HAMPTON BAY SW18030 WH User manual

CLARKSTON 44 INCH CEILING FAN
USE AND CARE GUIDE
1-877-527-0313
Item #XXXXXX
Model #SW18030 WH
HOMEDEPOT.COM

2
Installation .....................................................................
Table of Contents ..........................................................2
Safety Information .........................................................2
Warranty .........................................................................3
Pre-installation ..............................................................
Specifications ..........................................................................
Tools Required .........................................................................
Hardware Included ..................................................................
Package Contents ...................................................................
3
3
3
4
5
6
Assembly .......................................................................
Hanging the Fan ....................................................................
Attaching the Fan Blades ......................................................
Installing the Light Kit ...........................................................
7
7
10
10
Operation ......................................................................11
Care and Cleaning .......................................................12
Troubleshooting .......................................................... 12
Service Parts ............................................................... 13
Table of Contents

3HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
SPECIFICATIONS
TOOLS REQUIRED
Phillips
screwdriver
Electrical
Tape
Wire
stripper
Flat blade
screwdriver
Step
ladder
NOTE: These are approximate measures. They do not
include amps and wattage used by the light kit.
Warranty
Pre-InstallationPre-Installation
We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period
of 15 years after the date of purchase by the original purchaser. We also warrant that all other fan parts, excluding any glass or acrylic
blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of one year after the
date of purchase by the original purchaser. We agree to correct such defects without charge or at our option replace with a comparable or
superior model if the product is returned. To obtain warranty service, you must present a copy of the receipt as proof of purchase. All
costs of removing and reinstalling the product are your responsibility. Damage to any part such as by accident, misuse, improper installa-
tion or by affixing any accessories, is not covered by this warranty. Because of varying climatic conditions this warranty does not cover
any changes in brass finish, including rusting, pitting, corroding, tarnishing or peeling. Brass finishes of this type give their longest useful
life when protected from varying weather conditions. A certain amount of “wobble” is normal and should not be considered a defect.
Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. We hereby disclaim
any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by
law. The duration of any implied warranty which cannot be disclaimed is limited to the time period as specified in the express warranty.
Some states do not allow limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The retailer shall
not be liable for incidental, consequential, or special damages arising out of or in connection with product use or performance except as
may otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential damages, so the above
exclusion or limitation may not apply to you. This warranty gives specific legal rights, and you may also have other rights which vary from
state to state. This warranty supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty
must be paid by the customer.
Contact the Customer Service Team at 1-877-527-0313 or visit WWW.HOMEDEPOT.COM.
44 in.(1.12 m)
Low
Medium
High
120
Fan size WattsRPM CFMSpeed VoltsAmps
2.04 ft.
N.W. G.W. C.F.
0.23
0.32
0.41
15.62
30.15
48.52
103
144
184
1320
1978
2572
6.84 kgs
(15.05 lbs)
7.99 kgs
(17.58 lbs)

4
Pre-Installation (continued)
HARDWARE INCLUDED
AA
BB
CC
DD
EE
FF
GG
Blade screw
Fiber washer
Blade bracket screw
Plastic wire nut
Fan pull chain fob
Light kit pull chain fob
Mounting plate screw ( pre-assembled)
PartDescription
15 + 1 spare
15 + 1 spare
10 + 1 spare
3
1
1
4
Quantity
NOTE: Hardware shown to actual size unless noted
otherwise in the table below.
AA
GG
EE
FF
BB
CC
DD
HH
II
Fan housing screw (pre-assembled)
Switch house cover screw (pre-assembled)
4
3
JJ Glass holder screw (pre-assembled) 9
HH
II
JJ

HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
5
PACKAGE CONTENTS
G
H
I
Fan housing
Light kit assembly
Glass shade
DMounting plate (assembled with fan motor assembly) 1
Pre-Installation (continued)
Part
A
B
C
Quantity
5
5
1
1
1
3
Description
Blade
Blade bracket
Mounting bracket
E
G
H
I
B
A
C
D
F
J
EFan motor assembly 1
J9W A19 LED Bulb 3
FSwitch house cover (pre-assembled) 1

6
To hang your fan where there is an existing fixturebutnoceiling
joist, you mayneed an installation hanger bar (2) (not included)
as shown above.
If your ceiling fan doesnot have an existing UL-listed mounting
box, then install one using the following instructions:
□ Disconnect the power by removing the fuses or turning off
the circuit breakers.
□ Secure the outlet box (1) (not included) directly to the
building structure. Use appropriate fastenersand materials
(not included). Theoutletbox and itsbracing must be able
to fullysupport the weightofthemoving fan (atleast 35
lbs.). Do not use aplastic outlet box.
The illustrations below showtwo different ways to mount the
outletbox(not included).
WARNING: To reduce the risk of fire, electric shock, or
personal injury, mount the fan to an outlet box marked
acceptable for fan support using the screws provided with the
outlet box. An outlet box commonly used for the support of
lighting fixtures may not be acceptable for fan support and
may need to be replaced. If in doubt, consult a qualified
electrician.
Installation
MOUNTING OPTIONS
2
1
1
1

HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
7
Assembly — Hanging the Fan
1Installing the mounting bracket to
the electrical box
Hanging the fan to the
mounting bracket
□Attach the mounting bracket (C) to the outlet box with
two screws and washers provided with the outlet box.
Make sure the mounting bracket (C) is tight and
secured.
WARNING: To reduce the risk of fire, electric shock or
other personal injury, mount the fan only to an outlet box or
supporting system marked acceptable for fan support and
use the mounting screws provided with the outlet box.
□Lift the fan into position by hanging the mounting plate (D)
portion of the fan motor assembly (E) onto the hook from
the ceiling mounting bracket (C) allowing it to hang freely.
C
C
D
E
2

3
Assembly — Hanging the Fan (continued)
8
C
E
D
connect the ground wire from the mounting plate (D)
to the ground wire from the mounting bracket (C)

HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
WARNING: Ensure you complete this step correctly and
follow all steps. Failure to correctly follow this step might
cause the fan to fall.
9
□Remove one of the four screws (GG) on the mounting
bracket (C) and loosen, but do not remove, the other
three screws (GG).
□Remove the motor assembly (E) from the J hook.
□Lift and place the key holes (1) on the mounting plate
(D) over the three screws (GG) previously loosened on the
mounting bracket (C) and turn the mounting plate (D)
until it locks in place and no longer turns.
□Secure by tightening the three screws (GG) previously
loosened and the screw (GG) previously removed.
Assembly — Hanging the Fan (continued)
4Finishing the fan installation
5
Attaching the fan motor assembly
to the mounting bracket
□Align the four large screwheads (HH) pre-locked on the fan
housing (G) to the key holes (1) of the mounting bracket (C).
□Turn the fan housing (G) at the right side and twist the
screwheads (HH) to the end of the slotted holes (2) until they
lock in place and no longer turn.
C
C
HH
G
1
2
1
D
GG
E

10
Assembly — Attaching the Fan Blades
6Fastening the blade
assemblies to the motor
□Attach the fan blades (A) to the blade bracket (B) using
the blade screws (AA) and fiber washers (BB). Tighten
the screws (AA) and fiber washer (BB) securely.
□Fasten the blade bracket (B) to fan motor assembly (E)
by using the blade bracket screws (CC). Tighten the
screws (CC) securely.
□Repeat this procedure with the remaining blade
assemblies.
Assembly — Installing the Light Kit
□Disassemble the switch house cover (F) by removing the three
screws (II) from the switch house of fan motor assembly (E).
While holding the light kit assembly (H) under your fan, snap the
white connection plug from fan motor assembly (E) to the white
connection plug from light kit assembly (H). Snap the black
connection plug from motor assembly (E) to the black connection
plug from light kit plate (H).
Carefully push all wires back into the switch house of fan motor
assembly (E), then install the light kit assembly (H) onto the switch
house with the three screws (II) removed previously and securely
tighten all screws.
To install the glass shade (I), loosen the glass holder screws (JJ)
and install the glass shade (I) to the light kit assembly (H). Secure
by tightening the glass holder screws (JJ) previously loosened.
Install 3*9W A19 LED bulbs (J) (included).
7Finishing the light kit assembly
and glass shades mounting
□
□
□
I
J
JJ
JJ
H
Black White
E
II
E
II
F
E
AA
BB
CC
B
□

HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
11
Operation
NOTE: Wait for the fan to stop before reversing the direction
of the blade rotation.
Reverse function
The reverse switch (LL) is located on the surface of fan motor
assembly (E): forward (switch down) or reverse (switch up).
Attach the fan pull chain fob (EE) to the chain on the switch house of
fan motor assembly (E), and attach the light kit pull chain fob (FF) to the
chain on the light kit assembly (H).
Turn on power and check the operation of your fan.
The fan pull chain controls the fan speed as follows:
1 pull-High, 2 pulls-Medium, 3 pulls-Low and 4 pulls-Off.
The light kit pull chain turns the light "ON" or "OFF".
Warm weather - (Counterclockwise Direction) A downward air flow
creates a cooling effect. This allows you to set your air conditioner
on a higher setting without affecting your comfort.
Cool weather - (Clockwise Direction) An upward air flow moves
warm air off the ceiling. This allows you to set your heating unit on
a lower setting without affecting your comfort.
□
□
E
FF
EE
LL
H

12
Care and Cleaning
□Check the support connections, brackets, and blade attachments
twice a year. Ensure they are secure. Because of the fan’s natural
movement, some connections may become loose over time. It is not
necessary to remove the fan from the ceiling.
□Clean your fan periodically. Use only a soft brush or
lint-free cloth to avoid scratching the finish. The plating is
sealed with a lacquer to minimize discoloration or
tarnishing.
□(Optional) Apply a light coat of furniture polish to the wood blades.
□(Optional) Cover small scratches with a light application of shoe polish.
Do
□Do not use water when cleaning. Water could damage the
motor, or the wood, or possibly cause an electrical shock.
□Do not apply oil to your fan or motor. The motor has
permanently-lubricated sealed ball bearings.
Do not
□
□
□
Check that all blade and blade arm screws are secure.
Most fan wobble problems are caused when blade levels are unequal. Check this level by selecting a
point on the ceiling above the tip of one of the blades. Measure from a point on the center of each blade
to the point on the ceiling. Rotate the fan until the next blade is positioned for measurement. Repeat for
each blade. Measurements deviation should be within 1/8 in. Run the fan for 10 minutes.
Use the enclosed blade balancing kit if the blade wobble is still noticeable.
The fan wobbles.
Troubleshooting
Problem Solution
□Check the main and branch circuit fuses or breakers.
□Check the line wire connections to the fan and switch wire connections in the switch housing.
□Check to ensure the dip switches from the remote control and receiver are set to the same
frequency.
□Ensure all motor housing screws are snug.
□Ensure the screws that attach the fan blade arm to the motor hub are tight.
□Ensure wire nut connections are not rattling against each other or the interior wall of the switch
housing.
□Allow a 24-hour "breaking-in" period. Most noises associated with a new fan disappear during this
time.
□If using the ceiling light kit, ensure the screws securing the glassware are tight. Check that the light
bulb is also secure.
□Ensure there is a short distance from the ceiling to the canopy. It should not touch the ceiling.
□Ensure your ceiling box is secure and rubber isolator pads are used between the mounting bracket
and outlet box.
The fan will not start.
The fan sounds noisy.
WARNING: Ensure the power is off at the electrical
panel box before you attempt any repairs. Refer to the section
“Making the Electrical Connections” on page 8.

HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
31
Service Parts
AA
BB
CC
DD
EE
GG
FF
HH
II
JJ
B
A
C
E
G
D
F
H
I
J
AA
BB
CC
DD
EE
FF
GG
Blade screw
Fiber washer
Blade bracket screw
Plastic wire nut
Fan pull chain fob
Light kit pull chain fob
Mounting plate screw
PartDescription
HH
II
Fan housing screw
Switch house cover screw
JJ Glass holder screw
G
H
I
Fan housing
Light kit assembly
Glass shade
DMounting plate
Part
A
B
C
Description
Blade
Blade bracket
Mounting bracket
EFan motor assembly
J9W A19 LED Bulb
FSwitch house cover

Retain this manual for future use.
1-877-527-0313
HOMEDEPOT.COM
