HAMPTON BAY GFM00469A User manual

THANK YOU
We appreciate the trust and confidence you have p laced in Hampton Bay through the purchase of this gazebo. We strive to continually create.
.sdeentnemevorpmiemohruoyrofelbaliavastcudorpfoenilllufruoeesotenilnosutisiV.emohruoyecnahneotdengisedstcudorpytilauq
Thank you for choosing Hampton Bay!
Model # GFM00469A
USE AND CARE GUIDE
ARCHED GAZEBO
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 5 p.m., PST, Monday - Friday
1-866-988-3300
HAMPTONBAY.COM

2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Warranty
1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame and fabric to be freeof manufacturing defects to the original purchaser for one year.
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-866-988-3300 or visit www.HamptonBay.com.
Safety Information
PRODUCT CAUTION
This gazebo was made for the explicit purpose of providing outdoor functions and isnottobe used as a toy. This productis intended for
normal outdoor use; however, the manufacturer recommends storing and / or covering thisgazebo when any formidable/ severe weather is
he product.
Children under the age of 10 near thisproduct, should be supervised by acompetent adult at all times. Thisproduct isNOTintended for
commercial useand will void the warranty.
SAFETY WARNINGS
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty. We
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Ass ..........ylbme ............................................................. 5
Package Cont stne ....................................................................
4
Safety Information .......................................................2
Product Caution .................................................................... 2
WARNING: Please keep children out of the assembly area
before assembly. CAUTION: Do notlocate theproduct near any heat source.
CAUTION: When not in use, securetheproduct in a
!
!
Safety Warnings ..................................................................... 2
Care and Cleaning............................ .... .. ......................
14
cool and covered location.
WARNING: This gazebo unit is heavy, and may require two
adults for safe assembly.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
Part
Description
Quantity
AA M6x15 bolt
BB M6x18 countersunkbolt 8+1
49+1
HARDWARE INCLUDED
HAMPTONBAY.COM
CC M6x35 bolt 1+4
DD
M6x75 bolt 1+62
NOTE: Hardware not shown to actual size.
EE
Washer 1+97
AA BB CC DD EE
FF GG
FF
Ground spike 1+61
GG
Hex wrench 2
Please contact 1-866-988-3300 for further assistance.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part
Description
Quantity
A
Right connector bar
2
B
Left connector bar
2
Lengthways bar
4
Side top bar
2
Center lengthways bar
1
Part
Description
Quantity
I
Protective cover
1
J
Fabric shade
1
K
Magnet iron plate
1
L
End tip
4
C
D
E
E1 Center fabric hanger 4
Short shade rod 2
Long shade rod 4
Post 4
F
G
H
L1
Side fabric hanger 8
Q
Center tip 2
R
Post base plate 4
S
Inner tip 8
H
A
B
A
B
C
D
E
F
G
I
J
K
L
SQ
R
F

1
l
5
Assembly
Attach the back right connector bar (A) to the back left connector bar (B) with the magnet iron plate (K) using M6x15 bolts (AA)
and washers (EE).
Connecting the back connector bar with the magnet iron plate
NOTE: Loosely tighten all bolts using the hex wrench (GG).
A
B
B
A
AA
A
B
K
AA AA
EE
EE
EE
K
HAMPTONBAY.COM
Please contact 1-866-988-3300 for further assistance.

2
l
6
Assembly (continued)
Connecting the front connector bar
Attach the front right connector bar (A) to the front left connector bar (B) using M6x15 bolts (AA) and washers (EE).
NOTE: Loosely tighten all bolts using the hex wrench (GG).
A
B
B
A
AA
AA
EE
EE

3
l
7
Assembly (continued)
Attaching the crossbar
Insert the inner tips (S) into the lengthways bars (C), the center tips (Q) into the center lengthways bar (E) and the end tips (L)
into the side top bars (D).
Attach the center lengthways bar (E) to the center of the front connector bars (A and B) and the back connector bars (A and B)
using M6x75 bolts (DD), M6x15 bolts (AA), and washers (EE).
Attach the lengthways bars (C) and the side top bars (D) to the front connector bars (A and B) and back connector bars (A and B)
using M6x15 bolts (AA), M6x75 bolts (DD), and washers (EE).
S
C
Q
E
D
D
C
C
E
L
L
S
S
S
S
Q
Q
A
B
B
A
L
D
L
L
Q
EE
DD
AA
EE
DD
EE
EE
DD
EE
AA
DD
EE
EE AA
A&B
A&B
E
A
B
A
B
K
HAMPTONBAY.COM
Please contact 1-866-988-3300 for further assistance.

4
l
8
Attach the post base plates (R) to the posts (H) using M6x15 bolts (AA) and washers (EE).
Attaching the post base plates to the posts
Assembly (continued)
NOTE: Loosely tighten all bolts using the hex wrench (GG).
H
R
HR
AA
EE

5
l
9
Assembly (continued)
Attaching the posts to the assembled structure
Attach the posts (H) to the assembled structure using M6x15 bolts (AA), M6x75 bolts (DD), and washers (EE).
NOTE: Loosely tighten all boltsusing thehexwrench (GG).
H
H
H
H
H
D
D
D
L
BA
DD
EE
EE
AA
AB
A&B
HAMPTONBAY.COM
Please contact 1-866-988-3300 for further assistance.

6
l
10
Insert the short shade rods (F) into the remaining slots of the fabric shade (J).
Inserting the short shade rods into the fabric shade
Assembly (continued)
J
F
F

7
l
11
Assembly (continued)
Attaching the short shade rods
Attach the four ends of the short shade rod (F) to the connector bars (A and B) using M6x35 bolts (CC) and washers (EE).
NOTE: Loosely tighten all bolts using the hexwrench (GG).
A
F
F
E
F
A
3-1
3-2
B
F3-3
CC
EE
CC
EE
CC
J
B
CC
EE
EE
HAMPTONBAY.COM
Please contact 1-866-988-3300 for further assistance.

8
l
12
Assembly (continued)
Connecting the long shade rods
Insert the long shade rods (G) into the side fabric hangers (L1) on the side top bar (D), the slot at the end of the fabric shades (J),
through the center fabric hangers (E1), into the remaining slots of the fabric shades (J) and attach to the side fabric hangers on the
other side top bar (D) using M6x18 countersunk bolts (BB). Fully tighten M6x18 countersunk bolts using the hex wrench (GG).
NOTE: Loosely tighten all bolts using the hex wrench (GG).
D
G
G
J
4-3
BB
J4-1
GJE
GJ
4-2
G
D
G
J4-4
BB
G
G
BB
BB
BB
BB
BB
GG

9
l
13
Assembly (continued)
Installing the protective cover and the ground spikes
Attach the protective cover (I) to the side top bars (D) and the center lengthways bar (E) using M6x15 bolts (AA) and washers (EE).
Insert the ground spikes (FF) through the post base plates (R) and into the ground.
NOTE: Loosely tighten all boltsusing thehexwrench (GG).
E
I
H
R
I
D
I
FF
AA
EE
AA
EE
FF
FF
FF
HAMPTONBAY.COM
Please contact 1-866-988-3300 for further assistance.

10
l
14
Ensure all connections are secure before use.
Completing the assembly
Assembly (continued)
Care and Cleaning
For best results, cleanthe gazebo with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the gazebo in a dry, sheltered place when notin use.
Keep the gazebo away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 5 p.m., PST, Monday- Friday,
1-866-988-3300
HAMPTONBAY.COM
Retain this manual for future use.
