Mobile Bluetooth®SpeakerSOUNDCUP-D
MobilerBluetooth®-Lautsprecher

3
2
3
1
4
4
1

True Wireless
Stereo
Pic 1 Pic 2

2
Controls andDisplays
1. Power on/off button /Status LED /
Functionbutton
2. Function button+
3. Function button–
4. Micro-USBcharging connection
Thank youfor choosing aHama product.
Take your time and read the following instructions
andinformation completely. Please keepthese
instructions in asafeplace forfuturereference. If
yousellthe device, pleasepass these operating
instructions on to the newowner.
1. Explanation of Warning Symbols and
Notes
Warning
This symbolisused to indicate safety
instructions or to draw your attentionto
specichazards and risks.
Note
This symbol is used to indicate additional
information or importantnotes.
2. PackageContents
•Mobile
Bluetooth
®
Speaker Soundcup-D
•Micro-USBcharging cable
•Removable silicone case
•These operating instructions
3. SafetyNotes
•Use theproduct for its intended purpose only.
•The product is intended forprivate, non-
commercial use only.
•Donot use the product in the immediate
vicinity of heaters or otherheat sourcesorin
directsunlight.
•Donot use the product in areaswhere the use
of electronicdevices is not permitted.
•Donot operatethe product outside thepower
limits given in thespecications.
•Since thebattery is integrated and cannot be
removed, youwillneedtodisposeofthe
product as awhole. Dothis in compliance
withthe legal requirements.
•Donot drop the product anddonot expose it
to any major shocks.
•Donot attempt to service or repair the product
yourself.Leave any and allservicework to
qualied experts.
•Donot open thedeviceorcontinue to operate
it if it becomesdamaged.
•Keep thepackagingmaterialout of thereach
of children due to the risk of suffocation.
•Beconsiderate. Loud volumes can have a
detrimental effect on your surroundings.
•Dispose of packaging material immediately
according to locally applicable regulations.
•Donot modifythe product in anyway.Doing
so voids thewarranty.
•Keep this product, as allelectrical products,
out of the reachofchildren!
Note–Use in wet
environments
Thespeaker is waterproof at depths of up
to 1maccording to IPX7. It cantherefore
be used in wetenvironments(e.g. the
shower) withoutproblems.Pleasenotethat
allchargingports mustbeclosed whenthe
speaker comes into contact with water.
4. Getting started and operation
4.1 Switching on theproduct
•Press andholdthe two function buttons
(1) for about2secondstoswitchthe speaker
on or off.
•Avoice notication conrms thatthe device is
readyfor operation. The LEDindicator (1)
lights up blue.
GOperating instruction

3
4.2 Switchingoff the product
Note–Automatic shutdown
Note that the speakerwillautomatically
switchoff after 10 minutes without
action (no audio playback/no
Bluetooth
®
function).
4.2 Chargingthe battery
Warning –Rechargeable
battery
•Onlyuse suitable chargingdevicesor
USB connections to charge the product.
•Asarule, do not use charging devices
or USB connections that are defective
and do nottry to repairthem yourself.
•Donot overcharge the product orallow
the batterytocompletely discharge.
•Avoid storing,chargingorusing
batteries in extreme temperatures.
•Whenstoredover along period of time,
batteries should be chargedregularly
(at leastevery three months).
Note
Each halfofthe SoundCup-Dhas itsown
battery.Bothhalves must be charged in
ordertouse the speaker.
Thefollowing steps therefore have to be
performedfor both halves.
Note
•Carefully seal the Micro-USBport after
charging to make sure that the product
is waterproof.
•Note thatwater may affect the range
and tone of thespeaker.
•Charge both speakers fullybefore using them
for the rst time.
•Openthe closureonthe Micro-USBport (4).
•Connectthe included Micro-USB charging
cable to the speaker’sMicro-USB port(4).
•Connectthe unusedconnector on the Micro-
USB chargingcable to asuitable USBcharger.
Pleaserefer tothe operating instructions for
theUSB charger used.
•The statusLED (1)lightsupconstantly in
redduring the chargingprocess.
•Ifthe battery is fully charged,the status LED
(1)willgoout.
Note –Charging
•Ittakes approx. 3-4 hours to completely
charge theproduct.
•The speaker’s batterycan be charged
whether the speaker is on or off.
•Ifthe battery capacity is lessthan10%,
the speaker will emit two acoustic
signals. Youwillonlyreceivethis
information if thespeakerison.
•The actual battery life varies dependingonuse
of the device, the settings and theambient
conditions (rechargeablebatteries have a
limited service life).
4.3
Bluetooth
®
pairing
Note
•Check whether your mobile device
(MP3 player,mobile phone, etc.) is
Bluetooth
®
capable.
•Note that the maximum range for
Bluetooth
®
is 10 metres without
obstacles such as walls, people, etc.

4
•Make surethat your Bluetooth
®
capable terminal device is on and
Bluetooth
®
is activated.
•Make surethat the speaker is located
within the Bluetooth
®
range of max.
10 metres.
•Switch on thespeakersasdescribed in
4.1 Switching theproductonand off.
•The statusLEDs (1)start ashingblue. The
twohalvesofthe speaker then connect to
each other automatically.
•Once thehalveshavesuccessfully connected,
thestatusLED (1)onone speaker lights
up blue.
•The statusLED (1)onthe master speaker
continues ashingblue whilethe speaker
searches foraconnection to theterminal
device.
•Open the Bluetooth
®
settings on your terminal
device andwaituntil HamaSoundcup-D
appears in the list of Bluetooth
®
devices
found.
•Select Hama Soundcup-D andwaituntil
the speaker is listed as connected in the
Bluetooth
®
settings on your terminal device.
An acoustic signal conrms thatconnection
wassuccessful.
•The statusLED (1) on the master
speaker remains lit.
Note–
Bluetooth
®
password
•Some terminal devicesrequire a
passwordinorder to connectto
another
Bluetooth
®
device.
•Ifyour terminal device requests a
passwordfor connection to thespeaker,
enter 0000.
Note–Connection to anew
device
•Ifyou wanttoconnectanew
Bluetooth
®
terminaldevice to the
speaker,press thefunction button
(1) twice in shortsuccession until the
statusLED (1)beginstoashblue
and an acoustic signal sounds.
•The current connection is disconnected
and thesearch for new terminal
devicesstarts.
•The speaker always stores the last eight
terminal devicespaired.
•The speaker will automatically connect
to the lastterminaldevicepairedwhen
it is switched on thenext time.
4.4 Automatic
Bluetooth
®
connection (after
successful pairing)
•Make surethat your
Bluetooth
®
capable
terminaldeviceisonand Bluetooth
®
is
activated.
•Make surethat the speaker is locatedwithin
the Bluetooth
®
range of max.10metres.
•Switch on thespeakersasdescribed in 4.1
Switching the productonand off.
•Aftersuccessfulconnection,the status LED
(1)willlight up in blue.Anacoustic signal
conrmsthat connectionwas successful.
Note –Connection impaired
•Afterthe speakerand terminal device
havebeenpaired, aconnection
is establishedautomatically.If
the
Bluetooth
®
connection is not
establishedautomatically, check the
following:
•Check the Bluetooth
®
settings of
your terminal device to see whether
HamaSoundcup-D is connected.
If not, repeatthe steps listed under
Bluetooth
®
pairing.

5
•Check whether yourterminaldevice
and the speaker areless than 10
metresapart. If not,move them closer
together.
•Check whether obstacles areimpairing
the range. If so, move thedevices
closer together.
4.5 Audio playback (via
Bluetooth
®
)
Startand control audioplayback on the
connectedterminal device accordingly.
Alternatively, audio playback can also be
controlled on thespeaker(if the connected device
supports this function).
•Press the functionbutton (1)tostartor
pauseaudioplayback.
•Hold down the+function button (2) to skip
to the next track.
•Hold down the–functionbutton (3) to return
to theprevioustrack..
•Brieypress the+functionbutton(2) to
increase thevolume.
•Brieypress the –function button (3)to
reduce thevolume.
5. TrueWireless Stereo–connect the halves
of the speakerfor stereo sound
Note–Master
•The speaker that is switched on rstwill
be the master.
•Ifyou are only using onespeaker, it is
automatically themaster.
•Disconnect the speaker halves by twisting
them. (Pic 1)
•Disable the
Bluetooth
®
functiononyour
terminaldevice.
• Switch on both speakers as described in
4.1 Switching theproduct on and off .
•The twohalves automatically connect to
eachother.
•Now enable the Bluetooth
®
functiononyour
terminal device.
•Openthe Bluetooth
®
settings on your terminal
device andwaituntil Soundcup-D appearsin
thelist of Bluetooth
®
devicesfound.
•Select SoundCup-D andwaituntil the
speaker is listed as connected in the
Bluetooth
®
settings on your terminal device.
•Aftersuccessfulconnection,anacousticsignal
soundsfromboth speakers.
•Positionthe speaker that is themaster to
yourleft. Position the second speaker to your
right. (Pic 2)
6. Care andMaintenance
Onlyclean thisproduct with aslightly damp,
lint-freecloth anddonot useaggressive cleaning
agents.
7. Warranty Disclaimer
Hama GmbH &CoKG assumes no liabilityand
provides no warranty fordamage resulting from
improper installation/mounting, improper use
of the product or from failuretoobserve the
operating instructions and/or safety notes.
8. Service and Support
Pleasecontact Hama Product Consulting if you
haveany questions about thisproduct.
Hotline: [phone] (German/English)
Furthersupport informationcan be found here:
www.hama.com

6
9. Service and Support
Mobile Bluetooth
®
Speaker
Soundcup-D
Bluetooth
®
Technology
4.2
Frequency 100 Hz –20kHz
Range <10m
Max. musicoutput20W(2x 10W)
Chargingvoltage Max. 5V 1A
SoundSystem Stereo/True Wireless
Stereo
Impedanc 4 Ω
Distortion(THD) ≤1%
Size 210 x84x84 mm
Weight 745 g
Connections Micro USB
Battery
Type 2x Lithium-Ion, 3.7 V,
1500 mA/5.5 Wh
Charging time ~3h
Playback
~6h
(depending on
volume and audio
content)
10. Declaration of Conformity
Hereby, Hama GmbH&Co KG
declaresthat theradio equipment
type [00173186] is in compliance
with Directive 2014/53/EU.The full text of theEU
declarationofconformityisavailable at the
following internet address: www.hama.
com->00173186->Downloads.
Frequencyband(s) 2402MHz ~
2480MHz
Maximum radio-frequency
power transmitted 0.88dBm

7
Bedienungselementeund Anzeigen
1. Ein-/Ausschalttaste /Status LED /
Funktionstaste
2. Funktionstaste+
3. Funktionstaste–
4. USB-Ladeanschluss Micro-USB
VielenDank, dass Siesich für einHamaProdukt
entschiedenhaben!
Nehmen SiesichZeitund lesenSie die folgenden
Anweisungen undHinweise zunächst ganz
durch. BewahrenSie diese Bedienungsanleitung
anschließendaneinem sicherenOrt auf, um
beiBedarf darin nachschlagen zu können.
Sollten Siedas Gerät veräußern, geben Siediese
Bedienungsanleitunganden neuen Eigentümer
weiter.
1. Erklärungvon Warnsymbolen und
Hinweisen
Warnung
Wird verwendet,umSicherheitshinweisezu
kennzeichnen oder um Aufmerksamkeit auf
besondereGefahren und Risikenzulenken.
Hinweis
Wird verwendet,umzusätzlich
Informationen oderwichtigeHinweise zu
kennzeichnen.
2. Packungsinhalt
•Mobiler
Bluetooth
®
Lautsprecher Soundcup-D
•Micro-USBLadekabel
•AbnehmbareSilikonhülle
•Diese Bedienungsanleitung
3. Sicherheitshinweise
•Verwenden Siedas Produkt ausschließlich für
den dazu vorgesehenenZweck.
•Das Produkt ist für den privaten,nicht-
gewerblichen Haushaltsgebrauch vorgesehen.
•Betreiben Sie das Produkt nichtin
unmittelbarerNähe derHeizung,
anderer Hitzequellen oder in direkter
Sonneneinstrahlung.
•Benutzen Siedas Produkt nichtinBereichen,
in denen elektronische Produkte nicht
erlaubt sind.
•Betreiben Sie das Produkt nichtaußerhalb
seinerinden technischenDaten angegebenen
Leistungsgrenzen.
•Der Akku istfest eingebaut und kann
nicht entfernt werden, entsorgen Siedas
Produkt alsGanzesgemäß den gesetzlichen
Bestimmungen.
•Lassen Sie dasProdukt nicht fallenund setzen
Sie es keinenheftigen Erschütterungen aus.
•Versuchen Sienicht, das Produktselbst zu
warten oder zu reparieren. Überlassen Sie
jegliche Wartungsarbeit demzuständigen
Fachpersonal.
•Öffnen Sie das Produktnicht und betreiben Sie
es beiBeschädigungennicht weiter.
•HaltenSie Kinder unbedingtvon dem
Verpackungsmaterialfern, es besteht
Erstickungsgefahr.
•Nehmen SieRücksicht.HoheLautstärken
können ihreUmgebungstörenoder
beeinträchtigen.
•Entsorgen Siedas Verpackungsmaterial
sofortgemäß den örtlich gültigen
Entsorgungsvorschriften.
•Nehmen Siekeine Veränderungen am
Produkt vor. Dadurch verlieren sie jegliche
Gewährleistungsansprüche.
•DiesesProduktgehört, wie alle elektrischen
Produkte,nicht in Kinderhände!
DBedienungsanleitung

8
Hinweis–Wasserdichtigkeit
DerLautsprecherist gemäß IPX7
wasserdicht bis1mWassertiefe.Der
Einsatz in feuchter Umgebung (z.B.Dusche)
ist damit problemlosmöglich. Achten Sie
darauf,dassbei Kontakt mit Wasseralle
Ladeanschlüssegeschlossen seinmüssen.
4. Inbetriebnahmeund Betrieb
4.1 Ein-/ Ausschalten
•Drücken undhaltenSie beide Funktionstasten
(1)ca. 2Sekunden,umden Lautsprecher
ein-/auszuschalten.
•Esertönt ein akustisches Signal unddie
Status-LED (1)beginnt zu blinken.
Hinweis –Automatisches
Ausschalten
BeachtenSie,dasssich derLautsprecher
nach 10 Minutenohne Aktion(keine
Audiowiedergabe/ keine
Bluetooth
®
Funktion)abschaltet.
4.2 Aufladen desAkkus
Warnung -Akku
•Verwenden Sienur geeignete Ladegeräte
oderUSB-Anschlüsse zum Auaden.
•Verwenden SiedefekteLadegeräte oder
USB-Anschlüsse generell nicht mehrund
versuchen Sie nicht, diesezureparieren.
•Überladen oder tiefentladen Siedas
Produkt nicht.
•Vermeiden Sie Lagerung, Ladenund
Benutzungbei extremen Temperaturen.
•LadenSie bei längerer Lagerung
regelmäßig (mind. vierteljährig) nach.
Hinweis
Beide Hälftendes Soundcup-D verfügen
über eineneigenen Akku. Um den
Lautsprecher zu nutzen,müssen beide
Hälften geladen sein.
Führen Siedaher die folgendenSchritte für
beide Hälftendurch.
Hinweis
•VerschließenSie den Micro-USB-
Anschluss nach dem Ladevorgang
sorgfältig, umsicherzustellen, dass das
Produkt wasserdichtist.
•Beachten Sie, dassWasser die
Reichweiteund denKlang des
Lautsprechersbeeinussen kann.
•LadenSie vor dem ersten Gebrauch beide
Lautsprecher einmal vollständig auf.
•Öffnen Sie den Verschluss des Micro-USB-
Anschlusses (4).
•Schließen Sie das mitgelieferteMicro-USB
LadekabelamMicro-USBAnschuss (4) des
Lautsprechersan.
•Schließen Sie den freien Stecker des
Micro-USBLadekabelsaneinem geeigneten
USB Ladegerät an. BeachtenSie hierzudie
Bedienungsanleitungdes verwendeten USB
Ladegeräts.
•Die Status-LED (1) leuchtetwährend des
Ladevorgangs dauerhaftrot.
•Ist derAkku vollständig geladen, erlischtdie
Status-LED (1).
