Haier QPCA08 User manual

49- 5000543 Rev. 2 10- 21 GEA
Installation and User Manual
Instruccionesde instalación y
Manual del usuario
QPCA08
Portable Room Air Conditioner
Accondicionadores de Aire Para Sala
Design may vary by model number.
Some models may have an addit ional
letter after the model number.
El diseño puede variar según el número
de modelo
Algunos modelos pueden tener una
let ra adicional después del número de
modelo.

249- 5000543 Rev. 2
ENGLISH ENGLISH

49- 5000543 Rev. 2 3
ENGLISH
RECORD KEEPING
Thank you for purchasing this Haier product. This user manual will
help you get the best performance from your new air conditioner.
For future reference, record the model and serial number located on
the label on the side of your air conditioner, and the date of purchase.
Staple your proof of purchase to this manual to aid in obtaining
warranty service if needed.
_______________________________________
Model number
_______________________________________
Serial number
_______________________________________
Date of purchase
TABLEOF CONTENTS
SAFETY INFORMATION .......................................................................................................4
USING THE AIR CONDITIONER
Controls ............................................................................................................................5
Frost Prot ection.....................................................................................................................6
Drainage Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Remote Control .....................................................................................................................7
CARE AND CLEANING
Cleaning the Surface ................................................................................................................8
Air Filter.............................................................................................................................8
St orage .............................................................................................................................8
INSTALLATION INSTRUCTIONS
Before you begin ....................................................................................................................9
Electrical Requirements .............................................................................................................9
Part s Included ......................................................................................................................10
Window Panel Combinations........................................................................................................11
Unpacking t he Air Conditioner ......................................................................................................12
Install the Air Conditioner...........................................................................................................12
TROUBLESHOOTING TIPS ..................................................................................................15
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

449- 5000543 Rev. 2
ENGLISH
READ AND SAVE THESE INSTRUCTIONS
SAFETY INFORMATION
WARNING For your safety, the information in this manual must be followed to minimize the risk of fire, electric
shock or personal injury.
• Use this appliance only for its intended purpose as
described in this Owner’s Manual.
• This air conditioner must be properly installed in
accordance wit h the Installation Instructions before it is
used.
• Never unplug your air conditioner by pulling on the power
cord. Always grip plug firmly and pull straight out from the
receptacle.
• Replace immediately all electric service cords that have
become frayed or otherwise damaged. A damaged power
supply cord must be replaced wit h a new power supply
cord obtained from the manufacturer and not repaired.
Do not use a cord that shows cracks or abrasion damage
along its length or at either the plug or connect or end.
• Turn the unit OFF and unplug your air conditioner before
cleaning.
• For your safety…do not store or use combustible
materials, gasoline or other flammable vapors or liquids in
the vicinity of t his or any other appliance.
• If the receptacle does not match the plug, the receptacle
must be changed out by a qualified electrician.

49- 5000543 Rev. 2 5
ENGLISH
CONTROLS
Features and appearance will vary.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
5 4
PowerMode
Sleep
Fan
Timer
Low
High
Timer
Water Full
Power
Cool
Fan
DrySleep
3 6 2 1
NOTE: When the machine is powered on for the first time, the
buzzer will play power-on music and t hen the machine will go
into standby status.
1. Power Button
Turns ON/OFFpower to the air condit ioner.
NOTE: Turning off power by pressing the Power button
does NOT disconnect the appliance from
power supply.
Press the Power button. The power indicator and
temperature display will illuminate, select desired settings.
After one minute, the display lights will turn off. Press
any button on the unit or t he remote. The display will
illuminate. Then press corresponding buttons to change
unit function.
Note: If changes functions from the remote, it may
required multiple button pushes to synchronize remote to
the unit.
2. Mode Button
Press the Mode button to toggle among the operating
options. The corresponding indicator will illuminate:
Cool – Cools t he room to t he set temperature
DRY – Reduces t he humidity in the room
Fan – Circulates t he air in t he room wit hout cooling
3. + and – Buttons
Sets the Temperature when in Cooling Mode or sets the
Time when Timer is selected.
To Set the Temperature:
Press the +or –button to select the required temperature.
NOTE: The temperature cannot be set when t he air
conditioner is in either Fan or DRY mode.
To Set the Time:
Press the +or –button to select the required time.
4. Fan Speed Button
The fan speed can be adjusted from Low to High speed when
the air conditioner is in operation.
NOTE: The fan speed cannot be adjusted when the unit is in
DRYmode.
5. Timer Button
Program atime from (1 hour to 24 hours) for the air
conditioner to turn Off or On.
6. Sleep Mode
Press the Sleep but ton to turn on Sleep Mode.
NOTE: You cannot turn on the Sleep mode in the Dry or Fan
Mode.
NOTE: When t he inner unit chassis is full of water, the Water
Full light will turn on. A buzzer will sound for several seconds
and the compressor will stop.
Refer to the instructions on page 6 for draining the water from
the unit.

649- 5000543 Rev. 2
ENGLISH
CONTROLS
FROST PROTECTION FUNCTION:
In cooling or dry mode, if the temperature of the exhaust
hose is too low, the AC will automatically go into a unit
protection state.
When the temperature rises to a normal temperature, the
unit will automatically resume normal operation.
OVERFLOW PROTECTION FUNCTION:
When water in the water pan exceeds the warning level,
the machine will automatically sound an alarm, the FULL
indicator light will flash and the unit will shut down. At this
point , you need to drain the water from the lower drain (See
Drainage instructions for details)
After the water is emptied, the machine the machine will
automatically resume normal operation.
AUTOMATIC DEFROSTING (on some models)
The machine has an automatic defrosting function.
PROTECTION FUNCTION OF THE COMPRESSOR
To increase the service life of the compressor, the AC has a
3-minute delay after the compressor has shut off to protect
the compressor.
The display will always default to show SET temperature.
When the air conditioner is turned on, it will automatically start in the last mode and fan settings selected.
DRAINAGE INSTRUCTIONS
Draining the unit manually:
Note: Please move the AC carefully, do not spill the water in
the water pan at t he bottom of the unit.
1. When the AC stops after the water is full, turn off the AC
power and unplug the power plug.
2. Place a water cont ainer larger t han the sump capacity (at
least 1-1/ 2 quart) below the lower rear water outlet on
the back side of unit.
3. Remove the plug, the water will automatically flow into
the container.
Note: During drainage, the body can be tilted slightly
backwards. If the water container cannot hold all the water,
before the water container is full, replace the water plug as
soon as possible to prevent water from flowing to the floor or
the carpet.
4. After water has been drained from the unit, re-install the
water plug securely.
Note: Restart the AC after the water plug is installed,
otherwise condensate water from the AC will drain onto t he
floor or carpet .
Continuousdrainage (optional, and only in dry mode)
1. Remove the upper drain plug.
2. Connect a drain hose with an inside diameter of 5/ 8” to
the water outlet.
3. Route drain hose to a bucket or floor drain.
4. Be sure to use a large container (3 gallons or larger is
recommended) and monitor t he water level in the container
continuously. The unit will not shut off when the container
is full. An overflowing container can cause flooding and
damage to the floor.

49- 5000543 Rev. 2 7
ENGLISH
CONTROLS
Features and appearance may vary.
Icons on the remote control indicate the selected settings
CA
B
F
D
E
REMOTECONTROL
1. Insert the two AAA batteries (provided).
2. Aim the remote cont rol at the signal receiver on the
control panel to operate t he air conditioner.
A. Power Button
Turns ON/OFFpower to the air condit ioner.
B. Mode Button
Press the Mode button to toggle among the operating
options, cooling, fan and dry mode.
C. + and – Button
Adjusts the Temperature or Timing set value.
D. Fan Button
Press the Fan button to adjust fan speed from Low to High
speed.
E. Timer
Press Timer button to activate the ON/OFFtimer. Use the
+and –buttons to adjust the timer.
F. Sleep Button
Press the Sleep button to turn on the sleep mode.
Note:Ýëèäìõæòñçì÷ìòñèõÕÎÍçìöóïäüúìïï÷øõñòģ!ðìñø÷èafter last button is pushed. To turn on the LED display,
press any button on the unit or the remote. Then press
corresponding function to change settings, the remote may
require multiple pushes to synchronize the unit .

849- 5000543 Rev. 2
ENGLISH
AIRFILTER
The air filters should be cleaned at least every two weeks for
your unit to operate at opt imum efficiency.
CAUTION DO NOT operate the air conditioner
without a filter because dirt and lint will clog it and reduce
performance.
To clean the upper filter screen frame:
1. Remove the upper and lower filter screens. On the top
filter, place finger in recess at top of filter and pull down
and outward to remove. On the lower filter, place finger
in recess at bottom of filter, pull upward and outward to
remove filter.
2. Remove the filter from the filter frame. It is held in place by
4 tabs. After removal, wash or vacuum the filter to remove
the dirt and lint. Make sure filter is dry before reinstalling
on the unit.
CAREAND CLEANING
CLEANING THE SURFACE
Clean surface of machine with a wet soft cloth. Do not
use chemicals, such as benzene, alcohol, gasoline, etc.;
otherwise, the surface of the air conditioner will be damaged
or the entire unit will be damaged.
CLEANING 1. Unplug or disconnect power.
2. Use only a soft cloth dampened with water to clean the
cabinet.
NOTE:
•Do not use a liquid or spray cleaner to clean the air
conditioner.
•DO NOT use chemicals, abrasives, ammonia, chlorine
bleach, concentrated detergents, solvents or scouring
pads. Some of these chemicals/items may damage and/or
discolor your air conditioner.
3. Dry thoroughly wit h a soft cloth.
4. Plug in or reconnect power.
WARNING
Electrical Shock Hazard
Disconnect power before cleaning.
STORAGE
If the unit is not being used for a long period of time:
To Empty the Internal Water Tank:
1. Unplug or disconnect power.
2. Drain the water from the water tank. (See “Internal Water
Tank section” above.)
3. Use the original packaging to repack the unit to avoid a
buildup of dust or dirt.
4. Store the air conditioner in a cool, dry location.

49- 5000543 Rev. 2 9
ENGLISH
INSTALLATION INSTRUCTIONS
LOCATION REQUIREMENTS
• Place the air conditioner on a flat, level surface in a
location that is at least 20” (50 cm) from any wall.
NOTE: A minimum clearance of 20” (50 cm) from the air
conditioner to the wall must be maintained to ensure
proper airflow.
• Maint ain a minimum 20” (50 cm) clearance around t he air
conditioner to not block airflow.
• Keep the air conditioner free of any obstructions such as
drapes, curtains, blinds, etc.
• The exhaust hose should be free of any obstructions.
• Do not place the air conditioner on an unstable or raised
surface because it could fall and cause damage or injury.
• Do not place the air conditioner in direct sunlight or near
a heat source such as baseboard heaters, stoves, etc.
• The window panel can be installed in a window with a
minimum 20” (50.8 cm) to a maximum 48” (121.9 cm)
opening.
Questions? Call GEAppliances at 866.907.1655 or visit our Website at: GEAppliances.com.
BEFORE YOU BEGIN
Read these instruct ions complet ely and carefully.
•IMPORTANT —Save these instructions for local
inspector’s use.
•IMPORTANT —Observe all governing codes and
ordinances.
•Note to Installer – Be sure to leave these instructions
with the Consumer.
• Note to Consumer – Keep these instructions for future
reference.
• Skill level – Installation of this appliance requires basic
mechanical skills.
•Completion time – Approximately 1 hour
• We recommend two people to install this product.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installat ion is not
covered under the Warranty.
• You MUST use all supplied part s and use proper
installation procedures as described in these
instructions when installing t his air conditioner.
CAUTION
Do not, under any circumstances, cut or remove the third
(ground) prong from t he power cord.
Do not change the plug on the power cord of t his air
conditioner.
Aluminium house wiring may present special problems—
consult a qualified elect rician.
ÎÕÎÌÝÛÒÌÊÕÛÎÚÞÒÛÎÖÎ×ÝÜThese models require a 115/ 120-volt AC,
60- Hz grounded outlet protect ed with a 15- amp
time- delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility of
electric shock hazard. If the wall outlet you plan to use is
only a 2- prong outlet, it is your responsibility t o have it
replaced with a properly grounded 3- prong wall outlet.
Power cord includes a current
interrupter device. A test and reset
button is provided on the plug case.
The device should be tested on
a periodic basis by first pressing
÷ëèÝÎÜÝåø÷÷òñäñç÷ëèñ÷ëèÛÎÜÎÝåø÷÷òñúëìïèóïøêêèçìñ÷ò÷ëèòø÷ïè÷Òé÷ëèÝÎÜÝåø÷÷òñçòèöñò÷÷õìóòõìé÷ëèÛÎÜÎÝåø÷÷òñúìïïñò÷stay engaged, discontinue use of the
air conditioner and cont act a qualified
service technician.
RESET
TEST

10 49- 5000543 Rev. 2
ENGLISH
INSTALLATION INSTRUCTIONS
PARTS INCLUDED
(Appearance may vary)
1. Top Cover
2. Control Panel
3. Side Panel
4. Air Outlet / Louver
5. Front Housing
6. Rear Housing
7. Caster
8. Base Pan
9. Upper Filter
10. Upper Continuous Drain
11. Cord Wrapping Post
12. Exhaust Air Vent
13. Lower Filter
14. Lower Drain
21
3
7
8
5
4
9
6
10
12
11
13
14

Exhaust Hose Assembly
Remote Control
Batt eries (2)
Phillips head screwdriver
(Not Included)
TOOLSYOU WILL NEED
Window Mounting Kit 1 pc – 20” Center Panel
1 pc – 5 ½” Entension
1 pc – 9” Extension
2 pc – 16” Extensions
Pointed Screws (7)
2 – Top Window Bracket
1 – Security Bracket
4 – Main Window Panel
Security BracketBottom Window Bracket (2)Top Window Bracket (2)
Top Foam Strip
Bottom Foam St rip
Foam St rip
Flat Tip Screw
For exhaust nozzle to
main window panel.

49- 5000543 Rev. 2 11
ENGLISH
INSTALLATION INSTRUCTIONS
WINDOW PANEL COMBINATIONS TO FIT WINDOW OPENINGS
(Appearance may vary)
Window Opening 20” - Center Panel Only
Window Opening 20”- 23½” - Center Panel + 5½” Extension
Window Opening 23½”- 27” - Center Panel + 9” Extension
Window Opening 23½”- 30½” - Center Panel + 9” and 5½” Extensions
Window Opening 30½” - 34” - Center Panel + 16” Extension
Window Opening 34”- 41” - Center Panel + 9” and 16” Extensions
Window Opening 41”- 48” - Center Panel + (2) 16” Extensions

12 49- 5000543 Rev. 2
ENGLISH
INSTALLATION INSTRUCTIONS
1. UNPACK AIRCONDITIONER
NOTE: Before using the air conditioner, keep it upright
for at least 2 hours.
• Remove packaging materials. Save the carton and the
foam packaging for storing the air condit ioner when not
in use.
NOTE: There are NO packing materials inside the air
conditioner to remove—Do Not open the cabinet.
• Properly dispose of/recycle all packing material.
• Handle the air condit ioner gently.
• Keep the air conditioner upright and level. Do not set t he
air conditioner on it s side, front, back or upside down.
Excessive Weight Hazard
• Use two or more people to move and install air
conditioner.
• Failure to do so can result in back or other injury.
WARNING
2. INSTALL EXHAUST NOZZLE TO
MAIN WINDOW PANEL
1. Hold the main
window panel so
that the L-shaped
edges of the panel
are facing you.
2. Align the exhaust
nozzle with the slots in
the opening, and then
insert and slide the nozzle
to access the hole from
the back of the main
window panel.
3. Turn the main window panel over, so that the nozzle
is away from you. Insert
a flat tip screw t hrough
the hole to fasten t he
window panel to the
adapt er.
3. INSTALL MAIN WINDOW PANEL AND
EXTENSION PANELS
NOTE: Measure the window opening and use the
extension panels as referenced on page 10 to fit your
window.
1. Open the window and place the window kit assembly
into the window.
NOTE: The window assembly is designed to
accommodate either a double hung or sliding window.
2. Adjust t he extension panel(s) to the width or height of
the window as shown.
3. Depending on the number of extension panels used,
turn the knobs to secure the extension panel(s) to the
main panel. Install from the back.
NOTE: There are many window types on the market
today. Use the foam strips and brackets (provided) to
secure the extension panels that will fit the window
opening.
Double Hung Window
Sliding Window

49- 5000543 Rev. 2 13
ENGLISH
INSTALLATION INSTRUCTIONS
3. INSTALL MAIN WINDOW PANEL AND
EXTENSION PANELS (cont)
6. Place the window panel assembly in the window, and
using the screws provided, fasten the assembly to t he
window sill and window frame.
7. Using one pointed screw, install the Security bracket to
the window.
NOTE: The security bracket prevents the window from
being opened from the outside.
B
A
3. INSTALL MAIN WINDOW PANEL AND
EXTENSION PANELS (cont)
4. For vinyl windows only.
Skip to step 6 for wood windows.
Place the two top window brackets and two bottom
window brackets where t hey will best support the
extension panels. Use painted screws to attach top
bracket to the support panels.
5. Apply the top foam strip (provided) across the
top of t he window panel assembly, and then
apply the bottom foam strip (provided) across the
bottom front edge of the window panel assembly, as
shown.
Use only for vinyl
A
B
A
B
Before Assembly
Attach with pointed screw(2).
After Assembly
A
B
C
D E
Typical Vinyl Window Installation
4. Attach Exhaust Hose to the Exhaust
Nozzle
1. Grasp both ends of the exhaust hose and gently pull
to expand fully the ends of the hose. Note: Do not
attach multiple hoses to extend t he length, this would
decrease the cooling efficiency and may cause damage
to the air conditioner.
2.Turn hose clockwise and screw into the nozzle in the
window panel. Attach adapter to other end of hose by
turning clockwise.

14 49- 5000543 Rev. 2
ENGLISH
INSTALLATION INSTRUCTIONS
5. CONNECT EXHAUST HOSE TO THE AIRCONDITIONER
NOTE: When connecting the hose, the air conditioner must be close enough to the window that you will not dislodge the
window seal plate. Once the hose is connected, move the air conditioner 20” (51 cm) from the wall.
1. Extend the flexible exhaust hose to reach out to the unit.
2. Aim the opening of the hose to t he air exhaust outlet and push it hard straight into t he outlet until it clicks.
12
3 4

49- 5000543 Rev. 2 15
ENGLISH
TROUBLESHOOTING TIPS
Problem Possible Causes Solution
Unit doesnot start or
operate
Power supply cord is not plugged into an
outlet.
Plug the power cord into a grounded 3 prong outlet.
Power supply cord has tripped. Press and release the RESET button on the power
supply cord.
The Power button has not been pressed. Press the Power button on the Cont rol Panel or
Remote Control to turn ON the air conditioner.
There is no power to t he electrical outlet. Plug aworking lamp into t he outlet to check for
power.
A household fuse has blown or a circuit
breaker has tripped.
Replace the fuse or reset the circuit breaker.
The control was programmed for a Time
Delay.
Cancel the Time Delay. See “Control Panel.”
The batteries in the remote control are dead. Replace the batteries.
The internal water tank is full.
NOTE: The air conditioner automatically
turns off, and t he Water Full indicator
illuminates to alert you of this condition.
Empty the water tank. See “Air Conditioner
Care.”
Remote control isnot
working
Batteries are dead. Replace the batteries.
Batteries are installed incorrectly. Make sure the batteries are inserted in the correct
position.
Air conditioner is
working but the room
isnot cooling.
The room temperature is hot.
NOTE: On extremely hot and humid days,the
air conditioner will take longer to cool the
room.
Allow time for t he room to cool when you first turn
on the unit.
Make sure the air conditioner has an adequate
BTU rating for the size of the room being cooled.
The control is set incorrectly to Fan or Dehum
mode.
Set the Mode to Cool and the Fan Speed to High.
Airflow is restricted. Remove any obstacles to the airflow and redirect
airflow for uniform cooling.
Temperature set too high. Lower t he set temperature.
Air filters are dirty or restricted. Clean the air filter. See “Air Conditioner Care.”
Air conditioner installed incorrectly Check the exhaust hose and window panel for
proper installation.
Doors and windows are open. Close the doors and windows to the room being
cooled to prevent cooled air from escaping.

16 49- 5000543 Rev. 2
ENGLISH
LIMITED WARRANTY
• Service trips to your home to teach you how to use the
product.
• Improper installation, delivery or maintenance. If you
have an installation problem, or if the air conditioner is of
improper cooling capacity for the intended use, contact
your dealer or installer. You are responsible for providing
adequate electrical connecting facilities.
• Failure of the product resulting from modificationsto the
product or due to unreasonable use including failure to
provide reasonable and necessary maintenance.
• In commercial locations, labor necessary to move the unit to
a location where it is accessible for service by an individual
technician.
• Replacement of house fusesor resetting of circuit breakers.
• Failure due to corrosion onmodelsnot corrosion-protected.
• Damage to the product caused by improper power supply
voltage, accident, fire, floodsor actsof God.
• Incidental or consequential damage caused by possible
defects with thisair conditioner.
• Damage caused after delivery.
What Haier Appliances Will Not Cover:
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased
for home use within the USA. If the product is located in an area where service by a GEAuthorized Servicer is not
available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized
ÐÎÜèõùìæèïòæä÷ìòñéòõöèõùìæèÒñÊïäöîä÷ëèïìðì÷èçúäõõäñ÷üèûæïøçèö÷ëèæòö÷òéöëìóóìñêòõöèõùìæèæäïïö÷òyour home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what
your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor US:
GEAppliances, a Haier company
Louisville, KY 40225
Call 866.907.1655 (in the United States)to initiate the product replacement process. Have serial number and model
number available when calling for service.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in this Limited
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose,
are limited to one year or the shortest period allowed by law.
For The Period Of: Haier Appliances Will Replace:
One Year
From the date of the original
purchase
Any part of the air conditioner which fails due to a defect in materials or workmanship. During
this limited one- year warranty, GEAppliances will also provide, free of charge, all labor and
related service to replace the defective part.

49- 5000543 Rev. 2 17
ESPAÑOL
INFORMACIÓN A TENEREN CUENTA
Le agradecemos la compra de este producto de marca Haier. Este
manual para el usuario le ayudará a obtener el mejor funcionamiento de
su nueva acondicionador de aire.
Para referencia fut ura, anote el modelo y número de serie en la etiquet a
en el lado de su acondicionador de aire, y la fecha de compra.
Engrape la prueba de compra a este manual para asistirle cuando
necesite obtener servicio bajo la garantía.
_______________________________________
Número de modelo
_______________________________________
Número de serie
_______________________________________
Fecha de compra
ÍNDICE
INFORMACIÓN DE SEGURIDAD ...............................................................................................18
USO DEL ACONDICIONADOR DE AIRE
Controles ..........................................................................................................................19
Protección contra las heladas .......................................................................................................20
Instrucciones de Drenaje ...........................................................................................................20
Control Remoto ....................................................................................................................21
CUIDADO Y LIMPIEZA
Limpieza de la superficie............................................................................................................22
Filtro de Aire .......................................................................................................................22
Rangement ........................................................................................................................22
INSTRUCCIONES DE INSTALACIÓN
Antes de comenzar .................................................................................................................23
Requisitos Eléctricos ...............................................................................................................23
Partes Incluidas ....................................................................................................................24
Combinaciones del Panel de Ventana................................................................................................25
Desembale el Acondicionador de Aire ...............................................................................................26
Instale el Aire Acondicionado. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
CONSEJOS PARA LA SOLUCIÓN DE PROBLEMAS.........................................................................29
GARANTÍA LIMITADA .........................................................................................................31

18 49- 5000543 Rev. 2
ESPAÑOL
LEA Y GUARDE ESTAS INSTRUCCIONES
SEGURIDAD DEL ACONDICIONADORDEAIRE
Para su seguridad, siga las instruccionesde este manual a fin de minimizar riesgos de incendio, descargas
eléctricas o heridas personales.
• Use este electrodoméstico sólo para su propósito original, como
se describe en el Manual del Propiet ario.
• Este acondicionador de aire se debe instalar de forma apropiada
de acuerdo con las Instrucciones de Instalación antes de ser
usado.
• Nunca desenchufe su acondicionador de aire empujando el cable
de corriente. Siempre tome su enchufe de manera firme y empuje
el mismo hacia afuera del receptáculo.
• Reemplace de inmediato todos los cables del servicio de
electricidad pelados o con cualquier tipo de daño. Un cable del
servicio de corriente que esté dañado deberá ser reemplazado
por uno nuevo provisto por el fabricante, y no deberá ser
reparado. No use un cable con cortaduras o abrasión sobre su
extensión o en cualquiera de sus enchufes o extremos.
• Coloque la unidad en OFF (Apagado) y desenchufe el
acondicionador de aire antes de usar el mismo.
• Para su seguridad... no acumule ni use materiales combustibles,
gasolina u otros vapores o líquidos inflamables cerca de éste u
otro electrodoméstico.
• Si el receptáculo no coincide con el enchufe, el cambio del mismo
deberá ser realizado por un elect ricista calificado.
ADVERTENCIA

49- 5000543 Rev. 2 19
ESPAÑOL
CONTROLES
Las luces al lado de las teclas de toque en el panel de cont rol del acondicionador de aire indicarán los ajustes seleccionados. Las
funciones y el aspecto pueden variar.
5 4
Power
Mode
Sleep
Fan
Timer
Low
High
Timer
Water Full
Power
Cool
Fan
DrySleep
3 6 2 1
NOTA: Cuando se encienda el motor por primera vez, el indicador sonoro emit irá la música de encendido y luego el motor
quedará en el modo de espera.
1. Botón de Encendido
Activa ON/OFF (Encendido/ Apagado) en el
acondicionador de aire.
NOTA: Apagar el encendido presionando el botón Power
(Encendido) NO desconecta el electrodoméstico del
suministro de corriente.
Presione el botón Power (Encendido). La pantalla del
indicador de encendido y temperatura se iluminará;
seleccione las configuraciones deseadas luego de un
minuto una vez que las luces de Display (Pantalla) se hayan
apagado. Presionar cualquier botón de la unidad o unidad
remot a hará que la pantalla se ilumine. Luego presione los
botones correspondientes para cambiar la función de la
unidad.
Nota: Si se cambian las funciones desde el control remoto,
se podrá requerir presionar botones varias veces para
sincronizar el control remoto con la unidad.
2. Botón de Modo
Presione el botón Mode (Modo) para pasar a través de las
opciones de funcionamiento. El indicador correspondiente
se iluminará:
Cool (Frío) – Refrigera la sala en la temperatura
configurada.
Dry (Seco) – Reduce la humedad de la sala.
Fan (Ventilación) – Hace circular el aire de la sala sin
refrigerar.
3. Botones + y –
Configuran la temperatura al estar en el Modo Cooling
(Refrigeración) o configura Time (Tiempo) cuando esta
función es seleccionada.
Para Configurar la Temperatura:
Presione los botones + o – para seleccionar la temperatura
deseada.
NOTA: La temperatura no se podrá configurar cuando el
acondicionador de aire se encuentre en los modos Fan
(Ventilación) o DRY (Seco).
Para Configurar el Temporizador:
Presione los botones + o – para seleccionar el tiempo
deseado.
4. Botón Fan Speed (Velocidad del Ventilador):
La velocidad del ventilador se podrá ajustar desde Low
(Baja) a High (Alta) cuando el acondicionador de aire se
encuentre en funcionamiento.
NOTA: La velocidad del ventilador no se podrá ajustar
cuando la unidad se encuent re en el modo DRY (Seco).
5. Botón del Temporizador
Programe un tiempo desde 1 hora hasta 24 horas para que
el acondicionador de aire se configure en Off (Apagado) u
On (Encendido).
6. Modo de Inactividad
Presione el botón Sleep (Inactividad) para iniciar dicho
modo.
NOTA: El modo Sleep (Inactividad) no se podrá activar en
los modos Dry (Seco) o Fan (Vent ilación).
NOTA: Cuando el chasis de la unidad interior se llene de
agua, la luz de Water Full (Lleno de Agua) se encenderá. Un
indicador sonoro se activará durante varios segundos y el
compresor se detendrá.
Para acceder a instrucciones sobre el drenaje de agua de la
unidad, consulte la página 5.

20 49- 5000543 Rev. 2
ESPAÑOL
CONTROLES
La pantalla siempre mostrará la temperatura ambiente por omisión.
Cuando el acondicionador de aire sea encendido, se iniciará de forma automática en las configuraciones de modo y ventilación que fueron usadas por
última vez.
FUNCIÓN DEPROTECCIÓN DECONGELACIÓN:
En los modos de refrigeración o seco, si la temperatura de la
manguera de salida se encuentra demasiado baja, el acondicionador
de aire pasará de forma automática a un estado de protección de la
unidad. Cuando la temperatura se eleve a un nivel normal, launidad
reiniciará de forma automática el funcionamiento normal.
FUNCIÓN DEPROTECCIÓN CONTRA DESBORDES:
Cuando el agua de la bandeja supere el nivel de advertencia, el
motor activará de forma automática una alarma, la luz indicadora
FULL (Completo) parpadeará y la unidad se apagará. En este punto,
usted necesitará drenar el agua desde el drenaje inferior (para más
detalles, consulte las instrucciones sobre Drenaje). Una vez vaciada
el agua, el motor reiniciará de forma automática el funcionamiento
normal.
DESCONGELACIÓN AUTOMÁTICA (EN ALGUNOS MODELOS)
El motor cuenta con una función de descongelación automática.
FUNCIÓN DEPROTECCIÓN DEL COMPRESOR
A fin de incrementar la vida útil del compresor, el acondicionador
de aire cuentacon un retraso de 3 minutos luego del apagado del
compresor que permite la protección del mismo.
INSTRUCCIONES DE DRENAJE
Drenaje manual de la unidad:
Nota: Por favor, muevael acondicionador de aire con cuidado, no
derrame agua sobre la bandeja en la parte inferior de la unidad.
1. Cuando el acondicionador de aire se detenga una vez que el
agua llegue hasta el tope, apague el mismo y desenchufe el
cable de corriente.
2. Coloque un recipiente de agua con capacidad superior a aquella
del sumidero (por lo menos 1 ½ cuartos de galón) debajo de la
salida de agua inferior trasera, sobre el lado trasero de la unidad.
3. Retire el enchufe y el agua circulará de forma automática hacia
adent ro del recipiente.
Nota: Durante el drenaje, el cuerpo se podrá inclinar levemente
hacia atrás. Si el recipiente de agua no logra contener toda el agua,
antes de que éste se llene, vuelva a colocar el t apón del agua tan
pronto como se posible para evit ar que éstacircule hacia el piso o la
alfombra.
4. Una vez que el agua sea drenada de la unidad, vuelva a colocar el
tapón de agua de forma segura.
Nota: Reinicie el acondicionador de aire luego de haber colocado el
tapón de agua; de otro modo, el agua condensada del acondicionador
de aire serádrenadasobre el piso o laalfombra.
Drenaje continuo (opción, y sólo en el modo seco)
1. Retire el t apón del drenaje superior.
2. Conecte una manguera de drenaje con un diámetro exterior de
5/ 8” en la salida de agua.
3. Hagacircular una manguera de drenaje hasta un balde o el
drenaje en el piso.
4. Asegúrese de usar un recipiente grande (se recomienda uno de
3 galones o más) y monitoree el nivel de agua del recipiente de
forma continua. La unidad no se apagará cuando el recipiente
esté lleno. Un recipiente que se desborde podrá ocasionar una
inundación y daños sobre el piso.
