Halcro Eclipse mono User manual

Contents
Introduction ......................................................... 2
Important Safety Information............................... 3
Symbols ...................................................................... 3
Electrical safety.......................................................... 4
Protection from fluids................................................ 5
Service warnings........................................................ 5
Protection from overheating .................................... 6
Lifting or moving........................................................ 6
Wiring to the Loudspeaker Terminals to Class 2
Wiring (US Wiring Regulations).......................... 6
Additional Important Safety Instructions for the
USA....................................................................... 7
Interference warning - US FCC Regulations.......... 8
For Consumers within the European Union ......... 9
Unpacking........................................................... 10
Controls and Connections .................................. 12
Diagrams .................................................................. 12
Eclipse mono inputs................................................. 14
Minimal Path Input.................................................. 15
Setup .................................................................. 16
Operation ........................................................... 18
Electronic Protection and Reliability................... 19
Output Current Limiting ..................................... 20
Output transistor protection ...................................21
Unusual output conditions.......................................22
Power supply output current limiting .....................22
Internal power supply protection............................22
Mains transient overload protection.......................22
Input overload protection........................................22
Amplifier inter-stage protection..............................22
Eclipse mono Specifications ............................... 23
Care and Maintenance ....................................... 26
Troubleshooting ................................................. 27
Service and Warranty Information ..................... 28
Overview ...................................................................28
Product warranty......................................................28
If service is required .................................................29
Transportation of products......................................30
Thank you for choosing Halcro!.......................... 31

2
Introduction
Congratulations –You have purchased one of the
very finest audio components ever made. This bold
statement is not only measurable, but immediately
apparent from the very first note.
Halcro designs and manufactures the only Super
Fidelity amplifiers in the world. This Super Fidelity
amplifier reproduces with better than 99.9997%
purity of all tones across the entire audio range.
The concept behind the electronic design was to
create an amplifier that did not color the sound with
its own electronic characteristics —to recreate the
original sound as it was at the time of recording.
Please enjoy the Halcro audio experience.
Halcro has enjoyed creating perfect audio
reproduction for the world's music connoisseurs.
To contact Halcro with feedback on your purchase or
for general enquiries please feel free to contact us
via:
E-mail: [email protected]
Telephone: + 61 8 8390 1673

3
Important Safety Information
Symbols
The following symbols are used on this equipment:
The lightning flash with arrowhead
symbol, within an equilateral
triangle, is intended to alert the
user to the presence of
uninsulated ‘hazardous voltage’
that may be of sufficient
magnitude to constitute a risk of
electric shock to a person if
exposed or contacted.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the following pages.
The ‘CE’ symbol indicates
compliance of this device with the
relevant directives of the
European community including
the EMC (Electromagnetic
Compatibility) and LVD (Low
Voltage Directive) standards.
Warning of electrical shock
hazard. Do not open cover
(or back). There are no user
serviceable parts inside.
Refer servicing to qualified
service personnel.
This symbol is to indicate
that the unit is heavy and
that precautions are
required when lifting or
moving the unit.

4
Electrical safety
WARNING: This product must
always be connected to a mains
socket outlet with a protective
earth connection.
Only use a suitable approved mains cord complying
with European individual country requirements in
the CE Low Voltage Directive Scheme.
DANGER: Do not open
the cover or back, or
remove any panels, or try
to modify or repair the
Eclipse. Opening the
Eclipse may expose you
to dangerous voltages
and will void the
warranty.
WARNING: The Standby/On mode
switch does not disconnect the unit
from the mains power.
To disconnect the unit from the
mains, switch off the unit at the
mains socket outlet and withdraw
the mains plug from the socket
outlet.
The unit should be installed in a position where the
mains plug is easily accessible. Disconnect the unit
from the mains if it is to be left unused for a long
period.
WARNING: No naked flame sources,
such as lighted candles, should be
placed on the unit.
If naked flame sources tip over they
could result in a fire.

5
Protection from fluids
The Halcro Eclipse amplifiers are designed for indoor
use only and are not protected against liquids. They
must not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, should be
placed on them.
If liquid is accidentally spilled on the device,
immediately disconnect the unit from the mains.
Allow sufficient time for complete evaporation
before using the Eclipse again. If the liquid is
anything other than water, do not use the device
before a qualified service technician has examined it.
Cleaning may be performed with a slightly damp
cloth that has been wrung until nearly dry. Refer to
the section Cleaning on page 265.
WARNING: To reduce the risk of
fire or electric shock, do not
expose this equipment to rain or
moisture.
Do not allow liquids to enter the
unit or contact electrical
terminals.
Service warnings
All compartments are sealed at the factory. If the
seals are broken, the warranty will be void and all
service costs will be charged to the owner.
DANGER: Contains no user
serviceable parts. Do not attempt
to open any of the Eclipse
compartments as this may
expose you to dangerous voltages
and will void the warranty.
Requires an appropriate fuse for continued
protection against the risk of fire (F 10A L 250V or F
15A L 110V). Never bypass or use any other type of
fuse. The fuse is located on the bottom of the lower
panel of the power supply compartment (p13, fig C,
⑦).
WARNING: Always replace the
fuse with the same type and
rating as specified: F 10A L 250V
or F 15A L 110V as appropriate.
Always disconnect the unit from
the mains before touching the
loudspeaker terminals or
replacing the fuse.

6
Protection from overheating
The Eclipse generates a certain amount of heat and
requires ventilation. Slots and ventilation holes are
provided for ventilation purposes, and to ensure
reliable operation of the product. To prevent fire
hazards, these openings must never be blocked or
covered.
Follow the precautions listed below. If these
precautions are not followed, overheating or failure
may result. Overheating also shortens the working
life of all components.
oDo not block the ventilation slots in the sides
of the unit with any object, including paper,
cloths or curtains
oAvoid placing the unit in a built-in installation
place such as a bookcase or a rack unless you
can provide proper ventilation
oDo not operate the unit inside a cabinet unless
it has adequate ventilation (such as an open
back panel)
oAllow at least 12 in (300 mm) clearance
around the unit
WARNING: Do not obstruct
ventilation slots in the chassis.
Lifting or moving
WARNING: Weighs 62 kg (137 lb)
per unit. Shipping weight is 83 kg
(183 lb) per amplifier crate, and
175 kg (390 lb) for a palletised
pair. Never lift the amplifier by
yourself.
Always use two people to unpack
or move the amplifier. Always
bend at the knees when lifting. Do
not strain your back.
Wiring to the Loudspeaker Terminals to
Class 2 Wiring (US Wiring Regulations)
This equipment has been classified as having a Class
2 loudspeaker output requiring wiring to connect
the output terminals to class 2 according to the
National Electrical Code. Consult a qualified installer
or electrical contractor for further information.

7
Additional Important Safety Instructions for the USA
The following instructions should be followed by
customers in the USA in addition to the safety
instructions in the rest of this chapter:
oRead these instructions
oKeep these instructions
oHeed all warnings
oFollow all instructions
oDo not use this apparatus near water
oClean only with dry cloth or according to the
cleaning instructions
oDo not block any ventilation openings
oInstall in accordance with the manufacturer’s
instructions
oDo not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat
oDo not defeat the safety purpose of the
polarised or grounding-type plug
A polarised plug has two blades, with one
wider than the other. A grounding type plug
has two blades and a third grounding prong.
The wide blade or the third prong is provided
for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet
oProtect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus
oOnly use attachments/accessories specified by
the manufacturer
oUnplug this apparatus during lightning storms
or when unused for long periods of time
oRefer all servicing to qualified service
personnel
Servicing is required when the apparatus has
been damaged in any way, such as if the
power-supply cord or plug is damaged, liquid
has been spilled, or objects have fallen into
the apparatus, if the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped

8
Interference warning - US FCC Regulations
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
oIncrease the separation between the
equipment and receiver
oConnect the equipment into an outlet on a
circuit different from that to which the
amplifier is connected
oConsult the dealer or an experienced radio/TV
technician for help
Changes or modifications not expressly approved by
Halcro could void the user's authority to operate the
equipment.

9
For Consumers within the European Union
Do not dispose of this equipment in general
household waste or unsorted municipal waste.
The crossed-out wheeled bin indicated on this
equipment is an indicator that this unit should not be
disposed of in general household waste, but recycled
in compliance with local government regulations or
environmental requirements.
Please dispose of this equipment via a recycling
service or centre, or by returning the unit to the local
Halcro distributor. This will enable the equipment to
be disposed of in an environmentally safe manner.
Disposal of unwanted waste electronic equipment in
landfilled waste may contribute to adverse long term
environmental effects due to the leaching of
contaminating and/or toxic substances contained
within some electronic equipment.
