HandHeld ALGIZ 10X User manual

ALGIZ 10X User’s Manual
ALGIZ 10X
User’s Manual V1.0

ALGIZ 10X User’s Manual
i
Accessory
Item
Description
Note
Default Packing Accessories
1 piece of 2 Cell Li-Ion Battery Pack
1 piece of 12V Adapter w/ Standard
Power Cord.
Euro / U.S. Std type, 1.8M
1 piece of Windows 7 Recovery User’s
Guide.
With Windows 7
Ultimate
embedded
preinstalled
1 piece of Rugged Tablet PC
Users Manual.
Item
Description
Note
Optional Accessories
1 piece of 4 Cell Li-Ion Battery Pack

ALGIZ 10X User’s Manual
ii
Copyright Notice
Copyright © 2012 Handheld Inc., ALL RIGHTS RESERVED. No part of this
document may be reproduced, copied, translated, or transmitted in any form or by
any electronic or mechanical means, for any purposes without the permission of
the original manufacturer in advance.
Trademark Acknowledgement
Brand and product name are trademarks or registered trademarks of their
respective owners.
Disclaimer
Handheld Inc. reserves the right to make any product changes without notice,
including circuits and/or software described or contained in this manual in order
to improve product design and/or performance. Handheld Inc. assumes no
responsibility or liability for the use of the described product(s), conveys no
license or title under any patent, copyright, or masks work rights to these products,
and makes no representations or warranties that these products are free from
patent, copyright, or mask work right infringement, unless otherwise specified.
Applications that are described in this manual are for illustration purposes only.
Handheld Inc. makes no representation or warranty that such application will be
suitable for the specified use without further testing or modification.
Warranty
Handheld Inc. guarantees that all Handheld products will be free including
material and workmanship defects for one year from the invoice date. If the
customer discovers any defects, Winmate will, at its option, repair or replace the
defective product without any charge to customers, and ship the returned product
with prepaid transportation charges during the warranty time of one year. The
returned product must be properly packaged in its original packaging to be qualified
for warranty service.
If there is a time gap of over 30 days between the date marked on the serial
number and the shipping date, the one-year warranty time will then activate from
the shipping date. The third and fourth digits of the serial numbers stand for the
manufacturing year and the fifth digit stands for the manufacturing month (e. g.,
with A for October, B for November and C for December). For example, the serial
number 1W10Axxxxxxxx means October of year 2010.

ALGIZ 10X User’s Manual
iii
Customer Service
We provide service guide for any problem as follow steps：
1. Visit Handheld website www.handheldgroup.com to get the updated product
information.
2. Contact with your distributor, sales representative, or our customer service
center for technical support if you need further assistance. You may have the
following information ready before you make the phone call：
Product serial number
Peripheral attachments
Software (OS, version, application software, etc.)
Detailed description of problems
The exact wording or print screen images of any error messages
In addition, free technical support is available at Winmate in every business
day. We are always ready to provide guidance in terms of application requirements
or specific information in terms of installation and operation of all our products.
Please feel free to call or e-mail us.
Manufacturer：Handheld Inc.
Address：Handheld Group AB, Kinnegatan 17 A, S-531 33, Linkoping, Sweden
TEL：[phone]
FAX：[phone]

ALGIZ 10X User’s Manual
iv
Safety Precautions
Warning!
Always completely disconnect the power cord from the
device before you uncover the device and work on the
hardware. Do not connect the electronic device with power
socket while the power is on. Sensitive electronic components
can be damaged by sudden power surges. Only experienced
electronics personnel are suggested to open mechanical
housing.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. The electronic devices are very
sensitive to static electricity. For safety concerns, please use a
grounding wrist strap all the time. Place all electronic
components in a static-dissipative surface or static-shielded bag
when they are outside of the chassis.
UL Safety Announcement
UL Classification: Class I mark: with respect to electronic shock; Fire and
hazardous material only in accordance with the regulation of UL-60950
and CAN/CSA C22.2 No. 601.1.
Power Supply Announcement
The Handheld Rugged Tablet PC Power is supplied by Power Adapter and Battery
Pack, the power rating announcement and manufacturer information are listed as
below.

ALGIZ 10X User’s Manual
v
Power Notice!
Please notice that the power code of adapter needs to be connected to
the ground (earth).
Please push the power button for at least 4 seconds to enter sleep mode
(See Chapter 2.1 Starting and Stopping the Tablet PC).
Power Adapter
Manufacture: EDAC Power Electronics Co Ltd
Model: EA11001C-120
Input Rated: 100-240Vac, 1.8A, 50-60Hz.
Output Rated: DC 12V, 6.66A.
Battery Pack
Manufacture: T-Gee Electronic Co., Ltd
Model: ALG10X-08A
Rated: 5300mAh DC 7.4V
WARNING
Do not fix or replace battery, it may cause explosion!
Only use with specified battery by following the
manufacturer’s user manual’s instruction.

ALGIZ 10X User’s Manual
1
FEDERAL COMMUNICATIONS COMMISSION
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
–Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
RF exposure warning
The equipment complies with FCC RF exposure limits set forth for an
uncontrolled environment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.

ALGIZ 10X User’s Manual
2
RF exposure information (SAR)
This Rugged Tablet PC meets the government's requirements for exposure to
radio waves. This Rugged Tablet PC is designed and manufactured not to
exceed the emission limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S. Government. The
exposure standard for wireless Rugged Tablet PC employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard
operating positions accepted by the FCC with the Rugged Tablet PC
transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual
SAR level of the Rugged Tablet PC while operating can be well below the
maximum value. This is because the Rugged Tablet PC is designed to operate
at multiple power levels so as to use only the poser required to reach the
network. In general, the closer you are to a wireless base station antenna, the
lower the power output. The highest SAR value for US model Rugged Tablet
PC as reported to the FCC when tested for use at the body, as described in
this user guide, is 1.115 W/kg.

ALGIZ 10X User’s Manual
3
Index
Chapter 1 Specification ......................................................................... 5
1. System Specification ...........................................................................6
Chapter 2.......................................................................................... 7
Identifying Hardware Components ........................................................... 7
1. TOP Side ..............................................................................................8
2. Left and Right Side................................................................................9
3. Bottom side .......................................................................................10
Chapter 3........................................................................................ 11
Buttons and Indicators ....................................................................... 11
1. Function Keys ....................................................................................12
2. LED Indicators....................................................................................13
Chapter 4........................................................................................ 14
Getting Your Device Ready ................................................................... 14
1. Plug in the AC Power ...........................................................................15
2. Using Battery Power ...........................................................................16
3. Installing 3G Module...........................................................................18
4. How to use the Wireless Network.........................................................19
5. How to use the Bluetooth ....................................................................21
6. How to use the 3G Feature ...................................................................24
7. How to use the GPS Feature .................................................................25
8. How to use the Camera Feature............................................................28
9. How to use the external antenna. .........................................................30
10. How to adjust the LCD brightness.........................................................31
11. How to adjust the speaker volume........................................................32
12. Show the battery information...............................................................33
13. Show the system information...............................................................33
Chapter 5........................................................................................ 34
Installing the Device Driver .................................................................. 34
1. Chipset Driver Installation ..................................................................35
2. Graphic Driver Installation..................................................................39
3. Audio Driver Installation .....................................................................42
4. LAN Driver Installation ........................................................................45
5. HotTab Utility Installation ...................................................................47
6. HotTab Driver Installation ...................................................................49

ALGIZ 10X User’s Manual
4
7. Wireless LAN Driver Installation ..........................................................50
8. Bluetooth Driver Installation. ..............................................................54
9. 3G Module Driver Installations ............................................................57
10. AirCard Watcher Installations .............................................................59
11. GPS Driver Installations ......................................................................61
12. U-Center Installations ........................................................................65
Chapter 6........................................................................................ 68
Caring Your Tablet PC ......................................................................... 68
1. Battery Protection Tips .......................................................................69
2. Touch screen Protection Tips..............................................................70
3. Trouble shooting from A to L ................................................................71
4. Appendix...........................................................................................77

ALGIZ 10X User’s Manual
5
Chapter 1
Specification

ALGIZ 10X User’s Manual
6
ALGIZ 10X is a rugged Tablet PC designed for the use in various challenging
environments, e.g., field work, outdoor activities and construction site. With its
rugged design, ALGIZ 10X is able to sustain shock, vibration, high humidity as well as
high/ low temperatures.
1. System Specification
System
Processor
Intel® Atom™ Processor N2800
BIOS
AMI System BIOS
Chipset
Intel® NM10 Express Chipset
Memory
1 x SODIMM, DDR3 1600 4GB
LAN Controller
Broadcom BCM57780 Gigabit-LAN
Storage
SATA interface support Mini-PCIe interface SSD 128GB
Audio
Audio-out for headset, Audio-in to send in audio signal,
Microphone-in for microphone jack,1.5W Speaker (Internal)
Display Specification
Size
10.1” (16:9)
Resolution
1366 x 768
Brightness
600 cd/m2 (typ.)
Touch
4W Resistive Touch
I/O Connectors
Left I/O Port
1x DC Power Jack,1xVGA,1XUSB,1XRS232
Right I/O Port
1x LAN, 1x USB , 1xCombo ,Audio Jack , 1x SIM Card Slot ,
1xMirco SD Card Slot
Bottom I/O Port
1x Pogo-pin for Docking, 1x Service Window
Buttons and Indicators
Control Button
1x Power On/Off, 1x Menu, 1x Up, 1x Down, 1x Left, 1x Right
3x Programmable Hotkeys
LED indicators
1x Power Status, 1x HDD Status, 1x RF Device Status , 1x
Battery Status,1x GPS Status

ALGIZ 10X User’s Manual
7
Chapter 2
Identifying
Hardware
Components

ALGIZ 10X User’s Manual
8
○
3
○
2
○
4
1. TOP Side
Ref.
Item
Description
1
LED Display
The Tablet PC uses a high brightness LED
TFT LCD. Use a soft cloth without
chemical liquids to clean the display
panel.
2
Front Microphone
Receives sound and voice to record
voice.
3
Light Sensor
Senses the ambient light for automatic
adjustments of the display backlight. The
features can be enabled through OSD
Control Keypad.
4
OSD Control Keypad
The OSD Control Keypad provides
hotkeys with all the functions including
1x Power On/Off, 1x Menu, 1x Up, 1x
Down, 1x Left, 1x Right,3x Programmable
Hotkeys.
○
1

ALGIZ 10X User’s Manual
9
○
2
○
3
○
4
○
5
○
6
○
7
○
8
○
9
2. Left and Right Side
Ref.
Item
Description
1
DC Power Jack
Plug in DC plug to input the power to the device
2
VGA
For connection with external displays devices such as
monitors and projectors
3
USB 2.0 Port x 1
Can be connected with any USB-interface peripherals
4
RS232
Accepts external connection that is with interface of
RS232 (D-sub 9 pins)
5
Ethernet(RJ45) Port
Connect to a Ethernet 10/100/1000 based network
6
USB 2.0 Port x 1
Can be connected with any USB-interface peripherals
7
Combo Audio Jack
Connects a set of headphones or external speakers.
8
SIM Card Slot
Accepts a SIM Card use the WWAN feature to connect
to the Internet.
9
Micro SD Card Slot
Accepts a Micro SD Card for additional feature.
○
1

ALGIZ 10X User’s Manual
10
3. Bottom side
Ref.
Item
Description
1
Docking Connector
Connects to the Docking Station .
2
Service Window
Unscrew to install and uninstall 3G/ module and SIM
card
○
1
○
2

ALGIZ 10X User’s Manual
11
Chapter 3
Buttons and
Indicators

ALGIZ 10X User’s Manual
12
1. Function Keys
Components
Function Description
See Other
Intro.
1
Power On Button
PUSH 4 seconds to turn on the tablet
pc
2
LED Indicator
Shows the Power Status, HDD Status,
RF Device Status, Battery Status, and
GPS Status
3
Menu
Push Menu function to show
Brightness(Include Auto Light Sensor),
Volume,Battery status and
Wireless/Bluetooth/3G/GPS/Camera
Enable/Disable &Internal/External
3G&GPS Antenna switch.
4
F1 –F3 Hotkey
6 programmable Hot-key for user to
define by application, default first
short push key (F1 short) will turn-on
Outlook Express
5
Up/Down/ Left/
Right/OK Button
Cotrol the up, down, left, right and
Enter function.

ALGIZ 10X User’s Manual
13
2. LED Indicators
Function
Icon
Description
Power Status
Green light –Power on
Orange light –Sleep mode
HDD Status
Green light –System is accessing the hard disk drive
RF Status
Green light –When RF radio is on.
Battery Status
Red light –Low Battery
Green light –Full Battery
Yellow light –Charging
GPS Status
Indicates if the GPS is workable.

ALGIZ 10X User’s Manual
14
Chapter 4
Getting Your Device
Ready
