H3C S7502 User manual

H3C S7502 Ethernet Switch
Installation Manual
Hangzhou H3C Technologies Co., Ltd.
http://www.h3c.com
Manual Version: T2-08046H-20071205-C-1.02
Product Version: Release 3000/3100

Copyright © 2006-2007, Hangzhou H3C Technologies Co., Ltd.
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form or by any means
without prior written consent of Hangzhou H3C Technologies Co., Ltd.
Trademarks
H3C, , Aolynk, , H3Care, , TOP G, , IRF, NetPilot,
Neocean, NeoVTL, SecPro, SecPoint, SecEngine, SecPath, Comware, Secware,
Storware, NQA, VVG, V2G, VnG, PSPT, XGbus, N-Bus, TiGem, InnoVision and
HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd.
All other trademarks that may be mentioned in this manual are the property of their
respective owners.
Notice
The information in this document is subject to change without notice. Every effort has
been made in the preparation of this document to ensure accuracy of the contents, but
all statements, information, and recommendations in this document do not constitute
the warranty of any kind, express or implied.
To obtain the latest information, please access:
http://www. h3c.com
Technical Support
[e-mail]
http://www. h3c.com

About This Manual
Related Documentation
In addition to this manual, each H3C S7502 Ethernet Switch documentation set
includes the following:
Manual Description
H3C S7500 Series Ethernet Switches
Operation Manual Guides the user to configure the features supported by the S7500 series.
H3C S7500 Series Ethernet Switches
Command Manual Elaborates on the commands for configuring the S7500 series.
Organization
H3C S7502 Ethernet Switch Installation Manual is organized as follows:
Chapter Contents
1 Product Overview Introduces the characteristics of the
H3C S7502 Ethernet switch.
2 Line Processing Units Introduces LPUs of the H3C S7502
Ethernet switch.
3 Installation Preparations Introduces the preparations and
precautions for the H3C S7502 Ethernet
switch installation.
4 Hardware Installation
Introduces the integrated equipment
installation and cable connection
(including connection of grounding
cables, power cables, and interface
cables, recommended cabling, and
cable binding) of the H3C S7502
Ethernet switch.
5 System Commissioning Introduces the initial power-on startup
process of the H3C S7502 Ethernet
switch.
6 Hardware Maintenance
Introduces the removal and installation
of power modules, LPUs, fan tray, and
delivered cable management brackets
of the H3C S7502 Ethernet switch.
7. Software Maintenance Introduces how to load and upgrade
software of the H3C S7502 Ethernet
switch.

Chapter Contents
8. Troubleshooting
Introduces how to troubleshoot the
configuration system, power system,
fans, and LPUs of the H3C S7502
Ethernet Switch.
Appendix A Lightning Protection Introduces lightning protection of the
H3C S7502 Ethernet switch.
Appendix B AC Power Cables Used in
Different Countries
Introduces the AC power cables used in
different countries, including 10A AC
power cables and 16A AC power cables.
Conventions
The manual uses the following conventions:
I. GUI conventions
Convention Description
< > Button names are inside angle brackets. For example, click
<OK>.
[ ] Window names, menu items, data table and field names are inside square brackets. For example, pop up the [New
User] window.
/ Multi-level menus are separated by forward slashes. For
example, [File/Create/Folder].
II. Symbols
Convention Description
Warning Means reader be extremely careful. Improper operation
may cause bodily injury.
Caution Means reader be careful. Improper operation may cause
data loss or damage to equipment.
Note Means a complementary description.
Environmental Protection
This product has been designed to comply with the requirements on environmental
protection. For the proper storage, use and disposal of this product, national laws and
regulations must be observed.
