H.Koenig arya900 User manual

arya900
3 in 1 cordless vacuum & dry cleaner
Aspirateur nettoyeur sécheur sans fil 3 en 1
Kabelloser 3-in-1-Staubsauger Reiniger Trockner
3-in-1 snoerloze stofzuiger droger
Secador aspirador sin cable 3 en 1
Aspirapolvere a batteria 3 in 1

ENGLISH
SAFETY INSTRUCTIONS
Warning:
Before use, make sure to read all below instructions in order
to avoid injury or damage, and to get the best results from
the appliance. Make sure to keep this manual in a safe
place. If you give or transfer this appliance to someone else,
make sure to also include this manual.
In case of damage caused by user failing to follow the
instructions in this manual, the warranty will be void. The
manufacturer accepts no liability for damages caused by
failure to follow the manual, a negligent use or use not in
accordance with the requirements of this manual.
This appliance is for indoor use only.
1. This appliance can be used by children aged from 8
years and above, and persons with reduced physical,
sensory, or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand hazards involved.
2. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.

3. Cleaning and maintenance should not be carried out by
children unless they are at least 8 years of age and are
supervised by an adult.
4. Keep the appliance and its power cord out of reach of
children under 8 years of age.
5. Make sure that the voltage rating on the typeplate
corresponds to your main voltage of your installation. If this
is not the case, contact the dealer and do not connect the
unit
6. Do not operate this appliance if it has a damaged cord or
plug, if it is not working properly or if it has been damaged or
dropped. If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
7. Do not touch the plug or any liver parts of the appliance.
This could cause electric shock. 4. Stop to use the
adapter/plug if it is broken. This could cause electric shock.
And call our professional for replacement.
8. Keep hair, loose clothing, fingers, and other parts of
body away from opening and moving parts of the appliance.
Do not point the vacuum tube, accessories, or tools to eyes,
ears, or put them into mouth.

9. Stop to use the appliance if electric leakage, motor over-
heating, or abnormal sound is found. And call our
professional for help.
10. For recharging the battery, only use the supply unit
provided with this appliance. Other types of chargers can
cause battery failure or extreme thermal effects. If the
appliance is to be stored unused for a long period, unplug
the adapter to turn off the power. 7. After using, please clean
the dirty water tank, clear the ventilating duct clear to avoid
blockage, reduced suction, motor overheating which will
affect the service life of the appliance. Put the appliance in a
dry place after using. Humidity will affect the insulation and
service life of the appliance.
11. Do not immerse the main body, motorized brush, or
adapter into water or other liquids. There is danger of
electric shock.
12. Check the suction nozzle regularly. If there is blockage,
please remove it to avoid the reduction of suction and affect
the performance of the appliance. Power off the appliance
before disassemble the roller.
13. Do not repair the appliance when it’s broken. Call our
professional to get help.

14. The appliance can be used on indoor even hard floors,
such as waxed floor, rubber floor, marble floor, granite floor,
terrazzo floor, wood floor, bamboo floor, mirror brick surface,
porcelain tile floor. The appliance will fail to reach best
performance on uneven floors.
15. Do not pick up anything that is burning or smoking such
as cigarettes, matches, or hot ashes.
16. Do not operate the appliance too close to heaters,
radiators, or cigarette butts.
17. Do not pick up flammable or combustible liquids such as
gasoline, or use in areas where they may be presented.
18. Do not vacuum up hard or sharp objects such as glass,
nails, screws, or cions that could damage the appliance. Do
not vacuum up drywall dust, fireplace ash, or embers. Do not
use as an attachment to power tools for dust collection.
19. Do not vacuum up toxic solutions such as chlorine
bleach, ammonia, or drain cleaner.
20. Do not use the appliance to clean stains with strong
grease, strong viscosity, and strong dyeing, such as shoe
polish, paintings, pigment.
21. Use extra care when cleaning on stairs.
22. Do not shake or bump the appliance violently. It could
bring the dirty water into the motor.

23. Do not move or lift the appliance while it is working. Do
not tilt the appliance to a side or put it horizontally. It could
bring dirty water into the motor.
24. Put the appliance against the wall to avoid stumble.
25. Do not use the appliance if the clean water tank and
dirty water tank are not correctly assembled.
26. Do not put any objects into openings. Do not use with
any openings blocked. Keep free of dust, lint, hair, and
anything else that may reduce air flow.
27. Do not charge the battery at temperature below 5℃or
above 40℃.
28. Never immerse the appliance, its power cord or plug in
water or any other liquid
About self-drying
The roller will enter self-drying mode after self-cleaning. Self-
cleaning indicator will keep flashing green lights until it is
ended. It takes 5 minutes for self-drying. Press on-off switch
can turn off self-drying.

Product introduction
1
ON/OFF button / self-
cleaning button
7
Tube
2
Speed button
8
Dirty water tank
3
Display screen
9
Clean water tank
releasing button
4
Dirty water tank releasing
button
10
Water filling nozzle
5
Dirty water tank handle
11
Clean water tank
6
Roller
measuring cup HEPA filter adapter storage base
Cleaning tool

1
Power indicator
2
Low speed
3
Clean water tank empty indicator
4
Self-cleaning (green light flashing) / Roller tangled (redlight
flashing) indicator
5
High speed
6
Dirty water tank full indicator

Insert the end of the handle into the nozzle of
the main body vertically until you hear a click.
Make sure the handle is firmly installed.
If you want to disassemble the handle, please
press the latch in the hole on the back of the
main body with a screwdriver.
Meanwhile, pull up the handle.
Press the dirty water tank releasing button to
take out the dirty water tank.
Put the bottom of the dirty water tank onto the
holding point, then push the tank into the main
body until you hear a click.

Press the clean water tank releasing button to
take out the clean water tank.
Silde the lock of the roller outwards and then
upwards to take it out.
Align the buckle at the ends of clean water
tank with the slots of the brush, and press the
tank until you hear a click.
Align one end of the roller with the slot, and
put the other end into the slot.

Press to speed button to switch speed.
Put the product on the storage base, and
press on-off switch for 3 seconds to start
self-cleaning. (Notice: please don’t
charge the product while self-cleaning.)
Please tilt the product while using. The
tilt angle should be less than 142° or
there will be water leak from dirty water
tank.
Please put the product on
storage base after using.

Water filling (method 1)
1. Pull out the plug on
3. Pour the water into the clean the clean water tank to
get some water. It’s water tank through the nozzle.
Water filling (method 2)
1. Take out the clean water tank. 2. Pull out the plug on the filling nozzle
3. Use the measuring cup to get the water.
4. Pour the water into the tank through the nozzle
It’s possible to add cleaning product
(tablet or liquid).
2. Use
the measuring
cup to get some
water. It’s
possible to add
cleaning product
(tablet or liquid).

Cleaning agent
Compatible with different types of solutions such as liquid detergent, solids tabs and cleaning slices
(included in the pack).
Pour the dirty water
1. Press the dirt water tank releasing button to
2. Rotate the dirty water tank cover in above take out the dirty water tank.
Direction and open the dirty water tank.

3. Take out the filters. 4. Pour the dirty water, and clean the dirty
water tank.
Put the product on the storage base, then plug the adapter.
Put away the adapter after charging is finished. Please keep the adapter away from water. While
charging, please put the product upright on the storage base, and put them against to the wall to
avoid stumble.
Warning:
If you won’t use the product for a long time, please charge the product for three hours every three
months to protect the product (no need fully charged).
When you lift up the product, please make sure the brush is 90° from the main body to avoid water
leak from the clean water tank.
The plug of the water filling nozzle has a hole to balance the air pressure.

Do not lay flat or shake violently so as to prevent dirty water leakage.

Clean the product
It’s recommended to maintain the products regularly in order
not to affect the performance.
Use wet cloth to clean the product. Before cleaning, please
power off the product, and make sure not to wet inner
electric device.
Clean the filters
1. Take out the HEPA.2. Take out the filter assembly.

3. Separate the filter assembly in 4. Clean the filter.
above direction
Self-cleaning
Self-cleaning can’t be used while charging.
It’s recommended to use self-cleaning under more than 25%
power, and refill the clean water tank.
Please clean the dirty water tank after self-cleaning.
Please clean the storage base if there is residual water or
dirt.
Press on-off switch for three seconds to start self-cleaning.

It’s recommended to clean the clean water tank regularly to
maintain the performance.
1. Take out the clean water tank.
2. Clean it under running water.
Clean it under running water
1.Take out the roller. 2. Remove dirt and hairs tangled
around the roller.
3. Please take out the rubber gasket if you need to change
the roller cover.

4. Unscrew and take out the roller cover.
5.Align the roller shaft with the hole
6. Align slot of the roller shaft with the slot of the
on the new roller cover. new roller cover, screw on, and
cover with rubber gasket
The roller can be cleaned under running water if necessary.
Please wipe off the water on the ends of roller because the
motor is in the roller.

Trouble shooting
To reduce the risk of shock and unintended operation, turn off power before servicing.
Problem
Possible cause
Possible solution
Not working
Low battery
Full charged the battery.
Roller tangled
Clean the roller.
Poor suction
Dirty water reaches max volume
Clean dirty water tank.
Roller, or dirty water tank not installed
correctly
Reinstall the roller and dirty water tank.
Roller tangled
Clean the roller.
Mesh filer in the dirty water tank get
blocked
Clean the mesh filter.
HEPA blocked or not installed
Clean the HEPA.
Nozzle or dirt passage blocked
Clean nozzle or dirt passage.
Abnormal
sound in motor
Nozzle or dirt passage blocked
Clean nozzle or dirt passage.
Dirty water reaches max volume
Clean dirty water tank.
No clean water
come out
Clean water tank not correctly installed
Reinstall clean water tank.
Clean water tank lack of water
Refill clean water tank.
Water leak from
air outlet
Floater not installed
Install floater.
HEPA is wet
Dry HEPA.
Can’t charged
Plug isn’t well connected
Make sure the plug is well connected.
Adapter isn’t well connected with the
appliance
Make sure the adapter is well
connected with the appliance.
Dirty water tank
full indicator
flashing
Dirty water tank is full or the dirt passage
is blocked
Clean dirty water tank, or clean dirt
passage.
Clean water
tank empty
indicator
flashing
Clean water tank is empty
Refill clean water tank.
Self-
cleaning/roller
tangled
indicator
flashing red
lights
Roller tangled
Clean roller.
