Halma Ocean Optics JAZ User manual

Installation and Operation Manual
Document Number 013-RD000-000-02-201510
For Products: JAZ, JAZ-INDY, JAZ-PX
Document: 013-RD000-000-02-201510

AMERICAS & WORLD HEADQUARTERS
Phone: [phone]
Fax: [phone]
Sales: [email protected]
Orders: [email protected]
Support: [email protected]
EUROPE, MIDDLE EAST & AFRICA
Phone: [phone]
Fax: [phone]
Email: [email protected]
Germany : [phone]
UK : [phone]
France : [phone]
ASIA
Phone: [phone]
Fax: [phone]
Email: [email protected]
Japan & Korea: [phone]
www.oceanoptics.com
Copyright © 2010 Ocean Optics, Inc.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, by any means,
electronic, mechanical, photocopying, recording, or otherwise, without written permission from Ocean Optics, Inc.
Trademarks
All products and services herein are the trademarks, service marks, registered trademarks or registered service marks of their
respective owners.
Limit of Liability
Every effort has been made to make this manual as complete and as accurate as possible, but no warranty or fitness is implied. The
information provided is on an “as is” basis. Ocean Optics, Inc. shall have neither liability nor responsibility to any person or entity
with respect to any loss or damages arising from the information contained in this manual.
Ocean Optics, Inc.
830 Douglas Ave.
Dunedin, FL 34698
USA
Manufacturing & Logistics
4301 Metric Dr.
Winter Park, FL 32792
USA
Ocean Optics Asia
666 Gubei Road
Kirin Tower Suite 601B
Changning District
Shanghai
PRC, 200336
Sales & Support
Geograaf 24
6921 EW Duiven
The Netherlands
Manufacturing & Logistics
Maybachstrasse 11
73760 Ostfildern
Germany

013-RD000-000-02-201510 i
Table of Contents
About This Manual.........................................................................................................v
Document Purpose and Intended Audience..............................................................................v
What’s New in this Document ...................................................................................................v
Document Summary..................................................................................................................v
Product-Related Documentation ...............................................................................................vi
Upgrades.......................................................................................................................vi
Chapter 1: Introduction .....................................................................1
Product Overview..........................................................................................................1
Jaz Modules..................................................................................................................2
Features........................................................................................................................2
System Requirements...................................................................................................3
EEPROM Utilization ..................................................................................................................3
About OceanView Software.......................................................................................................3
Sampling System Overview.......................................................................................................4
How Sampling Works............................................................................................................4
Interface Options...........................................................................................................4
Shipment Components..................................................................................................4
Additional Equipment Available .....................................................................................5
Chapter 2: Installing Jaz....................................................................9
Overview .......................................................................................................................9
Installing the Jaz Unit ....................................................................................................10
Connecting Jaz to a Computer via USB....................................................................................10
Ethernet Connection..................................................................................................................10
Chapter 3: Operating Jaz ..................................................................13
Overview .......................................................................................................................13
Powering Your Jaz Unit.................................................................................................14
Jaz Menus.....................................................................................................................15
Main Menu.................................................................................................................................15
Measurement Wizards...............................................................................................................19
*Tools....................................................................................................................................20
JAZ-PX Menu ............................................................................................................................22

Table of Contents
ii 013-RD000-000-02-201510
JAZ-INDY Menu ........................................................................................................................22
Storing Data on an SD Card..........................................................................................22
Chapter 4: Operating the JAZ-PX Module........................................23
JAZ- PX Module Overview.............................................................................................23
JAZ-PX Module Features ..............................................................................................24
JAZ-PX Menu................................................................................................................25
JAZ-PX Menu Tree....................................................................................................................25
PX Menu Default Values ...........................................................................................................29
Getting Started with the JAZ-PX Module .......................................................................29
Setting JAZ-PX for Free Running Mode....................................................................................30
Setting JAZ-PX for Triggered Mode ..........................................................................................30
Operating JAZ-PX from OceanView..........................................................................................31
Getting Started using JAZ-PX with OceanView....................................................................31
Synchronizing a Spectrometer Module to a JAZ-PX Module (recommended).....................33
Chapter 5: Operating the JAZ-INDY Module....................................35
JAZ- INDY Module Overview.........................................................................................35
JAZ-INDY Module Features...........................................................................................35
JAZ-INDY Menu ............................................................................................................36
JAZ-INDY Menu Defaults..........................................................................................................41
Calibrating the JAZ-INDY Module..................................................................................41
Calibrating the Voltage Outputs ................................................................................................42
Calibrating the Voltage Inputs ...................................................................................................42
Calibrating the 4-20mA Transmitter ..........................................................................................43
Calibrating the 4-20mA Receiver ..............................................................................................43
Chapter 6: Maintenance ....................................................................45
Overview .......................................................................................................................45
Software Updates..........................................................................................................45
OceanView ................................................................................................................................45
Jaz.............................................................................................................................................45
Jaz Troubleshooting......................................................................................................45
Jaz Connected to Computer Prior to OceanView Installation ...................................................45
Windows Operating Systems................................................................................................45
Mac Operating Systems........................................................................................................47
Linux Operating Systems......................................................................................................47
Jaz Troubleshooting Tips ..........................................................................................................47
Replacing an LED Assembly in the JAZ-INTLED Module..............................................48
Parts Needed.............................................................................................................................48

Table of Contents
013-RD000-000-02-201510 iii
LED Assembly Replacement Procedure...................................................................................49
Appendix A: Calibrating the Wavelength of Jaz..............................51
Overview .......................................................................................................................51
About Wavelength Calibration .......................................................................................51
Calibrating the Spectrometer.........................................................................................52
Preparing for Calibration............................................................................................................52
Calibrating the Wavelength of the Spectrometer ......................................................................52
Saving the New Calibration Coefficients: USB Mode.....................................................54
Appendix B: Specifications...............................................................55
Overview .......................................................................................................................55
Index...................................................................................................59

Table of Contents
iv 013-RD000-000-02-201510

013-RD000-000-02-201510 v
About This Manual
Document Purpose and Intended Audience
This document provides the users of Jaz with instructions for setting up, calibrating and performing
experiments with their Jaz unit.
What’s New in this Document
This version of the Jaz Installation and Operation Manual updates information for the Jaz Battery Pack.
Document Summary
Chapter
Description
Chapter 1: Introduction
Contains descriptive information about Jaz and how sampling
works. It also provides a list of system requirements, interface
options, and shipment components.
Chapter 2: Installing Jaz
Provides installation instructions.
Chapter 3: Operating Jaz
Provides instructions for using Jaz without OceanView
software. For information on using Jaz with OceanView, see
the OceanView manual (see Product-Related Documentation
below).
Chapter 4: Operating the JAZ-PX
Module
Contains instructions for using the JAZ-PX module. Includes
menus and setup information.
Chapter 5: Operating the JAZ-
INDY Module
Provides instructions for the JAZ-INDY module.
Chapter 6: Maintenance
Contains recommended steps to isolate and correct common
problems. Also contains instructions for obtaining software
updates and replacing an LED in the JAZ-INTLED module.
Appendix A: Calibrating the
Wavelength of Jaz
Provides instructions for calibrating the Jaz spectrometer
module.
Appendix B: Appendix B
Specifications
Contains technical specifications for the Jaz stack and its
individual modules.

About This Manual
vi 013-RD000-000-02-201510
Product-Related Documentation
You can access documentation for Ocean Optics products by visiting our website at
http://www.oceanoptics.com. Select Support Technical Documents, then choose the appropriate
document from the available drop-down lists.
Jaz Absolute Irradiance Installation and Operation Manual
JAZ-ADP-GPIO Adapter and JAZ-CBL-DB15 Accessory Cable Instructions
Jaz-ALP Adjustable Laser Pointer Operation Manual
Jaz Battery Pack (JAZ-EXT-BP) Instructions
Jaz Ethernet Ferrite Installation
JAZ-PX Lamp Module Engineering Note
Jaz Data Sheet
NeoFox and NeoFox Sport Installation and Operation Manual
Detailed instructions for OceanView Spectrometer Operating Software are located at:
http://oceanoptics.com///wp-content/uploads/OceanViewIO.pdf.
Ocean Optics offers a Glossary of spectroscopy terms to help you further understand your state-of-the-art
products and how they function, located at: http://oceanoptics.com/glossary/.
Upgrades
Occasionally, you may find that you need Ocean Optics to make a change or an upgrade to your system.
To facilitate these changes, you must first contact Customer Support and obtain a Return Merchandise
Authorization (RMA) number. Please contact Ocean Optics for specific instructions when returning a
product.
Warranty
Our 3-Year Warranty covers Ocean Optics miniature fiber optic spectrometers, light sources and
sampling accessories –regardless of the application –from manufacturing defects. It also covers fibers
and probes for a full 12 months: http://oceanoptics.com/services/exclusive-3-year-warranty/.
This comprehensive warranty ensures you of the highest level of craftsmanship and reliability for years to
come. No other manufacturer offers such a solid guarantee of quality and reliability.
The Ocean Optics 3-Year Warranty applies to Ocean Optics equipment (excluding OEM configurations)
purchased on or after July 1, 2010. The warranty covers parts and labor needed to repair manufacturing
defects that occur during the warranty period. We also will cover the costs of shipping warranty-related
repairs from our customers to Ocean Optics and from us to our customers.

About This Manual
013-RD000-000-02-201510 vii
WARNING
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which the user will be required to correct the interference at his on
expense.
WARNING: The authority to operate this equipment is conditioned by the
requirement that no modifications will be made to the equipment unless the changes
or modifications are expressly approved by the manufacturer.

About This Manual
viii 013-RD000-000-02-201510

013-RD000-000-02-201510 1
Chapter 1
Introduction
Product Overview
Jaz is a community of stackable, modular and autonomous component modules that combine to create a
community of smart sensing instruments that is unfettered by the limits of traditional optical sensing
instrumentation: a powerful microprocessor and onboard display eliminate the need for a PC; stackable,
autonomous instrument modules allow users to customize the system to their changing application needs;
and Ethernet connectivity plus SD card data storage capability facilitate remote operation.
Jaz is built on a platform that expands to include a light source, rechargeable lithium-ion battery and up to
8 spectrometer modules to make Jaz the first analytical instrument easily adaptable for the field, lab or
process environment. Jaz can also connect to a computer via the USB port. When connected through a
USB 2.0 or 1.1, the spectrometer draws power from the host computer. Jaz, like all USB devices, can be
controlled by our OceanView software.
Jaz is extremely adaptable. It can be powered via battery, USB connection, over the Ethernet, or from a
power outlet. The Jaz display can be rotated 180 degrees in either direction, and the faceplate itself can be
specified for either orientation. You can order the specific modules needed for your particular application
to be built in the Jaz stack, making Jaz a uniquely customizable scientific instrument and eliminating the
cost of unnecessary components.
Stack of Jaz Modules

1: Introduction
2013-RD000-000-02-201510
Jaz Modules
Jaz consist of a stack of individual spectroscopic instruments specified by the user to suit their unique
application. Modules available for the Jaz stack include the following:
Module
Description
JAZ-S
Spectrometer and grating (up to 8 can be configured in a stack)
JAZ-DPU
Processor (CPU), OLED display and keypad
JAZ-E
Ethernet and memory module. Includes one slot for an SD card (up to 2 GB).
JAZ-B
Battery (lithium-ion) and memory module. Includes two slots for an SD card (up to 2 GB
each). A Jaz 50-Watt battery extender (JAZ-EXT-BP-50WH) is also available.
JAZ-INDY
Industrial module enables communication with RS-232 and RS-485 data standards.
Offers both analog and digital inputs and outputs.
JAZ-PX
Pulsed xenon light source
JAZ-UV-VIS
Deuterium-tungsten halogen light source
JAZ-VIS-NIR
Tungsten-halogen light source
JAZ-INTLED
LED module that allows you to replace the following LED assmblies:
- JAZ-L640: 640 nm red LED
- JAZ-L590: 590 nm yellow LED
- JAZ-L450: 470 nm blue LED
- JAZ-L365: 365 nm UV LED
- JAZ-LWHITE: White LED
JAZ-NEOFOX
Jaz NeoFox Sport oxygen sensing module for measuring percentage of oxygen.
A Jaz Combo consists of a combination of up to three JAZ-S spectrometer modules and a JAZ-DPU
module.
Features
Sony ILX511B 2048-element linear silicon CCD array detector
14 grating options, UV through shortwave NIR
Responsive from 200 to 1100 nm
Maximum Wavelength range 650 nm
Sensitivity of up to 75 photons/count at 400 nm; 41 photons/count at 600 nm
An optical resolution of ~0.3 to 10.0 nm (FWHM)
Integration times from 870 µ to 65 seconds
EEPROM storage for
Wavelength Calibration Coefficients

1: Introduction
013-RD000-000-02-201510 3
Linearity Correction Coefficients
Absolute Irradiance Calibration (optional)
SD card data storage
Low power consumption of ~ 2.5 W
16 bit, 3MHz A/D Converter
20-pin connector for interfacing to external products
8-hour rechargable lithium-ion battery
Up to 3 spectrometer channels in a stack for simultaneous multipoint measurement
CE Certification
RoHS compliant
Ethernet IEEE 802.3 compliant 10/100
System Requirements
You can use the Jaz USB connectivity with any computer that meets the following requirements:
Microsoft Windows –Windows 2000/XP/7; 32-bit and 64-bit and Windows Vista (32-bit only)
Apple Macintosh –version 10.5 Intel or later
Linux –Any version released for an x86 or amd64 platform since 2010
Ocean Optics’spectrometer operating software application installed and configured for use.
EEPROM Utilization
An EEPROM memory chip in each JAZ-S spectrometer module contains wavelength calibration
coefficients, linearity coefficients, and a serial number unique to each individual spectrometer module.
The OceanView software application reads these values directly from the spectrometer, enabling the
ability to “hot-swap” spectrometers between computers without entering the spectrometer coefficients
manually on each computer.
About OceanView Software
Although Jaz is unique in that it can perform a number of spectroscopy measurements and display results
right on its display screen, OceanView spectrometer operating software is also available to enhance Jaz’s
functionality. OceanView is the latest generation of operating software for all Ocean Optics
spectrometers. It is a Java-based spectroscopy software platform that operates on Windows, Macintosh
and Linux operating systems. The software can control any Ocean Optics USB spectrometer and device.
OceanView is a user-customizable, advanced acquisition and display program that provides a real-time
interface to a variety of signal-processing functions. With OceanView, you have the ability to perform
spectroscopic measurements (such as absorbance, reflectance, and emission), control all system
parameters, collect and display data in real time, and perform reference monitoring and time acquisition
experiments. Consult the OceanView manual for hardware requirements when using OceanView (see
Product-Related Documentation).

1: Introduction
4013-RD000-000-02-201510
Sampling System Overview
How Sampling Works
Ocean Optics components function in a sampling system as follows:
1. The user stores reference and dark measurements to correct for instrument response variables.
2. The light from the light source transmits through an optical fiber to the sample.
3. The light interacts with the sample.
4. Another optical fiber collects and transmits the result of the interaction to the spectrometer.
5. The spectrometer measures the amount of light and transforms the data collected by the
spectrometer into digital information.
6. The spectrometer passes the sample information to OceanView.
7. OceanView compares the sample to the reference measurement and displays processed spectral
information.
Interface Options
Jaz is field-portable and can collect data as a free-standing unit from the battery embedded in the stack.
The Jaz stack also has both USB and Ethernet port connectors, enabling you to connect the spectrometer
to a computer via a USB port or to the network via a connection from the Ethernet port to a Power Over
Ethernet (POE) bridge or a switch to the network (e.g., a network hub). Your Jaz stack receives power
from either connection, and both connections enable Jaz to be recognized by OceanView software.
Shipment Components
Jaz is a scalable system, allowing you to design the instrument most appropriate for your application.
However, a typical Jaz system could consist of the following components:
Packing List
The packing list is inside a plastic bag attached to the outside of the shipment box (the invoice
arrives separately). It lists all items in the order, including customized components in the
spectrometer (such as the grating, detector collection lens, and slit). The packing list also includes
the shipping and billing addresses, as well as any items on back order.

1: Introduction
013-RD000-000-02-201510 5
Jaz Stack
Usually consists of up to eight spectrometer modules (JAZ-S), a CPU module (JAZ-DPU), a
battery/memory module (JAZ-B), and an Ethernet/SD module (JAZ-E).
Mini USB Cable (USB-CBL-MINI)
Use this cable to connect your Jaz spectrometer module to a computer running on a Windows,
Mac or Linux operating system.
Ethernet Cable (if an Ethernet module is included)
A 14-foot cable to connect the JAZ-E module to a bridge or switch to access the network.
Power Supply (USB-CBL-PS)
A 5 V power supply to provide an extra power source in addition to the battery, USB power and
POE (Power Over Ethernet).
Wavelength Calibration Data Sheet
Each spectrometer is shipped with a Wavelength Calibration Data Sheet that contains information
unique to your spectrometer. OceanView Operating Software reads this calibration data from
your spectrometer when it interfaces to a computer via the USB port.
Note
Please save the Wavelength Calibration Data Sheet for future reference.
Additional Equipment Available
In addition to the Jaz Modules, the following software and accessories are available for use with Jaz. Visit
us at www.OceanOptics.com for a complete list of products available for all of your spectroscopy needs.
JAZ-MNT-DIN3 rail-mounting kit
JAZ-MNT-WALL wall-mounting kit for mounting Jaz stacks with 3 or fewer modules
(excluding the DPU and end module) onto a wall.
JAZ-MOUNT Jaz side-mounting kit for 3 different orientations.
JAZ-CBL-DB15 accessory cable.
JAZ-ADP-GPIO adapter for DPUs manufactured on January 1, 2008.
JAZ-PACK soft-sided Jaz carrying pack with adjustable shoulder strap (-S) or waist belt (-W).
JAZ-CASE-1450 black Jaz Pelican 1450 case.
JAZ-SOLAR solar battery supply with charger for an additional 4 hours of battery life.
JAZ-ULM-200 Jaz light measurement system for spectroradiometric analysis.
JAZ-PX Jaz PX pulsed xenon light source. See Chapter 4: Operating the JAZ-PX Module.
JAZ-EXT-BP battery pack (38 Watt-hour)
Accessory Lithium-ion external 5V power supply.

1: Introduction
6013-RD000-000-02-201510
INTLED-KIT tool kit for changing LEDs in the JAZ-INTLED module. See Replacing an LED
Assembly in the JAZ-INTLED Module.
Jaz Light Meter convenient light-sensing tool containing the following:
Jaz Spectrometer containing reverse-orientation keypad, Grating 2 (200-850 nm), 2000-
series detector with 200-850 nm order-sorting filter and UV upgrade, L2 detector collection
lens, 10µm slit
JAZ-MOUNT side-mount module for hands-free operation
Battery module
Ethernet module with SD card
Direct-attach cosine corrector
JAZ-A-IRRAD software for irradiance measurements
Spectroradiometric calibration service (350-1000 nm)
JAZ-PACK-S carrying case with shoulder strap
JAZ-CASE-1450 Jaz Pelican case
Jaz EL 350 for VIS-NIR applications includes the following:
Jaz Spectrometer
Grating #2 (350-1000 nm)
Detector 350-1000 nm
INTSMA-25 (25mm slit)
L2 light collection lens
Battery module
OceanView software
Jaz EL 200 for UV-VIS applications
Jaz Spectrometer
Grating #1 (200-850 nm)
Detector 200-850 nm
INTSMA-25 (25mm slit)
L2 light collection lens
Battery module
OceanView software
Jaz EL 200-XR1 for both VIS/NIR and UV/VIS applications
Jaz Spectrometer
Grating #31 (200-1025 nm)
Detector 200-1050 nm
INTSMA-25 (25mm slit)
L2 light collection lens
Battery module
OceanView software
Jaz-FL-365 for fluorescence applications
JAZ-COMBO
JAZ-L365 (365 mm LED module)

1: Introduction
013-RD000-000-02-201510 7
JAZ-B battery module
JAZ-E Ethernet module
Grating #2 (250-800 nm)
Detector 250-800 nm
INTSMA-200 (200mm slit)
L2 light collection lens
OceanView software
Jaz-FL-450 for fluorescence applications
JAZ-COMBO
JAZ-L450 (450 mm LED module)
JAZ-B battery module
JAZ-E Ethernet module
Grating #3 (350-1000 nm)
Detector 350-1000 nm
INTSMA-200 (200mm slit)
L2 light collection lens
OceanView Operating Software. See About OceanView for more information.
OmniDriver software driver package for Windows, Mac OSX and Linux operating systems.
JAZ-A-IRRAD absolute irradiance application.
Available on an SD card for onboard absolute irradiance measurements.
Jaz Scripting Language. Allows you to write scripts for your Jaz system to perform simple data
acquisition, processing and exporting of results to an SD card.
Jaz Application Programming Interface (API) enables 3rd party development for Jaz.
NeoFox Sport
Available as an additional module (JAZ-NEOFOX), when coupled with a probe, light source
module and spectrometer module, the NeoFox Sport offers a turnkey Oxygen and pH sensing
instrument, along with spectrometer functionality in a convenient handheld, portable device.
Fibers
Light Sources
Integrated Sampling Systems
Cuvettes
Filter Holders

1: Introduction
8013-RD000-000-02-201510

013-RD000-000-02-201510 9
Chapter 2
Installing Jaz
Overview
Your Jaz unit is field-portable and can collect data as a free-standing unit from the battery embedded in
the stack. You also have two options for connecting Jaz to a computer to process the data you have
collected:
A USB connection directly to a computer running OceanView.
An Ethernet connection to a computer network.
Note
Your Jaz unit receives power from either connection.
If you have purchased OceanView software, you must install it prior to connecting Jaz Spectrometer to a
computer. The OceanView software installation installs the drivers required for Jaz. If you do not install
OceanView first, the computer will not properly recognize Jaz. Follow the prompts in the OceanView
installer wizard.
If you have already connected Jaz to a computer running on a Windows platform prior to installing
OceanView, consult Jaz Connected to Computer Prior to OceanView Installation for information on
correcting a corrupt Jaz installation.
Caution
Connect all cables before powering-on your Jaz unit. Install Jaz in the following
order:
1. Connect the external power supply (if used).
2. Open OceanView.
3. Connect the USB cable between Jaz and your computer (if used).
4. Press F5 to display Jaz in OceanView.

2: Installing Jaz
10 013-RD000-000-02-201510
Installing the Jaz Unit
This section contains instructions for connecting Jaz directly to a computer through the USB port or to the
network through the Ethernet port.
Connecting Jaz to a Computer via USB
►Procedure
1. Connect the USB (B) cable that you received with your Jaz unit from the JAZ-DPU module to
your computer.
2. When first connecting Jaz to your computer, you must run the Hardware Wizard for your PC to
recognize the new hardware. For Mac users, this step is not necessary.
3. In OceanView, use the Device Manager for your Jaz unit to be recognized in the OceanView
software.
Ethernet Connection
You can connect Jaz to the network via the Ethernet port on the JAZ-E module. A ferrite is provided with
your JAZ-E Ethernet module to be used in the event that you experience interference with any electronic
devices.
►Procedure
Follow the steps below to connect the port on the Jaz Ethernet & Memory module to a Power Over
Ethernet (POE) bridge or a switch to the network (e.g., an 8-port network hub):
1. Find the Ethernet cable and the ferrite that you received in your Jaz package.
