blue Light Change the display blue light from 0 to 100.
2.3 Color Settings

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
10
Sharpness Change the display Sharpness value from 0 to 100.
Response Time Turn the Response Time feature On or Off.
Noise Reduction Select the Noise Reduction Value from Low, Middle, High or turn it
Off.
Super Resolution Select the Super Resolution Value from Low, Middle, High or turn it
Off.
Dynamic
Luminance Control Turn the Dynamic Luminance Control feature On or Off.
2.4 Picture Quality Settings

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
11
Aspect Ratio Change the image aspect ratio to Full Screen, Auto, 4:3, 5:4 or 1:1.
2.5 Display
2.6 Audio

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
12
Mute Turn On or Off to mute the audio source.
Volume Change the audio source volume from 0 to 100.
Audi Source Select the audio source to DisplayPort, HDMI1, HDMI2, HDMI3. or
Auto to have the monitor choose.

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
13
Multi-Window Change the multi-window to Off, PIP Mode, PBP 2Win~4.
Sub Win2 Input Change the sub win2 input to DP, HDMI1 (2.0), HDMI2 (1.4),
HDMI3(1.4).
Sub Win3 Input Change the sub win2 input to DP, HDMI1 (2.0), HDMI2 (1.4), HDMI3
(1.4).
Sub Win4 Input Change the sub win2 input to DP, HDMI1 (2.0), HDMI2 (1.4), HDMI3
(1.4).
PIP Size Change the PIP size to Small, Medium, Large.
PIP Position Change the PIP position to Top Right, Top Left, Bottom Right.
Swap Exchange function.
2.7 Multi-Window

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
14
Language Change the OSD Menu display language.
OSD H Position Change the horizontal position of the OSD Menu.
OSD V Position Change the vertical position of the OSD Menu.
OSD Transparency Change the transparency value of the OSD Menu from 0 to 100.
OSD Timer Out Change how long the OSD Menu is on before it automatically exits.
Menu Rotation Rotate the OSD Menu.
2.8 OSD

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
15
FreeSync Mode Turn FreeSync On or Off.
HDR Turn HDR On or Off.
Flicker Free Turn Flicker Free On or Off.
Reset Restore factory default setting.
2.9 Other

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
16
MODEL C55BI-AC-4000
Screen Size 55-Inch
Resolution 3840 x 2160
Refresh 60Hz
Brightness (MAX) 300cd/m²
Response Time (Typical) 5ms
Aspect Ratio 16:9
Viewing Angle 178°(H) / 178°(V)
Display Color 1.07 Billion
INTERFACE
HDMI 3
DisplayPort (DP) 1
Audio Out 1
AUDIO
Speaker 5Wx2
CABINET
Color/Material Black/Plastic
POWER
Consumption Typical 155W
Electrical Rating AC 100~240V 50/60Hz
TEMPERATURE
Operating -20~50°C
Storage -30~70°C
VESA™
Mount Size 200x400mm
Specifications subject to change without any notice
3Specifications

WWW.GVISION-USA.COM
30398 Esperanza, Rancho Santa Margarita CA 92688 / Tel. [phone] / Fax. [phone] / Email. [e-mail]
17
4Dimensions
C55BI-AC-4000
