H3C S5500-EI series User manual

H3C S5500-EI Series Ethernet Switches
Operation Manual
Hangzhou H3C Technologies Co., Ltd.
http://www.h3c.com
Manual Version: 20071120-C-1.01
Product Version: Release 2102

Copyright © 2007, Hangzhou H3C Technologies Co., Ltd. and its licensors
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form or by any means
without prior written consent of Hangzhou H3C Technologies Co., Ltd.
Trademarks
H3C, , Aolynk, , H3Care, , TOP G, , IRF, NetPilot,
Neocean, NeoVTL, SecPro, SecPoint, SecEngine, SecPath, Comware, Secware,
Storware, NQA, VVG, V2G, VnG, PSPT, XGbus, N-Bus, TiGem, InnoVision and
HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd.
All other trademarks that may be mentioned in this manual are the property of their
respective owners.
Notice
The information in this document is subject to change without notice. Every effort has
been made in the preparation of this document to ensure accuracy of the contents, but
all statements, information, and recommendations in this document do not constitute
the warranty of any kind, express or implied.
To obtain the latest information, please access:
http://www. h3c.com
Technical Support
[e-mail]
http://www. h3c.com

About This Manual
Related Documentation
In addition to this manual, each H3C S5500-EI Series Ethernet Switches
documentation set includes the following:
Manual Description
H3C S5500-EI Series Ethernet Switches
Installation Manual It provides information for the system installation.
H3C S5500-EI Series Ethernet Switches
Command Manual It is used for assisting the users in using various commands.
Organization
H3C S5500-EI Series Ethernet Switches Operation Manual is organized as follows:
Part Contents
0 Overview Introduces the ways for you to obtain
documentation, product overview, and
network application of the switches.
1 Login Introduces the ways to log into an Ethernet
switch.
2 VLAN Introduces VLAN, Voice VLAN, GVRP
fundamental and the related configuration.
3 IP Addressing and IP Performance Introduces IP address and IP performance
fundamental and the related configuration.
4 QinQ-BPDU Tunneling Introduces QinQ, BPDU Tunneling and the
related configuration.
5 Port Correlation Configuration Introduces basic port configuration and port
isolation configuration.
6 Link Aggregation Introduces link aggregation fundamental
and the related configuration.
7 MAC Address Table Management Introduces MAC address forwarding table
and the related configuration.
8 IP Source Guard Introduces MAC address, IP address and
port binding configuration.

Part Contents
9 DLDP Introduces DLDP and the related
configurations.
10 MSTP Introduces STP, BRDU tunnel and the
related configurations.
11 IP Routing-GR Overview Introduces the basic routing information,
the classification of routing protocols, and
GR fundamental.
12 IPv4 Routing Introduces IPv4 routing related
configurations, such as static routing, RIP,
OSPF, IS-IS, BGP, and route policy.
13 IPv6 Routing Introduces IPv6 routing related configurations, such as static routing,
RIPng, OSPFv3, IS-ISv6, and BGP4+.
14 IPv6 Configuration Introduces IPv6 basic configuration and
application, IPv6 tunneling, and so on.
15 Multicast Configuration Introduces the multicast protocol-related
configurations.
16 802.1x-HABP-MAC Authentication Introduces 802.1x, HABP, MAC and
related configurations.
17 AAA RADIUS HWTACACS Introduces AAA, RADIUS, HWTACACS,
and the related configurations.
18 ARP Introduces ARP and the related
configuration.
19 DHCP Introduces DHCP and the related
configuration.
20 ACL Introduces IPv4&IPv6-based ACL and the
related configuration.
21 QoS Introduces QoS and the related
configuration.
22 Port Mirroring Introduces port mirroring and the related
configuration.
23 Cluster Management Introduces Cluster and the related
configurations.
24 UDP Helper Introduces UDP Helper and the related
configuration.
25 SNMP-RMON Introduces the configuration to manage
network devices through SNMP and
RMON.
26 NTP Introduces NTP and the related
configuration.
27 DNS Introduces DNS and the related
configuration.

Part Contents
28 File System Management Introduces basic configuration for file
system management.
29 Information Center Introduces the configuration to analyze and
diagnose networks using the information
center.
30 System Maintaining and
Debugging Introduces daily system maintenance and debugging.
31 NQA Introduces NQA and the related
configurations.
32 VRRP Introduces VRRP and the related
configurations.
33 SSH Introduces SSH and the related
configurations.
34 RRPP Introduces RRPR and the related
configurations.
35 Port Security Introduces Port Security and the related
configurations.
36 LLDP Introduces LLDP and the related
configurations.
37 PoE Introduces PoE and the related
configuration.
38 sFlow Introduces sFlow and the related
configurations.
39 SSL-HTTPS Introduces SSL, HTTPS and the related
configurations.
40 PKI Introduces PKI and the related
configurations.
41 Track Introduces Track and the related
configurations.
42 Appendix Lists the acronyms used in this manual.
Conventions
The manual uses the following conventions:
I. Command conventions
Convention Description
Boldface The keywords of a command line are in Boldface.
italic Command arguments are in italic.

Convention Description
[ ] Items (keywords or arguments) in square brackets [ ] are
optional.
{ x | y | ... }
Alternative items are grouped in braces and separated by
vertical bars. One is selected.
[ x | y | ... ]
Optional alternative items are grouped in square brackets
and separated by vertical bars. One or none is selected.
{ x | y | ... } *
Alternative items are grouped in braces and separated by
vertical bars. A minimum of one or a maximum of all can be
selected.
[ x | y | ... ] *
Optional alternative items are grouped in square brackets
and separated by vertical bars. Many or none can be
selected.
&<1-n> The argument(s) before the ampersand (&) sign can be
entered 1 to n times.
# A line starting with the # sign is comments.
II. GUI conventions
Convention Description
< > Button names are inside angle brackets. For example, click
<OK>.
[ ] Window names, menu items, data table and field names
are inside square brackets. For example, pop up the [New
User] window.
/ Multi-level menus are separated by forward slashes. For
example, [File/Create/Folder].
III. Symbols
Convention Description
Warning Means reader be extremely careful. Improper operation
may cause bodily injury.
Caution Means reader be careful. Improper operation may cause
data loss or damage to equipment.
Note Means a complementary description.
