H3C WA6330 User manual

i
Contents
1 Preparing for installation······························································· 1-1
Safety recommendations ·········································································································· 1-1
Site preparation ······················································································································ 1-1
Installation accessories ············································································································ 1-1
Installation tools······················································································································ 1-2
2 Installing the AP ········································································· 2-1
Installation flowchart ················································································································ 2-1
Pre-installation tasks················································································································ 2-1
Determining the installation position ···························································································· 2-1
Mounting the AP ····················································································································· 2-2
Mounting the AP on a wall·································································································· 2-2
Mounting the AP on a ceiling ······························································································ 2-4
Connecting the AP to a power source·························································································· 2-5
Connecting a PoE power source·························································································· 2-5
Connecting a local power source ························································································· 2-6
Check after power-on ········································································································ 2-6
Connecting the AP to the network······························································································· 2-6
3 Appendix A Technical specifications ··············································· 3-1
4 Appendix B Ports and LEDs·························································· 4-1
Ports ···································································································································· 4-1
LEDs···································································································································· 4-2

1-1
1 Preparing for installation
Safety recommendations
WARNING!
Only qualified personnel can install and remove the AP and its accessories. You must read all
safety instructions carefully before working with the AP.
To avoid possible bodily injury and equipment damage, read the following safety recommendations
before installing the AP. Note that the recommendations do not cover every possible hazardous
condition.
•Take adequate safety measures to avoid bodily injury and device damage.
•Place the AP in a dry and flat location and take anti-slip measures.
•Keep the AP clean and dust-free.
•Do not place the AP in a moist area and avoid liquid intrusion.
•Keep the AP and installation tools away from walkways.
Site preparation
Before installing the AP, examine the installation site and ensure that the AP will operate in a
favorable environment. Make sure the temperate and humidity at the installation site meets the
requirements in Table1-1.
Table1-1 Temperature and humidity requirements
Item Specification
Operating temperature –10°C to +55°C (14°F to 131°F)
Storage temperature –40°C to +70°C (–40°F to +158°F)
Operating humidity 5% RH to 95% RH, noncondensing
Installation accessories
Figure1-1 Accessories provided with the AP

1-2
Installation tools
When installing the AP, you might need the following tools. Prepare the installation tools yourself as
required.
Figure1-2 Installation tools

2-1
2 Installing the AP
Installation flowchart
Figure2-1 Installation flowchart
Pre-installation tasks
Before installing the AP, perform the following tasks:
•Connect the AP to a power source and the network. Examine the LEDs to verify that the AP is
operating correctly. For information about AP LEDs, see "LEDs."
•Record the MAC address and serial number at the rear of the AP for future use.
•Make sure you have completed cabling at the installation site.
Determining the installation position
Determine the installation position by observing the following principles:
•Few obstacles such as wall exist between the AP and clients.
•The AP is far away from electronic devices (such as microwave oven) that might generate
radio frequency (RF) noise.
•The AP does not hinder people’s daily work and life.
Start
Complete pre-installation tasks
Determine
the mounting option
On the wall On the ceiling
Connect the AP to the power
source
Connect the AP to the network
End
Install the AP

2-2
•The place is not water seeping, water soaking, and condensing.
Mounting the AP
The AP can be installed only indoors. You can mount the AP on a wall or a ceiling.
Mounting the AP on a wall
1. Place the mounting bracket against the wall and mark the installation holes on the wall.
Figure2-2 Marking the installation holes on the wall
2. Drill holes with a diameter of 6 mm (0.24 in) and a depth of 30 mm (1.18 in) at the marked
locations, as shown in Figure2-3.
Figure2-3 Drilling holes in the wall
3. Insert a screw anchor into each hole, and tap the screw anchor with a rubber hammer until it is
all flush with the wall surface, as shown in Figure2-4.

2-3
Figure2-4 Hammering the screw anchor into the wall
4. Insert the screws through the installation holes in the wall bracket into the holes in the wall.
Fasten the screws to secure the mounting bracket to the wall.
Figure2-5 Attaching the mounting bracket to the wall
5. Position the four pegs on the AP into the keyhole slots in the mounting bracket and then slide
the AP down until it clicks into place, as shown in Figure2-6.
Figure2-6 Attaching the AP to the mounting bracket

2-4
Mounting the AP on a ceiling
CAUTION:
The ceiling for installing the AP must be less than 18 mm (0.71 in) in thickness, and can bear a load
of 5 kg (11.02 lb). If you must install the AP on a ceiling not strong enough, use boards to reinforce
the ceiling.
To mount the AP on a ceiling:
1. Remove the ceiling tile.
2. Place the mounting bracket against the ceiling tile and mark the installation holes on the ceiling
tile.Drill three holes with a diameter of 6 mm (0.24 in) at the marked positions, as shown
in Figure2-7.
Figure2-7 Drilling holes in the ceiling tile
3. Thread the pan-head screws through the installation holes in the mounting bracket and into the
holes in the ceiling tile. Fasten washers and nuts at the other side of the ceiling to secure the
mounting bracket to the ceiling, as shown in Figure2-8.
Figure2-8 Attaching the mounting bracket to the ceiling
4. Position the four pegs on the AP into the keyhole slots in the mounting bracket and slide the
AP until it clicks into place, as shown in Figure2-9.

2-5
Figure2-9 Attaching the AP to the mounting bracket
5. Verify that the AP is securely installed to prevent it from falling off.
Connecting the AP to a power source
IMPORTANT:
The cable cover is not required in the following conditions:
•Shielded network cables are used to connect Ethernet ports on the AP.
•A power adapter with a straight connector is used to supply power to the AP.
You can supply power to the AP by using a local power source or through 802.3af/802.at PoE as
required. Before powering the AP, make sure the power source (the local power source or the PSE)
is reliably grounded.
Connecting a PoE power source
CAUTION:
The AP is to be connected only to PoE networks without routing to the outside plant.
To power the AP through PoE, use an Ethernet cable to connect an Ethernet port on a PoE switch to
the 2.5GE/PoE+ port on the AP. After connecting all cables to the AP, attach the cable cover
securely to the AP.
Figure2-10 Powering the AP through PoE

2-6
Connecting a local power source
You can use an AC/DC power adapter to connect the AP to a local power source. No power adapter
is provided with the AP. Prepare one yourself as required. Table2-1 describes the power adapter
specifications.
Table2-1 Power adapter specifications
Item Specification
Input 100 VAC to 240 VAC
Output +54 VDC at 0.74 A
Figure2-11 Using a power adapter to connect the AP to a local power source
Check after power-on
Examine the LEDs on the AP after you power on it to verify that the AP is operating correctly. For
more information about AP LEDs, see "LEDs."
Connecting the AP to the network
All AP settings are configured on the AC. To verify the network connectivity of the AP, execute the
display wlan ap all command on the AC. If the AP status is R/M, the AP has been connected
to the network.
<Sysname> display wlan ap all
Total number of APs: 1
Total number of connected APs: 1
Total number of connected manual APs: 1
Total number of connected auto APs: 0
Total number of connected common APs: 1
Total number of connected WTUs: 0
Total number of inside APs: 0
Maximum supported APs: 3072
Remaining APs: 3071
Total AP licenses: 128
Remaining AP licenses: 127
AP information
State : I = Idle, J = Join, JA = JoinAck, IL = ImageLoad
C = Config, DC = DataCheck, R = Run M = Master, B = Backup

2-7
AP name APID State Model Serial ID
ap1 1 R WA6330 219801A23V8192E00021

3-1
3 Appendix A Technical specifications
Table3-1 Technical specifications
Item Specification
Dimensions (H × W × D) (without the
mounting bracket) 45 × 215 × 215 mm (1.77 × 8.46 × 8.46 in)
Weight 940 g (33.16 oz)
Antenna (built-in) •2.4 G: gain of 3 dBi
•5 G: gain of 5 dBi
System power consumption
•≤16.5 W (not supplying PoE power)
•≤32 W (supplying PoE power)
•≤12.93 W (Not supplying PoE power and with the radios
operating in 1×1 MIMO mode)
Powering option
•Local DC power source
•802.3at PoE (the system power consumption ≤16.5 W)
•802.3af PoE (the system power consumption ≤12.93 W)
Protocol •802.11b/g/a/n/ac/ax
•802.3at/af

4-1
4 Appendix B Ports and LEDs
Ports
The AP provides the following ports:
•One console port
•One USB port
•One GE port
•One 2.5GE port
•One power port
The AP also has a reset button and a security slot. The security slot is 7 × 3 mm (0.28 × 0.12 in) in
size.
Figure4-1 Ports on the AP
(1) Reset button (2) Console port (3) USB port
(4) 10/100/1000M Ethernet copper port (5) 100/1000/2500M Ethernet copper port
(6) Power port (7) Security slot
Table4-1 Port and button descriptions
Port Standards and
protocols Description
Reset button N/A
•To reset the AP, press and hold the button for
no more than 5 seconds.
•To restore the factory default, press and hold
the button for more than 5 seconds.
Console port RS/EIA-232 Used for device configuration and management
only.
USB port USB 2.0 N/A
10/100/1000M Ethernet
copper port (GE/PSE)
•IEEE802.3
•IEEE802.3u
•IEEE802.3af
•IEEE802.3at
Used for connecting a downlink device. It can also
supply PoE power to the downlink device.
It is represented by interface number GE1/0/1 in the
MAP file and gigabitethernet 1 for configuration on
the AC.

4-2
Port Standards and
protocols Description
100/1000/2500M Ethernet
copper port (2.5GE/PoE+)
•IEEE802.3
•IEEE802.3u
•IEEE802.3af
•IEEE802.3at
Used for connecting the AP to an uplink device for
Internet or MAN access. It can also receive PoE+
power from the uplink device.
It is represented by interface number SGE1/0/1 in
the MAP file and smartrate-ethernet 1 for
configuration on the AC.
Power port (54 V) N/A Used for receiving +54 VDC power from the local
power source.
LEDs
Table4-2 LED descriptions
LED Status Description
Off No power is present or the LED has been turned off
from the CLI.
Yellow
Steady on The AP is initializing, or an initialization exception
has occurred.
Flashing at 1 Hz No radio cards have been detected.
Flashing at 2 Hz The Ethernet interfaces are down and no mesh links
are established.
Green
Steady on The AP has registered to an AC, but does not have
any associated clients.
Flashing at 0.5 Hz The AP has started up but has not registered to any
AC.
Flashing at 1 Hz Only the 2.4G radio has associated clients.
Flashing at 2 Hz The AP is upgrading the image.
Blue Flashing at 1 Hz Only the 5G radio has associated clients.
Alternating between green and blue at
1 Hz
Both the 2.4G and 5G radios have associated
clients.
