H3C WA5620i-ACN User manual

H3C WA5620i-ACN Access Point
Installation Guide
New H3C Technologies Co., Ltd.
http://www.h3c.com.hk
Document version: 6W101-20170414

Copyright © 2017, New H3C Technologies Co., Ltd. and its licensors
All rights reserved
No part of this manual may be reproduced or transmitted in any form or by any means without prior written
consent of New H3C Technologies Co., Ltd.
Trademarks
H3C, , H3CS, H3CIE, H3CNE,Aolynk, , H3Care, , IRF, NetPilot, Netflow, SecEngine,
SecPath, SecCenter, SecBlade, Comware, ITCMM and HUASAN are trademarks of New H3C Technologies
Co., Ltd.
All other trademarks that may be mentioned in this manual are the property of their respective owners
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.
Environmental protection
This product has been designed to comply with the environmental protection requirements. The storage, use,
and disposal of this product must meet the applicable national laws and regulations.

Preface
The H3C WA5620i-ACN Access Points Installation Guide guides you through the installation of your
AP. It covers product overview, preparing for installation, installing theAP, and LEDs and ports.
This preface includes the following topics about the documentation:
•Audience.
•Conventions
•Obtaining documentation
•Technical support
•Documentation feedback
Audience
This documentation is intended for:
•Network planners.
•Field technical support and servicing engineers.
•Network administrators working with the WA5620i-ACN APs.
Conventions
The following information describes the conventions used in the documentation.
Command conventions
Convention Description
Boldface Bold text represents commands and keywords that you enter literally as shown.
Italic Italic text represents arguments that you replace with actual values.
[ ] Square brackets enclose syntax choices (keywords or arguments) that are optional.
{ x | y | ... }
Braces enclose a set of required syntax choices separated by vertical bars, from which
you select one.
[ x | y | ... ]
Square brackets enclose a set of optional syntax choices separated by vertical bars,
from which you select one or none.
{ x | y | ... } *
Asterisk marked braces enclose a set of required syntax choices separated by vertical
bars, from which you select a minimum of one.
[ x | y | ... ] *
Asterisk marked square brackets enclose optional syntax choices separated by vertical
bars, from which you select one choice, multiple choices, or none.
&<1-n> The argument or keyword and argument combination before the ampersand (&) sign
can be entered 1 to n times.
# A line that starts with a pound (#) sign is comments.
GUI conventions
Convention Description
Boldface Window names, button names, field names, and menu items are in Boldface. For
example, the New User window opens; click OK.

Convention Description
> Multi-level menus are separated by angle brackets. For example, File > Create >
Folder.
Symbols
Convention Description
WARNING! An alert that calls attention to important information that if not understood or followed
can result in personal injury.
CAUTION: An alert that calls attention to important information that if not understood or followed
can result in data loss, data corruption, or damage to hardware or software.
IMPORTANT: An alert that calls attention to essential information.
NOTE: An alert that contains additional or supplementary information.
TIP: An alert that provides helpful information.
Network topology icons
Convention Description
Represents a generic network device, such as a router, switch, or firewall.
Represents a routing-capable device, such as a router or Layer 3 switch.
Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that
supports Layer 2 forwarding and other Layer 2 features.
Represents an access controller, a unified wired-WLAN module, or the access
controller engine on a unified wired-WLAN switch.
Represents an access point.
Wireless terminator unit.
Wireless terminator.
Represents a mesh access point.
Represents omnidirectional signals.
Represents directional signals.
Represents a security product, such as a firewall, UTM, multiservice security
gateway, or load balancing device.
Represents a security module, such as a firewall, load balancing, NetStream, SSL
VPN, IPS, or ACG module.
T
T
T
T





Examples provided in this document
Examples in this document might use devices that differ from your device in hardware model,
configuration, or software version. It is normal that the port numbers, sample output, screenshots,
and other information in the examples differ from what you have on your device.
Obtaining documentation
To access the most up-to-date H3C product documentation, go to the H3C website at
http://www.h3c.com.hk
To obtain information about installation, configuration, and maintenance, click
http://www.h3c.com.hk/Technical_Documents
To obtain software version information such as release notes, click
http://www.h3c.com.hk/Software_Download
Technical support
[e-mail]
http://www.h3c.com.hk
Documentation feedback
You can e-mail your comments about product documentation to [e-mail].
We appreciate your comments.

i
Contents
Product overview ·············································································1
Preparing for installation····································································2
Safety recommendations·············································································································2
Temperature and humidity requirements·························································································2
Accessories provided with the AP··································································································2
Installation tools and equipment····································································································3
Installing the AP···············································································4
Check before installation ·············································································································4
Determining the installation position·······························································································4
Installing the AP ························································································································5
Mounting the AP on a wall·····································································································5
Installing the AP on a ceiling··································································································7
Connecting the AP to a power supply···························································································10
Connecting a PoE power supply···························································································10
Connecting the local power supply························································································10
Check after power-on·········································································································11
Connecting the AP to the network································································································11
Verifying network connection for the fit AP··············································································11

1
Product overview
An H3C WA5620i-ACNAP can act as a fitAP to cooperate with access controller modules or access
controllers to provide wireless access for WLAN users. The network settings are configured on the
access controller modules or access controllers.
Figure 1 Deployment of WA5620i-ACN APs
Table 1 H3C WA5620i-ACN specifications
Item Specification
Protocol •IEEE 802.11a/b/g/n/ac
•Dual-radio
Built-in antennas •2.4 G antenna: gain 4 dBi
•5 G antenna: gain 4 dBi
Power consumption 12.5 to 25 W
Dimensions (H × W × D) 52 × 220 × 227 mm (2.05 × 8.66 × 8.94 in)
Weight 1.06 kg (2.34 lb)

2
Preparing for installation
Safety recommendations
WARNING!
Only qualified personnel can install and remove the APand its accessories. You must read all safety
instructions supplied with the AP before installation and operation.
To avoid possible bodily injury and equipment damage, read the following safety recommendations
before installing the AP. Note that the recommendations do not cover every possible hazardous
condition.
•Take adequate safety measures to avoid injury andAP damage.
•Place the AP in a dry and flat location and take anti-slip measures.
•Keep the AP clean and dust-free.
•Do not place the AP in a moist area and avoid liquid surrounding the AP.
•Keep the AP and installation tools away from walkways.
Temperature and humidity requirements
Item Specification
Operating temperature (indoor) –10°C to +55°C (14°F to 131°F)
Storage temperature –40°C to +70°C (–40°F to +158°F)
Operating humidity (noncondensing) 5% to 95%
Accessories provided with the AP
Mounting kit
Three sets of M4 × 30 pan head
screw, washer, and nut
Three sets of wall anchor kit
MAC address label

3
One M4 × 10 pan head screw
Installation tools and equipment
When installing the AP, you may need the following tools. Prepare these tools and equipment
yourself.
Needle-nose pliers Wire-stripping pliers Diagonal pliers Marker
Percussion drill with
matching drills Rubber hammer Phillips screwdriver

4
Installing the AP
Figure 2 Installation flowchart
Check before installation
Before installing anAP, perform the following tasks:
•Connect the AP to the power supply and the network. Examine the LEDs to verify that the AP
can operate correctly. For more information about AP LEDs, see "Appendix LEDs and ports."
•Verify that cabling on the installation site has been completed.
•To power the AP through PoE/PoE+, use 802.3at PoE+ as a best practice. If 802.3af PoE is
used, the AP supports only one spatial stream and the USB and unused Ethernet ports are
shutdown automatically.
•Record the AP MAC address and serial number marked on the rear of theAP for future use.
NOTE:
•Use a category 5e cable to connect the AP's 2.5 GE port. For the interface to operate at 2500
Mbps, use an H3C switch that provides a 2.5 GE interface.
•Use a category 5 cable to connect the AP's GE port. The auto-negotiated transmission rate is
1000 or 100 Mbps.
Determining the installation position
You can mount the AP to a wall or ceiling. Determine the installation position by observing the
following principles:
Start
Determine the installation
position
Wall-mounting the AP
End
Mount the mounting bracket to
the wall
Install the AP
Connect the AP to the power supply
Connect the AP to the network
Mount the mounting bracket to
the ceiling
Ceiling-mounting the AP
Check before installation

5
•Few obstacles such as wall and ceiling exist between AP and clients.
•The AP is far away from electronic devices (such as microwave oven) that may generate radio
frequency (RF) noise.
•The AP does not hinder people’s daily work and life.
•The place is not water seeping, water soaking, and condensing.
•A lightning arrester (user supplied) is installed on theAP for cabling outdoors.
•The AP must be over 5-meter away from 3G and 4G stations and antennas.
Installing the AP
Mounting the AP on a wall
1. Align the screw hole in the AP bracket with the screw hole in the AP rear. Use the M4 × 10
screw to secure the AP bracket to the AP.
Figure 3 Attaching the AP bracket to the AP rear
2. Mark the installation holes on the wall by using the mounting bracket, as shown in Figure 4.
Figure 4 Mounting holes in the mounting bracket

6
Figure 5 Marking installation holes on the wall
3. Drill holes with a diameter of 5 mm (0.197 in) and a depth of 30 mm (1.18 in) in the marked
locations, as shown in Figure 6.
Figure 6 Drilling holes in the wall
4. Insert a wall anchor into each hole, and tap the wall anchor with a rubber hammer until it is all
flush with the wall surface, as shown in Figure 7.
Figure 7 Hammering the anchor
73 mm (2.87 in)
69.4 mm (2.73 in)
69.4 mm (2.73 in)

7
5. Align the mounting holes in the mounting bracket with the anchors and insert screws through
the mounting holes into the wall anchors. Adjust the position of the mounting bracket and
tighten the screws.
Figure 8 Attaching the mounting bracket to the wall
6. Connect the AP to the LAN by using Ethernet cables.
7. Align the AP at a 45 degree angle with the mounting bracket, and rotate the AP clockwise until
it clicks into place, as shown in Figure 9.
Figure 9 Attaching the AP to the wall mounting bracket
Installing the AP on a ceiling
CAUTION:
The ceiling for installing the AP must be less than 18 mm (0.71 in) in thickness, and can bear a load
of 5 kg (11.02 lb). As a best practice, reinforce the ceiling by using boards if the ceiling is not strong
enough.

8
To install the AP on a ceiling:
1. Align the screw hole in the AP bracket with the screw hole in the AP rear. Use the M4 × 10
screw to secure the AP bracket to the AP.
Figure 10 Attaching the AP bracket to the AP rear
2. Mark the installation holes on the ceiling by using the mounting bracket.
3. Drill holes with a diameter of 5 mm (0.197 in) in the marked positions, as shown in Figure 11.
Figure 11 Drilling holes in the ceiling
4. Insert the M4 × 30 pan head screws through the mounting holes in the mounting bracket and
the holes in the ceiling. Fasten washers and nuts at the other side of the ceiling to attach the
mounting bracket to the ceiling, as shown in Figure 12.

9
Figure 12 Attaching the mounting bracket to the ceiling
5. Connect the AP to the LAN by using Ethernet cables.
6. Align the AP with the mounting bracket and rotate the AP clockwise until it clicks into place, as
shown in Figure 13.
Figure 13 Attaching the AP to the ceiling mounting bracket
7. Verify that the AP is securely installed to prevent it from falling off.

10
Connecting the AP to a power supply
CAUTION:
Before powering on the AP, make sure the power supply is reliably grounded.
You can power the AP with a local power or by using PoE+ or PoE.
If 802.3af PoE is used, the AP supports only one spatial stream and the USB and unused Ethernet
ports are shutdown automatically.
Connecting a PoE power supply
Use an Ethernet cable to connect the Ethernet interface that supports PoE on the AP to a PoE
switch.
Figure 14 Connecting a PoE power supply
Connecting the local power supply
No AC/DC adapter and power cord are provided with the AP. Prepare them yourself if required.
Table 2 AC/DC adapter specifications
Item Specification
Input 100 VAC to 240 VAC
Output +54V at 0.74 A
You can power the AP by using an AC/DC adapter. Use the AC/DC adapter to connect the power
port of the AP to the local power source.

11
Figure 15 Connecting the local power supply
Check after power-on
Verify that the AP is powered on and operating correctly by examining the AP status LED. For more
information aboutAP LEDs, see "Appendix LEDs and ports."
Connecting the AP to the network
Connect an Ethernet port of the AP to an Ethernet port of an Ethernet switch for Internet or MAN
access.
Verifying network connection for the fit AP
All settings of the fitAP are configured on the AC. Use the display wlan ap all command on the AC
that connects to the fitAP. If theAP status is R/M, the AP is connected to the network.
<AC> display wlan ap all
Total number of APs: 1
Total number of connected APs: 1
Total number of connected manual APs: 1
Total number of connected auto APs: 0
Total number of connected common APs: 0
Total number of connected WTUs: 0
Total number of inside APs: 0
Maximum supported APs: 3072
Remaining APs: 3070
Total AP licenses: 128
Remaining AP licenses: 127
AP information
State : I = Idle, J = Join, JA = JoinAck, IL = ImageLoad
C = Config, DC = DataCheck, R = Run M = Master, B = Backup
AP name APID State Model Serial ID
ap1 1 R WA5620i-ACN 210235A1SVC15C000002

i
Contents
Appendix LEDs and ports ··································································1
LEDs·······································································································································1
Ports·······································································································································2

1
Appendix LEDs and ports
LEDs
Figure 1 LEDs on the AP
Table 1 LED description
Power LED 2.5-GE port
LED GE port LED WLAN LED Description
Off Off Off Off
No power supply is connected to the
AP.
Orange Off Off Off
A power supply has been connected
to the AP.
If the power LED remains orange
after a few minutes, an initialization
exception has occurred to the AP.
Flashing
green (0.5 Hz) Off Off Off The AP is booting.
Flashing
green (1 Hz) Off Off Off
The AP is requesting IP addresses
or is creating a VLAN list.
Flashing green in turn Off The AP has obtained IP addresses
and is attempting to discover an AC.
Steady green Flashing green in turn Off The AP has discovered an AC and is
attempting to register on the AC.
Steady green Off N/A N/A No link or traffic is present on the 2.5
GE port.
Steady green Flashing green
(1 Hz) N/A N/A
The 2.5 GE port is sending or
receiving data at 2.5 Gbps.
Steady green Steady green N/A N/A The 2.5 GE port is sending or
receiving data at 1000 Mbps.
Steady green Steady orange N/A N/A The 2.5 GE port is sending or
receiving data at 10 or 100 Mbps.
Steady green N/A Off N/A No link is present on the GE port.
Steady green N/A Steady green N/A The GE port is sending or receiving
data at 1000 Mbps.
Steady green N/A Steady orange N/A The GE port is sending or receiving
data at 10 or 100 Mbps.

2
Power LED 2.5-GE port
LED GE port LED WLAN LED Description
Steady green N/A N/A Off No client is associated with the 2.4
GHz or 5 GHz radios.
Steady green N/A N/A Flashing
orange (1
Hz)
Clients are associated only with the
2.4 GHz radio.
Steady green N/A N/A Flashing
green (1 Hz) Clients are associated only with the 5 GHz radio.
Steady green N/A N/A
Alternatively
flashing
green and
orange (1
Hz)
Clients are associated with both the
2.4 GHz and 5 GHz radios.
NOTE:
N/A in Table 1 represents any LED status.
Table 2 Reset button description
Pressing time LED status Description
0 to 5 seconds The power, 2.5-GE port, and GE port LEDs are
steady green and the WLAN LED is off. The AP is reset.
5 to 15 seconds The power, 2.5-GE port, and GE port LEDs are
flashing green at 0.5 Hz and the WLAN LED is off. Factory settings are restored.
Ports
The AP provides the following ports:
•One console port
•One 10/100/1000 Mbps copper Ethernet port and one 100/1000/2500 Mbps copper Ethernet
port
•One power port
•One USB port
NOTE:
The AP also has a reset button and a security slot. The security slot is 7 × 3 mm (0.28 × 0.12 in) in
size.
