HAMPTON BAY 3022-CM4-SW User manual

USE AND CARE GUIDE
WHITFIELD 2PC ALL MOTION CHAIRS
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item # xxxxxxxxxx
Model # 3022-CM4-SW

2
Table of Contents
Safety Informa tion
PRODUCT CAUTION
SAFETY WARNINGS
WARNING: Weight limit for the chairs is 250 lbs
(113.39 kg) for each seat.
WARNING: This swivel chair unit is heavy, and may
require two adults for safe assembly.
WARNING: Do not place heavy objects on the chair.
CAUTION: Do not locate the product near any
heat source.
Table of Contents .......................................................... 2
Safety Inf ormation ....................................................... 2
Product Caution .............................................................. 2
Safety Warnings .............................................................. 2
Warranty ......................................................................... 3
What is Covered ............................................................... 3
What is Not Covered ......................................................... 3
Pre-Assembly ................................................................. 3
Planning Assembly ............................................................. 3
Hardware Included ............................................................. 3
Package Contents............................................................... 4
Assembly.......................................................................... 5
Care and Cleaning........................................................... 7
Warranty
1 YEAR FRAME WAR RANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for one years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
This chair was made for the explicit purpose of providing outdoor functions and is not to be used as a toy. This product is intended for
normal outdoor use; however, the manufacturer recommends storing and / or covering this chair when any formidable / severe weather is
approaching. Do not locate the product near open flames. Do not use the oduct as a support. Do not shake, lean or climb on the product.
Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is NOT intended for
commercial use and will void the warranty.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit HAMPTONBAY.COM
CAUTION: When not in use, secure the product in a
cool and covered location.

3
AA
BB
CC
DD
EE
FF
Long bolt 4
4
8
8
8
1
Nut
Rectangle gasket
Bolt cover
Wrench
Round gasket
Part Description Quantity
Pre-Assembly
PLANNING ASSEMBLY
HARDWARE INCLUDED
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
NOTE: Hardware not shown to actual size.
AA BB CC
DD EE FF

4
Pre-Assembly (continued)
PACKAGE CONTENTS
A B
C D
A
B
C
D
Chair frame 2
2
2
2
Back cushion
Base
Seat cushion
Part Description Quantity

5
Assembly
1Attaching the table legs to the table top
Place the chair frame (A) on a flat, solid surface.
Set the swivel base (B) on the chair frame (A). Guide two long bolts (AA) through the holes in the U bar,
and through the holes in the rocker plate, place the metal plate(BB), add a spring (CC) and a nut (DD)
to the bottom of each bolt(AA), Hand tighten the nuts (DD) 3-4 revolutions only.
Repeat the same procedure on the other side of the rocker assembly.
Fully tighten all bolts including screws preassembled by factory. Cover all bolts with bolt covers (EE).
B
EE
DD
CC
BB
AA
Rocker plate
U bar
A

6
Assembly (continued)
3Tightening the bolts
Once all of the bolts are in place, fully tighten the bolts.
Turn the table right side up.
Ensure all connections are secure before use.
Put the umbrella ring cover (D) into the table top (A).
Ensure the table is tightly assembled and stable before use.
B
C
A
D

7
Care and Maintenance
Maintenance
FRAME:
Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. To thoroughly drain
the frames, remove the caps and tilt the frames, if necessary, to remove all water. This is critical. Water allowed to
accumulate inside the frames and then exposed to sub-freezing temperatures can cause damage to the frame tubing.
Such damage is not covered under the warranty. Always clean, drain, and dry thoroughly before storing for the winter.
For best results, always store or cover your furniture when not in use.
FABRIC (CUSHIONS/SLINGS):
The best way to maintain the beauty of cushions and slings is to store them in a dry area and out of the elements
when not in use or cover with commercially available outdoor furniture covers.
Care and Cleaning
FRAME:
Use mild soap and warm water. Do not use abrasive materials, cleansers, or bleach products. Rinse with clean
water and dry thoroughly.
FABRIC (CUSHIONS/SLINGS):
Wipe minor spills immediately. Clean with mild soap, warm clean water, and a soft cloth. Do not use abrasive
materials, cleansers, or bleach products. Although fabric has been treated to resist stains, occasional use of
commercially available fabric cleaners may be necessary.
Troubleshooting
If your chair is not rocking properly, double-check your assembly procedure.
Care and Maintenance (continued)

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Retain this manual for future use.
1-855-HD-HAMPTON
HAMPTONBAY.COM
For certification use only
Factory Model ID: 3022-CM4-SW
