Hand Held Products Scanteam 5700 User manual

Decoded Output

Disclaimer
Welch Allynreserves the right to make changes in specifications and
other information contained in this document without prior notice, and the
reader should in all cases consult Welch Allyn to determine whether any
such changes have been made. The information in this publication does
not represent a commitment on the part of Welch Allyn.
Welch Allyn shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of this
material.
This document contains proprietary information which is protected by
copyright. All rights are reserved. No part of this document may be
photocopied, reproduced, or translated into another language without the
prior written consent of Welch Allyn, Incorporated.
E1999–2000 Welch Allyn Data Collection, Inc. All rights reserved.
Web Address: http://dcd.welchallyn.com

SCANTEAM 5700 User’s Guide
CDRH Statement
This product complies with 21 CFR Part 1040. This product is a Class II (Class
IIIa for 5700ALR) laser product with a maximum output of 1.0 mW (1.5 mW for
5700ALR) at 650 nanometers and continuous wave.
This equipment does not exceed the Class B limits for radio noise emissions as
described in the Radio Interference Regulations of the Canadian Department of
Communications.
Canadian Notice
Le present appareil numerique n’emet pas de bruits radioelectriques depassant
les limites applicables aux appareils numeriques de la classe B prescrites dans
le Reglement sur le brouillage radioelectrique edicte par le ministere des
Communications du Canada.
This equipment has been tested and found to comply with the limits for a Class B
digital device pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
FCC Class B Compliance Statement
Caution: Any changes or modifications made to this device that are not
expressly approved by Welch Allyn, Inc. may void the user’s authority to
operate the equipment.
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
•Consult the dealer or an experienced radio or television technician for help.
Note: To maintain compliance with FCC Rules and Regulations, cables
connected to this device must be shielded cables, in which the cable shield
wire(s) have been grounded (tied) to the connector shell.
C.S.A. Statement
This product must be used with a certified Class 2 power
supply or be powered by a certified SELV (Safety Extra
Low Voltage) output.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.

SCANTEAM 5700 User’s Guide
The SCANTEAM 5700 product is covered by one or more of the following U.S.
Patents:
4,360,798; 4,369,361; 4,387,297; 4,496,831; 4,593,186; 4,603,262; 4,607,156;
4,652,750; 4,673,805; 4,736,095; 4,816,660; 4,845,350; 4,896,026; 4,923,281;
4,992,717; 5,017,765; 5,047,617; 5,113,445; 5,140,144; 5,149,950; 5,168,148;
5,168,149; 5,180,904; 5,247,162; 5,250,792; 5,262,627;5,280,163; 5,280,164;
5,304,786; 5,304,788; 5,367,151; 5,373,148; 5,396,053; 5,408,081; 5,410,139;
5,436,440; 5,468,949; 5,479,000, 5,942,741.
Other U.S. and foreign patents pending.
Patents
Welch Allyn shall not be liable for use of our product with equipment
(i.e., power supplies, personal computers, etc.) that is not CE marked and
does not comply with the Low Voltage Directive.
For further information, please contact:
Welch Allyn Ltd.
1st Floor
Dallam Court Dallam Lane
Warrington, Cheshire WA2 7LT
England
The CE mark on the product indicates that the system has been tested to and
conforms with the provisions noted within the 89/336/EEC Electromagnetic
Compatibility Directive and the 73/23/EEC Low Voltage Directive.

i
SCANTEAM 5700 User’s Guide
TABLE OF CONTENTS
Section 1 Introduction & Quick Start Menu
Section Page
Introduction 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scanner Identification 1–2. . . . . . . . . . . . . . . . . . . . . . . . . .
Connecting the Scanner 1–3. . . . . . . . . . . . . . . . . . . . . . . .
Scan Maps 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Plug and Play Selections
IBM PC Interface 1–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IBM 4683 Interface 1–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OCIA Interface 1–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OCR, RS232 Interface 1–10. . . . . . . . . . . . . . . . . . . . . . . . . .
Terminal Interface Selections
Supported Terminals 1–11. . . . . . . . . . . . . . . . . . . . . . . . . . .
Reset Factory Settings 1–13. . . . . . . . . . . . . . . . . . . . . . . . .
Status Check 1–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick Suffix Selections 1–13. . . . . . . . . . . . . . . . . . . . . . . . .
Dual Interface Selections
Programming Instructions 1–14. . . . . . . . . . . . . . . . . . . . . . .
Code 39 Wand Emulation Selection 1–15. . . . . . . . . . . . . .
Same Code Wand Emulation Selection 1–15. . . . . . . . . . .
RS-232 Selection 1–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Laser Emulation Selection 1–15. . . . . . . . . . . . . . . . . . . . . .
Dual Interface Enable/Disable Selection 1–16. . . . . . . . . .
Switched Power Mode Selections 1–16. . . . . . . . . . . . . . . .
Laser Emulation Power Up Delay Selection 1–16. . . . . . .
Section 2 Output Parameters Menu
Section Page
Prefix / Suffix Selections
Introduction 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Primary Interface Prefix Selection 2–3. . . . . . . . . . . . . . . .
Primary Interface Suffix Selection 2–3. . . . . . . . . . . . . . . .
Exit Selection for Prefix / Suffix 2–3. . . . . . . . . . . . . . . . . .
Secondary Interface Prefix Selection 2–5. . . . . . . . . . . . .
Secondary Interface Suffix Selection 2–5. . . . . . . . . . . . .
Exit Selection for Prefix / Suffix 2–5. . . . . . . . . . . . . . . . . .

ii SCANTEAM 5700 User’s Guide
Section 2 Output Parameters Menu, continued
Output Selections
Beeper Volume Selection 2–8. . . . . . . . . . . . . . . . . . . . . . .
Output Delays Selection 2–8. . . . . . . . . . . . . . . . . . . . . . . .
Reread Delay Selection 2–9. . . . . . . . . . . . . . . . . . . . . . . . .
Good Read Delay Selection 2–9. . . . . . . . . . . . . . . . . . . . .
Laser Voting Selection 2–9. . . . . . . . . . . . . . . . . . . . . . . . . .
Buffered Scans Selection 2–10. . . . . . . . . . . . . . . . . . . . . . .
Code I.D. Transmit Selection 2–10. . . . . . . . . . . . . . . . . . . .
AIM I.D. Transmit Selection 2–10. . . . . . . . . . . . . . . . . . . . .
Function Code Transmit Selection 2–10. . . . . . . . . . . . . . . .
Serial Communication Selections
CTS Check Selection 2–11. . . . . . . . . . . . . . . . . . . . . . . . . . .
Baud Rate Selection 2–11. . . . . . . . . . . . . . . . . . . . . . . . . . .
RS-232 Word Length Selection 2–12. . . . . . . . . . . . . . . . . .
Parity Selection 2–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Protocol Selection 2–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Wedge Output Selection 2–13. . . . . . . . . . . . . . . . . .
Data Formatter Selections
Status Check 2–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Require Data Format 2–15. . . . . . . . . . . . . . . . . . . . . . . . . . .
Data Format Editor 2–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 3 General Operating Menu
Section Page
Laser Options
Introduction 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Marker Beam Selection 3–2. . . . . . . . . . . . . . . . . . . . . . . .
AutoTrigger Selection 3–2. . . . . . . . . . . . . . . . . . . . . . . . . .
Wand Emulation Selections
Transmission Rate Selection 3–3. . . . . . . . . . . . . . . . . . . .
Wake Up Pulse Selection 3–3. . . . . . . . . . . . . . . . . . . . . . .
Output Polarity Selection 3–3. . . . . . . . . . . . . . . . . . . . . . .
Country Code Selections
Foreign Keyboard Selection 3–4. . . . . . . . . . . . . . . . . . . . .
Keyboard Selections
AT Direct Connect Selection 3–5. . . . . . . . . . . . . . . . . . . . .
NCR 7052 Keypad Selection 3–5. . . . . . . . . . . . . . . . . . . .
Keyboard Style Selection 3–6. . . . . . . . . . . . . . . . . . . . . . .
Keyboard Style Modifiers 3–8. . . . . . . . . . . . . . . . . . . . . . .

iii
SCANTEAM 5700 User’s Guide
Section 4 Symbology Menu
Section Page
Industrial Symbology Selections
Introduction 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Codabar Selection 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Code 39 Selection 4–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Code 93 Selection 4–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interleaved 2 of 5 Selection 4–7. . . . . . . . . . . . . . . . . . . . .
Matrix 2 of 5 Selection 4–8. . . . . . . . . . . . . . . . . . . . . . . . . .
Code 2 of 5 Selection 4–8. . . . . . . . . . . . . . . . . . . . . . . . . . .
Code 11 Selection 4–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Code 128 Selection 4–9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Code 128 Function Character Selection 4–10. . . . . . . . . . .
Code 16K Selection 4–11. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Code 49 Selection 4–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Retail Symbology Selections
EAN Selection 4–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UPC Selection 4–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EAN Addenda Selection 4–14. . . . . . . . . . . . . . . . . . . . . . . .
UPC Addenda Selection 4–14. . . . . . . . . . . . . . . . . . . . . . . .
MSI Selection 4–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Plessey Selection 4–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 5 Firmware Utility Menu
Section Page
Introduction 5–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Downloading Utility 5–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uploading Utility 5–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cloning Utility 5–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temporary Serial Communication Configuration 5–3. . .
Section 6 Supported Interface Keys
Section Page
Keyboard Function Relationships 6–1. . . . . . . . . . . . . . . .
Supported Interface Keys 6–2. . . . . . . . . . . . . . . . . . . . . . .
Section 7 Product Specifications and Pinouts
Section Page
SCANTEAM 5700 Product Specifications 7–1. . . . . . . . .
Standard Cable Pin Outs 7–2. . . . . . . . . . . . . . . . . . . . . . . .

iv SCANTEAM 5700 User’s Guide
Section 8 Maintenance and Troubleshooting
Section Page
Maintenance 8–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 8–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Section 9 Customer Service
Section Page
Obtaining Factory Service 9–1. . . . . . . . . . . . . . . . . . . . . . .
Technical Support 9–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limited Warranty 9–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Default Charts
Programming Chart (inside back cover)
Sample Bar Codes (back cover)

1–1
SCANTEAM 5700 User’s Guide
The scanner recognizes and decodes 14 industry-standard bar code
symbologies.
Your scanner provides high value performance in an economical, durable
solution for a wide variety of bar code data collection applications. The scanner
contains Welch Allyn’s Instant Interface module, which integrates aggressive
(“snappy”) decoding, advanced data editing and formatting capabilities, and
multiple interface connectivity.
The scanner can be programmed for many communications parameters and
input/output protocols compatible to the host. Programming is accomplished by
using the single programming bar codes in this menu. Use this chapter to
program your laser scanner to work with your terminal/computer.
Introduction
Section 1 Introduction & Quick Start Menu
This programming section contains the following:
•Getting Started Information
•Plug and Play Selections
•Terminal Interface Selections
•Main Menu Selections
•Dual Interface Selections

SCANTEAM 5700 User’s Guide
1–2
SCANTEAM 5700 Identification Label
Interface Option
Option IBM
4683 OCIA OCR Bar Image Laser Out Wand Emulation TTL RS–232 True RS–232 Keyboard Wedge
0*
1
2
3
4**
DD
D
D
D
D
D
D
D
D
D
Various
Various
DEC Only
RS–232
Wedge
D
➌➋
➌
➊
Model Number 5X00/A–12
Scanner Identification
AutoTrigger Option
0 = Hands Free AutoTrigger Feature Not Included
1 = Hands Free AutoTrigger Feature Included
Engine Type
A = Increased
Performance
➊➋
* Operates only from +5V power source for 5700/A.
** Operates only from either +5 or +12V power.
HD = High Density
ALR = Advanced Long
Range
Manufactured Month/Year
ModelNumber 5X00/A-12
SerialNumber 12345
Rev=1.1=B=A

1–3
SCANTEAM 5700 User’s Guide
Connecting the Scanner
Install the scanner by following the steps shown below:
➊Turn off the power to the host system.
➋Connect the interface cable to the scanner and to the terminal/computer.
Keyboard Wedge Interface Example
Disconnect
1
2
3
➌Turn on the power to the host system.
➍Program your scanner to work with your terminal or computer by scanning
the Terminal Set–Up Codes. Either scan the Plug and Play codes (Pages
1–7 to 1–10) or use the Supported Terminal list (Pages 1–11 to 1–12) to
determine your terminal’s Terminal ID.
With Plug and Play programming, you connect the scanner and scan only one
bar code to program the scanner to work with a designated interface, including
any required prefixes and suffixes.
➎To determine if your scanner is set up correctly, scan one of the sample bar
codes on the back cover of this guide.
(Cable, Keyboard, and Terminal will vary.)

SCANTEAM 5700 User’s Guide
1–4
In.
Typical Depth of Field in Inches/Centimeters
Cm.
0
0
2
5.08
4
10.2
6
15.2
8
20.3
10
25.4
12
30.5
14
35.6.
16
40.6
18
45.7
20
50.8
22
55.9
24
61
26
66
28
71.1
30
76.2
32
81.3
In. Cm.
9.65 24.511
9.65 24.511
5 mil
2.5
3.5
7.5 mil
2
7
20mil
1.5 18
40 mil
3.5
26
55 mil
4
31
19.3”
Typical Performance at 20°C for
SCANTEAM 5700/A
113 mil
14

1–5
SCANTEAM 5700 User’s Guide
In. Cm.
2 5.08
2 5.08
1 2.54
00
1 2.54
2.0” 3”
3 mil
1.0 2.5
.5
5 mil
7.5 mil 4.0
4.5
In.
Typical Depth of Field in Inches/Centimeters
Cm.
0
0
1
2.54
2
5.08
3
7.62
4
10.16
5
12.7
6
15.24
Typical Performance at 20°C for
SCANTEAM 5700/HD
2.8”
13 mil
6.0
.5
1.0
10 mil
5.5.5

SCANTEAM 5700 User’s Guide
1–6
In. Cm.
41
15 mil
25 88
55 mil
In.
Typical Depth of Field in Inches/Centimeters
Cm.
0 90 180 270 360
Typical Performance at 20°C for
SCANTEAM 5700ALR
100 mil
322
123
30
104.1
20
76.2
10
50.8
25.4
00
25.410
50.820
76.230
104.141
30 mil
43
22
99
40
70 mil retroreflective – 68” (172.7 cm) – 13.5’ (411.5 cm)
100 mil retroreflective – 82” (208.3 cm) – 17.5’ (533.4 cm)
30 60 120 150 210 240 300 330
0 228.6 457.2 685.8 914.476.2 152.4 304.8 381.0 533.4 609.6 762.0 838.2

1–7
SCANTEAM 5700 User’s Guide
IBM PC AT and Compatibles Interface (Default)
IBM PC, Wand Emulation Interface
IBM PS/2 and Compatibles Interface
IBM PC XT and Compatibles Interface
These bar codes also program a carriage return (CR) suffix.
(also PS/2 30-286, 50, 55SX, 60, 70, 70-061, 70-121, 80)
( for PS/2 25, 30 models)
Wand Emulation (Code 39 Format) Interface
Wand Emulation (Same Code Format) Interface [
[Supports Code 39, UPC, EAN, Code 128, Interleaved 2 of 5, and Codabar.
All other odes output as Code 39.
Transmission Rate 20 inches per second
Output Polarity Black High
Programmable Option Setting
These bar codes also program the following parameters:

SCANTEAM 5700 User’s Guide
1–8
IBM 4683 Port 5B Interface
IBM 4683 Interface
IBM 4683 Port 9B HHBCR–1 Interface
IBM 4683 Port 9B HHBCR–2 Interface
IBM 4683 Port 17 Interface
EAN 8 0C Code 39 00 0A 0B
EAN 13 16 I 2 of 5 00 0D 0B
UPC A 0D Code 128 00 18 0B
UPC E 0A
Symbology Suffix Symbology Prefix
These bar codes also program the following parameters:

1–9
SCANTEAM 5700 User’s Guide
The bar code above also programs the following parameters:
Spectra-Physics OCIA Interface
OCIA Interface
NCR OCIA Short Form Format (Eight Bit) Interface
NCR OCIA Long Form Format (Nine Bit) Interface
EAN 8 06 06 UPC A 01
EAN 13 06 UPC E 05
Symbology Suffix Symbology Prefix
EAN 8 0F 0F UPC A 0A
EAN 13 0F UPC E 0E
Symbology Suffix Symbology Prefix
EAN 8 46 46 Code 39 42 31
EAN 13 46 I 2 of 5 42 32
UPC A 41 Code 128 42 33
UPC E 45
Symbology Suffix Symbology Prefix
The bar code above also programs the following parameters:
The bar code above also programs the following parameters:
This bar code above also programs the following parameters:
Nixdorf OCIA Interface
EAN/UPC with Addenda 44 4B
Code 39 44 49
I 2 of 5 44 48
2 of 5 44 47
Code 128 44 4A
Symbology Prefix

SCANTEAM 5700 User’s Guide
1–10
The bar code above also programs the following parameters:
EAN 8 0C UPC A 0D
EAN 13 16 UPC E 0A
Code 128 1D
EAN 8 17 UPC A 17
EAN 13 17 UPC E 17
I 2 of 5 03 (Application Dependent)
Fujitsu OCR Interface
OCR, RS232 Interface
IBM OCR (Port 21) Interface
Symbology Suffix Symbology Prefix
Symbology Suffix Symbology Prefix
The bar code above also programs the following parameters:
RS-232 Interface
Baud Rate 9600 bits per second
Parity even
Data Format 7 data bits, parity bit, 1 stop bit
(8 Bit Data)
The bar code above also programs the following parameters:
Programmable Option Setting
End of “Plug and Play” programming...

1–11
SCANTEAM 5700 User’s Guide
Supported Terminals
Terminal Model(s) Terminal I.D.
ADI 1496 72
Apple Desktop Bus ADB MAC Classic, SE SE30, II (All) 49
Bull BDS–7 (HDS–7) 35
Burroughs B25 75
Decision Data DDC3596, 3597 30
DEC VT–220, 320, 330, 340 420 04
Esprit 200, 400 05
Falco 5220 47
Heath Zenith PC 90
HP 700/44, 700/92, 700/94, 20
700/96, 700/98
HP 700/60 79
HP Vectra QS–16 03
IBM PC XT 01
IBM PS/2 25, 30 02
IBM AT, PS/2 30–286, 50, 55SX, 03*
60, 70, 70–061, 70–121, 80
IBM 4683, 4684 51
IBM 102 Key 3151, 3161, 3162, 3163, 3191, 06
3192, 3196, 3197, 3471, 3472,
3476, 3477
IBM 122 Key 3179–1, 3191, 3192, 3471, 07
3472, 3194
IBM 122 Key 3196, 3197, 3476, 3477, 08
3486, 3488, 3482
IBM 122 Key 3180 24
Program Terminal Interface
If your terminal is not one of the Plug and Play options, you must program one
of the terminals listed below. To program the terminal interface, scan the
Program Terminal Interface bar code below, then scan the appropriate two digit
Terminal I.D. code from the Programming Chart on the inside back cover of this
manual.
* = Default

SCANTEAM 5700 User’s Guide
1–12
Supported Terminals
Terminal Model(s) Terminal I.D.
ICL 300 77
IDEAS 08
ITT 9271 07
Lee Data IIS 07
Link MC–5 18
Mac 49
OCIA 52
OCR 53
Olivetti M19, M24, M28, M200 01
Olivetti 240, 250, 290, 380, P500 03
Qume ANSI QVT 61, 62, 70, 191, 321, 322 82
Qume ASCII QVT 31, 51, 61, 62, 70, 191 74
Qume Enhanced PC QVT 61, 62, 70, 82, 191, Qx15 38
RS232 True 00
RS232 TTL 00
Serial Wedge 50
Siemens 9758 (German Only) 34
Stratus V103 14
Televideo 955, 965 36
Telex 88 Key 078A, 078, 79, 80, 191, 196, 25
1191, 1192, 1471, 1472, 1476
Telex 102 Key 078A, 078, 79, 80, 191, 196, 45
1191, 1192, 1471, 1472, 1476
Telex 122 Key 078A, 078, 79, 80, 191, 196, 46
1191, 1192, 1471, 1472, 1476
Wand Emulation 61
WYSE WY–30 13
WYSE WY–85/185 16
WYSE ANSI WY 60, 120, 150, 160 15
WYSE ASCII WY 60, 120, 150, 160, 99GT 14
WYSE Enhanced PC WY 60, 120, 150, 160 18
