Haier AU122AEEAA User manual

ROOM AIR CONDITIONER
OUTDOOR UNIT
Before using the air conditioner,please read this anual carefully.
Please keep this anual properly for future use.
CONTENTS
Name of Parts----------------------1
Safety Cautions------------------2-3
Installation Procedure---------4-13
INSTALLATION INSTRUCTIONS
No.0010577959
F
A 242AGEAA
A 48NAIEAA
A 60NAIEAA
A 36NAIEAA
A 362AIEAA
A 122AEEAA
A 182AEEAA
A 282AHEAA
A 28NAHEAA
A 362ALEAA
A 42NALEAA

Na e of Parts
1
Air inlet
Air outlet
(Inside of unit)
Co pressor
A 36NAIEAA
A 362AIEAA
A 48NAIEAA
A 60NAIEAA
A 242AGEAAA 122AEEAA A 182AEEAA
Air inlet
Air outlet
(Inside of unit)
Co pressor
Air inlet
Air outlet
(Inside of unit)
Co pressor
Air inlet
Air outlet
(Inside of unit)
Co pressor
A 282AHEAA
A 28NAHEAA A 362ALEAA
A 42NALEAA
Air inlet
Air outlet
(Inside of unit)
Co pressor

Below are listed three kinds of Safety Cautions and Suggestions.
WARNING!
CAUTION! Incorrect operations may result in injuries or machine damages; in some cases may
cause serious consequences.
Incorrect operations may result in severe consequences of death or serious injuries.
INSTRUCTIONS: These information can ensure the correct operation of the machine.
Be sure to conform with the following important Safety Cautions.
The Safety Cautions should be at hand so that they can be checked at any ti e when needed.
If the conditioner is transferred to the new user, this manual should be as well transferred to the
new user.
Safety Cautions
Carefully read the following infor ation in order to operate the airconditioner
correctly.
WARNING!
If any abnor al pheno ena is found
(e. g.s ell of firing), please cut off the
power supply i ediately, and contact
the dealer to find out the handling
ethod.
Don't dis antle the outlet of the
outdoor unit.
The exposure of fan is very dangerous
whichmay harm human beings.
switch
off
In such case, to continue using the
conditioner will damage the conditioner,
and may cause electrical shock or fire
hazard.
Incorrect maintenance and repairment
may cause water leak, electrical shock
and fire hazard.
When need aintenance and repair ent,
call dealer to handle it.
After a long ti e use of air-conditioner
the base should be checked for any
da ages.
If the damaged base is not repaired, the
unit may fall down and cause accidents.
2

Air-conditioner can't be installed in
the environ ent with infla able
gases because the infla able gases
near to air-conditioner ay cause fire
hazard.
Connect earthing wire.
Use discharge pipe correctly to ensure
efficient discharge.
Earthing wire should not be con-
nected to the gas pipe, water pipe,
lightning rod or phone line, in-
correct earthing may cause shock.
Incorrect pipe use may cause water
leaking.
Earthing
Safety Cautions
WARNING!
Installed electrical-leaking circuit
breaker.
It easily cause electrical shock without
circuit breaker.
Please let the dealer be responsible for
installing the conditioner.
Incorrect installation may cause water
leak, electrical shock and fire hazard.
Call the dealer to take easures to
prevent the refrigerant fro leaking.
If conditioner is installed in a small
room be sure to take every measure in
order to prevent suffocation accident
even in case of refrigerant leakage.
When conditioner is deinstalled or
reinstalleddealer should be respon-
sible for the .
Incorrect installation may cause water
leaking, electrical shock and fire hazard.
No goods or nobody is per itted to
placed on or stand on outdoor unit.
The falling of goods and people may
cause accidents.
Don't operate the air-conditioner with
da p hands.
Otherwise will be shocked.
Only use correctly-typed fuse.
May not use wire or any other materials
replacing fuse, other-wise may cause
faults or fire accidents.
3

Note :
(1). Fix the parts with screws
(2).Don't intake the strong wind directly to the
outlet air-flow hole.
(3).A one meter distance should be kept from the
unit top
(4).Don't block the surroundings of the unit with
sundries
Installation Procedure
2. Selection of the place of installation
1. Accessories
"Edging" for protection of electric wires from an
opening edge.
Select the place of installation satisfying the following conditions and, at the
same time, obtain a consent from the client or user.
Edging
Place where air circulates.
Place free from heat radiation from other heat sources.
Place where drain water may be discharged.
Place where noise and hot air may not disturb the neighborhood.
Place where there is not heavy snowfall in the winter time.
Place where obstacles do not exist near the air inlet and air outlet .
Place where the air outlet may not be exposed to a strong wind.
Place surrounded at four sides are not suitable for installation. A 1m or more
of overhead space is needed for the unit.
Mount guide-louvers to place where short-circuit is a possibility.
When installing several units, secure sufficient suction space to avoid short
circuiting.
Wind direction
NO
(2) Installation where the area with strong winds.
Install the unit so that the air outlet section of the unit must NOT be faced
toward wind direction.
(1) Open space require ent around the unit
L2
L3
L1
500
(Servicing
space)
Air outlet
Air inlet
Air
inlet
Case
Distance
nit: mm
open open
open
500
150
150 300
300 300
L1
L2
L3
III III
Installation of outdoor unit
4

(a) Concrete foundation (b) Foundation anchor
(b) Foundation anchor
(a) Concrete foundation
(a) Concrete foundation (b) Foundation anchor
(a) Concrete foundation (b) Foundation anchor
Installation of outdoor unit
5
Installation Procedure
3. Installation of outdoor unit
Fix the unit in a proper way according to the condition of a place where it is
installed by referring to the following .
(1) Installation
A 122AEEAA A 182AEEAA
A 282AHEAA A 28NAHEAA
Install the unit so that the angle of inclination must be less than 3 degrees.
Note: (1) Give enough room for the concrete foundation to fix by anchor bolts.
(2) Place the concrete foundation deep enough.
nit
Concrete foundation
Anchor bolt
A 242AGEAA A 362ALEAA A 42NALEAA
Concrete foundation
nit
Anchor bolt
Anchor bolt
Concrete foundation
nit
To fix by bolts
A 362AIEAA A 36NAIEAA A 48NAIEAA A 60NAIEAA
Concrete foundation
nit
Anchor bolt
Anchor bolt
Concrete foundation
nit
To fix by bolts
Concrete foundation
nit
Anchor bolt
Anchor bolt
Concrete foundation
nit
To fix by bolts
nit
To fix by bolts
Anchor bolt Concrete foundation

(2) Installation sketch of outdoor unit
180
447
180 648
410
Installation of outdoor unit
6
Installation Procedure
A 122AEEAA A 182AEEAA
A 282AHEAA A 28NAHEAA
A 242AGEAA
730
630
308 335
Power Wiring Terminal
Power Wiring
Distribution Hole
860
Power Wiring Terminal
Power Wiring
Distribution Hole
25
780
640
500
245
Power Wiring Terminal
Power Wiring
Distribution Hole
25
948
840
580
340
380
A 362ALEAA A 42NALEAA
Power Wiring Terminal
Power Wiring
Distribution Hole
1008
830
25

(1) Outline piping
4. Refrigerant piping
Installation of outdoor unit
7
580
340
380
Installation Procedure
Outdoor
unit
3-way stop valve
Gas pipe
Liquid
pipe
Flare connection
Indoor
unit
Flare connection 3-way stop valve
Outdoor
unit
3-way stop valve
Gas pipe
Liquid
pipe
Flare connection
Indoor
unit
Flare connection 2-way stop valve
A 362AIEAA A 36NAIEAA A 48NAIEAA A 60NAIEAA
948
Power
wiring
Terminal
25
1250
A 122AEEAA A 182AEEAA A 362ALEAA A 42NALEAA
A 242AGEAA A 282AHEAA A 28NAHEAA A 362AIEAA A 36NAIEAA
A 48NAIEAA A 60NAIEAA

(2) Piping size
Gas pipe 15.88x1.0mm
Install the removed flare nuts to
the pipes to be connected, then
flare the pipes.
Liquid pipe
Gas pipe
9.52x0.8mm
19.05x1.0mm
Liquid pipe 9.52x0.8mm
(3) Li itations for one way piping length and vertical height difference.
Forced fastening without centering
may damage the threads and cause a
gas leakage.
Gas pipe 12.7x1.0mm
Liquid pipe 6.35x0.8mm
Precautions for refrigerant piping
Do not twist or crush piping.
Be sure that no dust is mixed in piping.
Bend piping with as wide angle as possible.
Keep insulating both gas and liquid piping.
Check flare-connected area for gas leakage.
Connecting method (indoor unit)
Apply refrigerant oil at half union as large and flare nut.
To bend a pipe, give the roundness as possible not to crush
the pipe.
When connecting pipe, hold the pipe centre to centre then
screw nut on by hand, refer to Fig.
Be careful not to let foreign matters, such as sands enter
the pipe.
(4) Piping connection
Pipe dia Fastening torque
Liquid pipe 6.35mm
Gas pipe 15.88mm
Liquid pipe 9.52mm
Gas pipe 19.05mm
14.2-17.2N.m
61.8-75.4N.m
32.7-39.9N.m
97.2-118.6N.m
Gas pipe 12.7mm 49.5-60.3N.m
Model One way piping length Vertical height difference
(between indoor and outdoor)
less than 30 m
A 362AIEAA A 36NAIEAA
A 362ALEAA A 42NALEAA
A 48NAIEAA A 60NAIEAA
A 242AGEAA A 282AHEAA
A 28NAHEAA
A 36NAIEAA A 362ALEAA
A 362AIEAA A 42NALEAA
A 48NAIEAA A 60NAIEAA
Refrigerant piping
8
90+0.5
A 242AGEAA
A 282AHEAA
A 28NAHEAA
Installation Procedure
A 122AEEAA
A 182AEEAA
less than 50 m
less than 15 m
less than 30 m
A 122AEEAA less than 10 m less than 5 m
A 182AEEAA less than 20 m less than 10 m

In the first to third test steps, if the pressure drops, check the leakage in each joint
use sense of hearing, feeling and soap water, etc. methods to find the leaking point.
After confirming the leaking point, welding it again or tighten the nut tightly again.
Checking the leaking point
First step: 0.3MPa (3.
0kg/cm
2g) pressurize
over 3 minutes.
Second step: 1.5Mpa
(15kg/cm2g) pressurize
over 3 minutes. Large
leakage will be found.
Third step: 3.0 MPa
(30kg/cm2g) pressurize
about 24 hours. Little
leakage will be found.
After finishing connection of refrigerant pipe, it shall perform air tightness test.
The air tightness test adopts nitrogen tank to give pressure according to the pipe connection
mode as the following figure shown.
The gas and liquid valve are all in close state. In order to prevent the nitrogen entering the
circulation system of outdoor unit, tighten the valve rod before giving pressure (both gas
and liquid valve rods).
Outdoor
Completely tightened
Completely tightened
Flare part
Outdoor units
Manhole
Discharging valve
stop valve totally closed
(Gas side)
Low pressure peizometer
High pressure peizometer
Meter separator
Dropping valve
stop valve totally closed
(Liquid side)
Nitrogen tank
VL VH
Indoor units
Indoor
Flare part
9
From pressurizing to 24 hours later, each 1¡ difference of ambient temperature
will make 0.01MPa(0.1kg/cm2g) pressure change. It shall be corrected during test.
Check if the pressure drops
The pressure does not drop-passed
The pressure drops-check the leaking point.
5. Air discharging ethod
CYLINDER
OF
NITROGEN
SERVICE
HO SE
LARGE
SLIP-ON
CONNECTOR
SWEAT
JOINT
T BING
BRING
BRAZED
LINE
PRESS RE
GA GE
CYLINDER
PRESS RE
GA GE
Installation Procedure
Refrigerant piping
