HAMPTON BAY CHAT SET FRS60704R-ST User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive to continually
create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
COASTAL WOOD LOOK MIXED MATERIAL 5PC CHAT SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
Item # 0000 000 000
Model # FRS60704R-ST

2
Table of Contents
Table of Contents................................... . 2
Important Safety Instructions.......................... 2
What is covered ...................................3
What is not covered ................................3
Warranty ................................... . . . . . . . 3
Pre-Assembly..................................... . . 3
Planning Assembly ............................... . . 3
Hardware Included ............................... . . 4
Chair Package Contents . . . . . ........ . . . . . . . . . . . . . . . . 4
Table Package Contents . ............ . . . . . . . . . . . . . . . . 5
Table Assembly ................................... . 9
Care and Cleaning ................................. . 10
Chair Assembly. . . . . . ...................... . . . . . . . . . .
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS SET IS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR FUNCTIONS AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE; HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while it is occupied. Failure
to obey this caution could result in injury.
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE AND WILL VOID THE WARRANTY.
WARNING: This chair/ table unit is heavy, and
may require two adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the chair
or table.
WARNING: Weight limit for the chair is 250lbs
(113.39Kg) for each seat.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
Save These Instructions .............................2
Read All Instructions Before Use.......................2
6

Warranty
2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for
the fabric.
WHAT IS NOT COVERED
Its remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HOMEDEPOT.ca.
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to assemble this product.
3 HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.

CHAIR PACKAGE CONTENTS
Pre-Assembly (continued)
4
Right Arm
Left Arm
4
4
A
B
Seat 4 C
Back 4 D
Back Cushion
4
E
Seat Cushion
4
F
Part Description Quantity
F
G
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
M6x15 Combination Bolt 52+1
16+1
AA
BB
M8x20 Combination Hex Bolt
Part Description Quantity
2 CC Hex Wrench
1 DD Wrench
AA BB CC DD
AB
C
D
E
Leg
G
4

TABLE PACKAGE CONTENTS
Pre-Assembly (continued)
Table Top 1
1
I
J
Table Leg
Part Description Quantity
4
H
Leg Connector
5HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
H
I
J

Chair Assembly
1Attaching The Chair Seat To The Chair Back
2Attaching The Left Arm To The Chair Seat And Chair Back
Place the chair bucket (D) upside down on a soft surface.
Attach the chair seat (C) to the chair back (D) using M6x15 combination bolts (AA).
NOTE: Loosely tighten all the bolts using the hex wrench (CC).
NOTE: Loosely tighten all the bolts using the hex wrench (CC).
Attach the left arm (B) to the chair seat (C) and chair back (D) using M6x15 combination bolts (AA).
6
AA AA
C
D
AA
AA AA
C
D
B

Chair Assembly (continued)
3Attaching The Right Arm To The Chair Seat And Chair Back
4Attaching The Leg To The Chair Seat
NOTE: Loosely tighten all the bolts using the hex wrench (CC).
Attach the right arm (A) to the chair seat (C) and chair back (D) using M6x15 combination bolts (AA).
Attach the leg (E) to the chair seat (C) using M8x20 combination hex bolts (BB).
7HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
AA AA
AA
C
D
A
NOTE: Loosely tighten all the bolts using the wrench (DD).
C
E
BB BB

Chair Assembly (continued)
8
5Tightening All Bolts
Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (CC) and the wrench (DD).
Put the back cushion (F) and seat cushion (G) on the chair.
Ensure all connections are secure before use.
F
G

Table Assembly
1Connecting The Upper Leg To The Table Top
2Connecting The Leg Connector To The Table Leg
Place the table top (H) upside down on a soft surface.
Attach the table legs (J) and the table top (H) using M6x15 combination bolts (AA).
NOTE: Loosely tighten all the bolts using the hex wrench (CC).
NOTE: Loosely tighten all the bolts using the hex wrench (CC).
Connect the leg connector (I) to the table legs (J) using M6x15 combination bolts (AA).
9HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
AA
AA
H
J
J
I
AA

Table Assembly (continued)
3Tightening The Bolts
Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (CC).
Turn the table right side up.
Ensure that all connections are secure.
Care Care and Cleaning
For best results, clean the frame and cushions with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrrasive materials, bleach or solvents.
Store the set in a dry sheltered place when not in use.
Keep the set out of fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
10

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
Retain this manual for future use.
For certification use only
Factory Chair ID# FRS60704R
Factory Table ID# FTS61203
