Hanover HSD0451 User manual

Assembly & Care Guide
For Motorized Lift Desk
Model: HSD0451

2
Lift Desk Assembly Instructions
The model number of your desk is printed on the side of your carton.
Always use this number to identify your desk.
Thank you for your purchase of this quality office furniture. With proper use and care, your
furniture will provide you with years of use. Please follow the instructions on how to assemble
and disassemble your furniture. If you should have any problems with your furniture DO NOT
return it to the place of purchase. Please refer to the trouble shooting section of this manual
or call our toll free number: 877-397-5144 and a customer service representative will assist
you.
Your Packages Includes:
1 Desktop, 3 Legs, 1 Motor & Assembly Hardware
Please read all instructions completely before assembling your desk.
Technical Specifications
Height Range: 23.5” – 49” (not including desktop)
Travel Speed: 1.5” per second (no load)
Weight Capacity: 528 lbs.

3
Table of Contents
Safety Information 4
Parts List and Breakdowns 5
Assembling the Base 6-7
Attaching the Desktop 7-8
Connecting the Power 9
Trouble Shooting 9
Warranty 10

4
Safety Information
Keep children away from motorized height adjustable desks, control units, and handsets
to avoid risk of injury and electric shock.
Keep all electrical components away from liquids.
Do not sit or stand on the desk frame.
Do not crawl or lie under the desk frame.
Do not place any objects taller than 20” underneath the desk.
Do not open any of the components; legs, control box, or switch box, to avoid the risk of
injury or electric shock.
In the event of a power outage or if the power cord is unplugged, a manual reset may be
necessary. See Reset Procedure on page 9.
This motorized adjustable desk has electric motors and is designed for use in dry areas
only.
The desk height is adjustable so that it can be positioned at the most ergonomically
suitable height.
Any other use it at user’s risk.

5
Parts List
Tools Required:
Note: Phillips Head Screwdriver, Power Drill, and Tape Measure are not included.
Parts Included:
Hardware Included:
Parts List:

6
Assembly Instructions
Assembling the Base
NOTE: Lay out all components and hardware on a clean surface to ensure you have all components and
hardware listed on the parts page.
1. Fully separate the Crossbar Ends (P4). You
will find the Crossbar Center Rails (P5) inside.
2. Position one of the Crossbar Ends (P4) on its side.
Place one of the Legs (P1) into the Crossbar End (P4) ensuring the
bar (arrow) is on top in relation to the Leg (P1). Line up the holes
on each Leg (P1) with the holes on each Crossbar End (P4).
3. Using the supplied Allen Wrench, insert four M6*14
Machine Screws (P14) through the holes in each Crossbar
End (P4) going into the Leg (P1) and rotate each screw just
a few turns. You will need to flip the Crossbar over to gain
access to all four screws. Repeat Step 3 with the other two
Crossbars.
WARNING: DO NOT tighten the screws at this point.
NOTE: If you drop a screw inside the Crossbar End (P4), simply tilt to
retrieve.
4. Prop up one of the Crossbars from Step 3, as shown. Insert four
M6*14 Machine Screws (P14) through the four holes of the side
bracket (P6 or P7) going into the Crossbar End/Leg assembly.
Using the Allen Wrench, rotate each screw just a few turns.
Repeat Step 4 with the other two Crossbars.
WARNING: If you are having difficulty inserting any of the screws from
Step 3 or 4, it is because some of the screws are too tight.
5. Tighten all the screws from Step 3 and Step 4.

7
6. Remove backing from the Noise Attenuation Pads (P13) and
position along the brackets as shown.
7. Slide the two Crossbar Center Rails (P5) into the two Crossbar Ends (P4) ensuring:
a. The Crossbar with the short Side Bracket (450)(P7) is placed on the side that will be the center
leg of the desk base.
b. The slots in the Center Rails (P5) face inward.
c. The slots in the Center Rails (P5) are closer to the top edge when the assembly is upside down
(see inset).
8. For the two Crossbars that will be the outer legs of the desk
base, attach a Foot (P2) with four M6*14 Machine Screws (P14)
and tighten the screws in a cross pattern.
9. For the one Crossbar that will be the center leg of the desk
base, attach the Stand-Off (P3) with four M6*14 Machine
Screws (P14) and tighten screws in a cross pattern.
Attaching The Desktop
Note: Your desktop is pre-drilled. Check both sides of the desktop before placing the desk base on the
underside of the desktop.
1. Place desktop face down on a clean surface.
2. Carefully place the upside down 2-leg desk base on the
underside of the desktop on the longer side and/or the
side with a seam in desktop as shown. Adjust the width of
the 2-leg desk base to fit the pre-drilled desktop by sliding
the two halves outward. Place the 1-leg desk base on the
shorter end of the pre-drilled desktop.
3. Double check that the desk base in properly aligned with
the pre-drilled holes on the underside of the desktop.

8
WARNING: Use caution that the screws are not overtightened so they do not puncture the top surface when
screwed all the way in.
a. Attach the 2-leg desk base to the underside
of the desktop using eight M5*20 Wood
Screws (P16).
i. 3 per Side Bracket (P6) –6 total
ii. 1 per Crossbar End (P4) –2 total
b. Attach the 1-leg desk base to the underside
of the desktop using four M5*20 Wood
Screws (P16).
i. 3 per Side Bracket (P6) –3 total
ii. 1 per Crossbar End (P4) –1 total
NOTE: It is recommended that you pre-drill any holes needed for fasteners connecting the Control Box (P8)
and Switch (P9) to the desktop. Never use countersunk screws.
4. Attach the Control Box (P8) to the underside of the destop using two M5*16 Wood Screws (P17).
Ensure enough clearance to the wire ports for the cable connections.
5. Place the Switch (P9) so the front of the Switch is flush with the front desktop edge. The Switch may
be placed anywhere along the front edge of the desktop but the recommended placing is toward the
end so it does not interfere with your chair when seated. Use two M5*16 Wood Screws (P17) to
attach the Switch to the desktop.
WARNING: Use caution that the screws are not overtightened. Overtightening could cause damage to the
wood desktop or other components.
6. Connect the LC Cables (P11 & P12), Switch Cable (P9), and the
Power Cord (P10) to the Control Box (P8) as per the diagram.
The adhesive-backed Cable Clips (P18) can be used to secure
the Cables and Switch Cable so they do not hang.
7. With at least two people hold the Desk Base (NOT THE DESKTOP) and turn the desk right side up.
Adjust the pre-installed Leveling Studs on the Feet (P2) and the Stand-Off (P3) as needed to level the
desk.

9
Connecting The Power
Plug the Power Cord (P10) into an 110V-240V outlet.
WARNINGS:
Do not locate the desktop directly against any walls.
Make sure there are no obstacles in the desk’s path.
Make sure all cords are appropriate length to accommodate the change in height.
NOTE: You must reset the desk prior to use.
Reset Procedure: Press and hold the DOWN button on the Switch (P7) until the desk reaches the lowest
position. Release the DOWN button. Press and hold the DOWN button again until the LED display reads
“RST”. Release the DOWN button. Press and hold the DOWN button again until the desk again lowers then
slightly rises and stops. Release the DOWN button. Your desk is now ready to use.
Programming Presets: Use the up/down buttons to find a desired height, then press “M” followed by a
number 1-4.
CAUTION: Once a preset button is pushed, the desk will move to the programmed height (see warnings
above).
Troubleshooting
If your desk is not functioning properly it may need to be reset. Unplug the power cord for 20 seconds.
Plug the power cord back in and follow the Reset Procedure outlined above.
If your desk display reads “RST” (reset), perform the Reset Procedure outlined above.
If your desk displays an error message confirm that all wired connections are secure (legs to cables,
cables to control box). Then perform the reset procedure outlined above.
If your desk displays “HOT”, let the base cool down for 20 minutes.

10
Hanover Office Furniture
2-Year Limited Warranty Program
For a period of two (2) years after purchase, Hanover Products (“Manufacturer”) will either repair or replace defective components in accordance
with this Limited Warranty. This warranty is between Manufacturer and the original purchaser and is valid only when accompanied by the original
purchaser’s sales receipt showing original date of purchase and location of purchase. Replacements under this warranty revert back to the date of
original purchase for future warranty.
Manufacturer or its authorized dealer can accept or reject warranty claims based on its findings. This warranty applies in normal office use only
and is not intended for industrial or public use. Manufacturer can make substitutions as required of materials, components, and sub-components
of comparable value and utility. This warranty is limited to product repair or replacement (to be determined solely by Manufacturer). Warranty
replacement is limited to only the single affected component.
This warranty covers only manufacturing defects and does not cover normal wear and tear, abuse or misuse, exposure to extreme heat or cold,
abrasion or excessive weight. This product is intended to be used in standard installations only. This warranty is invalid if the product is not used
for intended purpose. Manufacturer disclaims liability for any aspect of installation and any inconvenience caused by a defective part of a
component.
Certain items are not covered by this warranty. These include, but are not limited to the following:
1. Components subjected to abuse, including abuse intended to simulate failure.
2. Damages caused by retailer, shipper or installation crew (such as scratches, dents, tears, chips, etc.).
3. Any part which merely exhibits normal wear yet functions essentially as new, including chips, scratches or stretching of materials and
stitching.
4. Tears, punctures, scratches or any damage caused by improper installation or use.
5. Damage to frames/welds resulting from improper assembly is not covered. General frame rusting is not covered.
6. Fading and/or discoloration of fabrics resulting from exposure to the elements, chemicals, oils, fluids or any other cause are not covered.
To make a claim, call the toll-free number below. Please have available a copy of the original sales receipt along with a brief description of the
problem. Please also provide your email address and daytime telephone or cell phone #. All items may be charged actual freight costs plus $15 for
handling. Repairs or replacement will be made at the Manufacturer’s option. Sales and use taxes, plus shipping and handling charges are the
responsibility of the consumer.
THIS IS THE ENTIRE EXCLUSIVE EXPRESS LIMITED LIABILITY. THE MANUFACTURER NEITHER MAKES NOR IS RESPONSIBLE FOR ANY OTHER WARRANTIES, EITHER
EXPRESS OR IMPLIED, INCLUDING THOSE OF RETAILING DEALERS. THIS EXCLUSIVE REMEDY IS LIMITED TO RECEIPT OF A CREDIT IN CONNECTION WITH THE REPAIR
OR REPLACEMENT OF ANY PRODUCT OR COMPONENT DEEMED TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER
HANOVER PRODUCTS, THE PRODUCT MANUFACTURER NOR ITS AGENTS SHALL BE LIABLE IN ANY CASE FOR INCIDENTAL, INDIRECT, SPECIAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. EXCEPT AS OTHERWISE MAY BE REQUIRED BY LAW, THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN
THE WARRANTY DESCRIBED HEREIN, AND ALL OTHER WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE ARE EXPRESSLY DISCLAIMED.
Contact Warranty Services at: [email protected]
www.Hanover-Products.com
877-397-5144
