GOperating instruction
Controls and Displays
ABase station
1. Outdoor temperature
2. Battery symbol
3. Room temperature
4. Time
5. Summer time
6. Wireless symbol
7. button =Increases the current setting/Toggles 12/24 hour format/Manual
search for signal from the measuring station
8. MODE button =Settings/Conrms the setting
9. button =Decreases the current setting/Toggles between °C and °F/Activates/
deactivates manual radio signal reception
10. Battery compartment
BMeasuring station
11. Transmission indicator lamp
12. Opening for wall mounting
13. Battery compartment
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to
specichazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
•Weather Station EWS-152
(base station for indoor/outdoor measuring station)
•4AAA batteries
•These operating instructions

3
3. Safety Instructions
•The product is intended for private, non-commercial use only.
•Donot operate the product outside the power limits given in the specications.
•Donot use the product in moist environments and avoid splashes.
•Donot use the product in the immediate vicinity of heaters or other heat sources
or in direct sunlight.
•Donot use the product in areas wherethe use of electronic devices is not permitted.
•Donot place the product near interference elds, metal frames, computers, TVs,
etc. Electronic devices and window frames can negatively affect the product’s
functionality.
•Donot drop the product and do not expose it to any major shocks.
•Donot open the device or continue to operate it if it becomes damaged.
•Donot attempt to service or repair the product yourself.Leave any and all service
work to qualied experts.
•Keep the packaging material out of the reach of children due to the risk of suffocation.
•Dispose of packaging material immediately according to locally applicable
regulations.
•Donot modify the product in any way.Doing so voids the warranty.
•Use the product for its intended purpose only.
•Use the item only in moderate climatic conditions.
•Keep this product, as all electrical products, out of the reach of children!

4
Warning –Batteries
•When inserting batteries, note the correct polarity (+ and -markings) and insert the
batteries accordingly.Failure to do so could result in the batteries leaking or exploding.
•Only use batteries (or rechargeable batteries) that match the specied type.
•Beforeyou insert the batteries, clean the battery contacts and the polar contacts.
•Donot allow children to change batteries without supervision.
•Donot mix old and new batteries or batteries of adifferent type or make.
•Remove the batteries from products that arenot being used for an extended period
(unless these arebeing kept ready for an emergency).
•Donot short-circuit batteries.
•Donot charge batteries.
•Donot throw batteries in a re.
•Keep batteries out of the reach of children.
•Never open, damage or swallow batteries or allow them to enter the environment. They
can contain toxic, environmentally harmful heavy metals.
•Immediately remove and dispose of dead batteries from the product.
•Avoid storing, charging or using the device in extreme temperatures and
extremely low atmospheric pressure(for example, at high altitudes).
4. Getting Started
4.1 Measuring station
•Open the battery compartment (13) and insert two AAA batteries with the correct
polarity.Close the battery compartment.
Note
Beforeuse, ensureyou insert the batteries in the measuring station rst and then
in the base station.
4.2 Base station
•Open the battery compartment (10) and insert two AAA batteries with the correct
polarity.Close the battery compartment.

5
5. Installation
Note –Installation
•Werecommend initially placing the base and measuring stations in the intended
locations without installing them and making all the settings described in 6.
Operating –todo
•Only install the stations once the appropriate settings have been made and a
stable wireless connection is established between the stations.
•Donot mount the product above locations wherepersons might linger.
Note
•The wireless transmission range between the measuring and base stations is up
to 30 minopen spaces.
•Beforeinstallation, ensurethat wireless transmission will not be disrupted by
interference or obstacles like buildings, trees, vehicles, high-voltage lines, etc.
•Beforethe nal installation, ensurethat thereissucient reception between the
intended installation locations.
•When installing the measuring station, ensurethat it is protected from direct
sunlight and rain.
•The international standardheight for measuring air temperatureis1.25 m(4
ft) above ground.
Warning
•Buy special or suitable installation material from aspecialised dealer for
wall-mounting.
•Ensurethat no faulty or damaged parts areinstalled.
•Never apply force during installation. This could damage the product.
•Beforeinstallation, ensurethat the chosen wall is suitable for the weight to be
installation, and make surethat thereare no electrical wires, water,gas or other
lines at the installation site on the wall.
5.1 Base station
•Use the base to position the base station on alevel surface.

6
5.2 Measuring station
•You can also position the measuring station on alevel outdoor surface.
•Werecommend installing the measuring station securely on an outdoor wall using
the opening (12). Install an anchor,screw,nail, etc. in the wall of your choice.
•Hang up the base/measuring station using the opening intended for this purpose.
6. Operation
Note –Input
Hold down the button (7) or the button (9) to select values faster.
6.1 Connection to the measuring station
•After you insert the batteries, the base station automatically searches for a
connection to the measuring station and performs initial setup.
Note
•Initial setup takes approx. 3minutes.
•Donot press any buttons during setup. Otherwise, values may not be transmitted
correctly and thereisarisk of value errors and inaccuracies.
•The setup process is completed when the indoor (3) and outdoor (1)
measurement data is displayed.
•Ifthe base station still does not receive asignal from the measuring station ,press
and hold the button (7) for approx. 3seconds to start the manual search for
the signal.

7
6.2 Basic and manual settings
Automatic setting using the DCF signal
•After the base station is switched on for the rst time and successful transmission
is established between the base station and the measuring station, the clock will
automatically search for aDCF signal. During the search, the wireless symbol (6)
will ash.
Display Searching for the DCF signal
Flashing
Active
Displayed continuously
Successful –signal is being received
No display Deactivated
•Ifthe station still does not receive asignal, press and hold the button (9) for
approx. 3seconds to start the manual search for the DCF signal. The wireless
symbol (6) will start to ash.
Note –Time settings
•The search process takes about 7minutes. If the search fails, it ends and is
repeated at the next clock hour.The wireless symbol (6) will go out.
•Inthe meantime you can, however,set the time and the date manually.
•The clock automatically continues to search for the DCF signal on adaily basis
(between 1:00 a.m. and 3:00 a.m.). If the signal is received successfully,the
manually-set time and date areoverwritten.

8
Note –Summer time
•The clock automatically switches to summer time. Sappears on the display as
long as summer time is activated.
•Press and hold the button (9) again for approx. 3seconds to stop the manual
search.
Manually setting the date/time
•Press and hold the button (9) for approx. 3seconds to stop the search for the
DCF signal. The wireless symbol (6) goes out and you can set the time manually.
•Press and hold the MODE button (8) for approx. 3seconds to start manually setting
the date/time.
•Set the following information in the order listed:
•Time zone (difference in hours), hour,minute.
•Toselect individual values, press the button (7) or the button (9) and conrm
each selection by pressing the MODE button (8). .
•Ifyou do not make an entry for 20 seconds, you automatically exit setup mode.
Note –Time zone
•The DCF signal can be received over long distances, but always transmits the
current Central European Time in Germany.Make sureyou account for the time
difference in countries with another time zone.
•Ifyou areinMoscow,the time is 3hours later than in Germany.This means that
you should set +3 for the time zone. The clock then automatically sets the time
to 3hours after the DCF signal received or relative to the manually set time.
Celsius/Fahrenheit
•Press the button (9) to switch between °C and °F for the temperaturedisplay.
12/24 hour format
•Press the button (7) to switch the time between the 12 and 24 hour format.
6.3 Low battery capacity
As soon as the battery symbol (2) appears on the display of the base station, the
capacity of the batteries in the measuring station is very low.Replace the batteries
immediately.

9
Note –Replacing the batteries
•Note that the stations have to be resynchronised each time after you change the
batteries in the measuring or base station.
•Todothis, remove the batteries from the other station and then reinsert them, or
change them as required.
7. Care and Maintenance
Only clean this product with aslightly damp, lint-free cloth and do not use aggressive
cleaning agents.
8. Warranty Disclaimer
Hama GmbH &CoKG assumes no liability and provides no warranty for damage
resulting from improper installation/mounting, improper use of the product or from
failuretoobserve the operating instructions and/or safety notes.
