HAMPTON BAY Algiers 672 099 User manual

672 099
672 396
672 132
672 429
S/O
S/O
Algiers
Algiers
54
37

54” Algiers
Ceiling Fan by Hampton Bay
3-Speed Reverse Function for
Year-Round Comfort and Savings
Tri-Mount Installation
Steeper Blade Pitch for
Greater Air Movement
QUESTIONS, PROBLEMS, MISSING PARTS:
Before returning to your local Home Depot, please call our
Customer Service Team at 1-877-527-0313 or visit www.homedepot.com.
Please reference your SKU (672 099 bavarian bronze, 672 132 cambridge silver)
or UPC (082392 561383 bavarian bronze, 082392 561390 cambridge silver).
Thank you for purchasing this Hampton Bay ceiling
fan. This product has been manufactured with the
highest standards of safety and quality. The nish
of this fan is weather resistant, but over time will
naturally weather and fade.
Safety Rules .................................. 1
Unpacking Your Fan.................... 2
Installing Your Fan ...................... 3
Operating Your Fan ..................... 10
Care of Your Fan.......................... 11
Troubleshooting............................ 11
Specications ................................ 12
Warranty Information................. 13
Table of Contents
UL Model No. 56138

Safety Rules .................................. 1
Unpacking Your Fan.................... 2
Installing Your Fan ...................... 3
Operating Your Fan ..................... 10
Care of Your Fan.......................... 11
Troubleshooting............................ 11
Specications ................................ 12
Warranty Information................. 13
1. To reduce the risk of electric shock, insure electricity
has been turned off at the circuit breaker or fuse box
before beginning.
2. All wiring must be in accordance with the National
Electrical Code (ANSI/NFPA 70-1999) and local electri-
cal codes. Electrical installation should be performed by a
qualied licensed electrician.
3. WARNING: To reduce the risk of re or electric shock, do not
use this fan with any solid-state fan speed control device.
4. CAUTION: To reduce the risk of personal injury, use only
the screws provided with the outlet box.
5. The outlet box and support structure must be securely
mounted and capable of reliably supporting a minimum of
35 pounds.
6. The fan must be mounted with a minimum of 7 feet
clearance from the trailing edge of the blades to the oor.
7. Do not operate reversing switch while fan blades are in mo-
tion. Fan must be turned off and blades stopped before re-
versing blade direction.
8. Avoid placing objects in path of the blades.
9. To avoid personal injury or damage to the fan and
other items, be cautious when working around or
cleaning the fan.
10. Do not use water or detergents when cleaning the fan or fan
blades. A dry dust cloth or lightly dampened cloth will be
suitable for most cleaning.
11. After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into
outlet box. The wires should be spread apart with the
grounded conductor and the equipment-grounding
conductor on one side of the outlet box.
12. Electrical diagrams are for reference only. Light kits that are
not packed with the fan must be UL Listed and marked suit-
able for use with the model fan you are installing. Switches
must be UL General Use Switches. Refer to the instructions
packaged with the light kits and switches for proper assembly.
13. All set screws must be checked and retightened where neces-
sary before installation.
14. Suitable for use in damp locations.
Safety Rules 1.
READ AND SAVE THESE INSTRUCTIONS
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL
INJURY, MOUNT FAN TO OUTLET BOX MARKED “ACCEPTABLE FOR
FAN SUPPORT” WITH THE SCREWS PROVIDED WITH THE OUTLET
BOX.
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE
BLADE BRACKETS (ALSO REFERRED TO AS (“FLANGES”) DURING
ASSEMBLY OR AFTER INSTALLATION. DO NOT INSERT OBJECTS IN
THE PATH OF THE BLADES.
TO REDUCE THE RISK OF ELECTRIC SHOCK, THIS FAN MUST BE IN-
STALLED WITH AN ISOLATION WALL CONTROL/SWITCH.

a. Mounting Hardware
(1 hanger pin, 1 locking pin, 1 rubber gasket)
b. Electrical Hardware & Balancing Kit
(3 plastic wire connectors, 1 pull chain for
the fan, 1 pull chain for the light kit, blade
balancing kit)
c. Blade Attachment Hardware (15 screws)
7. Blade Bracket
8. Blades (5)
9. Light Kit Fitter
10. Glass Bowl
11. Bulb (2)
1. Mounting Plate (Inside Canopy)
2. Ball/Downrod Assembly
3. Canopy
4. Decorative Motor Collar Cover
5. Fan Motor Assembly
6. Switch Cup Cover
2. Unpacking Your Fan
IMPORTANT: THIS PRODUCT AND/OR COMPONENTS ARE COVERED
BY ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,947,436;
5,988,580; 5,971,573; 6,010,306; 6,039,541; 6,046,416 AND OTHER
PATENTS PENDING.
Unpack your fan and check the contents. You should have the following items:

Installing Your Fan 3.
Tools Required
Phillips screw driver, straight slot screw
driver, adjustable wrench, step ladder, and
wire cutters.
Mounting Options
If there isn’t an existing outlet box, then read
the following instructions. Disconnect the
power by removing fuses or turning off
circuit breakers.
Secure the outlet box directly to the building
structure. Use appropriate fasteners and
building materials. The outlet box and its
support must be able to fully support the
moving weight of the fan (at least 35 lbs.)
Do not use plastic outlet boxes.
Figures 1, 2, and 3 are examples of different
ways to mount the outlet box.
Outlet Box
Outlet Box
Note: You may need a longer downrod to
maintain proper blade clearance when install-
ing on a steep, sloped ceiling. The maximum
angle allowable is 30˚. If the canopy touches
downrod, remove the decorative canopy
bottom cover and turn the canopy 180˚ before
attaching the canopy to the mounting plate.
To hang your fan where there is an existing
xture but no ceiling joist, you may need an
installation hanger bar as shown in Figure 4
(available at your Hampton Bay retailer).
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PERSONAL INJURY, MOUNT
FAN ONLY TO AN OUTLET BOX MARKED
ACCEPTABLE FOR FAN SUPPORT AND
USE THE MOUNTING SCREWS PROVIDED
WITH THE OUTLET BOX. OUTLET BOXES
COMMONLY USED FOR THE SUPPORT OF
LIGHTING FIXTURES MAY NOT BE ACCEPT-
ABLE FOR FAN SUPPORT AND MAY NEED TO
BE REPLACED. CONSULT A QUALIFIED ELEC-
TRICIAN IF IN DOUBT.
Figure 1
Figure 2
Figure 4
Figure 3

3. Route the wires exiting the top of the fan
motor through the decorative motor collar
cover then the canopy ring. Make sure the
slot openings are on top. Route the wires
through the canopy and then through the
ball/downrod assembly (Figure 7).
4. Loosen, but do not remove, the set screws
on the collar on top of the motor housing.
5. Align the holes at the bottom of the down-
rod with holes in the collar on top of the
motor housing (Figure 7). Carefully insert
the bolt through the holes in the collar
and downrod. Be careful not to jam bolt
against the wiring inside the downrod. In-
sert locking pin through the hole near the
end of the hanger pin until it snaps into its
locked position.
6. Re-tighten the set screws on the collar on
the top of the motor housing.
7. Make sure the grommet is properly in-
stalled in the collar cover, then slide the
collar cover on the downrod until it rests
on the motor housing. Be sure that the can-
opy and the collar cover are both oriented
correctly.
8. Proceed to “Installing the Fan” section.
following instructions. Where necessary,
each section of the instructions will note the
different procedures to follow for the two
types of installation.
Standard Ceiling Mounting
1. Remove the canopy ring from the canopy
by turning the ring to the right until it un-
locks (Figure 5).
2. Remove the mounting plate from the cano-
py by loosening the four screws on the top
of the canopy. Remove the two non-slotted
screws and loosen the slotted screws. This
will enable you to remove the mounting
plate (Figure 6).
4.
Hanging the Fan
REMEMBER to turn off the pow-
er. Follow the steps below to hang your
fan properly.
NOTE: This ceiling fan is supplied with two
types of hanging assemblies; the standard
ceiling installation using the downrod with
ball and socket mounting, and the “close-to-
ceiling” mounting. The “close-to-ceiling”
mounting is recommended in rooms with
less than 8-foot ceilings or in areas where
additional space is desired from the oor
to the fan blades. When using standard
downrod installation, the distance from the
ceiling to the bottom of the fan blades will be
approximately 13 inches. The “close-to-ceiling”
installation reduces the distance from the
ceiling to the bottom of the fan blades to
approximately 8 inches.
Once you have decided which ceiling
installation you will use, proceed with the
FAILURE TO PROPERLY INSTALL LOCKING PIN
AS NOTED IN STEP 5 COULD RESULT IN FAN
LOOSENING AND POSSIBLY FALLING.
Figure 5
Turn Canopy Ring
to Remove
Figure 6
WHEN MOUNTING THE FAN ON A SLOPED
CEILING, THE STANDARD BALL/DOWNROD
MOUNTING METHOD MUST BE USED. THE
MOUNTING PLATE MUST BE MOUNTED SO
THAT THE SLOT OPENINGS ARE ON THE
LOWER SIDE BY SLIDING THE MOUNTING
PLATE FROM THE TOP DOWN. FOR A GREATER
MOUNTING ANGLE, REMOVE THE DECORA-
TIVE CANOPY BOTTOM COVER (FIGURE 8).

5.
FAILURE TO COMPLETELY TIGHTEN THE
THREE SCREWS IN STEP 7 COULD RESULT IN
FAN LOOSENING AND POSSIBLY FALLING.
“Close-to-Ceiling” Mounting
1. Remove the canopy ring from the canopy by
turning the ring to the right until it unlocks
(Figure 5).
2. Remove the mounting plate from the cano-
py by loosening the four screws on the top
of the canopy. Remove the two non-slotted
screws and loosen the slotted screws. This
will enable you to remove the mounting
plate (Figure 6).
3. Remove the decorative canopy from the
bottom cover from the canopy by depress-
ing the three studs (Figure 8).
4. Remove three of the six screws and lock-
washers (every other one) securing the mo-
tor collar to the top of the fan motor housing
(Figure 9).
5. Place the rubber gasket over the remain-
ing three screws, route the wires exiting
the top of the fan motor through the canopy
ring (make sure the slot openings are on
top), then proceed to place the ceiling can-
opy over the collar at the top of the motor
(Figure 10).
Figure 8
Canopy
Bottom
Cover
Figure 9
Figure 10
Collar
Screw and
Lockwasher
(3 Screws)
Ceiling
Canopy Canopy
Ring
Rubber
Gasket
Figure 7
6. Align the mounting holes with the holes
in the motor and fasten, using the three
screws and lockwashers removed in step 4
(Figure 10).
7. Tighten the mounting screws securely.

Installing Fan to
the Outlet Box
1. Pass the 120-volt supply wires through the
center hole in the ceiling mounting plate as
shown in Figure 7.
2. Install the ceiling mounting plate on the out-
let box by sliding the mounting plate over
the two screws provided with the outlet
box (Figure 7).When using close-to-ceiling
mounting, it is important that the mount-
ing plate be level. If necessary, use leveling
washers (not included) between the mount-
ing plate and the outlet box. Note that the
at side of the mounting plate is toward the
outlet box.
3. Securely tighten the two mounting screws.
4. Carefully lift the fan assembly up to the ceil-
ing mounting plate and hang the fan on the
hook provided by utilizing one of the holes
at the outer rim of the ceiling canopy (Fig-
ure 11). If using standard mounting, seat the
hanger ball in the mounting plate socket.
Make sure the tab on the mounting plate
socket is properly seated in the groove in
the hanger ball.
Figure 11
WHEN MOUNTING THE FAN ON A SLOPED CEIL-
ING, THE STANDARD BALL/DOWNROD MOUNT-
ING METHOD MUST BE USED. MAKE SURE THE
MOUNTING PLATE SLOTS ARE ON THE LOWER
SIDE BY SLIDING THE MOUNTING PLATE FROM
THE TOP DOWN.
THE HOOK AS SHOWN IN FIGURE 11 IS ONLY
TO BALANCE FAN WHILE ATTACHING WIRING.
FAILURE TO HANG AS SHOWN IN FIGURE 11
MAY RESULT IN HOOK BREAKING, CAUSING
THE FAN TO FALL. HOOK MUST PASS FROM
INSIDE TO OUTSIDE OF CANOPY
WHEN USING THE STANDARD BALL/DOWNROD
MOUNTING, THE TAB IN THE RING AT THE BOT-
TOM OF THE MOUNTING PLATE MUST REST IN
THE GROOVE OF THE HANGER BALL. FAILURE
TO PROPERLY SEAT THE TAB IN THE GROOVE
COULD CAUSE DAMAGE TO WIRING.
6.

Making the Electrical
Connections
REMEMBER to disconnect the power.
If you feel you do not have enough electrical
wiring knowledge or experience, have your fan
installed by a licensed electrician.
Follow the steps below to connect the fan
to your household wiring. Use the wire
connecting nuts supplied with your fan. Se-
cure the connectors with electrical tape.
Make sure there are no loose strands or
connections.
1. Connect the two green fan ground wires, lo-
cated on the downrod and mounting plate,
to the household ground wire. When using
“Close-to-Ceiling” mounting, there is only
one green ground wire from the ceiling
mounting plate since the ball/downrod as-
sembly is not used.
2. Connect the fan light supply (blue) wire to the
fan supply (black) wire to the black house-
hold supply wire as shown in gure 12.
3. Connect the neutral fan (white) wire to the
white neutral household wire.
4. After connecting the wires, spread them
apart so that the green and white wires are
on one side of the outlet box and the black
wire is on the other side.
7.
Figure 12
CHECK TO SEE THAT ALL CONNECTIONS ARE
TIGHT, INCLUDING GROUND, AND THAT NO
BARE WIRE IS VISIBLE AT THE WIRE NUTS, EX-
CEPT FOR THE GROUND WIRE.
ELECTRICAL DIAGRAMS ARE FOR REFERENCE
ONLY. OPTIONAL USE OF ANY LIGHT KIT SHALL
BE CUL LISTED AND MARKED SUITABLE FOR
USE WITH THIS FAN.
5. Turn the wire connecting nuts upward and
push the wiring into the outlet box.

8.
Finishing the Fan
Installation
STANDARD CEILING MOUNTING
1. Align the locking slots of the ceiling canopy
with the two screws in the mounting plate.
Push up to engage the slots and turn clock-
wise to lock in place. Immediately tighten
the two mounting screws rmly.
2. Install the remaining two mounting
screws into the holes in the canopy and
tighten rmly.
3. Install the decorative canopy ring by align-
ing the ring’s slots with the screws in the
canopy. Rotate the ring counter-clockwise
to lock in place.
4. You may now proceed to attaching the
fan blades.
CLOSE-TO-CEILING MOUNTING
1. Carefully unhook the fan from the mount-
ing plate and align the locking slots of the
ceiling canopy with the two screws in the
mounting plate. Push up to engage the slots
and turn clockwise to lock in place. Imme-
diately tighten the two mounting screws
rmly.
2. Install the remaining two mounting screws
into the holes in the canopy and tighten
rmly.
3. Install the decorative canopy ring by align-
ing the ring’s slots with the screws in the
canopy. Rotate the ring counter-clockwise
to lock in place
4. You may now proceed to attaching the fan
blades.
WHEN USING THE STANDARD BALL/DOWN-
ROD MOUNTING, THE TAB IN THE RING AT
THE BOTTOM OF THE MOUNTING PLATE MUST
REST IN THE GROOVE OF THE HANGER BALL.
FAILURE TO PROPERLY SEAT THE TAB IN THE
GROOVE COULD CAUSE DAMAGE TO WIRING.
LOCKING SLOTS OF CEILING CANOPY ARE
PROVIDED ONLY AS AN AID TO MOUNTING.
DO NOT LEAVE FAN ASSEMBLY UNATTENDED
UNTIL ALL FOUR CANOPY SCREWS ARE EN-
GAGED AND FIRMLY TIGHTENED.
Attaching the
Fan Blades
1. Attach blade to blade bracket using the
screws provided as shown in Figure 13.
Start a screw into the bracket. Repeat for the
two remaining screws.
2. Tighten each screw securely.
Figure 13
Figure 14
3. Fasten the blade assembly to the motor by
inserting the alignment post into the slot on
the bottom of the motor and tightening the
blade bracket screws. Please note that the
blade bracket screws are pre-attached into
the blade bracket (Figure 14).
4. Repeat steps 1-3 for the remaining blades.
