After installing your air conditioner, plug it into the proper electrical outlet in the
wall. Now set the air conditioner at your comfort level. This fully functional wireless
remote allows you to operate your air conditioner without having to get up and
go to the unit. The full function feature allows you to change the settings and turn
the unit on or off from the remote itself. This control pad works the same as the
control pad on the air conditioner. (See Fig. #1)
The following sounds are normally heard during the operation of an air conditioner.
Cool airflow movement as dictated by the set fan speed.
Water sounds. This is normal since your air conditioner also acts as a dehumidifier.
Thus you will hear water sounds from water drops falling on the condenser.
As the refrigerant flows through the inner sealed tubing, a rushing noise may be
occur.
Rattling or vibrating noises may be heard due to poor wall installation.
High pitch compressor sound may be heard.
7

OFF
FAN
COOL ON
HIGH
LOW
MODE SPEED TIMER
POWER
ON/OFF
TEMP / TIME
MODE SPEED TIMER
POWER
TEMP / TIME
OFF
FAN
COOL ON
HIGH
LOW
MODE SPEED TIMER
POWER
ON/OFF
TEMP / TIME
OFFCOOL ONLY
FAN ONLY ONHIGH
MED
DEHUM
ENERGY
SAVER LOW
ON/OFF
Every time you press the MODE button, it will change between FAN, COOL, ENERGY
SAVER and DEHUM. (See fig.#3)
After you plug in the unit, it will perform a self test. All the display lights will turn on
for 3 seconds. The LED display will read"88". If any display light fails to turn on you
may need service on the unit. After 3 seconds, the unit will automatically go to the
stand by mode. Now all lights will be off and you will have to turn"ON" by pressing
the On/Off key. After pressing"On/Off", the unit starts to work and enters the status
of "Fan" with the low setting. You will have to press the ( ) or ( ) key on the Temp/Time
to set the temperature at your desired comfort. You can choose a temperature between
61oF and 86oF. Once the temperature is set you can raise or lower it by pressing the
( ) or ( ) keys.The temperature setting can only be adjusted when the unit is in cooling,
energy saver, or dehumidifier. (See Fig. #2) Having set the temperature, you will set
the function of the air conditioner.
8

Timer off ( See Fig. #5)
The unit must be running to set time off. Use this to preset the time you would like the
unit to shut off.
a) Press TIMER OFF. LED display will show "XX" (time set last time).When power is connected
for the first time, LED display will show "01".
b) Set desired number by pressing the ( ) pad of the Temp/Time buttons, once for each
hour. If you pass the desired time, use the ( ) pad key to lower the selection.
c) After you set TIMER OFF, LED display will show the room temperature about 5 seconds
later. When using the timer, the unit will revert to the last COOL and FAN settings when
activated. The timer must be reset every time you choose to use it.
OFF
FAN
COOL ON
HIGH
LOW
MODE SPEED TIMER
POWER
ON/OFF
TEMP / TIME
MODE SPEED TIMER
POWER
TEMP / TIME
OFF
FAN
COOL ON
HIGH
LOW
MODE SPEED TIMER
POWER
ON/OFF
TEMP / TIME
OFFCOOL ONLY
FAN ONLY ONHIGH
MED
DEHUM
ENERGY
SAVER LOW
ON/OFF
Timer On or Timer Off mode is used to pre-start or shut off your unit in advance. You
can program this up to 24 hours in advance. You can use the Timer in 4 functions, i.e.
COOL, ENERGY SAVER, DEHUMID or FAN.
Timer on (See Fig.#5)
The unit must be on to set the timer. Unit will shut down automatically after it accepts the
settings in 5 seconds. Use this mode to pre-set the start time of the unit 24 hours in advance.
a) Press TIMER ON. LED display will show "XX" (time set last time). When power is connected
for the first time, LED display will show "01".
b) Set the desired number of hours by pressing the ( ) pad of the Temp/Time buttons,
once for each hour. If you pass the desired time, use the ( ) pad key to lower the selection.
c) After you set TIMER ON, LED display will show the time. This time displayed means:
the unit will starts after X hours.
10

OFF
FAN
COOL ON
HIGH
LOW
MODE SPEED TIMER
POWER
ON/OFF
TEMP / TIME
MODE SPEED TIMER
POWER
TEMP / TIME
OFF
FAN
COOL ON
HIGH
LOW
MODE SPEED TIMER
POWER
ON/OFF
TEMP / TIME
OFFCOOL ONLY
FAN ONLY ONHIGH
MED
DEHUM
ENERGY
SAVER LOW
ON/OFF
Adjusting the Air Flow Direction
Airflow can be adjusted by changing the direction of the air conditioner's louvers.
This can also increase the cooling efficiency of the air conditioner.
Adjusting Horizontal Air Flow
Direction
Adjusting the vertical louvers left and
right will change horizontal airflow.
Adjusting Vertical Air Flow Direction
Adjusting the Horizontal vane up and down will
change vertical airflow. The vane can be adjusted
by nudging the back or up and down of the vane.
Adjusting Horizontal Air Flow Adjusting Vertical Air Flow
Recommended orientation of louvers
Adjust louvers to face upwards when cooling to maximize cooling efficiency.
11

Before you install your air conditioner, check the following:
1) The unit is free of all obstructions inside and outside the room, e.g. drapes,
curtains, furniture, plants, shrubs, bushes, trees, other structures like buildings,
garage, etc. The air conditioner must have a clear, unobstructed airflow
through the condenser to remove heat.
2) The wall is strong enough to hold the unit. Extra brackets or supports may
be needed depending on the wall. (Brackets or supports not provided in all
models).
3) There is adequate and proper power supply near the air conditioner.
4) DO NOT use adapter plugs.
5) DO NOT use extension cords.
6) DO NOT cut or remove the ground prong.
7) DO NOT modify the plug or the electrical wall outlet in any way. If plug
does not fit the electrical outlet have a certified electrician do the necessary
change.
8) DO NOT connect electrical power to the unit before installation.
9) DO NOT use if power cord is worn out, frayed or otherwise damaged.
Avoid using if there are cracks or abrasion damage along the length, plug
or connection.
10) Be careful of exposed sharp edges of the cabinet and sharp coils (fins)
on the back of the unit that could cut and cause serious injury.
