Hand Held Products’ Quick Check®Model QCOLV-
SV100 Verifier is a universal system component that
can analyze linear bar code print quality, check
encoded data, and detect system failures. In its
basic mode of operation, the QCOLV-SV100 per-
forms bar code verification and operates in various
synchronous modes.
The QCOLV-SV100 combines state-of-the-art digital
signal processor (DSP) technology, a proprietary
high-speed moving beam laser scanner with unique
analog output capability, and flexible I/O and commu-
nications capability. This powerful architecture
enables the unit to be an economical Quality
Assurance tool for practically any bar code printing,
application, or conveyance system.
The QCOLV-SV100 performs most accepted
methods of bar code verification: ANSI method,
traditional method, encoded data format checks, and
laser scanning type analyses. These wide ranging
analysis parameters can be used to measure bar
code quality and detect failure mechanisms for any
print technology. Bar code quality and encoded data
information can be reported through the serial
communications port for each code analyzed;
therefore, accountability for all printed bar codes is
possible. The QCOLV-SV100 I/O consists of five
programmable output ports, two programmable
display LEDs, and a sync input. The programmable
ports allow the unit to be used as a controller for
pausing printers, activating lights, and gating
conveyors.
The recommended setup tool for the QCOLV-SV100
is Hand Held Products’ QC ScanView, Windows®-
based software. This program simplifies setup via
menus, and offers real time monitoring of bar codes
being analyzed. QC ScanView programs the
QCOLV-SV100 via serial communication using a PC
download language (described in the User’s Guide,
part #QCOLVSV/UG).
Quick Check®On-Line
SV Series Verifiers
State-of-the Art Digital Signal Processor (DSP) Technology -
Ensures higher processing speed, faster printers, and more
analysis per symbol.
ANSI, Traditional, Encoded Data Format, and Laser Scanning
Methods - Provide reflectance, dimensional, and format
measurements.
QC ScanView Windows®-based Software for System
Operation - Programmable and serial port outputs assist in
setup.
Flexible Optical Configurations - More adaptable optics read
higher density and low contrast symbols.
Datamatch Compatibility - Secures encoded data
equivalence.
Features

Worldwide Offices
Offices Serving North America
Skaneateles Falls, NY
Tel: [phone]
or, in North America: [phone]
napresal[email protected]om
Charlotte, NC
Tel: [phone]
or, in North America: [phone]
napresal[email protected]om
Offices Serving Europe,
Middle East, and Africa
Europe
Tel: [phone]
eupresal[email protected]om
United Kingdom
Tel: [phone]
eupresal[email protected]om
Italy
Tel: [phone]
eupresal[email protected]om
France
Tel: [phone]
eupresal[email protected]om
Germany
Tel: [phone]
eupresal[email protected]om
Spain
Tel: [phone]
eupresal[email protected]om
Offices Serving Asia and the
Pacific Rim
Hong Kong
Tel: [phone]
appresal[email protected]om
Japan
Tel: [phone]
appresal[email protected]om
Offices Serving Latin America
Naples, Florida
Tel: [phone]
[e-mail]
São Paulo
Tel: [phone]
[e-mail]
Rio De Janeiro
Tel: [phone]
[e-mail]
Web Site Address www.handheld.com
Hand Held Products, Inc., ("Hand Held Products”)
©
1999-2004. All rights reserved. Printed in the U.S.A.
Due to Hand Held Products’ continuing product improvement programs, specifications and features herein are subject to change without notice.
QCOLVSV-SS Rev B 12/04
Quick Check®On-Line SV Series Verifiers Specifications
Dimensions
Height: 5.2 in. (13.2 cm)
Width: 4.4 in. (11.2 cm)
Depth: 2.4 in. (6.1 cm)
Mechanical/Electrical
Communication Port: DB-9, male, RS-232C, programmable baud rate up to 115,200 baud
I/O Power: DB-15, male, 5 programmable outputs, 2 sync inputs +5VDC @ 1 amp required
Mounting: 2 sets of mounting holes on 2 surfaces, or clamp for tightening to 3/8 in.(.5 mm) rod
LEDs: 5
Environmental
Operating Temperature: 40 to 105° F (4 to 41° C)
Storage Temperature: -4 to 140° F (-20 to 60°C)
Relative Humidity: 10 to 95% Non-condensing
Ambient Light: Not to exceed .5 mW/sq-mm 600 nm to 700 nm (calculated at about 2% of laser light level;estimate, not verified)
MTBF: 10,000 hours (est.) (dominated by motor, then laser life)
Scanner
Scan Rate: 400 scans/second
Laser Power: 3 mW (+.5 mW)
Wavelength: 650-670 nm
Beam Shape: Elliptical
Analysis Rate: 100 analyses/second (min.)
Bar Code Density
X Dimension: 6.6 mil (.2 mm) min. to 40 mil (1 mm) max.
Scan Width: 6 inches (15.2 cm)
X Dimension: 10 mil (.25 mm) or larger; 4.5 in.(11.4 cm) - (x dimension <10 mil)
Depth of Field: ±.125 in. (3.2 mm) min.with all verification analysis enabled
Symbologies EAN/UPC with addenda, Code 39, Interleaved 2 of 5, Codabar, Code 128, Code 93
Operation Modes
Sync Mode
Moving Bar Codes: A sync signal is used to indicate when an object or label containing a bar code has entered or exited the laser beam. Bar codes are
analyzed, ports activated, and transmissions sent as the bar codes pass through the beam. The QCOLV-SV100 is programmed for the
number of bar codes to expect during a sync period. Therefore, the QCOLV-SV100 detects missing or undetectable bar codes. A hardware
input is the most common sync source for Sync Mode.
Sync Mode
Stationary Bar Codes: Bar codes are placed in the beam and held in a known position. A sync input commands the unit to turn on the laser beam, perform a
programmable number of scans, report the analysis, and turn off the laser beam. RS-232 communication sync command (-SA) is the most
common sync source. A rastering laser option is often used to analyze the bar code area.
Non Sync Mode
Free Scan Operation: A sync signal is not used and the unit scans and analyzes bar codes as they pass through the laser beam. This mode is only recommended
if the QCOLV-SV100 is used as a bar code decoder, since it can’t report missing or undetectable bar codes.
Parameters Analyzed
Safety/Regulatory FCC Class B, CE Certified
Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries.
Average Bar Deviation (Traditional method parameter)
Minimum Bar Deviation (Traditional method parameter)
Maximum Bar Deviation (Traditional method parameter)
PCS (Traditional method parameter)
Reflectance – Light (Traditional method parameter)
Reflectance – Dark (Traditional method parameter)
Ratio (Traditional method parameter)
Quiet Zone (Traditional method parameter)
X Dimension (Traditional method parameter)
Decodability (ANSI method parameter)
Defects (ANSI method parameter)
Edge Contrast (ANSI method parameter)
Global Threshold (ANSI method parameter)
Modulation (ANSI method parameter)
Overall Symbol Grade (ANSI method parameter)
Reference Decode (ANSI method parameter)
Rmin/Rmax (ANSI method parameter)
Symbol Contrast (ANSI method parameter)
Bar Code Direction (scanner decoder function)
Encoded Data (scanner decoder function)
SymbologyType (scanner decoder function)
% Decode (multiple scanning parameter)
Modulo Check Digits (mandatory symbology and optional
application parameters)
