HAMPTON BAY Enchantment 149-155 User manual

Hampton Bay Lifetime Limited Warranty
The retailer warrants the fan motor to be free from defects in workmanship and material
present at time of shipment from the factory for a lifetime after the date of purchase by the
original purchaser. The retailer also warrants that all other fan parts, excluding any glass or
plexiglass blades, to be free from defects in workmanship and material at the time of
shipment from the factory for a period of one year after the date of purchase by the original
purchaser. We agree to correct such defects without charge or at our option replace with a
comparable or superior model if the product is returned to the retailer. To obtain warranty
service, you must present a copy of the receipt as proof of purchase. All costs of removing
and reinstalling the product are your responsibility. Damage to any part such as by accident
or misuse or improper installation or by affixing any accessories, is not covered by this
warranty. Because of varyingclimatic conditions inthe United States this warranty does not
cover any changesin brass finish, including rusting, pitting, corroding, tarnishing orpeeling.
Brass finishes of this type give their longest useful life when protectedfrom varying weather
conditions. A certain amount of wobble is normal and should not be considered a defect.
Servicing performed by unauthorized persons shallrender the warranty invalid. There is no
other express warranty. The retailer hereby disclaims any and all warranties,
including but not limited to. Those of merchantability and fitness for a particular
purpose to the extent permitted by law. The duration of any implied warranty which
cannot be disclaimedis limited to the time period as specified inthe express warranty. Some
states do not allow limitation on how long an implied warranty lasts, so the above limitation
may not apply to you. The retailer shall not be liable for incidental, consequential, or
special damages arising out of or in connection with product use or performance except
as may otherwise be accorded by law. Some states do not allow theexclusion of incidental
or consequential damages, so the above exclusion or limitation may not apply to you. This
warranty gives specific legal rights, and you may also have other rights which vary from
state to state. This warranty supersedes all priorwarranties.
Lifetime Limited Warranty
Date Purchased
Store Purchased
Model No.
Serial No.
Vendor No.
UPC
149-155
219032
792145352037

Safety Rules.....................................................................................................................................
Unpacking Your Fan ........................................................................................................................
Installing Your Fan ...........................................................................................................................
Installing the Light Kit....................................................................................................................
Your .............................................................................................................
Care of Your Fan ...........................................................................................................................
Troubleshooting ............................................................................................................................
Specifications ...............................................................................................................................
Operating Transmitter
1.
2.
3.
9.
10.
11.
12.
13.
Table of Contents

1. Safety Rules
1. To reduce the risk of electric shock, insure electricity has been turned
off at the circuit breakeror fuse boxbefore beginning.
2. All wiring must be in accordance with the National Electrical Code
and local electrical codes. Electrical installation should be performed
by a qualifiedlicensed electrician.
3. NOTE: Suitable for use with solid-state speed controls.
4. WARNING: To reduce the risk of fire, electric shock, or personal
injury, mount to outlet box marked "Acceptable for Fan Support
of 22.7 kg (50 lbs.) Or Less" and use mounting screws provided
with the outlet box. Most outlet boxes commonly used for the
support of light fixtures are not acceptable for fan support and may
need to be replaced. Due to the complexity of the installation of
this fan, aqualified licensed electricianis strongly recommended.
8. Avoid placing objectsin the pathof the blades.
9. To avoid personal injury or damage to the fan and other items, be
cautious when workingaround or cleaningthe fan.
10. Do not use water or detergents when cleaning thefan or fan blades. A
dry dust cloth or lightly dampened cloth will be suitable for most
cleaning.
11. After making electrical connections, spliced conductors should be
turned upward and pushed carefully up into the outlet box. The wires
should be spread apart with the grounded conductor and the
equipment-grounding conductor onone side ofthe outlet box.
12. Electrical diagrams are for reference only. Light kits that are not
packed with the fan must be UL Listed and marked suitable for use
with the model fan you are installing. Switches must be UL General
Use Switches. Refer to the Instructions packaged with the light kits
and switches forproper assembly.
WARNING
TO REDUCETHE RISK OFFIRE, ELECTRIC SHOCKOR PERSONAL
INJURY, MOUNT FAN TO OUTLET BOX MARKEDACCEPTABLE FOR
FAN SUPPORT.
5. The outlet box and support structure must be securely mounted and
capable of reliably supporting a minimum of 50 pounds. Use only UL
Listed outlet boxesmarked FOR FAN SUPPORT.
6. The fan must be mounted with a minimum of 7 feet clearance from the
trailing edge ofthe blades tothe floor.
7. Do not operate the reverse switch while the fan blades are in motion.
The fan must be turned off and the blades stopped before reversing
the blades direction.
WARNING
TO REDUCETHE RISK OFPERSONAL INJURY, DO NOTBEND THE
BLADE ARMS(ALSO REFERRED TO AS BRACKETS) DURING
ASSEMBLYOR AFTERINSTALLATION. DO NOTINSERT OBJECTS IN
THE PATHOF THE BLADES.
NOTE
READ AND SAVE ALLINSTRUCTIONS!

Unpack your fanand check the contents. You should havethe following items;
.
1. Fan blades (5)
2. Canopy assembly
3.
Coupling cover
5. Fan motor assembly
6. Blade arms(5)
7. Mounting plate
Ball/downrod assembly
4.
8. Light kitassembly
9. Glass shade
10. 4
11.
12.
14. Balancing kit
0 Watt candelabra bulbs (3)
Receiver with 6wire nuts
Transmitter+holder+2 mounting screws
+ 2 plastic plugs
13. Extra plastic plug
1
2
3
5
47
8
10
9
11
12
14
6
15. Loose partsbag containing:
a. Blade attachmenthardware
b. Mounting hardware
( 3 plasticwire connectors)
(21 screws)
ab
15
13
WARNING
DO NOT INSTALL ORUSE FAN
IF ANYPARTIS DAMAGED OR MISSING.
CALL TOLLFREE 1-877-902-5588 Unpacking Your Fan 2.

3. Installing Your Fan
Tools Required
Phillips screwdriver, straight slot
screwdriver, adjustablewrench, step ladder,
and wire cutters.
Mounting Options
Heavy duty ceiling fan rated outlet box is
required (at least 50 lbs). Donot use regular
outlet box (metalor plastic).
Figure 1,2 and 3 are examples of different
ways to mountthe outlet box. Note: You may need a longer downrod to
maintain proper blade clearance when
installing on asteep, sloped ceiling.
Heavy duty fan brace
Figure 2
Heavy duty
outlet box for fan
Heavy duty
outlet box for fan
Figure 1
Provide strong support
Recessed
outlet box
Mounting bracket
opening must be
toward the top
Figure 3
Angled ceiling
maximum
18 angle

4.
Figure 4
Hanger
bracket
Ceiling
canopy
Canopy
cover
Figure 5
Motor wires
Ball/downrod
assembly
Hanger pin
Locking pin
Collar cover
Downrod
Canopy
Canopy cover
Set screws
Hanging the Fan
REMEMBER to turn off the power. Follow the
steps below to hang your fan properly:
Step 1. Remove the decorative canopy bottom
cover from the canopy by turning the cover
counter clockwise. (Fig. 4)
Step 2. Remove the hanger bracket from the
canopy by loosening the two screws on the
bottom of the hanging bracket a half turn from
the screw head and turning the canopy counter
clockwise. (Fig. 4)
Step 3. Remove the hanger pin, lock pin and set
screws from the top of the motor assembly. (Fig. 5)
Step 4. Route wires exiting from the top of the fan
motor through the collar cover, canopy cover,
canopy and then through the ball/downrod. (Fig. 5)
Step 5. Align the holes at the bottom of the
downrod with the holes in the collar on top of the
motor housing (Fig. 5). Carefully insert the
hanger pin through the holes in the collar and
downrod. Be careful not to jam the pin against
the wiring inside the downrod. Insert the locking
pin through the hole near the end of the hanger
pin until it snaps into its locked position. (Fig. 5)
Step 6. Tighten two set screws on top of the fan
motor firmly. (Fig. 5)
Step 7. Install the hanger bracket to the outlet
box; be sure to align the holes in the hanger
bracket with the post holes in the outlet box and
secure with screws and washers provided by the
outlet box.(Fig. 6)
Step 8. Hanging the assembled fan onto the
mounting bracket, place the downrod ball into
the mounting bracket. Rotate fan until the slot
of the downrod ball locks into the hook of the
mounting bracket. (Fig. 7)
Step 9. Secure the safety cable to the building
structure. (Fig. 7)
Step 10. Connecting the wires (see making the
electrical connections)
WARNING
FAILURETO PROPERLY INSTALL LOCKING
PIN ASNOTED IN STEP5 COULD RESULT IN
FAN LOOSENINGAND POSSIBLY FALLING.

5.
Make the Electric Connections
WARNING: To avoid possible electrical
shock, be sure electricity is turned off at the
main fuse boxbefore wiring.
NOTE: This remote control unit is equipped
with 16 code combinations to prevent possible
interference from or to other remote units. The
frequency switches on your receiver and
transmitter have been preset at the factory.
Please recheck to make sure the switches on the
transmitter and the receiver are set to the same
position, any combination of settings will
operate the fan as long as the transmitter and
receiver are set to the same position. (Fig. 8)
Step 1. (Fig. 9) Insert the receiver into the
mounting bracket with the flat side of the
receiver facing theceiling.
Step 2. (Fig. 10) Motor to Receiver Electrical
Connections: Connect the black wire from
the fan to black wire marked "TO MOTOR L".
Connect the white wire from the fan to the
white wire marked "TO MOTOR N" from the
receiver. Connect the blue wire from the fan
to the blue wire marked "For Light" from the
receiver. Secure the wire connections with the
plastic wire nutsprovided.
Step 3. (Fig. 10) Receiver to House Supply
Wires Electrical Connections: Connect the
black (hot) wire from the ceiling to the black
wire marked "AC in L" from the receiver.
Connect the white (neutral) wire from the
ceiling to the white wire marked "AC in N"
from the Receiver.Secure the wireconnections
with the plasticwire nuts provided.
Step 4. (Fig. 10) If your outlet box has a
ground wire (green or bare copper) connect it
to the fanground wires; otherwiseconnect the
hanging bracket ground wire to the mounting
bracket. Secure the wire connection with a
plastic nut provided. After connecting the
wires spread them apart so that the green
and white wires are on one side of the outlet
box and black and blue wires are on the other
side. Carefully tuck the wire connections up
into the outletbox.
Note: Fan must be installed at a maximum
distance of 20 feet from the transmitting unit
for proper signal transmission between the
transmitting unit andthe fan's receivingunit.
CAUTION: Do not use with wall light
dimmer switch.
Screws provided
by the outlet box
Hook
UL Listed
electrial
box
Figure 6
AC Wires
Washers
Hanger
bracket
Posts in the
outlet box
Figure 7
Hanger
bracket Safety cable

6.
Figure 11
Outlet box
Hanger
bracket
Canopy
Canopy
cover
Screws
Finishing the Installation
Step 1. Tuck connections neatly into ceiling
outlet box.
Step 2. Slide the canopy up to ceiling and
over the 2 screws on the hanger bracket.
Rotate canopy clockwise. Next, while
holding the canopy with one hand, slide the
canopy cover over the screws and rotate
clockwise until tight.Note: adjust the canopy
screws as necessary until the canopy and
canopy cover aresnug. (Fig. 11)
WARNING
Make sure thenotch on thehanging
bracket properly sitsin the groovein the
hanger ball beforeattaching the canopyto
the bracket byturning the housinguntil it
drops into place.
Figure 10
White (neutral)
White (neutral)
Green or bare
copper (ground)
White ("AC INN")
White ("to motor N")
Ground
(green)
(Connect to
ground wire on
hanger bracket
if no house
ground wire
exists.)
Outlet box
Black (hot)
Black ("AC INL")
Black ("to motor L")
Receiver
Blue ("for light")
Blue (light)
Black (motor)
SUPPLYCIRCUIT
Fan
Figure 9
Receiver
Figure 8
Code switch
Hanger
bracket
ONON

7.
Attaching the Fan Blades
Step 1 Attach blades to blade arms using three
screws and rubber washers. Start a screw
into the arm, do not tighten. Repeat for the
2 remaining screws and washers.
Step 2 Tighten each screw securely starting with
the center screw. Make sure the blade is straight.
(Fig. 13)
blade
Repeat steps for the remaining blades.
Step 3 Fasten the blade arms to the motor by
inserting the tab from the blade arms to the slot in
the bottom motor housing, then tighten the two
screws and washers already installed in the blade
arms. (Fig. 14)
WARNING
TO REDUCE THERISK OF PERSONALINJURY,
DO NOT BENDTHE BLADEARMS WHILE
INSTALLING, BALANCINGTHE BLADES, OR
CLEANING THE FAN. DO NO INSERT FOREIGN
OBJECTS BETWEEN ROTATING FAN BLADES.
Rubber packing
mounts
Screws
Rubber
washer
Blade
arm
Figure 13
Figure 12
Blade
Screws
Figure 14
Motor
Blade arm
Slot
Tab
CAUTION: Remove 5 rubber packing
mounts from fan motor assembly and discard
before installation. (Fig. 12)

8.
Mounting plate
Mounting ring
Screws
Figure 15
Installing the Mounting
Plate
Step 1. Remove the 1 of 3 screws from the
mounting ring and loosen the other 2 screws. (Do
not remove)
Step 2. Place the key holes on the mounting plate
over the 2 screws previously loosened from the
mounting ring, turn mounting plate until it locks in
place at the narrow section of the key holes.
Secure by tightening the 2 screws previously
loosened and the one previously removed. (Fig. 15)

Glass cap
Decorative nut
Bulbs
Glass shade
Screws
Light kit
assembly
Wire connection
plugs
NOTE: Before starting installation,
disconnect the power by turning off the
circuit breaker or removing the fuse at fuse
box.
Turning power off using the fan switch is
not sufficient to prevent electric shock.
1.
2. Carefully push all wires back into the
switch housing, then install the light kit
assembly onto the mounting plate with 4
screws provided. Be sure to tighten all
screws. (Fig. 16)
3. Install 3 x 40W (Max.) bulbs
(included). (Fig. 16)
4. Place glass shade over the light kit and
secure it with the glass cap and
decorative nut provided. DO NOT
OVER TIGHTEN. (Fig. 16)
5. Restore power and your light kit is ready
for operation.
While holding the light kit assembly under
your fan, snap together the wire connection
plugs .
candelabra
Figure 16
9. Installing the Light Kit
NOTE: Light bulbs have no warranty;
can be purchased at any Home Depot
store.
Fan without Light Kit
(Optional)
Disassemble the switch housing from the
light kit , you can keep the light kit for
future use.
2. Attach the plastic plug to the switch
housing. (Fig. 17)
H switch housing
Install the switch housing to the mounting
plate with screws provided. (Fig. 17)
1.
3. olding the under your fan,
snap together the wire connection plugs .
4.
Figure17
Screws
Wire connection
plugs
Mounting plate
Switch
housing
Plug

Operating Your Transmitter 10.
Speed settings for warm or cool weather
depend on factors such as the room size,
ceiling height, numberof fans, etc.
The Reverse switch is located on the switch
housing. Slide the switch to the Left for
warm weather operation. Slide the switch to
the Right forcool weather operation.
NOTE: Wait for fan to stop before changing
the setting ofthe slide switch.
Warm weather-(Counter-Clockwise
direction) A downward air flow creates a
cooling effect.(Fig. 20) This allows you to
set your air conditioner on a higher setting
without affecting your comfort.
Cool weather-(Clockwise direction) An
upward airflow moves warm air off the
ceiling area.(Fig. 21) This allows you to set
your heating unit on a lower setting without
affecting your comfort.
Restore power to the ceiling fan and test
for proper operation.
1. "HI, MED, LOW"buttons:
These three buttons are used to set the fan
speed as follows:
LOW=Low speed MED= Medium speed
HI=High speed
2. "OFF" button:
This button turnsthe fan off.
3.The " " button turns the light ON or OFF
and also controls the brightness setting.
Press and release the button to turn the light
ON or OFF. Press and hold the button to set
the desired brightness. The light key has an
auto-resume, it will stay at the same
brightness as thelast time itwas turned off.
Figure19
Installing the battery:
Install 12V MN21/A23 battery (not
included), to prevent damage to
transmitter, remove the battery if not used
for long periods.
Figure 18

11. Care of Your Fan
Figure 20
Figure 21
Here are some suggestions to help you maintain
your fan
1.Because of the fan's natural movement, some
connections may become loose. Check the
support connections, brackets, and blade
attachments twice a year. Make sure they are
secure. (It is not necessary to remove fan from
ceiling.)
2. Clean your fan periodically to help maintain
its new appearance over the years. Use only a
soft brush or lint-free cloth to avoid scratching
the finish. The plating is sealed with a lacquer to
minimize discoloration or tarnishing. Do not use
water when cleaning. This could damage the
motor, or the wood, or possibly cause an
electrical shock.
3. You can apply a light coat of furniture polish
to the wood blades for additional protection and
enhanced beauty. Cover small scratches with a
light application ofshoe polish.
4. There is no need to oil your fan. The motor
has permanently lubricatedbearings.
IMPORTANT
MAKE SURE THE POWER ISOFF AT
THE ELECTRICALPANELBOX
BEFORE YOU ATTEMPT ANY
REPAIRS. REFER TO THE SECTION
"MAKING ELECTRICAL
Figure 22
Touching
ceiling

Troubleshooting 12.
Problem
Fan will notstart.
Fan sounds noisy.
Fan wobble.
Remote control
malfunction:
Solution
1. Check circuitfuses or breakers.
2. Check linewire connections tothe fan and switch wire connectionsin the switchhousing.
CAUTION: Make suremain power isoff.
3. Check tomake sure thedip switches from the transmitter andreceiver are setto the samefrequency.
1. Make sureall motor housingscrews are snug.
2. Make surethe screws thatattach the fan blade bracket tothe motor hubis tight.
3. Make surewire nut connectionsare not rubbing against each otheror the interiorwall of theswitch housing.
CAUTION: Make suremain power isoff.
4. Allowa 24-hour "breaking-in"period. Most noise associated with a new fan disappearduring this time.
5. If using an optional light kit, make sure the screws securing the glassware are tight. Check that light bulb is also
secure.
6.
7. Make surethe upper canopyis a short distance from theceiling. It should not touch the ceiling.
the
Do not connectthe fan witha wall mountedvariable speed control (s)
1. Do notconnect the fanwith a wall mounted variable speed control(s).
2. Make surethe dip switchesare set correctly.
1. Check thatall blade andblade arm screws are secure.
2. Most fan wobbling problems are caused when blade levels are unequal. Check this level by selecting a point on the
ceiling above the tip of one of the blades. Measure this distance.(Fig. 22) Rotate the fan until the next blade is
positioned for measurement.Repeat for eachblade. The distance deviation should be equal within 1/8".
3. Use theenclosed Blade BalancingKit if the blade wobble isstill noticeable.
4. If the blade wobble is still noticeable, interchanging two adjacent (side by side) blades can redistribute the weight
and possibly resultin smoother operation.
WARNING: TO REDUCE THE RISK OF PERSONALINJURY, DO NOT BEND THE BLADE ARM WHILE INSTALLING, BALANCING
THE BLADES, ORCLEANING THE FAN. DO NOTINSERT FOREIGNOBJECTS BETWEEN ROTATING FAN BLADES.

These are approximatemeasures. They do not include Amps andWattageused by the light kit.
RPM CFM N.W. G.W.
C.F.
68"
120 4.04'16.7
kgs
19.3
kgs
0.48
0.66
0.70
27
58
82
63
100
125
2936
5015
7227
120
120
Fan Size Speed Volts Amps Watts
Low
Medium
High
13. Specifications
Distributed by
Your Other Warehouse, LLC
12100 Little Cayman Dr.
Baton Rouge, LA 70809
