Handicare Coral 3002010000 User manual

Manual no: LI09509.514 Ver.1 1301211
Coral
commode/shower stools
Art.no.:
3002010000, 3002010100
SWL: 150 kg/330 lbs
Coral commode/shower stool
3002010000
Coral shower stool
3002010100
Manual - English
Manual - Svenska
Manual - Norsk
Manual - Danske
Käyttöohje - Suomi
Gebrauchsanweisung - Deutsch
Handleiding - Nederlands
Manual - Français
Manual - Italiano
Manual - Español

Table of contents
Visual inspection/before use.................................................... 3
Read the manual........................................................................... 4
English...........................................................................................5-10
Dimensions................................................................................
Accessories....................................................................................

3
MANUAL
EN Visual inspection
Inspect the product regularly. Check to ensure that material
is free from damage.
EN Before use
Ensure that the product is correctly assembled/mounted/
installed.
SE Visuell inspektion
Gör regelbundna funktionskontroller av produkten.
Kontrollera att materialet är helt fritt från skador.
SE Före användning
Kontrollera att produkten är rätt monterad/installerad.
NO Visuell inspeksjon
Gjør regelmessige funksjonskontroller av produktet.
Kontroller at materialet er helt og uten skader.
NO Før bruk
Kontroller at produktet er korrekt installert.
FI Silmämääräinen tarkastus
Tarkasta tuotteen toimivuus säännöllisesti. Tarkasta, ettei
materiaalissa ole mitään vaurioita.
FI Ennen käyttöä
Tarkasta, että tuote on asennettu oikein.
DK Visuel inspektion
Foretag regelmæssige funktionskontroller af sengebordet.
Kontroller, at materiale er helt og ikke udviser tegn på
beskadigelse.
DK Før brug
Kontroller, at produktet er korrekt installeret.
DE Sichtprüfung
Unterziehen Sie das Hilfsmittel regelmäßigen
Funktionskontrollen. Vergewissern Sie sich, daß das
Material unbeschädigt ist.
DE Vor der Benutzung
Prüfen Sie das Produkt auf korrekte Montage.
NL Visuele controle
Inspecteer het product regelmatig. Controleer op mogelijke
beschadigingen van het materiaal.
NL Voor gebruik
Zorg ervoor dat het product juist is gemonteerd.
FR Inspection visuelle
Effectuer des inspections régulières du fonctionnement du
produit. Vérifier que le matériau est entièrement exempt de
dommages.
FR Avant l’utilisation
Vérifier que le produit est correctement installé.
IT Ispezione visiva
Testare il funzionamento del prodotto regolarmente.
Verificare che il materiale non sia danneggiato.
IT Prima dell’uso
Verificare che il prodotto sia installato correttamente.
ES Inspección visual
Realice periódicamente un control de funcionamiento del
producto. Asegúrese de que el material no presente ningún
tipo de desperfecto.
ES Antes de su uso
Compruebe que el producto esté correctamente
instalado.

4
MANUAL
EN Always read the manual
Always read the manual.
Keep the manual where it is easily accessible for users of the product.
SE Läs alltid manualen
Läs alltid manualen.
Förvara manualen tillgänglig för användare av produkten.
NO Les alltid manualen
Les alltid manualen.
Oppbevar manualen tilgjengelig for brukere av produktet.
DK Læs altid manualen
Læs altid manualen.
Opbevar manualen tilgængelig for brugere af produktet.
FI Lue aina käyttöohje
Lue aina käyttöohje.
Säilytä käyttöohje tuotteen käyttäjien saatavilla.
DE Lesen Sie stets die gebrauchsanweisung
Lesen Sie stets die gebrauchsanweisung.
Verwahren Sie die Anleitung so, dass sie der Anwender des Produktes rasch
zur Hand hat.
NL Lees altijd de handleiding
Lees altijd de handleiding.
Bewaar de handleiding zo dat deze voor gebruikers van het product altijd beschikbaar is.
FR Toujours lire le manuel
Toujours lire le manuel.
Conserver le manuel pour qu’il soit accessible aux utilisateurs du produit.
IT Leggere sempre il manuale
Leggere sempre il manuale.
Tenere il manuale delle istruzioni in un luogo facilmente accessibile agli operatori
che utilizzano il prodotto.
ES Lea siempre el manual
Lea siempre el manual.
Guarde el manual en un lugar accesible para el usuario del producto.

English
Coral
commode/shower stools
1. Adjust the height of the stool by repositioning the E-clips
(without a user in the stool).
1. Remove the E-clips
2. Lower or lift the leg to desired height
3. Snap the E-clips in place
4. Ensure that all legs have the same height
E-clip
1
Using the product
Table of contents
Using the product ...................................................................... 5-9
- Important information............................................................................ 6
- Assembly.............................................................................................. 7
- Disassembly ...................................................................................... 8-9
With Coral, you are the designer!..........................................10
5
MANUAL

English
Purpose
Coral commode and shower stool is a very versatile stool. It can be used as both a commode and a shower stool. Coral
commode and shower stool is mostly used in the bathroom and can be equipped with arm supports and back support.
Coral commode and shower stool is particularly suitable for immobile persons, who need assistance with toileting and
personal hygiene. The stool is intended for short-term use only.
Maintenance / Cleaning
To ensure optimal operation, the following should be regularly reviewed:
• CheckiftheE-clips(seedrawing,page5)aresecurelyfastened
The stool is to be wiped clean after use. Clean Coral commode and shower stool with non-abrasive, non-corrosive
domestic cleaning agents. Solvents and chlorine should not be applied. The stool’s surfaces can be disinfected with all
disinfectants that are approved by Health Authorities.
The toilet rails can be detached for cleaning purposes.
Make sure to reattach all removed parts correctly.
Reuse
Follow the above procedure. Defective or worn parts must be replaced.
Caution
Max.loadCoralcommodeandshowerstool:150kg/330lbs.
Check the condition of the E-clips frequently.
Regularly check that the E-clips are inserted correctly into the tubing.
Regularly check that all parts are in place and secured.
If the height adjustment tubes are detached, it is important to mount them again correctly.
Make sure all 4 height adjustment legs have the same height.
The stool is only to be used on an even surface. Do not stand on the stool.
The bed pan/bucket is only to be inserted or removed, when the user is not in the stool.
Do not place the stool in direct sunlight, as it might cause a hot surface on the seat.
Disposal
The plastic parts should be sorted as incinerated and stainless steel parts as metal.
Important information
6MANUAL

Assembly
Coral commode/shower stools
3002010000, 3002010100
12
English
3. Slide the base plate over the
front legs.
Make sure that the rear pins of
the seat fully protrude the base
plate. Push the base plate onto
the seat until all clickers snap
into place.
1. Position the leg with cover
(2x) on the seat. Make sure
that all pins of the seat fully
protrude the leg and the
cover.
2. Make sure that the leg and
cover (2x) are well fitted in the
seat. Lay this part on a table
for easier assembly of the other
parts.
3
4. Mount the safety lock (2x) on the
protruding pin.
Make sure that both safety locks are
screwed on tightly.
6. Slide the height adjustment tube
into the leg (4x).Adjust to the correct
height and click the E-clip through
the chair leg and height adjust-
ment tube. Make sure the legs are
mounted at the same height.
5.Mountthesafetykey(2x)betweenthe
clickers at the back of the stool.
Push downwards until it snaps in place.
45 6
7. Place the rear pin of the toilet rail (2x)
into the rear keyhole in the base plate.
Push forward until it snaps in place.
Applicable for commode seat: 3002010000 9. Turn the stool upright.
Make sure that all parts are
in place and secured.
8. Rotate the toilet rail until the front
pins align with the front keyholes. Push
outward until it snaps in place.
Applicable for commode seat: 3002010000
789
7
MANUAL

3. Remove the clip from the leg and
remove the tube (4x).
Disassembly
Coral commode/shower stool
3002010000, 3002010100
1
3
6
English
6. Remove the safety keys at the
backside of the base plate. Place the
wedge end in the open space of the
pocket. Remove the safety keys by
rotating the wedge upwards (2x).
2. Remove the toilet rail (2x) by:
1. Pulling the rail inward until the
upper part unlocks.
2. Pushing the rail backward
(direction: back of the chair) until
the rear pin unlocks.
1. Turn the stool upside down and lay the
stool with the seat on top of a table.
Applicable for commode seat: 3002010000
2
5
5.Usethetwotoolsfordisassembly,
to unlock the base plate (see pictures
6 to 10).
Only use the included tools.
4. Remove the safety lock from the pin
by unscrewing (2x).
2x
4
7. Unlock the clickers in alphabetical order (see pic-
tures 7 to 10).
A
B
C
D
E
F
AB
C
D
E
F
7
8
MANUAL

12. Remove the cover for back of
seat and the legs off the seat.
8
8. Pos A (2x):
- Fig 8A: Position the fork of the tool around the
pocket. Make sure the tip of the fork is between
the seat and the base plate.
- Fig 8B: Gently push/slide the tool downward
between both parts until the clicker unlocks.
A
B
9. Pos B-E (2x);
- Fig 9A: Place the wedge end in the pocket by sliding along the
back of the pocket. Tip of the wedge end touches the tip of the
clicker. Tool and base plate are angled.
- Fig 9B: Press down the tool toward the base plate, while lifting
the base plate, until the clicker unlocks.
9A B
English
12
10. Pos F (2x):
- Position the tool with the tip of the fork
between the seat and the base plate
(atapproximately5cm/2”fromthefront
corner of the seat).
- Press the tool gently between the seat
and the base plate to unlock the clicker.
11. Pull the base plate upward over the legs.
Keep the base plate horizontal while pulling.
11
10
9
MANUAL

With Coral, you are the designer!
With one stable and height-adjustable frame combined with optional extras and accessories, Handicare’s Coral concept
offers numerous possibilities to create individually adapted showering and toileting solutions. All combinations offer safe
and flexible user-friendliness, high-quality stainless materials and a contemporary design.
When life changes, so does your Coral
For increased comfort and usability, Coral commode/shower stools can be equipped with back support and/or arm
supports. The stool with a toilet seat can be equipped with a bedpan or bucket and soft toilet seats. The back and arm
supports can also be replaced with a backrest with folding armrests. For even greater comfort, or to accommodate for
changingneedsandrequirements,thechaircanbefittedwithcastorsandfootrests.Finally,withthe24”self-propelling
wheels adapter set, a Coral commode or shower chair fitted with the backrest with folding armrests can be conveni-
ently transformed into a self-propelled version providing the user with increased independence in showering and toileting
situations.
Recycling – an important part of the Coral concept
Naturally,anexistingCoralconfigurationcanalsobeadaptedtoa“smaller”solutionortofitanotheruser.Alldismantled
parts and accessories can be reconditioned and re-used in new configurations for other users.
English
10 MANUAL

MANUAL
Formaat
Naam Gecontroleerd Vrijgave
Art.nr.
Titel
Productgroep Tek. nr.
Handicare
Bathroom Safety B.V.
t:[phone]
f:[phone]
www.handicare.com
Dit document is vertrouwelijk. Het auteursrecht
berust bij Handicare Bathroom Safety B.V.
Alle rechten voorbehouden.
Blad Van Rev. Datum Revisie Schaal Projectie
Assembly
A4
C:\WorkingFolder\WorkSpace\Nieuwe ontwikkelingen\rfl-stoel\BPO- final\toilet commode.idw
BPO-final
7-6-2012
ML
4
3
toilet commode
0,09 : 1
420-570
490
525
1°
410
410
365-515
Dimensions/Måttbeskrivning/Målbeskrivelse/Mitat/Maßbeschreibung/
Afmetingen/Dimensioni/Dimensiones
410 mm / 16.1 inch
525mm/20.7inch
365-515mm/
14.4-20.3 inch
490 mm / 19.3 inch
420-570mm/
16.5-22.4inch
410 mm / 16.1 inch
Coral commode/shower stool: 3002010000

MANUAL
Formaat
Naam Gecontroleerd Vrijgave
Art.nr.
Titel
Productgroep Tek. nr.
Handicare
Bathroom Safety B.V.
t:[phone]
f:[phone]
www.handicare.com
Dit document is vertrouwelijk. Het auteursrecht
berust bij Handicare Bathroom Safety B.V.
Alle rechten voorbehouden.
Blad Van Rev. Datum Revisie Schaal Projectie
Assembly
A4
C:\WorkingFolder\WorkSpace\Nieuwe ontwikkelingen\rfl-stoel\BPO- final\technische tekeningen\taboeret_zitting.idw
BPO-final
9-7-2012
laura
1
1
taboeret_zitting
1 : 10
365-515
1°
525
490
420-570
410
410
410 mm / 16.1 inch
525mm/20.7inch
365-515mm/
14.4-20.3 inch
490 mm / 19.3 inch
420-570mm/
16.5-22.4inch
410 mm / 16.1 inch
Coral shower stool: 3002010100

68
MANUAL
Accessories/Tillbehör/Tilbehør/Lisävarusteet/Zubehör/Accessoires/
Accessori/Accesorios
Accessories for increased comfort and/or usability
3002920802 Bedpan, with lid, stainless steel
3002920803 Bucket, with lid, stainless steel
3002920400 Soft toilet seat, PUR, oval opening
3002920401 Soft toilet seat, PUR, keyhole opening
3002920500Transportationseat,PUR
3002800200 Shower seat, plastic, incl covers
3002800100 Toilet seat, plastic, incl covers and toilet rails
Accessories for creating more advanced configurations
3002800300 Back support, plastic
3002800500Armsupports,plastic,1pair
3002920402 Soft toilet seat, PUR, oval opening, with cut-outs for arm supports
3002920403 Soft toilet seat, PUR, keyhole opening, with cut-outs for arm supports
3002920501Transportationseat,PUR,withcut-outsforarmsupports
3002820200 Backrest frame with folding armrests, plastic frame, incl 2 hinge pins
3002800400 Backrest cover standard, textile, polyester mesh
3002921100 Armrest lock, prevents folding function, 1 pair
3002920900 Front support, for Backrest frame with folding armrests 3002820200
3002820800* Castors, twin castors, Ø 100 mm, incl legs, 4 pcs
3002820900*Castors,twincastors,Ø125mm,incllegs,4pcs
3002800600 Swing-away footrests, plastic, incl fixing clips, 1 set
3002810300 Folding footrests, plastic, with tubes, incl fixings, 1 set
3002921400 Headrest, for Backrest frame with folding armrests 3002820200
3002920200 Calf support, textile, with Velcro
3002920100 Amputee support left, for left underleg, with adjustable knee angle (a piece), incl fixings
3002920101 Amputee support right, for right underleg, with adjustable knee angle (a piece), incl fixings
3002921300 Safety belt, for hip and chest
3002921500*24”self-propellingwheelsadapterset,completeadapterset
3002921700 Anti tip set, for self-propelling chairs
*Castors and self-propelling wheels can only be added to a Coral stool/chair fitted with a Backrest frame with folding
armrests (3002820200).

Handicare offers solutions and support to increase the independence of disabled or elderly people as well as to improve conven-
ience for those who are caring for them.
The Handicare Group is one of the leading healthcare companies in Europe with own manufacturing organizations
and sales companies in Norway, Sweden, Denmark, Germany, the Netherlands, Great Britain, France, Poland, China,
Canada and the USA. Handicare’s products are also distributed by partners in more than 40 countries worldwide. Our
wide range of high-quality products includes various power and manual wheelchairs, scooters, seating systems, a com-
plete easy transfer system and other patient handling aids, stairlifts, car adaptations, rise- and recline chairs, and bathing
and toileting products.
