GW Instek MSO-2000E User manual

Mixed-Signal Oscilloscope
MSO-2000E & MSO-2000EA
USER MANUAL
ISO-9001 CERTIFIED MANUFACTURER
www. .com [e-mail]1.800.561.8187

September 2016
This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will company.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve products and reserves the
rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan
www. .com [e-mail]1.800.561.8187

TABLE OF CONTENTS
3
Table of Contents
SAFETY INSTRUCTIONS .................................................. 7
GETTING STARTED ........................................................ 12
MSO-2000E/2000EA Series Overview ... 14
Appearance .......................................... 18
Set Up.................................................. 31
Built-in Help ........................................ 41
MEASUREMENT ............................................................ 42
Basic Measurement ............................. 43
Automatic Measurement...................... 50
Cursor Measurement ........................... 65
Math Operation ................................... 73
ADVANCED CONFIGURATION ....................................... 83
Acquisition .......................................... 86
Segmented Memory Acquisition .......... 91
Display............................................... 103
Horizontal View ................................. 108
Vertical View (Channel)...................... 116
Bus Key Configuration........................ 124
Trigger ............................................... 151
Search................................................ 193
System Settings and Miscellaneous
Settings ............................................. 202
LOGIC ANALYZER .........................................................207
Logic Analyzer Operation................... 208
ARBITRARY WAVE GENERATOR ....................................223
Arbitrary Wave Generator Operation .. 224
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
4
APPLICATIONS .............................................................258
Introduction....................................... 259
Go-NoGo application ......................... 261
DVM application ................................ 266
Data Log application .......................... 268
Digital Filter application .................... 270
Mask application................................ 272
SAVE/RECALL ...............................................................282
File Format/Utility ............................. 283
Create/Edit Labels.............................. 289
Save ................................................... 292
Recall ................................................. 300
Reference Waveforms ......................... 306
FILE UTILITIES .............................................................308
File Navigation .................................. 309
Create Folder...................................... 311
Rename File ....................................... 312
Delete File or Folder .......................... 313
Copy File to USB ................................ 314
HARDCOPY KEY ...........................................................315
REMOTE CONTROL CONFIG ........................................319
Interface Configuration ...................... 320
MAINTENANCE ............................................................330
FAQ..............................................................................336
APPENDIX ....................................................................339
Updating the Firmware ...................... 340
MSO-2000E/2000EA Specifications .... 342
Probe Specifications .......................... 347
www. .com [e-mail]1.800.561.8187

TABLE OF CONTENTS
5
Dimensions ....................................... 349
Declaration of Conformity .................. 350
INDEX ..........................................................................351
www. .com [e-mail]1.800.561.8187

www. .com [e-mail]1.800.561.8187

SAFETY INSTRUCTIONS
7
SAFETY INSTRUCTIONS
This chapter contains important safety
instructions that you must follow during
operation and storage. Read the following before
any operation to insure your safety and to keep
the instrument in the best possible condition.
Safety Symbols
These safety symbols may appear in this manual or on the Product
name.
WARNING
Warning: Identifies conditions or practices that
could result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that
could result in damage to the equipment or to
other properties.
DANGER High Voltage
(Note)
Attention required
Refer to the Manual
Protective Conductor Terminal
Earth (ground) Terminal
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
8
Do not dispose electronic equipment as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased.
Safety Guidelines
General
Guideline
WARNING
CAUTION
Make sure the BNC input voltage does not
exceed 300Vrms.
Never connect a hazardous live voltage to the
ground side of the BNC connectors. It might
lead to fire and electric shock.
Do not place any heavy object on the MSO-
2000E/2000EA.
Avoid severe impact or rough handling that
leads to damaging the MSO-2000E/2000EA.
Do not discharge static electricity to the MSO-
2000E/2000EA.
Use only mating connectors, not bare wires, for
the terminals.
Do not block the cooling fan opening.
Do not perform measurement at a power source
or building installation (Note below).
Do not disassemble the MSO-2000E/2000EA
unless you are qualified.
Note
(Measurement categories) EN 61010-1:2010 specifies the
measurement categories and their requirements as follows. The
MSO-2000E/2000EA falls under category I.
Measurement category IV is for measurements performed at the
source of low-voltage installation.
Measurement category III is for measurements performed in the
building installation.
Measurement category II is for measurements performed on
circuits directly connected to the low voltage installation.
Measurement category I is for measurement performed on
circuits not directly connected to Mains.
www. .com [e-mail]1.800.561.8187

SAFETY INSTRUCTIONS
9
Power Supply
WARNING
AC Input voltage: 100 - 240V AC, 50 - 60Hz,
auto selection. Power consumption: 40 Watts.
Connect the protective grounding conductor of
the AC power cord to an earth ground, to avoid
electrical shock.
Cleaning the
MSO-2000E
Disconnect the power cord before cleaning.
Use a soft cloth dampened in a solution of mild
detergent and water. Do not spray any liquid.
Do not use chemicals containing harsh materials
such as benzene, toluene, xylene and acetone.
Operation
Environment
Location: Indoor, no direct sunlight, dust free,
almost non-conductive pollution (Note below)
Relative Humidity: ≤80%, 40°C or below; ≤45%,
41°C ~ 50°C
Altitude: < 2000m
Temperature: 0°C to 50°C
Note
(Pollution Degree) EN 61010-1:2010 specifies the pollution degrees
and their requirements as follows. The MSO-2000E/2000EA falls
under degree 2.
Pollution refers to “addition of foreign matter, solid, liquid, or
gaseous (ionized gases), that may produce a reduction of dielectric
strength or surface resistivity”.
Pollution degree 1: No pollution or only dry, non-conductive
pollution occurs. The pollution has no influence.
Pollution degree 2: Normally only non-conductive pollution
occurs. Occasionally, however, a temporary conductivity caused
by condensation must be expected.
Pollution degree 3: Conductive pollution occurs, or dry, non-
conductive pollution occurs which becomes conductive due to
condensation which is expected. In such conditions, equipment
is normally protected against exposure to direct sunlight,
precipitation, and full wind pressure, but neither temperature
nor humidity is controlled.
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
10
Storage
environment
Location: Indoor
Temperature: -10°C to 60°C
Humidity: Up to 93% RH (non-condensing) /
≤40ºC, up to 65% RH (non-condensing) / 41ºC
~ 60 ºC
Disposal
Do not dispose this instrument as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased. Please make sure
discarded electrical waste is properly recycled to
reduce environmental impact.
www. .com [e-mail]1.800.561.8187

SAFETY INSTRUCTIONS
11
Power cord for the United Kingdom
When using the oscilloscope in the United Kingdom, make sure the
power cord meets the following safety instructions.
NOTE: This lead/appliance must only be wired by competent persons
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in accordance with the
following code:
Green/ Yellow:
Earth
Blue:
Neutral
Brown:
Live (Phase)
As the colours of the wires in main leads may not correspond with
the coloured marking identified in your plug/appliance, proceed
as follows:
The wire which is coloured Green & Yellow must be connected to
the Earth terminal marked with either the letter E, the earth symbol
or coloured Green/Green & Yellow.
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the
terminal marked with the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment
or contact the supplier.
This cable/appliance should be protected by a suitably rated and
approved HBC mains fuse: refer to the rating information on the
equipment and/or user instructions for details. As a guide, a cable
of 0.75mm2should be protected by a 3A or 5A fuse. Larger
conductors would normally require 13A types, depending on the
connection method used.
Any exposed wiring from a cable, plug or connection that is
engaged in a live socket is extremely hazardous. If a cable or plug is
deemed hazardous, turn off the mains power and remove the cable,
any fuses and fuse assemblies. All hazardous wiring must be
immediately destroyed and replaced in accordance to the above
standard.
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
12
GETTING STARTED
This chapter describes the MSO-2000E/2000EA in
a nutshell, including its main features and front /
rear panel. After going through the overview,
follow the Set Up section to properly set up the
device for first time use. The Set Up section also
includes an introduction on how to use this
manual effectively.
MSO-2000E/2000EA Series Overview ...............................14
Integrated instruments and series lineup........................... 14
Main Features......................................................................... 15
Accessories.............................................................................. 16
Appearance.....................................................................18
MSO-2000E/2000EA 4-channel models Front Panel ... 18
MSO-2000E/2000EA 2-channel models Front Panel ... 19
MSO-2000E Rear Panel ....................................................... 26
MSO-2000EA Rear Panel .................................................... 26
Display..................................................................................... 28
Set Up ............................................................................31
Tilt Stand................................................................................. 31
Power Up ................................................................................ 32
First Time Use........................................................................ 33
How to Use This Manual..................................................... 36
www. .com [e-mail]1.800.561.8187

GETTING STARTED
13
Built-in Help .................................................................. 41
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
14
MSO-2000E/2000EA Series Overview
Integrated instruments and series lineup
The MSO-2000E and MSO-2000EA have different hardware
implemented instruments:
Model name
Logic Analyzer
(16 channels)
Arbitrary Wave Generator
(2 channels)
MSO-2000E
✓
✗
MSO-2000EA
✓
✓
The MSO-2000E/2000EA series consists of 6 models, divided into 2-
channel and 4-channel versions. Note that throughout the user
manual, the term “MSO-2000E/2000EA” refers to all models of the
series, unless stated otherwise.
Model name
Frequency
bandwidth
Input
channels
Max. Real-time
Sampling Rate
MSO-2072E / 2072EA
70MHz
2
1GSa/s
MSO-2074E / 2074EA
70MHz
4
1GSa/s
MSO-2102E / 2102EA
100MHz
2
1GSa/s
MSO-2104E / 2104EA
100MHz
4
1GSa/s
MSO-2202E / 2202EA
200MHz
2
1GSa/s
MSO-2204E / 2204EA
200MHz
4
1GSa/s
www. .com [e-mail]1.800.561.8187

GETTING STARTED
15
Main Features
Features
8 inch, 800 x 480, WVGA TFT display.
Available from 70MHz to 200MHz.
Real-time sampling rate of 1GSa/s (2 channel
models), 1GSa/s max. (4 channel models).
Deep memory: 10M points record length.
Waveform capture rate of 120,000 waveforms
per second.
Vertical sensitivity: 1mV/div~10V/div.
Segmented Memory: Optimizes the acquisition
memory to selectively capture only the
important signal details. Up to 29,000 successive
waveform segments can be captured with a
time-tag resolution of 4ns.
Waveform Search: Allows the scope to search
for a number of different signal events.
Logic Analyzer: Can be used to measure
discrete inputs or measure values on parallel or
serial buses.
Arbitrary Wave generator (MSO-2000EA only):
Full-function dual channel arbitrary waveform
generator.
Powerful embedded applications such as: Data
Logging, Digital Voltmeter, Go-No Go, Mask,
Digital filter, etc …
On-screen Help.
32 MB internal flash disk.
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
16
Interface
USB host port: front panel, for storage devices.
USB device port: rear panel, for remote control
or printing.
Ethernet port as standard.
Probe compensation output with selectable
output frequency (1kHz ~ 200kHz).
Calibration output.
Accessories
Standard
Accessories
Part number
Description
N/A
Quick Start Guide
N/A region dependent
Power cord
GTP-070B-4, for
MSO-2072E/2072EA
MSO-2074E/2074EA
Passive probe; 70 MHz
GTP-100B-4, for
MSO-2102E/2102EA
MSO-2104E/2104EA
Passive probe; 100 MHz
GTP-200B-4, for
MSO-2202E/2202EA
MSO-2204E/2204EA
Passive probe; 200 MHz
GTL-16E
16-channel Logic
Analyzer probe
Standard Apps
Name
Description
Go-NoGo
Go-NoGo testing app.
DataLog
Waveform or image data logging
app.
DVM
Digital Voltmeter app.
Digital Filter
High or low pass digital filter for
analog inputs.
www. .com [e-mail]1.800.561.8187

GETTING STARTED
17
Mask
Creates shape templates for signal
comparison.
Remote Disk
Allows the scope to mount a network
share drive.
Optional
Accessories
Part number
Description
Demo mode
Demonstration mode that is used
with the GDB-03 demo board.
GDB-03
Demo board.
Drivers, others
USB driver
LabVIEW driver
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
18
Appearance
MSO-2000E/2000EA 4-channel models Front Panel
LCD
Variable knob
and Select key
Autoset, Run/Stop, Single
and Default settings
CH1~CH4
Trigger
controls
Function
keys
USB Host port, Probe
Compensation terminals
Power
button
Hardcopy key
Option key
Math, Reference
and Bus keys
Bottom
menu
keys
Horizontal
controls
Menu key
Vertical
controls
Side menu keys
Logic Analyzer
probe connector
www. .com [e-mail]1.800.561.8187

GETTING STARTED
19
MSO-2000E/2000EA 2-channel models Front Panel
LCD
Variable knob
and Select key
Autoset, Run/Stop, Single
and Default settings
CH1~CH2,
EXT TRIG
Trigger
controls
Function
keys
USB Host port, Probe
Compensation terminals
Power
button
Hardcopy key
Option key
Math, Reference
and Bus keys
Bottom
menu
keys
Horizontal
controls
Menu key
Vertical
controls
Side menu keys
Logic Analyzer
probe connector
LCD Display
8” WVGA TFT color LCD. 800 x 480 resolution,
wide angle view display.
Menu Off Key
Use the Menu Off key to hide the
onscreen menu system.
Option Key
The Option key is used to access
installed options.
www. .com [e-mail]1.800.561.8187

MSO-2000E & 2000EA User Manual
20
Menu Keys
The side menu and bottom menu keys are used to
make selections from the soft-menus on the LCD
user interface.
To choose menu items, use the 7 Bottom menu
keys located on the bottom of the display panel.
To select a variable or option from a menu, use the
side menu keys on the side of the panel. See page
36 for details.
VARIABLE
POSITION
HORIZONTAL
TRIGGER
LEVEL
PUSH TO
ZERO
PUSH TO
ZERO
SCALE
Measure
Display
Cursor
Help
Test
Save/Recall
Acquire
Utility
Autoset
Run/Stop
Single
Default
Select Search
Set/Clear
Zoom
Menu
50 %
Force-Trig
POSITION
POSITION
VERTICAL
MATH
REF
BUS
SCALESCALE
PUSH TO
ZERO
PUSH TO
ZERO
M
R
B
Digital Storage Oscilloscope
GDS-2202E 200 MHz 1 GS/s Visual Persistence Oscilloscope
POWER
CH1 CH2 EXT TRIG
2V
CAT I
1MW16pF
300Vpk MAX.
CAT I
1MW16pF
300Vpk MAX.
Side menu keys
Bottom menu keys
Hardcopy Key
The Hardcopy key is a quick-save
or quick-print key, depending on
its configuration. For more
information see pages 317 (save)
or 316 (print).
Variable Knob
and Select Key
Select
VARIABLE
The Variable knob is used to
increase/decrease values or to
move between parameters.
The Select key, when lit up, is
used to make selections.
www. .com [e-mail]1.800.561.8187
